PORTABLE KEROSENE HEATER
MAINTENANCE INSTRUCTIONS
IMPORTANT
READ AND UNDERSTAND INSTRUCTIONS BEFORE USING HEATER.
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
This heater is designed to be used at altitudes up to 1,300m above sea level. Consult with your dealer otherwise.
···················································· 1
····················································· 3
OPERATION AND
DR-37
Model
CONTENTS
······························ 4
································· 9
································ 10
······················································· 13
············································· 13
······································· 14
Advertisement
Table of Contents
Related Manuals for Toyotomi DR-37
Summary of Contents for Toyotomi DR-37
-
Page 1: Table Of Contents
DR-37_US.qxd 16.6.14 15:31 ページ a PORTABLE KEROSENE HEATER OPERATION AND MAINTENANCE INSTRUCTIONS DR-37 Model IMPORTANT READ AND UNDERSTAND INSTRUCTIONS BEFORE USING HEATER. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. This heater is designed to be used at altitudes up to 1,300m above sea level. Consult with your dealer otherwise. -
Page 2: Safety Tips
DR-37_US.qxd 16.6.14 15:31 ページ 1 SAFETY TIPS BEFORE OPERATING YOUR HEATER, PLEASE review these safety tips: WARNING RISK OF EXPLOSION 1. NEVER use any fuel other than clean kerosene (paraffin). NEVER use gasoline (petrol). Use of gasoline (petrol) can lead to uncontrollable flames resulting in destructive fire. - Page 3 DR-37_US.qxd 16.6.14 15:31 ページ 2 3. DO NOT use heater to heat or boil water or as a cooking appliance. DO NOT place cooking utensils, tea kettles or any other object on top of heater while in operation. 4. To avoid possible burns or fire, do not move, refuel or attempt to service your heater while it is burning or still hot.
-
Page 4: Fuel Guide
DR-37_US.qxd 16.6.14 15:31 ページ 3 FUEL GUIDE The RCA-37WX is designed for use with high-quality kerosene (paraffin). Use of low-quality kerosene (paraffin) will cause wick performance to drop, leading to “Iow flame” and “odor problem” conditions. The kerosene commonly known as “industrial kerosene (paraffin)” is not suitable for your heater. Purchase only kerosene (paraffin) in non-red cans reserved exclusively for kerosene (paraffin) and marked accordingly with the word “KEROSENE (PARAFFIN)”. -
Page 5: Assembly And Operation
DR-37_US.qxd 16.6.14 15:31 ページ 4 ASSEMBLY AND OPERATION INSPECTION AND ASSEMBLY NOTE: Please save the shipping carton and packing materials for future storage of your heater. 1. REMOVE PACKING MATERIALS Open the grille by raising the lower right hand corner of grille and pulling straight out. Slide the cardboard packing down by spreading out to release the heat chamber assembly. - Page 6 DR-37_US.qxd 16.6.14 15:31 ページ 5 1. Open the fuel tank lid on the top of heater cabinet and lift out the removable fuel tank. Turn the removable tank upside down and remove the fuel tank cap. 2. Insert the straight tube of the manual siphon into the kerosene container. Insert the siphon’s flexible hose into the removable fuel tank opening.
- Page 7 DR-37_US.qxd 16.6.14 15:31 ページ 6 LIGHTING NOTE: When you first use your new heater, ignite it out of the living area of your house, either in a garage or on area outside protected from strong drafts. Burn it for about 15 minutes to remove all of the protective oil present on the burner parts.
- Page 8 DR-37_US.qxd 16.6.14 15:31 ページ 7 ADJUSTING THE FLAME 1. After lighting, wait for the heat chamber to reach operating temperature. This will take ten-fifteen minutes, after which the flame will be visible through the glass cylinder. 2. CHECK THE FLAME LENGTH Look at the flame and check its length.
- Page 9 DR-37_US.qxd 16.6.14 15:31 ページ 8 The wick height adjuster knob, with three small holes marked 1, 2, and 3, can be Wick hight adjuster knob seen. The stem pin is engaged in one of the holes. Pull the control dial toward you and change the location of the pin from 1 to 2, or from 2 to 3.
-
Page 10: Care And Maintenance
DR-37_US.qxd 16.6.14 15:31 ページ 9 CARE AND MAINTENANCE As with any good appliance, preventive as well as corrective maintenance is occasionally required. Please read the following section carefully in order to enjoy the greatest benefits from your heater. INSPECTlON OF THE WlCK NOTE: One of the simplest but also the most important components of your heater is the wick. -
Page 11: Replacement Of Parts
DR-37_US.qxd 16.6.14 15:31 ページ 10 REPLACEMENT OF PARTS REPLACING THE WICK WARNING: Before disassembling your heater, allow it to cool completely. 1. Remove the fuel tank assembly out of tank. And remove the four (4) batteries out of battery holder. 2. - Page 12 DR-37_US.qxd 16.6.14 15:31 ページ 11 7. Place the knurled wick adjustment knob on the wick mechanism. Turn the knob as far to the right as possible. Wick sleeve Handle arm 8. Turn the wick sleeve counterclockwise and lift the wick sleeve with wick up. Remove it from the primary air tube.
- Page 13 DR-37_US.qxd 16.6.14 15:31 ページ 12 12. Put the wick holder back into position. 13. Make certain the top plate of the wick holder and Space the top of primary air tube are the same height. If Top of Top of they are uneven, the flames tend to be uneven, wick primary...
-
Page 14: Storage
The original shipping carton is the best place to store your heater. If you do not have original packing materials, cover the heater with a large plastic bag and store in a dry place. SPECIFICATIONS Model DR-37 Heat rating 10,990 BTU/h (2,770 kcal/h) Fuel tank capacity 4.7 L... -
Page 15: Component Parts
DR-37_US.qxd 16.6.14 15:31 ページ 14 COMPONENT PARTS REF # PART NAME REF # PART NAME REF # PART NAME Tank lid Removable fuel tank Glass fiber wick Top plate Fuel filter cap Rubber packing Grille Wick adjuster assembly Fuel sub tank Heat chamber assembly Igniter unit Fuel acceptance fitting... - Page 16 DR-37_US.qxd 16.6.14 15:31 ページ 15 TOYOTOMI CO., LTD. 5-17, Momozono-cho Mizuho-ku, Nagoya, Japan Printed in Japan New 07/16 0272000903...
