Please do not return unit to retailer.
Por favor, no devuelva el aparato al lugar de compra.
Veuillez ne pas retourner l'outil au détaillant.
1- -800- -554- -6723
Manual de Instrucciones
1950 / 1975 / 2050 / 2055 / 2075
2150 / 2155 / 2175 / 2350 / 2375
For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e en-
strucciones de seguridad. El no hacerlo puede resultar en lesiones
graves.
AVERTISSEMENT:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le faire
pourrait entraîner des blessures graves.
Electrolux Home Products, Inc.
104 Warren Road
Augusta, GA 30907
Copyright E2004 Electrolux Home Products, Inc.
www.poulan.com
Instruction Manual
Manuel d'Instructions
2050WT / 2150PR
Electrolux Canada Corporation
Mississauga, Ontario L5R 4C2
R
6150 McLaughlin Road
530164603
6/16/04
Advertisement
Table of Contents
Related Manuals for Poulan Pro 530164603
Summary of Contents for Poulan Pro 530164603
-
Page 1: Instruction Manual
Tout défaut de le faire pourrait entraîner des blessures graves. Electrolux Home Products, Inc. 104 Warren Road Augusta, GA 30907 Copyright E2004 Electrolux Home Products, Inc. Instruction Manual 2050WT / 2150PR Electrolux Canada Corporation 6150 McLaughlin Road Mississauga, Ontario L5R 4C2 530164603 6/16/04... -
Page 2: Identification Of Symbols
IDENTIFICATION OF SYMBOLS WARNING! This chain saw can be dangerous! Care- less or improper use can cause serious or even fatal injury. Always wear appropriate ear protection, eye protection and head protection. Always use two hands when operating the chain saw. WARNING! should be avoided;... -
Page 3: Kickback Warning
vance. Do not start cutting until you have a clear work area, secure footing, and, if you are felling trees, a planned retreat path. OPERATE YOUR SAW SAFELY S Do not operate a chain saw with one hand. Serious injury to the operator, helpers, by- standers or any combination of these per- sons may result from one-handed opera- tion. -
Page 4: Maintain Control
Avoid Obstructions Clear The Working Area REDUCE THE CHANCE OF KICKBACK S Recognize that kickback can happen. With a basic understanding of kickback, you can reduce the element of surprise which contributes to accidents. S Never let the moving chain contact any ob- ject at the tip of the guide bar. - Page 5 Symmetrical Guide Bar Large Radius Tip S Low- -Kickback Chain, designed with a contoured depth gauge and guard link which deflect kickback force and allow wood to gradually ride into the cutter. Low- - Kickback Chain has met kickback per- formance requirements when tested on a representative sample of chain saws be- low 3.8 cubic inch displacement specified...
-
Page 6: Assembly
mercial logging, a chain brake is required and shall not be removed or otherwise dis- abled to comply with Federal OSHA Regula- tions for Commercial Logging. SAFETY NOTICE: Exposure to vibrations through prolonged use of gasoline powered hand tools could cause blood vessel or nerve damage in the fingers, hands, and joints of people prone to circulation disorders or abnormal swellings. -
Page 7: Chain Tension
Drive Links Place chain onto the sprocket 7. Place chain over and behind clutch, fit- ting the drive links in the clutch drum sprocket. 8. Fit bottom of drive links between the teeth in the sprocket in the nose of the guide bar. -
Page 8: Operation
OPERATION KNOW YOUR CHAIN SAW READ THIS INSTRUCTION MANUAL AND SAFETY RULES BEFORE OPERATING YOUR CHAIN SAW. Compare the illustrations with your unit to familiarize yourself with the location of the various controls and adjustments. Save this manual for future reference. Front Hand Guard Chain Adjustment Tool... -
Page 9: Fueling
Before operation, gasoline must be mixed with a good quality synthetic 2-cycle air-cooled engine oil designed to be mixed at a ratio of 40:1. Poulan/Weed Eater brand synthetic oil is recommended. A 40:1 ratio is obtained by mixing 3.2 ounces (95 ml) of oil with 1 gallon (4 liters) of unleaded gaso- line. -
Page 10: Cutting Methods
(SIDE VIEW) STOP 1. Move ON/STOP switch to the ON posi- tion. 2. Pull choke/fast idle lever out to the full extent (to the FULL CHOKE position). 3. Slowly press primer bulb 6 times. 4. Pull the starter rope sharply 5 times with your right hand. -
Page 11: Tree Felling Techniques
small amount of dirt will quickly dull a chain and thus increase the possibility of kickback. S Practice cutting a few small logs using the following techniques to get the “feel” of us- ing your saw before you begin a major sawing operation. - Page 12 control fall Opening of felling Closing of notch NOTE: Before felling cut is complete, use wedges to open the cut if necessary to control the direction of fall. To avoid kickback and chain damage, use wood or plastic wedges, but never steel or iron wedges. S Be alert to signs that the tree is ready to fall: cracking sounds, widening of the fell- ing cut, or movement in the upper...
- Page 13 Using a support stand LIMBING AND PRUNING WARNING: Be alert for and guard against kickback. Do not allow the moving chain to contact any other branches or objects at the nose of the guide bar when limbing or pruning. Allowing such contact can result in serious injury.
-
Page 14: Cleaning The Spark Arrest- Ing Screen
MAINTENANCE SCHEDULE Check: Fuel mixture level ..Before each use Bar lubrication ..Before each use Chain tension ..Before each use Chain sharpness ..Before each use For damaged parts . -
Page 15: Bar Maintenance
about performing this procedure, contact your authorized service dealer 1- -800- -554- -6723. BAR MAINTENANCE If your saw cuts to one side, has to be forced through the cut, or been run with an improper amount of bar lubrication it may be neces- sary to service your bar. -
Page 16: Troubleshooting Table
LIMITED WARRANTY ELECTROLUX HOME PRODUCTS, INC., warrants to the original purchaser that each new Poulan brand gasoline chain saw is free from defects in material and workman- ship and agrees to repair or replace under this warranty any defective gasoline chain saw as follows from the original date of pur- chase. - Page 17 U.S. EPA / ENVIRONMENT CANADA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OB- LIGATIONS: The U. S. Environmental Protection Agency, Environment Canada and ELECTROLUX HOME PRODUCTS, INC., are pleased to explain the emissions control system warranty on your year 2002- -2004 small off- -road engine.
- Page 18 The information on the product label indicates which standard your engine is certified. Example: (Year) EPA Phase 1 or Phase 2 and/or CALIFORNIA. This engine is certified to be emissions compliant for the following use: Moderate (50 hours) Intermediate (125 hours) Extended (300 hours)
