Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2001 Porter-Cable Corporation
2/13/02
8:32 AM
Page 1
Double Insulated
Shear
MODEL
6602
MODEL
6604
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
ESPAÑOL: PÁGINA 11
FRANÇAISE : PAGE 22
IMPORTANT
Part No. 900276 - 10-31-01
Advertisement
Table of Contents
Related Manuals for Porter-Cable 6602
Summary of Contents for Porter-Cable 6602
- Page 1 900276 - 10-31-01.qxd 2/13/02 Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2001 Porter-Cable Corporation 8:32 AM Page 1 ESPAÑOL: PÁGINA 11 FRANÇAISE : PAGE 22 Double Insulated Shear MODEL 6602 MODEL 6604 IMPORTANT...
-
Page 2: General Safety Rules
900276 - 10-31-01.qxd 2/13/02 WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: · lead from lead-based paints, ·... - Page 3 900276 - 10-31-01.qxd 2/13/02 influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
- Page 4 WARNING: There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter-Cable and we have advised you.
-
Page 5: Replacement Parts
When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 6: Operation
900276 - 10-31-01.qxd 2/13/02 HOW TO HOLD SHEAR WARNlNG: The gear housing, intermediate plate, and cutting head may be made live if the tool cuts into live wiring. To prevent accidental shock, the tool must be held as shown in Fig. 1. TO START AND STOP SHEAR CAUTION: Make sure switch is in OFF position and hands, body and clothing are clear of cutting head before connecting tool to power circuit. -
Page 7: Replacing Cutters
900276 - 10-31-01.qxd 2/13/02 HOW TO USE SHEAR Model 6602: Be sure the material to be sheared is firmly supported. Clamping is recommended to insure control of the tool and the workpiece. Place side knives of shear slightly on the edge of the top side of the workpiece to steady tool. -
Page 8: Maintenance
Rotate the shear head to desired position (the shear head may be used at any radial position), and tighten all three cap screws (A). For Model 6602 tighten all three cap screws (A) to 30-35 in-lbs., failure to tighten the cap screws properly can cause the cap screws (A), to break. -
Page 9: Service And Repairs
900276 - 10-31-01.qxd 2/13/02 SERVICING THE ECCENTRIC BEARING (see Fig. 4) NOTE: For model 6602 only, Model 6604 does not require this service. Once every three months, depending upon usage, remove the shear head from the power unit following the instructions in the REPLACING CUTTERS section of the manual. - Page 10 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 11 Pour obtenir des pièces et accessoires pour les produits Porter-Cable • Delta, s’adresser à tout distributeur Porter- Cable • Delta, centre de service agréé ou centre de service d’usine Porter-Cable • Delta. Si vous n’avez accès à aucun de ces centres, appeler le 888-848-5175 et on vous dirigera vers le centre de service d’usine Porter-Cable •...
