VIPER
www.usviper.com
IMPORTANT: READ OWNERS MANUAL CAREFULLY
Please fill out & return your warranty card!
VIPER NORTH AMERICA
P.O. BOX 104
HAMILTON, MI 49419
(866) 418-4737
(866) 41 - VIPER
OWNERS MANUAL
MODEL#
SERIAL#
DRAGON SERIES
HIGH SPEEDS
DR1500H
VIPER ...exceptional
value
REV.05(12-08)
VF41529
Advertisement
Related Manuals for Viper DR1500H
Summary of Contents for Viper DR1500H
- Page 1 HIGH SPEEDS www.usviper.com OWNERS MANUAL IMPORTANT: READ OWNERS MANUAL CAREFULLY Please fill out & return your warranty card! DR1500H MODEL# SERIAL# VIPER NORTH AMERICA VIPER ...exceptional P.O. BOX 104 value HAMILTON, MI 49419 (866) 418-4737 REV.05(12-08) (866) 41 - VIPER VF41529...
-
Page 2: Table Of Contents
CONGRATULATIONS on your purchase of a Viper product, and welcome to the V.I.P. family. We appreciate your business and will do everything in our power to keep you happy with your purchase for many years to come. As part of the V.I.P. family, you are entitled to the best protection by one of the most comprehensive warranties the industry. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS !!! This machine must be grounded! 2) Before operating machine: Grounding provides the path of least - Make sure all safety devices are resistance for electrical current. To in place and operate properly. reduce the risk of electrical shock should the machine malfunction, the 3) When using machine: machine has a special grounding plug. -
Page 4: Machine Operation
Operation of High Speed Floor Machine * Read operators manual thoroughly prior to operating or servicing this machine. MAINTENANCE GENERAL USE To keep the machine performing well for 1] Remove any obstructions or other many years, please follow the following obstacles in the area which is to be maintenance procedures. -
Page 5: Parts Lists
PARTS LIST HANDLE GROUP FOR DR1500H... - Page 6 HANDLE GROUP PARTS LIST FOR DR1500H PART DESCRIPTION NUMBER REQ'D VF47009 FRONT COVER, SEAT, GEAR VF47029 SEAT, GEAR VF47028 GEAR GV40227 WASHER, NYLON GV40228 "O" RING, GEAR SEAT VF50120 GROMMET VF47015 REAR COVER, SEAT, GEAR VF14080 SELF-TAPPING SCREW, ST4x25 VF14087...
- Page 7 HANDLE GROUP PARTS LIST FOR DR1500H PART DESCRIPTION NUMBER REQ'D 39 VF46705 SAFETY BLOCK 40 GV40218 SPRING, SAFETY BLOCK 41 VF99010C CIRCUIT BREAKER, 17AMPS 42 VF13527 WASHER, EXTERNAL TOOTH, φ4 43 VF13526 HEX SOCKET SCREW, M4x30 44 VF46704 LEVELING HANDLE, RIGHT, SWITCH...
- Page 8 PARTS LIST BASE GROUP FOR DR1500H...
- Page 9 BASE GROUP PARTS LIST FOR DR1500H PART DESCRIPTION NUMBER REQ'D VF52102A UPPER COVER VF47035A "VIPER" LOGO VA13484 SELF-TAPPING SCREW, ST4x12 VF52114 PLASTIC STAND, RIGHT VF52115 PLASTIC STAND, LEFT VF52101A LOWER COVER VV20509 SCREW, M5x10, PH VF13503 NUT, M8, NYLON INSERT...
- Page 10 BASE GROUP PARTS LIST FOR DR1500H PART DESCRIPTION NUMBER REQ'D 39 VF14004 RETAINING RING, EXTERNAL, φ19 40 VF50123 WASHER, φ19 41 VF47027 WAVING WASHER, φ19 42 VF47055 WHEEL, 160mm 43 VA96851 CAP, AXLE 44 VF52021 WASHER, PLAIN 45 VF14008 SCREW, 5/16"-18...
-
Page 11: Wiring Diagram
Wiring Diagram DR1500H Switch Housing Circuit Switch Breaker Black White Motor Green Power Handle Motor Supply Cord Cord Cord...
