Astell & Kern PPM41 Instruction Book

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PPM41
INSTRUCTIONBOOK
User Guide

Advertisement

Table of Contents
loading

Related Manuals for Astell & Kern PPM41

Summary of Contents for Astell & Kern PPM41

  • Page 1 PPM41 INSTRUCTIONBOOK User Guide...

  • Page 2: Table Of Contents

    CONTENTS Getting Started Package Contents PPM41 at a Glance Power Management Charging Connecti ons Firmware Upgr Using the Device Basic Operations Home Screen N otification Bar S tore AK Connect Listenin g to Music Playlist M anagement USB DA CInstallation...
  • Page 3 UserGuide Package Contents may be changed without prior notice to improve the performance or quality of the product. Contents PPM41 Quick Start Guide Protective Film & Warranty Card Micro-USB Cable microSD Card Slot Cover Protective Film: Protect the device and its screen. Mic ro-USB Cable: Connect the device to a computeror ch arge the device.
  • Page 4 UserGuide The appearance of the product as well as the printed and PPM41 engraved information may vary depending on the model. at a Gla Earphone Jack Power Micro-USB Port Balanced Audio Port Volume Touchscreen Home Button Earphones: Output sound to connected earphones.
  • Page 5 UserGuide Next/Fast-Forward: Skip to thenext song. Long press: Fast-forward. L CD Touchscreen: Display with touch control. Vol ume: Control the volume by turning the wheel. microSD Card Slot: Insert a microSD card and access its files. Home Button: Show the home screen. Power Turn On/Off Manage-...

  • Page 6: Reset Function

    UserGuide Reset Function 1. In cases of unexpected device failure or freeze, press the [ ] button for 12 seconds to force a shutdown. The device can be restarted after a shutdown. The device can be restarted after a shutdown. Resetting the device will not affect the stored data or time setting.
  • Page 7 UserGuide Connec- Earphones/Headphones tions 1. Connect earphones or headphones to the earphones port. Balanced Earphones/Headphones 1. Connect supported earphones or headphones to the balanced port. Balanced Audio Device 1. Connect to an external audio device by using the Earphones port and Balanced port in conjunction. Earphones Port Balanced Port(LR) (Ground)

  • Page 8: Disconnecting From The Computer

    UserGuide Connecting to a Computer 1. Turn on the device and your PC. 2. Connect the device to your PC as a standard USB device by using a micro-USB cable. [ - Connect USB] Medi a Device (USB Drive): Transfer files from a PC to the device.
  • Page 9 UserGuide Copy Files/Folders to the Device 1. Tocopy files/folders from your computer, select the desired files/folders and drag & drop them into the USB device. Make sure that the micro-USB cable is securely connected. Note that removing the micro-USB cable or turning off the device or computer during a file transfer may corrupt data on the device.
  • Page 10 UserGuide Delete Files/Folderson the Device 1. Right-click the desired file/folder, and then select [Delete]. 2. Select [Yes] in the [Confirm File/Folder Deletion] window to delete the selected file/folder. Insert/Remove a microSD Card 1. Refer to the diagram and gently insert a microSD card into the microSD c ard slot.
  • Page 11 UserGuide Recommended microSDCards Brand : SanDisk, Transcend Maximum supported microSD card capacity: 128GB Notes on inserting 128GB microSD card. Do not force the microSD card into the slot. Doing so may cause damage to the device and/or microSD card. Do not repeatedlyinsert/remove the microSD card. If the microSDcardis improperlyinserted,it maybecome immovable or causedamage to the device.

  • Page 12: Firmware Upgrade

    User Guide Firmware Wi-Fi Update / OTA (Over-the-Air) Upgrade 1. Connect to a wireless network. 2. When a new firmware version is available, the screen will display a Firmware Update Guide window. 3. Select [Update] and choose the items for update. 4.

  • Page 13: Using The Device

    UserGuide Basic LCDTouchscreen Operations 1. This device features an LCD touchscreen that allows you to perform operations by touch. Interact with the device by touching the screen to access various features. Toprevent damage, do not use a sharp object or use excessive force when touching thescreen.
  • Page 14 UserGuide Moving a list in the home screen 1. You can move the list by dragging the home screen [up] / [down]. Navigating Up/Down in a List 1. Scroll through the list by dragging the list screen [up] and [down]. Using the Device...
  • Page 15 UserGuide Home Screen 1 AK CONNECT Launches AK Connect. 2 CurrentSong Currently playing song information. View the list of songs by different 3 Search Options search options. The search options can be long-pressed and dragged to change the irlocations. Using the Device...
  • Page 16 UserGuide Notification Using the Device...
  • Page 17 UserGuide Expand or collapse the notifi Notification Bar cation bar by dragging the bar down or up, respectively. Press [ ] to turn Wi-Fi on Wi-Fi or off. Press [ ] to turn Bluetooth Bluetooth on or off. Press [ ] to turn the EQ o n or off.
  • Page 18 UserGuide PC Connection Select the appropriate mode when connected to a computer. Mode :USB drive mode for tra DISK nsferring media files. :Listen to music located on a PC through the device. Press [ ] to turn the screen lock ScreenLock on or off.
  • Page 19 UserGuide Purchasing Conveniently purchase music from the Store when connected to a wireless network. Music from a Store Purchasing Music 1. Connect to a wireless network. 2. Select [Store] from the home screen. 3. Select the desired store. 4. Check the user guide or help menu within each store for detailed information.
  • Page 20 UserGuide The PPM41 can access and play back music files stored o n AK CON a computer on the same network as well as output soun d t NECT hrough Astell&Kern speakers. MQS Streaming Server Installation 1. Visit the Astell&Kern website and download the server in staller that corresponds to your operating system.
  • Page 21 UserGuide 4. A list of servers on the same network as the PPM41 will b e displayed. 5. Scroll the screen left and right to s elect a server. The selected server will be connected and the server h ome screen will be displayed.
  • Page 22 UserGuide Streaming and Downloading from the Music Server 1. Select a search option from the server Home Screen to display a list of music. 2. Select a song to begin streaming. 3. Press the [ ] button atthe upper-right corner of the music list. 4.
  • Page 23 UserGuide Selecting Speakers 1. Turn on the speaker(s) to be con nected, and then connect it to th e same network as the PPM41. 2. Turn on [AK Connect] from the devicesettings. 3. Press [ ] from the notification bar to display a list of speakers available on the same network as the PPM41.
  • Page 24 UserGuide Example 2 AK500N PPM41 AK T1 LIBRARY REMOTE SPEAKER Example 3 PPM41 AK500N REMOTE & LIBRARY SPEAKER Using the Device...
  • Page 25 UserGuide Example 4 PPM41 AK500N AK T1 LIBRARY REMOTE SPEAKER Example 5 PPM41 LIBRARY AKConnectAPP REMOTE AK T1 SPEAKER AK500N LIBRARY Using the Device...
  • Page 26 UserGuide Listening Selecting Music to Music 1. Select a search option at the bottom of the home screen to display the playlist. 2. Select a song from the list to begin playback. Select [Folder] to search music by folder. Continuous Playback: Approximately 10 hours (Basis: FLAC, 16-bit, 44 kHz, unbalanced output, volume 80, EQ off, LCD off) Supported Formats: PCM [8~192kHz(8/16/24bit)], DSD 64/128 Listening toMusic...
  • Page 27 UserGuide Drag the progress bar to the desired location during playback. Press the [Home] button on the device to go to the Home Screen. Press the album cover during playback to display an additional screen. : Display the previous screen. : Display the current playlist.
  • Page 28 UserGuide Playlist Screen Using the Device...
  • Page 29 UserGuide 1 Current Indicates the currentlocation. Press to return to the previous screen. Locatio 2 PlayAll Play all songs from the current playlist. 3 Playlist Displays the playlist for the current location. 4 List Sorting Select a method for sorting the playlist. 5 List View Select a view type for the list of albums.
  • Page 30 UserGuide Music Player Screen PreviousScreen Return to the previous screen. Album Cover Display album covers. Press the album cover to show additional functions. Using the Device...
  • Page 31 UserGuide Lyrics for the current song. Lyrics Add toPlaylist Add the current song to a playlist. Indicates song duration. Song Progress Displays bitrate and sampling Details frequency data. Title Song title information. File name is displayed when ID3Tag is unavailable. Artist Artist name.
  • Page 32 UserGuide Playlist Creating aPlaylist Manage- 1. Press [Playlist - Playlists] from the home screen to display a list of pl ment aylists. 2. Press [+] at the upper-right corner of thescreen. 3. Enter a name for the playlist, and then press [Add] to create a newplaylist.
  • Page 33 UserGuide Removing a Song from a Playlist 1. Press [Playlists] to display a list of playlists. 2. Select the desired playlist, and then press [ ] at the top of t h e screen. 3. Select the desired song, and then press [ ] to remove the song fro m the selected playlist.
  • Page 34 UserGuide Renaming aPlaylist 1. Press [Playlists] to display a list of playlists, and then press [ at the top of the screen. 2. Select a playlist to be renamed. 3. Press [ ] at the top of the screen t o display a rename window.

  • Page 35: Cinstallation

    UserGuide USB DAC The USB DAC functionality allows the PPM41 to be Installation recognized as a sound card on a computer. Music from the computer is played through the device’s earphones port for an enhanced listening experience. USB DACSpecifications Supported OS...
  • Page 36 UserGuide You can enjoy USB audio by linking with a portable amp and How to Use DAC available in the market. USB Audio How to Link Portable USB DAC 1. Connect the device’s micro USB jack with the portable USB DAC with dedicated cable. 2.
  • Page 37 UserGuide CD Ripping Connect the AK Ripper (sold separately) to rip CDs. Turning the AK Ripper On/Off 1. You can use the AK ripper once you connect the device w ith the AK ripper and press [ ] after scrolling down the n otification bar.
  • Page 38 CD or other similar reasons. Also indicates that CD ripping was canceled due to user interruption. To search the Gracenote database, the PPM41 must be connected t o the Internet via Wi-Fi. The database access time may vary depe n ding on the networkenvironment.
  • Page 39 Connect a Bluetooth device to listen to music wirelessly. uetooth Turning Bluetooth On/Off A Bluetooth device must be paired with the PPM41 prior to use. Refer to the Bluetooth device's instruction manualfor details. 1. Select [ ] from the Notification B ar, or select [On/Off] from [ - Blu etooth].
  • Page 40 UserGuide Removing a Bluetooth Pairing 1. Press [ ] to the right of the p aired device to be redirected to the settings screen. 2. Select[Remove Pairing] to complete the process. Bluetooth Support Specifications Profile: A2DP,aptX Deviceperformance may be affectedduring Hi-Fi playback. (48 kHz or lower is recommended.) Do not turn off the device while connected to Bluetooth.
  • Page 41 UserGuide Set up the device according to the user's needs. The settings Settings menu may vary depending on the firmware version. Setup 1. Select [ ] from the home screen notification bar. 2. Select the desired item for setup. Wi-Fi Change wireless network settings and turn Wi-Fi on or off.
  • Page 42 UserGuide Equalizer Set the equalizer according to the user's preferences. P r o EQ: EQ Preset recommended by professionals. Use r EQ: Adjust the frequencies according to the user's pre f erences. Supported Formats for EQ: PCM [8 – 192 kHz (8/16/24-bit)] DSD [64/128] Using the equalizer may negatively affect device performance.
  • Page 43 UserGuide Left-RightBalance Adjust the left-right balance for earphones/headphones. CDRipping Set the automatic CD ripping function as well as the file format and ripping speed. USBAudio It sets up the output type of DSD coming out through the portable USB DAC. Screen Brightness Adjust screen brightness settings.
  • Page 44 UserGuide Language Select the display language. Supported languages: English, Korean, Japanese, Chin ese (Simplified/Traditional), French, Russian, German Keyboard Selectthe keyboard language. Supported languages: English, Korean, Japanese, Chinese (Simplified/Traditional), Russian Power Automatic Shutdown: The device will turn off after a defined period if there is no user input. Screen Timeout: The screen will turn off after a defined period when there is no user input.

  • Page 45: Settings 40

    UserGuide Update System Update: Update the system when a new version is found. Application Update: Update the default applications (including the Store) when new versions are found. System Information System Information: View model number, firmware version, and data storage information. The microSD card can be mounted/dismounted, and data can be deleted.
  • Page 46 UserGuide Connecting Connecting to a Network to a Wir 1. Long-press [ ] from the Noti fication Bar or select [ eless N Wi-Fi] to display a list of access etwork points (AP). 2. Select the desired AP to connect to the wireless network.

  • Page 47: Equalizer Setup

    UserGuide Equalizer Equalizer Setup Setup 1. Long-press [EQ] from the Notification Bar, or turn on the feature from [ - Equalizer]. 2. Press [Pro] from the drop-down list and select [Add New]. 3. Enter a name for the custom EQ settings and select [Add]. Using the Device...
  • Page 48 UserGuide 4. Adjust the frequencies according to the user's preferences. Reset Equalizer 1. Select the desired EQ setting and select [Reset] to revert the EQ to its default settings. Using the Device...
  • Page 49 UserGuide Delete Equalizer 1. Select [Delete] and choose the desired EQ setting for deletion. 2. Press [Confirm] to complete process. Rename Equalizer 1. Select [Rename] and enter a new name for the EQ setting. 2. Press [Rename] to complete the process. Using the Device...

  • Page 50: Miscellaneous

    UserGuide Safety Pre Device cautions When a plug is inserted into the earphones, balanced, or USB port, do not apply any force or shock to the plug. Do not insert any metal objects (coins, hairpins, etc.) or flammable debris into the device. Do not place heavy objects on the device.
  • Page 51 UserGuide Using poor quality protective films or adhesive stickers on the screen may cause damage. Do not insert any foreign objects into the earphones port. If playing for extended periods, the device can be very hot, so please keep in mind when using. Other Do not use earphones/headphones or operate the product while operating any type of vehicle.
  • Page 52 UserGuide 2. The device will not charge when connected to a computer via USB cable. Use a USB port on the back of the computer, and check that the USB port is functioning properly. Check that the USB cable is connected correctly. 3.
  • Page 53 It is the responsibility of the user to comply with applicable copyright laws. © 1999-2016 iriver Limited. All rights reserved. The PPM41 was designed and audio-tuned under th e advisement of MSD. Certifi- KC / FCC / CE / TELEC...
  • Page 54 UserGuide (b) For a Class B digital device or peripheral, the instructions furnished the user shall include the following or similar statement, placed in a p rominent location in the text of the manual: NOTE: This equipment h a s been tested and found to comply with the limits for a Class B digit al device, pursuant to part 15 of the FCC Rules.
  • Page 55 UserGuide Specifi General Specifications Model PPM41 - catio Body Color Body Material Aluminum Display 4inch WVGA(480x800) Touch Screen Supported Audio WAV, FLAC, WMA, MP3, OGG, Formats APE(Normal, High, Fast), AAC, ALAC, AIFF, DFF, DSF Sample rate PCM : 8kHz~ 384kHz (8/16/24/32bits per Sample) DSD Native: DSD64(1bit 2.8MHz), Stereo/...
  • Page 56 UserGuide 110dB 이하 @ 1kHz, Unbalance/ Phone Out Low Gain 109dB 이하@1kHz, Balance 113dB 이하 @1kHz, Unbalance/ High Gain 115dB 이하@1kHz, Balance Line Out -110dB @ 1kHz, Unbalance/ Crosstalk Phone Out Low Gain -130dB @1kHz, Balance -107dB @1kHz, Unbalance/ High Gain -128dB @1kHz, Balance Line Out 0.004% @ 1kHz, Unbalance/...

  • Page 57: Emarks Disclaimers

    UserGuide Registered Windows 2000, Windows XP, Windows 7, Windows 8, Windows 10 and Windows Media Player are trademarks of Trademarks Microsoft Corp. Disclaimers The manufacturer, importer, and distributor shall not be li able for damages including accidental and personal injury due to the improper use or operation of this product.
