2. System Administration
lm2 16TX01
lm3 4FX11
cm MCM01
sm SM34
lm4 XX
lm5 M4FG03
lm6 8TX02
pm2 HI
main RX5000-F
em
In the slot-hardware
in bold text in the example above).
4. When ordering a new featurekey, provide the

2.8.5. Uploading a Featurekey

After receiving your featurekey file from RuggedCom, save the file to a computer that is accessible to
your device through your network.
2.8.5.1. Uploading a Featurekey Using the Web User Interface
Install Featurekey files using the Install Files forms found under the admin menu.
To install a featurekey file, navigate to admin/install-files. The Install Files form appears. In the in the File
type field, select featurekey. In the URL field, enter the URL to the file. On the Install Files to Devices
form, click the Perform button.
Figure 2.38. Install Files forms
For more information on installing files, see
2.8.5.2. Uploading a Featurekey Using the Command Line Interface
To upload the file to your device, you will need to know the following information:
• the featurekey filename.
• a user name and password to log in to the computer where you saved the featurekey file.
• the hostname or IP address of the computer where you saved the featurekey file.
Follow these steps to upload a featurekey file to your device:
ROX™ v2.2 User Guide
16x 10/100TX RJ45
4x 100FX Multimode LC 2km
MX5000 Control Module
SM 8 Gigabit Layer 3 w/ 2x 1000SX Multimode 850nm LC 500m
none
(MX)4x 1000LX Singlemode 1310nm LC 10km
8x 10/100TX MicroD
Power 88-300VDC or 85-264VAC w/ screw terminal block
Rack Rear Mount, Interfaces and LEDs on Front
Front Panel w/ Interfaces and LEDs
table, make note of the
Section 2.9.1, "Installing
cm and main slot serial numbers (highlighted
and slot serial numbers to RuggedCom.
cm main
Files".
54
L50R-3109-DEVEL
24
C50R-0310-00015
S50R-1410-00045
none
L50R-0310-00114
1234
P50R-1710-00092
B50R-3109-PR006
E50R-3109-PR001
