Page 1 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router NETGEAR, Inc. 4500 Great America Parkway Santa Clara, CA 95054 USA Phone 1-888-NETGEAR BETA August 2005 August 2005...
Page 2 In the interest of improving internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes to the products described in this document without notice. NETGEAR does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
Page 3: Customer Support
Modem Router. World Wide Web NETGEAR maintains a World Wide Web home page that you can access at the universal resource locator (URL) http://www.netgear.com. A direct connection to the Internet and a Web browser such as Internet Explorer or Netscape are required.
Page 4: Fcc Statement
Regulatory Approvals FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica- tions.
Page 5: Table Of Contents
Contents Chapter 1 About This Guide Audience, Conventions, Scope ..................1-1 How to Print this Manual ....................1-2 Chapter 2 Introduction About the Wireless ADSL Modem Router ..............2-1 Key Features ........................2-2 802.11g Wireless Networking ...................2-2 A Powerful, True Firewall ..................2-3 Easy Installation and Management ................2-3 Protocol Support ......................2-4 Content Filtering .......................2-5 Auto Sensing and Auto Uplink™...
Page 6 How to Configure WEP ..................4-13 How to Configure WPA-PSK ..................4-14 Chapter 5 Protecting Your Network Protecting Access to Your DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router How to Change the Built-In Password ..............5-1 Changing the Administrator Login Timeout ..............5-2 Configuring Basic Firewall Services ................5-2...
Page 7 Outbound Rules (Service Blocking) .................5-9 Outbound Rule Example: Blocking Instant Messenger ........5-10 Order of Precedence for Rules ................5-11 Services ........................5-12 How to Define Services ..................5-13 Setting Times and Scheduling Firewall Services ............5-14 How to Set Your Time Zone ...................5-14 How to Schedule Firewall Services ................5-15 Chapter 6 Managing Your Network...
Page 8 Disable Port Scan and DOS Protection ..............7-3 Respond to Ping on Internet WAN Port ..............7-3 MTU Size .........................7-3 Configuring LAN IP Settings ...................7-3 DHCP ........................7-5 Use Router as DHCP server ................7-5 Reserved IP addresses ..................7-6 How to Configure LAN TCP/IP Settings ..............7-7 Configuring Dynamic DNS ..................7-8 How to Configure Dynamic DNS ................7-8 Using Static Routes ......................7-9...
Page 9: About This Guide
Screen text, file and server names, extensions, commands, IP addresses mono space Note: This format is used to highlight information of importance or special interest. This manual is written for the DG834PN RangeMax Wireless ADSL Modem Router according to these specifications: Table 1-1.
Page 10: How To Print This Manual
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router How to Print this Manual To print this manual you can choose one of the following several options, according to your needs. • Printing a “How To” Sequence of Steps in the HTML View. Use the Print button on the upper right of the toolbar to print the currently displayed topic.
Page 11: Introduction
Chapter 2 Introduction This chapter describes the features of the NETGEAR DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router. The DG834PN RangeMax Wireless ADSL Modem Router is a combination of a built-in ADSL modem, wireless ADSL modem router, 4-port switch, firewall, and up to 108 Mbps wireless access point that enables your entire network to safely share an Internet connection that otherwise is used by a single computer.
Page 12: Key Features
802.11b devices or dedicating the wireless network to the higher bandwidth 802.11g or 108 Mbps only devices: — Auto 108 Mbps mode (i.e., all 802.11g, 802.11b, and Netgear 108 Mbps wireless stations can be used; this mode is the second fastest mode) —...
Page 13: A Powerful, True Firewall
Wireless network name broadcast can be turned off so that only devices that have the network name (SSID) can connect. A Powerful, True Firewall Unlike simple Internet sharing NAT routers, the DG834PN is a true firewall, using stateful packet inspection to defend against hacker attacks. Its firewall features include: •...
Page 14: Protocol Support
DNS lookup, and remote reboot. These functions allow you to test Internet connectivity and reboot the wireless ADSL modem router. You can use these diagnostic functions directly from the DG834PN when you are connected on the LAN or when you are connected over the Internet via the remote management function.
Page 15: Content Filtering
Content Filtering With its content filtering feature, the DG834PN prevents objectionable content from reaching your PCs. The wireless ADSL modem router allows you to control access to Internet content by screening for keywords within Web addresses. You can configure the wireless ADSL modem router to log and report attempts to access objectionable Internet sites.
Page 16: Auto Sensing And Auto Uplink™ Lan Ethernet Connections
Auto Sensing and Auto Uplink™ LAN Ethernet Connections With its internal 4-port 10/100 switch, the DG834PN can connect to either a 10 Mbps standard Ethernet network or a 100 Mbps Fast Ethernet network. The local LAN ports are autosensing and capable of full-duplex or half-duplex operation.
Page 17 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router NEED NEW IMAGE Power Test Wireless Internet Figure 2-2: DG834PN Front Panel You can use the LEDs to verify various conditions. Table 2-1 lists and describes each LED on the front panel of the router.
Page 18: The Router's Rear Panel
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Table 2-1. LED Descriptions Label Activity Description Power Power is supplied to the router. Power is not supplied to the router. Test The system is initializing. The system is ready and running.
Page 19 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router NEED NEW IMAGE ADSL Internet Power Wireless Reset Figure 2-3: DG834PN Rear Panel Viewed from left to right, the rear panel contains the following elements: • ADSL port for connecting the router to an ADSL line •...
Page 20 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router 2-10 Introduction August 2005...
Page 21: Connecting The Router To The Internet
Active Internet service such as that provided by an ADSL account. The Internet Service Provider (ISP) configuration information for your DSL account. Note: If you purchased the DG834PN in a country where a microfilter is not included, you must acquire one.
Page 22: Adsl Microfilter With Built-In Splitter
Each device such as a telephone, fax machine, answering machine, or caller ID display will require an ADSL microfilter. Note: Do not connect the DG834PN to the ADSL line through a microfilter unless the microfilter is a combination microfilter/splitter specifically designed for this purpose. Doing so will prevent the built-in ADSL modem in the DG834PN from establishing a connection to the Internet.
Page 23: Internet Configuration Requirements
For Macintosh computers, open the TCP/IP or Network control panel. • You can also refer to the DG834PN Resource CD for the NETGEAR Router ISP Guide which provides Internet connection information for many ISPs. Once you locate your Internet configuration parameters, you may want to record them on the next page.
Page 24 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router ISP Multiplexing Method and Virtual Circuit Number: The default settings of your DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router will work fine for most ISPs. However, some ISPs use a specific Multiplexing Method or a Virtual Circuit Number for either the Virtual Path Identifier (VPI) or Virtual Channel Identifier (VCI).
Page 25 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Set up the Router 1. C DG834PN ADSL L ONNECT THE TO THE ADSL signals degrade phone sound quality. Microfilters block such problems and are required for each phone or fax. There are two types: one-line microfilters; and two-line microfilters, which include a built-in splitter.
Page 26 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Connect the ADSL port (B) of the DG834PN to the ADSL connector of the two-line filter. Note: Improperly connecting a filter to your DG834PN will block ADSL signals and prevent connecting to the Internet.
Page 27 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router 2. L DG834PN OG IN TO THE Your computer needs to be configured for DHCP. For help with this, see the Reference Manual or tutorials on the Resource CD.
Page 28 When prompted, type admin for the user name and password for the password, both in lower case letters. Click Wireless Settings in the DG834PN main menu. Select a Region. Do not change the other settings. Click Apply. Configure the computer’s Wireless Adapter Settings Configure the wireless adapter of your computer to match these settings exactly.
Page 29: Troubleshooting Tips
For each powered on computer connected to the DG834PN with a securely plugged in Ethernet cable, the corresponding DG834PN LAN port status light will be lit. The label on the bottom of the wireless ADSL modem router identifies the number of each LAN port.
Page 30: Manually Configuring Your Internet Connection
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Check the router status lights to verify correct router operation. • If the Power light does not turn solid green within 2 minutes after turning the router on, reset the router according to the instructions in the Reference Manual on the CD.
Page 31: Internet Connection Requires Login And Uses Pppoe
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Select your country and language. Language choices are English, French, German, and Italian. After you change the language, the remaining setup screens change to the language of your choice.
Page 32: Internet Connection Requires Login And Uses Pppoa
Note: Disabling NAT will reboot the router and reset all the DG834PN configuration settings to the factory default. Disable NAT only if you plan to install the DG834PN in a setting where you will be manually administering the IP address space on the LAN side of the router.
Page 33: Internet Connection Does Note Require A Login
Note: Disabling NAT will reboot the router and reset all the DG834PN configuration settings to the factory default. Disable NAT only if you plan to install the DG834PN in a setting where you will be manually administering the IP address space on the LAN side of the router.
Page 34: Adsl Settings
Note: Disabling NAT will reboot the router and reset all the DG834PN configuration settings to the factory default. Disable NAT only if you plan to install the DG834PN in a setting where you will be manually administering the IP address space on the LAN side of the router...
Page 35 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Type a number between 0 and 255 for the VPI. The default is 8. Type a number between 1 and 65535 for the VCI. The default is 35.
Page 36 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router 3-16 Connecting the Router to the Internet August 2005...
Page 37: Wireless Configuration
Chapter 4 Wireless Configuration This chapter describes how to configure the wireless features of your DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router. Considerations for a Wireless Network In planning your wireless network, you should consider the level of security required. You should also select the physical placement of your wireless ADSL modem router in order to maximize the network speed.
Page 38: Implement Appropriate Wireless Security
Restrict Access Based on MAC Address. You can allow only trusted PCs to connect so that unknown PCs cannot wirelessly connect to the DG834PN. Restricting access by MAC address adds an obstacle against unwanted access to your network, but the data broadcast over the wireless link is fully exposed.
Page 39: Understanding Wireless Settings
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router • Turn Off the Broadcast of the Wireless Network Name SSID. If you disable broadcast of the SSID, only devices that have the correct SSID can connect. This nullifies wireless network ‘discovery’...
Page 40 32 alphanumeric characters. The same Name (SSID) must be assigned to all wireless devices in your network. The default SSID is NETGEAR, but NETGEAR strongly recommends that you change your network Name to a different value.
Page 41 “b only” allows 802.11b wireless stations; 802.11g wireless stations can still be used if they can operate in 802.11b mode. • “Auto 108 Mbps” means all 802.11g, 802.11b, and Netgear 108 Mbps wireless stations can be used. The Auto 108 Mbps mode is the second fastest mode. •...
Page 42 • If Shared or Open Network Authentication is enabled, you can choose 64- or 128-bit WEP data encryption. Note: With Open Network Authentication and 64- or 128-bit WEP Data Encryption, the DG834PN does perform 64- or 128-bit data encryption but does not perform any authentication. Security Encryption (WEP) Key These key values must be identical on all wireless devices in your network (key 1 must be the same for all, key 2 must be the same for all, and so on).
Page 43: How To Set Up And Test Basic Wireless Connectivity
Enter the port number used for connections to the Radius Server. • Radius Shared Key Enter the desired value for the Radius shared key. This key enables the DG834PN to log in to the Radius server and must match the value used on the Radius server.
Page 44: How To Restricting Wireless Access To Your Network
How to Restricting Wireless Access to Your Network By default, any wireless PC that is configured with the correct SSID will be allowed access to your wireless network. For increased security, the DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router provides several ways to restrict wireless access to your network: •...
Page 45: Restricting Access To Your Network By Turning Off Wireless Connectivity
Restricting Access to Your Network by Turning Off Wireless Connectivity You can completely turn off the wireless portion of the DG834PN. For example, if your notebook computer is used to wirelessly connect to your router and you take a business trip, you can turn off the wireless portion of the router while you are traveling.
Page 46 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Figure 4-5. Wireless Access menu Select the Turn Access Control On check box to enable restricting wireless computers by their MAC addresses. If the wireless station is currently connected to the network, you can select it from the Available Wireless Stations list.
Page 47: Choosing Wep Authentication And Security Encryption Methods
Make sure the Turn Access Control On check box is selected, then click Apply. Now, only devices on this list will be allowed to wirelessly connect to the DG834PN. This prevents unauthorized access to your network.
Page 48: Encryption Choices
If you require strong security, use both the Shared Key and WEP encryption settings. Set your wireless adapter according to the authentication scheme you choose for the DG834PN RangeMax Wireless ADSL Modem Router. Please refer to “Authentication and WEP Data Encryption”...
Page 49: How To Configure Wep
LAN address and password you have set up. Click the Wireless Settings link in the main menu of the DG834PN wireless ADSL modem router. Go to the Security Encryption portion of the page: Figure 4-7.
Page 50: How To Configure Wpa-Psk
Be sure you clearly understand how the WEP key settings are configured in your wireless adapter. Wireless adapter configuration utilities such as the one included in Windows XP only allow entry of one key which must match the default key you set in the DG834PN. Click Apply to save your settings.
Page 51: Protecting Your Network
Chapter 5 Protecting Your Network This chapter describes how to use the basic firewall features of the DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router to protect your network. Protecting Access to Your DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router For security reasons, the wireless ADSL modem router has its own user name and password.
Page 52: Changing The Administrator Login Timeout
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router From the Main Menu of the browser interface, under the Maintenance heading, select Set Password to bring up the menu shown in Figure 5-2. Figure 5-2: Set Password menu To change the password, first enter the old password, and then enter the new password twice.
Page 53: Blocking Keywords, Sites, And Services
How to Block Keywords and Sites The DG834PN RangeMax Wireless ADSL Modem Router allows you to restrict access to Internet content based on functions such as Web addresses and Web address keywords. Log in to the wireless ADSL modem router at its default LAN address of http://192.168.0.1 with its default User Name of admin, default password of password, or using whatever Password and LAN address you have chosen for the wireless ADSL modem router.
Page 54 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Figure 5-3: Block Sites menu To enable keyword blocking, select one of the following: • Per Schedule—to turn on keyword blocking according to the settings on the Schedule page.
Page 55: Firewall Rules
“Order of Precedence for Rules” on page 5-11 for more details. To access the rules configuration of the DG834PN, click the Firewall Rules link on the main menu, then click Add for either an Outbound or Inbound Service. Figure 5-4: Rules menu...
Page 56: Inbound Rules (Port Forwarding)
OK. Inbound Rules (Port Forwarding) Because the DG834PN uses Network Address Translation (NAT), your network presents only one IP address to the Internet, and outside users cannot directly address any of your local computers. However, by defining an inbound rule you can make a local server (for example, a Web server or game server) visible and available to the Internet.
Page 57 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router A Local Public Web Server Figure 5-5: Rule example: The parameters are: • Service From this list, select the application or service to be allowed or blocked. The list already displays many common services, but you are not limited to these choices.
Page 58: Inbound Rule Example: Allowing Videoconferencing
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router • WAN Users These settings determine which packets are covered by the rule, based on their source (WAN) IP address. Select the desired option: • Any — all IP addresses are covered by this rule.
Page 59: Considerations For Inbound Rules
WAN IP address will fail. Outbound Rules (Service Blocking) The DG834PN allows you to block the use of certain Internet services by computers on your network. This is called service blocking or port filtering. You can define an outbound rule to block Internet access from a local computer based on: •...
Page 60: Outbound Rule Example: Blocking Instant Messenger
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Following is an application example of outbound rules: Outbound Rule Example: Blocking Instant Messenger If you want to block Instant Messenger usage by employees during working hours, you can create an outbound rule to block that application from any internal IP address to any external address according to the schedule that you have created in the Schedule menu.
Page 61: Order Of Precedence For Rules
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router • LAN Users These settings determine which packets are covered by the rule, based on their source LAN IP address. Select the desired option: • Any — all IP addresses are covered by this rule.
Page 62: Services
1024 to 65535 by the authors of the application. Although the DG834PN already holds a list of many service port numbers, you are not limited to these choices. Use the procedure below to create your own service definitions.
Page 63: How To Define Services
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router How to Define Services Log in to the wireless ADSL modem router at its default LAN address of http://192.168.0.1 with its default User Name of admin, default password of password, or using whatever Password and LAN address you have chosen for the wireless ADSL modem router.
Page 64: Setting Times And Scheduling Firewall Services
Wireless ADSL Modem Router Setting Times and Scheduling Firewall Services The DG834PN RangeMax Wireless ADSL Modem Router uses the Network Time Protocol (NTP) to obtain the current time and date from one of several Network Time Servers on the Internet.
Page 65: How To Schedule Firewall Services
Enabling Daylight Savings Time will cause one hour to be added to the standard time. The wireless ADSL modem router has a list of NETGEAR NTP servers. If you would prefer to use a particular NTP server as the primary server, enter its IP address under Use this NTP Server.
Page 66 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router 5-16 Protecting Your Network August 2005...
Page 67: Managing Your Network
Chapter 6 Managing Your Network This chapter describes how to perform network management tasks with your DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router. Backing Up, Restoring, or Erasing Your Settings The configuration settings of the DG834PN RangeMax Wireless ADSL Modem Router are stored in a configuration file in the wireless ADSL modem router.
Page 68: How To Restore The Configuration From A File
“DG834PN Rear Panel“ on page 2-9. Upgrading the Wireless ADSL Modem Router’s Firmware The software of the DG834PN RangeMax Wireless ADSL Modem Router is stored in FLASH memory, and can be upgraded as new software is released by NETGEAR. Managing Your Network...
Page 69: How To Upgrade The Wireless Adsl Modem Router Firmware
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Upgrade files can be downloaded from NETGEAR's Web site. If the upgrade file is compressed (.ZIP file), you must first extract the binary (.BIN or .IMG) file before uploading it to the wireless ADSL modem router.
Page 70: Network Management Information
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Network Management Information The DG834PN provides a variety of status and usage information which is discussed below. Viewing Wireless ADSL Modem Router Status and Usage Statistics From the Main Menu, under Maintenance, select Wireless ADSL Modem Router Status to view...
Page 71 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Managing Your Network August 2005...
Page 72 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Table 6-1. Menu 3.2 - Wireless ADSL Modem Router Status Fields Field Description Account Name The Host Name assigned to the wireless ADSL modem router in the Basic Settings menu.
Page 73 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Table 6-1. Menu 3.2 - Wireless ADSL Modem Router Status Fields Field Description Upstream Speed The speed at which the modem is transmitting data to the ADSL line.
Page 74 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Table 6-1. Router Statistics Fields Field Description WAN, LAN, or The statistics for the WAN (Internet), LAN (local), and Serial ports. For each port, the Serial Port...
Page 75 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Figure 6-5: Connection Status screen for Dynamic IP Clicking the Renew button updates the status information. This screen shows the following statistics: Table 6-1. Connection Status Fields for Dynamic IP...
Page 76 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router An alternate view of the Connection Status screen is shown in Figure 6-6 below: Figure 6-6: Connection Status screen for PPPoA Clicking the Renew button updates the status information.
Page 77: Viewing Attached Devices
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Viewing Attached Devices The Attached Devices menu contains a table of all IP devices that the wireless ADSL modem router has discovered on the local network. From the Main Menu of the browser interface, under...
Page 78 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Figure 6-8: Security Logs menu Log entries are described in Table 6-1 below: 6-12 Managing Your Network August 2005...
Page 79: Selecting What Information To Log
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Table 6-1. Security Log entry descriptions Field Description Date and Time The date and time the log entry was recorded. Description or The type of event and what action was taken if any.
Page 80: Saving Log Files On A Server
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Saving Log Files on a Server You can choose to write the logs to a computer running a syslog program. To activate this feature, select to Broadcast on Lan or enter the IP address of the server where the Syslog file will be written.
Page 81: Enabling Security Event E-Mail Notification
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Enabling Security Event E-mail Notification In order to receive logs and alerts by e-mail, you must provide your e-mail information in the E-mail subheading: Figure 6-9: E-mail menu •...
Page 82: Running Diagnostic Utilities And Rebooting The Wireless Adsl Modem Router
Running Diagnostic Utilities and Rebooting the Wireless ADSL Modem Router The DG834PN RangeMax Wireless ADSL Modem Router has a diagnostics feature. You can use the diagnostics menu to perform the following functions from the wireless ADSL modem router: •...
Page 83: Enabling Remote Management
Wireless ADSL Modem Router Enabling Remote Management Using the Remote Management page, you can allow a user or users on the Internet to configure, upgrade and check the status of your DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router. Note: Be sure to change the wireless ADSL modem router's default password to a very secure password.
Page 84 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router When accessing your wireless ADSL modem router from the Internet, you will type your wireless ADSL modem router's WAN IP address in your browser's Address (in IE) or Location (in Netscape) box, followed by a colon (:) and the custom port number.
Page 85: Advanced Configuration
Chapter 7 Advanced Configuration This chapter describes how to configure the advanced features of your DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router. Configuring Advanced Security The DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router provides a variety of advanced features, such as: •...
Page 86: How To Configure A Default Dmz Server
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Note: For security reasons, you should avoid using the Default DMZ Server feature. When a computer is designated as the Default DMZ Server, it loses much of the protection of the firewall, and is exposed to many exploits from the Internet.
Page 87: Connect Automatically, As Required
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Connect Automatically, as Required Normally, this option should be enabled, so that an Internet connection will be made automatically, whenever Internet-bound traffic is detected. If this causes high connection costs, you can disable this setting.
Page 88 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router • LAN IP addresses—192.168.0.1 • Subnet mask—255.255.255.0 These addresses are part of the Internet Engineering Task Force (IETF)-designated private address range for use in private networks, and should be suitable in most applications. If your network has a requirement to use a different IP addressing scheme, you can make those changes in this menu.
Page 89: Dhcp
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router — When set to None, it will not send any RIP packets and will ignore any RIP packets received. • RIP Version This controls the format and the broadcasting method of the RIP packets that the wireless ADSL modem router sends.
Page 90: Reserved Ip Addresses
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Specify the pool of IP addresses to be assigned by setting the Starting IP Address and Ending IP Address. These addresses should be part of the same IP address subnet as the router’s LAN IP address.
Page 91: How To Configure Lan Tcp/Ip Settings
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router To edit or delete a reserved address entry: Click the button next to the reserved address you want to edit or delete. Click Edit or Delete. How to Configure LAN TCP/IP Settings Log in to the router at its default LAN address of http://192.168.0.1 with its default User Name...
Page 92: Configuring Dynamic Dns
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Configuring Dynamic DNS If your network has a permanently assigned IP address, you can register a domain name and have that name linked with your IP address by public Domain Name Servers (DNS). However, if your Internet account uses a dynamically assigned IP address, you will not know in advance what your IP address will be, and the address can change frequently.
Page 93: Using Static Routes
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Access the Web site of one of the dynamic DNS service providers whose names appear in the ‘Service Provider’ box, and register for an account. For example, for dyndns.org, go to www.dyndns.org.
Page 94: How To Configure Static Routes
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router • Your company’s network is 134.177.0.0. When you first configured your router, two implicit static routes were created. A default route was created with your ISP as the wireless ADSL modem router, and a second static route was created to your local network for all 192.168.0.x addresses.
Page 95 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Figure 7-5: Static Routes Table Advanced Configuration 7-11 August 2005...
Page 96 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router To add or edit a Static Route: Click the Edit button to open the Edit Menu, shown in Figure 7-6. Figure 7-6: Static Route Entry and Edit Menu Type a route name for this static route in the Route Name box under the table.
Page 97: Troubleshooting
Chapter 8 Troubleshooting This chapter gives information about troubleshooting your DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router. After each problem description, instructions are provided to help you diagnose and solve the problem. For the common problems listed, go to the section indicated.
Page 98: Power Led Not On
• Check that you are using the 12 V DC power adapter supplied by NETGEAR for this product. If the error persists, you have a hardware problem and should contact technical support.
Page 99: Troubleshooting The Web Configuration Interface
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router • Make sure that power is turned on to the connected hub or workstation. • Be sure you are using the correct cable: — When connecting the router’s WAN ADSL port, use the cable that was supplied with the DG834PN.
Page 100: Troubleshooting The Isp Connection
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router • Click the Refresh or Reload button in the Web browser. The changes may have occurred, but the Web browser may be caching the old configuration. Troubleshooting the ISP Connection If your router is unable to access the Internet, you should check the ADSL connection, then the WAN TCP/IP connection.
Page 101: Obtaining A Wan Ip Address
ADSL service. It may be necessary to use a swapper if you ADSL signal is on pins 1 and 4 or the RJ-11 jack. The DG834PN RangeMax Wireless ADSL Modem Router uses pins 2 and 3.
Page 102: Troubleshooting Pppoe Or Pppoa
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router • Your ISP may check for your computer's host name. Assign the computer Host Name of your ISP account to the wireless ADSL modem router in the browser-based Setup Wizard.
Page 103: Troubleshooting A Tcp/Ip Network Using The Ping Utility
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router A DNS server is a host on the Internet that translates Internet names (such as www addresses) to numeric IP addresses. Typically your ISP will provide the addresses of one or two DNS servers for your use.
Page 104: Testing The Path From Your Computer To A Remote Device
Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router If the path is not functioning correctly, you could have one of the following problems: • Wrong physical connections — Make sure the LAN port LED is on. If the LED is off, follow the instructions in “LAN...
Page 105: Restoring The Default Configuration And Password
The E-mail menu in the Content Filtering section displays the current date and time of day. The DG834PN RangeMax Wireless ADSL Modem Router uses the Network Time Protocol (NTP) to obtain the current time from one of several Network Time Servers on the Internet. Each entry in the log is stamped with the date and time of day.
Page 106 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router • Time is off by one hour Cause: The router does not automatically sense Daylight Savings Time. In the E-mail menu, check or uncheck the box marked “Adjust for Daylight Savings Time”.
Page 107: Technical Specifications
Appendix A Technical Specifications This appendix provides technical specifications for the DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router. Network Protocol and Standards Compatibility Data and Routing Protocols: TCP/IP, RIP-1, RIP-2, DHCP, PPP over Ethernet (PPPoE) or PPP over ATM (PPPoA), RFC 1483 Bridged or Routed...
Page 108 Reference Manual for the Model DG834PN 108 Mbps RangeMax Wireless ADSL Modem Router Electromagnetic Emissions Meets requirements of: FCC Part 15 Class B VCCI Class B EN 55 022 (CISPR 22), Class B Interface Specifications LAN: 10BASE-T or 100BASE-Tx, RJ-45...
