- Page 1 5.6” Portable DVD Player Model: PDV-0560M Operations Manual 20040917...
-
Page 2: Table Of Contents
Important Safety Instructions…………………………………………..… Characteristic Features………..………………………………………….. Disc Information…………………..………………………………………… Description-DVD Player ………….………..……………………………… Remote Control ……………………………………….…………………… Use of Remote Control………..…………………………………………. Remote Control Drawing…………………..………………………………… System Connections……………………………………………………………. Connecting to TV….………..………………………………………………… Connecting to Amplifier……………………………………….…..……….… Connecting to Audio/Video Sources………..……………………………… Connecting to Power Adapter……..………………………………………… Connecting to Car Adapter……………………………………………….…. Connecting to Headphone……………………………………………….….. -
Page 3: Important Safety Instructions
Important Safety Instructions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... - Page 4 Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Maintain well ventilated conditions around the product. Do not put product on bed, sofa or anything that blocks ventilation.
-
Page 5: Characteristic Features
Characteristic Features About this player This player incorporates a DVD player, color LCD screen display, 2 channel stereo audio output functions. When used in a vehicle, this player can be powered with the 12VDC car adapter. High Quality Properties High Resolution MPEG2 decoding format achieves more than 500 lines of horizontal resolution. -
Page 6: Disc Information
Disc Information Disc Formats Supported By This Player DISC LOGO The operating method of some DVD discs is specified by the software maker. Please refer to the instruction manual of the disc. The DVD player will play most recordable (CD-R) or erasable (CD-RW) CDs, but playback of CD-R or CD-RW discs created on a computer requires proper formatting and finalization of the disc for audio playback. -
Page 7: Description-Dvd Player
Description DVD Player Front View Open the cover to view the fashionable design of the unit: 1. OPEN button Press to open the disc tray. 2. TITLE button Press to display title menu (if present) on the disc. REV button Press to search backward. -
Page 8: Right View
Description-DVD Player 12. OK button Press to confirm selections in the menu. 13. MENU button Press to turn the menu on/off. 14. Disc tray cover Press the OPEN button to open the tray for loading disc. 15. Speakers Produce high quality sound. 16. -
Page 9: Remote Control
Use Of Remote Control Preparation of remote control Remove the battery compartment in the direction of the arrow. Place the lithium battery in the battery compartment. Make sure the polarity matches the marks inside the compartment. Insert the compartment into the remote. Under normal use the battery will last for about one year. -
Page 10: Remote Control Drawing
Remote Control Drawing 1. POWER button Press to put the unit into standby mode. Press again to put the unit into working mode. 2. INFO button Press for detailed information on the disc playing. Press repeatedly to remove information from screen. 3. - Page 11 PREV button Press skip track/chapter. NEXT button Press to skip to the next track/chapter. 10. SUBT button When a DVD is playing, press to select a subtitle language or the turn subtitle off. 11. ANGLE button Press to access various camera angles, if the DVD disc contains multiple camera angles.
-
Page 12: System Connections
System Connections Do not connect the power to the unit until all audio and video connections have been made. Switch AV IN/OUT to AV/OUT mode for playing discs. Connect the audio/video output jacks to the corresponding jacks on the TV, amplifier or speaker. Connecting to TV Connections should be made as follows: Connecting to an Amplifier... -
Page 13: Connecting To Audio/Video Sources
System Connections Connecting to Audio/Video Sources Move the switch “AV IN/OUT” to “IN” position on the right panel to put the unit into audio/video input mode. Use the audio cable to connect the AUDIO socket of your DVD player with the audio output socket of external AV signal source. -
Page 14: Connecting To Car Adapter
Connecting To Car Adapter You can use Car Adapter in a vehicle: 1. This player can be powered with a car adapter. (The car adapter is included 2. Connect the Car Adapter Power Plug into the unit’s Power Jack and the other end into the Vehicle Cigarette Lighter Socket: Note: Make sure the unit and the car adapter are not connected when starting the car. -
Page 15: About Rechargeable Battery
About Rechargeable Battery Normally the player is powered by connecting it to an AC power supply using the adapter. When used as a portable player outdoors or when traveling, the unit comes with a lithium ion rechargeable battery that attaches to the bottom of the player. You can enjoy the DVD player wherever you are. -
Page 16: Detaching The Rechargeable Battery
About Rechargeable Battery Detaching Battery Pack Important Note: Detach battery when not in use for an extended period of time to prolong the battery’s service life. 1. Press the tab towards the front of the unit. Hold the tab in the up position. 2. -
Page 17: Disc Play Operations
Disc Play Operations Basic operation Preparation After the connections have been made, turn on the relevant equipment and select the desired video input before playback. Open the LCD screen Press the button on the main panel, lift the LCD screen upward. Turn on the player’s power Turn on the player’s power by switching the POWER switch on the side of the... -
Page 18: Dvd Playback
Disc Play Operations During playback, press the COLOR, CONTRAST and BRIGHT buttons on the front panel of the DVD player to adjust the picture. During playback, rotate earphone/speaker volume increase and decrease the volume. VOLUME To interrupt playback press the STOP button once. -
Page 19: Cd Playback
Disc Play Operations Audio There are up to 8 kinds of audio languages in a DVD disc. When you play a multi-language DVD disc, press the AUDIO button on remote control to select a different audio language. Subtitle The DVD player can support up to 32 kinds of subtitles. -
Page 20: Jpeg Playback
Disc Play Operations Press the direction button to return to the root menu. JPEG Playback JPEG is a common picture format that requires very little storage per image with a low loss rate in resolution. Hundreds of pictures can be stored on a disc in this format. -
Page 21: Playback Functions
Stop During CD, DVD playback, press the STOP button on the remote control to stop playing. Press the PLAY button and then the player will resume play from the point where it stopped. Pressing the STOP button twice will stop the unit completely. - Page 22 Normal playback is resumed when you press the PLAY button. There is no slow playback function for CD and MP3 discs. Play Press the PLAY button to start playback. Press the POWER button on the remote control to enter the standby status, and press it again to enter playing status.
-
Page 23: System Setup
System Setup Setup Menu In stop status, press the SETUP button on the remote control and the TV screen will display a main menu. Press the SETUP button to exit the setup menu. - - General Setup Page- - TV Display Wide Angle Mark OSD Lang... - Page 24 Angle Mark In the General Setup Page, use the ▲/▼ direction buttons to highlight the “Angle Mark.” Press the access it. - - General Setup Page - - TV Display Wide Angle Mark OSD Lang Captions Screen Saver Set Angle Mark Use the ▲/▼...
-
Page 25: Speaker Setup
System Setup -General Setup Page- - TV Display Wide Angle Mark OSD Lang Captions Screen Saver Use the ▲/▼ direction buttons to select On or Off. Press the ENTER button to confirm it and return to the last level. When On is selected, the player will display a screen saver picture after playback has stopped for some time. -
Page 26: Video Setup
System Setup - - Dolby Digital Setup - - Dual Mono Dynamic Set DRC to Full Use the ▲/▼ direction buttons to select the item you want to set. Press the ENTER button to confirm it and return to the last level. Video Setup When Dolby Digital Setup has been done, press the... - Page 27 System Setup - -Preference Page- - Audio English Subtitle French Disc Menu Spanish Chinese Japanese Default Korean Version Russian Thai Preferred Audio Language Use the ▲/▼ direction buttons to select the item you want to set. Press the ENTER button to confirm it and return to the last level.
- Page 28 System Setup Default Reset In Preference menu, use the ▲/▼ direction button to highlight the “Default” and bring up the menu. Press the button to access it. - - Preference Setup Page- - Audio Subtitle Disc Menu Default Reset Version Load Factory Setting Press the ENTER if you want to recall the factory settings.
-
Page 29: Carrying Case
Carrying Case INSTRUCTIONS FOR ATTACHING YOUR PORTABLE DVD PLAYER CASE IN A VEHICLE Please read and follow these instructions carefully when attaching this case inside your vehicle. For ease of installation, do not place the DVD player into the case until after the case is attached inside the vehicle. - Page 30 Always position the plastic hooks and strap adjustment slider so that they do not contact the back of the head of the person in the front seat. Attach the DVD Player Case to a seat back (Photos 1 & 2): Unzip the main compartment that holds the player;...
- Page 31 To suspend the DVD Player Case between 2 bucket seats (Photo Unzip the main compartment that holds the player; locate the set of rings tucked inside the top edge of the case (A) Locate the 2 straps with hooks on each end Hook one end of each strap to the rings at the top of the case (A) Wrap each strap around the headrest or seat;...
-
Page 32: Troubleshooting
Symptom No TFT LCD display LCD is very bright or dark. Colors of picture are faded or bloomy. The player does not play discs or the display shows: no disc. No sound. Disc skips and will not continue to play. The remote control does not work. -
Page 33: Specifications
For service, support and warranty information, visit the US call 1-866-289-5168, in Canada call 1-866-301-7922 and in Mexico call 01-800-400-2443. “Polaroid” is a registered trademark of Polaroid Corporation of Waltham, MA USA and licensed for use on the PDV-0560M to Petters Consumer Brands, LLC. Wavelength: 780/650nm...
