The table below summarizes the EDID Minder settings and functions.
DIP Switch 1 Position LED Color
Stored (down)
Stored (down); EDID
Store button pressed
Stored (down)
Default (up)
Function Indicated
Red
EDID storing is enabled, but the default EDID is
still in effect.
Amber
EDID storing is enabled and the EDID of the
currently connected display is being recorded.
Green
An EDID other than the default has been stored.
Off
The factory default EDID of 1920x1080 @ 60 Hz
with 2-channel audio is in effect.
SW2 DP • Operation
