Mitsubishi Outlander Sport 2015-up
KIT FEATURES
• ISO DDIN radio provision
• 95-7018B - matte black
95-7018CHG - charcoal gloss
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) (4) #8 x 3/8" Phillips screws
B
A
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-7005
Antenna Adapter: • Not required
METRA - The World's best kits
Installation instructions for part 95-7018
95-7018
C
metraonline.com
®
®
Dash Disassembly ................................................. 2
Kit Assembly .......................................................... 3
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
CAUTION!
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
Table of Contents
All accessories, switches, climate controls panels, and
