Epson PowerLite X41 Plus Quick Setup

PowerLite X41+
®
Quick Setup
Before using the projector, make sure you read the safety instructions in the
online User's Guide.
Connect the projector
Choose from the following connections. See the sections below or the online
User's Guide for details.
Computer
Computer port
Connect one end of a VGA cable to the projector's Computer port, and the
other end to your laptop or computer's
your laptop to external display (see "Troubleshooting" on the back of this
sheet). You can also connect an audio cable.
HDMI port
Connect one end of an HDMI cable to the projector's HDMI port and the other
end to an HDMI port on your computer.
USB port
Connect the square end of a USB cable to the projector's USB-B (square) port.
Connect the flat end of the cable to any USB port on your computer.
Windows Vista or later: After turning on the projector, follow the on-screen
®
instructions to install the Epson ®
on first connection). If the software screen does not display automatically, open
My Computer or Computer, then double-click EPSON_PJ_UD.
OS X 10.7.x or higher: After turning on the projector, the setup folder for
USB Display appears in the Finder. Double-click USB Display Installer and
follow the on-screen instructions to install the Epson USB Display software
(only on first connection).
Video device
Connect multiple video devices and use the Source Search button on the
projector or the remote control to switch between them.
USB device
Connect a digital camera, USB flash drive, or USB storage device to the
projector's USB-A (flat) port.
If you connect a digital camera, USB flash drive, or USB storage device, you can
use the projector's PC Free feature. See the online User's Guide for details.
USB cable
HDMI cable
VGA cable
Audio cable
monitor port. Make sure to switch
USB Display software (EMP_UDSE.EXE; only
Component video to
VGA cable
HDMI cable
RCA video cable
(composite video)
RCA audio cable
USB cable
Turn on your equipment
1
Turn on your computer or video source.
2
Plug in the projector. The
3
Open the A/V Mute slide all the way.
4
Press the power button on the projector or remote control. The
projector beeps, the Status light flashes blue, and then stays on.
Note: To shut down the projector, press the
5
Use the arrow buttons on the remote control to highlight any of the
options on the Home screen that appears, then press
You can switch between projection sources and quickly access various
adjustment options from this screen.
6
The default language of the menu system is English. To select another
language, press the Menu button on the projector or remote control.
Select Extended and press
your language and press
system.
Adjust the image
1
If you don't see an image, press the Source Search button on the
projector or the remote control to select the image source.
Note: If you still see a blank screen or have other display problems, see
the troubleshooting tips on the back of this sheet.
2
To raise the image, press the foot release button and lift the front of the
projector. Release the button to lock the foot in position.
power light on the projector turns blue.
power button twice.
to select it.
. Select Language and press
. Press the Menu button to exit the menu
. Select
