HP ProLiant ML110 Generation 5 Quickspecs

Hide thumbs Also See for ProLiant ML110 Generation 5:
Table of Contents

Advertisement

Quick Links

Download this manual
QuickSpecs
Overview
Front View:
1.
DVD-ROM Drive
2.
Power LED
3.
Drive Activity LED
4.
Front Bezel
5.
SAS Cable (SAS model only)
6.
Hard Drive Controller Card (Optional)
7.
System Board
8.
HP ProLiant 100 G5 Lights-Out 100c Management Card
Port (Optional)
9.
System Fan
10.
365W Power Supply
What's New
The HP ProLiant ML110 G5 is now available with higher performance processors (quad-core up to 3.0GHz and dual-core up
to 3.16GHz) resulting in better processing power and increased productivity for the growing businesses.
Support for SAS Non-Hot Plug Enterprise Hard Drives
DA - 12867 U.S. QuickSpecs — Version 25 — 9-28-2009
HP ProLiant ML110 Generation 5
Rear View:
1.
Rear System Fan
2.
PCI Slot Cover Retainer
3.
PCI Slot Covers
4.
HP ProLiant 100 G5 Lights-Out 100c Management Card
Port (Optional)
5.
LAN Port (RJ-45)
6.
Rear USB 2.0 Ports
7.
Serial Port
8.
VGA Port
9.
PS/2 Keyboard Port
10. PS/2 Mouse Port
11. Power Supply Outlet
12. Power Supply Unit (PSU) Fan
Page 1

Advertisement

Table of Contents
loading

Related Manuals for HP ProLiant ML110 Generation 5

Summary of Contents for HP ProLiant ML110 Generation 5

  • Page 1 12. Power Supply Unit (PSU) Fan What's New The HP ProLiant ML110 G5 is now available with higher performance processors (quad-core up to 3.0GHz and dual-core up to 3.16GHz) resulting in better processing power and increased productivity for the growing businesses.
  • Page 2 Micro ATX tower (4U) Warranty: This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners. Hardware diagnostic support and repair are available for one year from date of purchase.

  • Page 3: Standard Features

    QuickSpecs HP ProLiant ML110 Generation 5 Standard Features Processor Quad-Core Processors One of the following Intel® Xeon® processor X3370 (3.00 GHz, 95W, 1333MHz FSB, 12MB) depending on Model NOTE: Available through Configure To Order only. See Factory Integration Models section for more details.
  • Page 4 QuickSpecs HP ProLiant ML110 Generation 5 Standard Features Memory Type PC2-6400 unbuffered DDR2 ECC 800MHz Standard 512 MB/1 GB Maximum 8 GB Network Controller Embedded NC105i PCI Express Gigabit Ethernet Server Adapter Expansion Slots # Technology Connector Device Form Factor...
  • Page 5 USB 2.0 Ports 8 total (4 rear, 2 front panel, 2 internal (one for USB Tape connectivity)) NOTE: Internal USB ports are optimal for the attachment of HP USB DAT Tape Drives NOTE: Please see the following URL for additional information regarding USB support: http://h18004.www1.hp.com/products/servers/platforms/usb-...
  • Page 6 HP entry server setup, providing a repeatable way to deploy reliable and consistent single-server configurations. The HP ProLiant Easy Set-up CDs assist with the OS installation process by preparing the system for installing "off-the-shelf" versions of Windows operating system software and automatically integrating optimized HP ProLiant server software drivers and utilities.
  • Page 7 Whether an SMB or large global corporation HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.
  • Page 8 Deployment Service – Installation and Start-up only Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays. For a complete listing of service offerings and information visit: http://www.hp.com/services/proliantservices...
  • Page 9 6MB (2 x 3MB) Level 2 cache Memory 1GB PC2-6400 UB ECC (DDR2-800MHz) (1 x 1GB) Storage Controller HP Embedded 6 Port SATA Controller with Embedded RAID (4 ports for HDD) Hard Drive 1 x 160GB 3.5-inch Non-hot-plug LFF SATA Internal Storage Non-Hot Plug SATA: Maximum 3.0TB (4 x 750GB)

  • Page 10: Smart Buys

    1 x 4MB Level 2 cache 455946-005 Memory 1 GB PC2-6400 ECC (DDR2-800Mhz) (1 x 1GB) Storage Controller HP Embedded 6 Port SATA Controller with embedded RAID (4 ports for HDD) Hard Drive (1) 160GB SATA 7.2K 3.5" Internal Storage Maximum 3.0TB (4 x 750GB) SATA...
  • Page 11 6 MB Level 2 cache Memory 2 GB PC2-6400 (1 x 2GB) ECC DIMM Storage Controller HP Embedded 6 Port SATA Controller with embedded RAID (4 ports for HDD) Hard Drive (1) 250GB SATA 7.2K 3.5" NDL HDD Internal Storage Maximum 3.0TB (4 x 750GB) SATA...

  • Page 12: Configuration Information-Factory Integrated Models

    NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements.
  • Page 13 NOTE: SATA drives have a 1 year warranty. Please see the QuickSpecs for Technical Specifications and additional information: http://h18000.www1.hp.com/products/quickspecs/11940_na/11940_na.html SAS Non-Hot Plug 3.5" Enterprise (ENT) Drives HP 600GB 6G SAS 15K 3.5" DP NHP ENT HDD 516830-B21 HP 450GB 6G SAS 15K 3.5" DP NHP ENT HDD 516826-B21 HP 450GB 3G SAS 15K 3.5"...

  • Page 14: Core Options

    NOTE: SATA drives have a 1 year warranty. Please see the QuickSpecs for Technical Specifications and additional information: http://h18000.www1.hp.com/products/quickspecs/11940_na/11940_na.html SAS Non-Hot Plug 3.5" Enterprise (ENT) Drives HP 600GB 6G SAS 15K 3.5" DP NHP ENT HDD 516830-B21 HP 450GB 6G SAS 15K 3.5" DP NHP ENT HDD 516826-B21 HP 450GB 3G SAS 15K 3.5"...
  • Page 15 Core Options Communications HP NC110T PCI Express Gigabit Server Adapter 434905-B21 HP NC360T PCI Express Dual Port Gigabit Server Adapter 412648-B21 HP NC373T PCI Express Multifunction Gigabit Server Adapter 394791-B21 NOTE: Please see the QuickSpecs for Technical Specifications and additional information: www.hp.com/go/ProLiantNICs...

  • Page 16: Additional Options

    Additional Options Remote Management HP ProLiant ML100 G5 Lights-Out 100c Remote Management Card 445513-B21 NOTE: Supports HP ProLiant DL180 G5, ML110 G5, ML115 G5 and ML150 G5 servers. NOTE: For additional information on Lights-Out 100c Remote Management Card, please see the QuickSpecs at: http://h18000.www1.hp.com/products/quickspecs/12468_na/12468_na.html...
  • Page 17 NOTE: 160GB of Disk Storage. HP StorageWorks RDX320 Internal Removable Disk Backup System AJ767A NOTE: 320GB of Disk Storage. NOTE: Please see the HP RDX Removable Disk Backup System QuickSpecs for additional information: http://h18000.www1.hp.com/products/quickspecs/13036_na/13036_na.html D2D Backup HP StorageWorks D2D2504i Backup System...
  • Page 18 HP Rack Options HP KVM Switch Options HP 1x4 Console Switch AF611A HP PS2 Server Console Cable, 6 foot, 2-Pack AF612A HP USB Server Console Cable, 6 foot, 2-Pack AF613A NOTE: required for supporting USB peripherals. NOTE: For additional information regarding KVM Switches, Serial Console...
  • Page 19 8 GB 2 GB 2 GB 2 GB 2 GB Following are memory options available from HP: 2 GB Unbuffered PC2-6400 ECC DIMM (1 x 2 GB) 450260-B21 1 GB Unbuffered PC2-6400 ECC DIMM (1 x 1 GB) 450259-B21 512 MB Unbuffered PC2-6400 ECC DIMM (1 x 512 MB) 450258-B21 DA - 12867 U.S.

  • Page 20: Drive Support

    QuickSpecs HP ProLiant ML110 Generation 5 Storage 16x SATA DVD-ROM Removable Media Bays (5.25" each) 3, 4, 5, Four Non-Hot Plug Drive Bays Drive Support Quantity Position Supported Supported Controller Removable Media DVD Drive 1 or 2 Integrated SATA DVD-RW Drive...
  • Page 21 1.8TB (4 x 450GB) Tape and Disk-Based Backup NOTE: Installation of SCSI tape drives in a ML110 G5 model requires SCSI controller kit (PN: 412911-B21). NOTE: For a complete listing of compatible tape and disk-based backup offerings, please visit: www.hp.com/go/connect. Controller/HBA Position...
  • Page 22 QuickSpecs HP ProLiant ML110 Generation 5 Storage HP StorageWorks RDX USB 2.0 Port Removable Disk Backup System RDX160 RDX320 HP StorageWorks D2D External Embedded Network Controller Backup Systems D2D120 D2D130 D2D2504i DA - 12867 U.S. QuickSpecs — Version 25 — 9-28-2009...

  • Page 23: Power Specifications

    QuickSpecs HP ProLiant ML110 Generation 5 Power Specifications Part Number 445067-001 Operational Input Voltage Range 100 to 127 and 200 to 240 V auto ranging (Vrms) Frequency Range (Nominal) (Hz) 50 to 60 Hz Nominal Input Voltage (Vrms) Max Rated Output Wattage Rating...

  • Page 24: System Specifications

    QuickSpecs HP ProLiant ML110 Generation 5 System Specifications Power HP ProLiant ML110 G5 Fully (see **) Configured Fully Loaded System output Wattage 365W Fully Loaded System Input Current 6A @ 100V, 3A @ 200V (A rms) Fully Loaded System Thermal (BTU-...

  • Page 25: Technical Specifications

    QuickSpecs HP ProLiant ML110 Generation 5 Technical Specifications System Unit Dimensions (HxWxD) 14.5 x 6.9 x 16.8 in (36.7 x 17.5 x 42.6 cm) (with feet) Weight (approximate) Maximum 39 lb (17.5 kg) (all hard drives, power supplies, and processors...
  • Page 26 QuickSpecs HP ProLiant ML110 Generation 5 Technical Specifications 74) and declared in accordance with ISO 9296 (ECMA 109). SATA Model Idle 4.2 Bels L WAd 26 dBA L pAm Operating 5.1 Bels L WAd 34 dBA L pAm SAS Model Idle 5.2 Bels...
  • Page 27 QuickSpecs HP ProLiant ML110 Generation 5 Technical Specifications 16X Max SATA DVD- Disk Applicable Disk CD-ROM, CD-XA, CD-DA ROM Drive (Mode 1, Mode 2, Form 1 and 2) Photo CD (Single and Multi-session) CD-R, CD-RW Mixed Mode (Audio and Data combined)
  • Page 28 QuickSpecs HP ProLiant ML110 Generation 5 Technical Specifications Simultaneous Drive 1 x4 Wide SAS Connectors Transfer Ports Port Transfer Rate 12 Gb/s per x4 Wide SAS Port (4 x 3 Gb/s) Software upgradeable Firmware Maximum Capacity 1.2TB (4 x 300GB)
  • Page 29 The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
