T640rn
User's Guide
June 2006
www.lexmark.com
Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.
All other trademarks are the property of their respective owners.
© 2006 Lexmark International, Inc.
All rights reserved.
740 West New Circle Road
Lexington, Kentucky 40550
Advertisement
Table of Contents
Related Manuals for Lexmark T640rn
Summary of Contents for Lexmark T640rn
- Page 1 User's Guide June 2006 www.lexmark.com Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. All other trademarks are the property of their respective owners. © 2006 Lexmark International, Inc.
-
Page 2: Safety Information
Refer service or repairs, other than those described in the user documentation, to a professional service person. This product is designed, tested, and approved to meet strict global safety standards with the use of specific Lexmark components. The safety features of some parts may not always be obvious. -
Page 3: Table Of Contents
Lexmark Confidential until announced Contents Introduction...........................5 Overview of Radio Frequency Identification (RFID)..................5 Choosing an output device..........................5 Preparing to print........................6 Loading RFID labels............................6 Printing...........................8 Printing on labels of different sizes......................8 Identifying rejected labels..........................8 Understanding the RFID menu.....................9 Configuring RFID-specific settings......................9 Understanding RFID printer messages................11 RFID error messages..........................11... - Page 4 Lexmark Confidential until announced...
-
Page 5: Introduction
Choose an output device based on the software program, the length of label needed, and the number of labels that you expect to print at one time. To order an output device, visit the Lexmark Web site at www.lexmark.com:... -
Page 6: Preparing To Print
The increased thickness of RFID labels reduces the input and output bin capacity. Test your software program to ensure that you understand the reduced input and output bin capabilities. For information on label construction, see the Card Stock and Label Guide on the Lexmark Web site at www.lexmark.com/publications. Preparing to print... - Page 7 Lexmark Confidential until announced Proper tag orientation for printing The following are examples of tag locations known to work correctly: Tag manufacturer (EPC class 1 Tag location Orientation generation 2 specification only) Symbol G2 4 x 4 1.5–8.5 in. from the left edge NA Raflatec 3.7–7.5 in from the left edge Parallel to the long edge of the label sheet...
-
Page 8: Printing
Lexmark Confidential until announced Printing Printing on labels of different sizes Label size/type Input options Output options Rejected label output Less than 7 in. 250-sheet tray • Set the default Reject Bin so that all rejected labels 5-bin Mailbox are sent to the same output device. -
Page 9: Understanding The Rfid Menu
Lexmark Confidential until announced Understanding the RFID menu Configuring RFID-specific settings The RFID menu is used to configure RFID-specific settings. It is located on the operator panel between the Help and Network/Ports menus. Note: RFID settings appear on the menu settings page. For information on printing a menu settings page, see the User's Guide available on the Software and Documentation CD. - Page 10 Lexmark Confidential until announced Reject Bin Menu selection Purpose Option Comments Reject Bin Determines where to send sheets with Disabled Standard Bin Disabled is the default value. RFID labels that failed to program Bin 1 correctly Standard Bin and Disabled are...
-
Page 11: Understanding Rfid Printer Messages
Lexmark Confidential until announced Understanding RFID printer messages RFID error messages Message Action 44.00 RFID error (generic) Turn the printer off. Unplug the power cord. Check all cable connections. Connect the power cord to a grounded outlet. Turn the printer on. -
Page 12: Rfid Service Messages
Lexmark Confidential until announced RFID service messages Message Action 902.81 Service engine software error Turn the printer off. Unplug the power cord. 985.01 Unable to communicate with interface card Check all cable connections. 985.02 Unable to communicate with radio Connect the power cord to a properly grounded outlet. -
Page 13: Notices
Comments about this publication may be addressed to Lexmark International, Inc., Department F95/032-2, 740 West New Circle Road, Lexington, Kentucky 40550, U.S.A. Lexmark may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you. -
Page 14: Exposure To Radio Frequency Radiation
Note: To assure compliance with FCC regulations on electromagnetic interference for a Class B computing device, use a properly shielded and grounded cable such as Lexmark part number 1021294 for USB attach. Use of a substitute cable not properly shielded and grounded may result in a violation of FCC regulations. -
Page 15: Power Consumption
Lexmark Confidential until announced Laser notice The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for Class I (1) laser products, and elsewhere is certified as a Class I laser product conforming to the requirements of IEC 60825-1. -
Page 16: Statement Of Limited Warranty
This limited warranty applies to the United States and Canada. For customers outside the U.S., refer to the country-specific warranty information that came with your product. This limited warranty applies to this product only if it was originally purchased for your use, and not for resale, from Lexmark or a Lexmark Remarketer, referred to in this statement as “Remarketer.”... - Page 17 Lexmark's liability for actual damages from any cause whatsoever will be limited to the amount you paid for the product that caused the damages. This limitation of liability will not apply to claims by you for bodily injury or damage to real property or tangible personal property for which Lexmark is legally liable.
-
Page 18: Index
Lexmark Confidential until announced Index Numerics 44.xx 11 902.xx 12 985.xx 12 emission notices 14 FCC notices 14 identifying rejected labels 8 labels loading 6 printing 8 tag orientation 6 loading labels 6 messages RFID error 11 RFID service 12...
