MAINTENANCE
Lights

Removing Halogen Bulbs

NOTE:
Do not touch a halogen bulb with bare fingers. Oil from skin leaves a
residue, causing a hot spot that will shorten the life of the lamp. If fin-
gers do touch the bulb, clean it with an alcohol-moistened towel.
1. Remove the plenum cov-
ering from the headlight
assembly.
2. Lift the rubber boot to
expose the bulb.
3. Push down on the spring
to release it from the
housing.
4. With the wire harness
attached to the bulb,
withdraw the bulb from
the housing.
5. Grasp the bulb by its metal base and carefully separate the bulb
from the harness.

Installing Halogen Bulbs

1. Hold the bulb by its metal base and install it into the wire harness.
2. Insert the bulb into the housing.
3. Connect the spring to the housing.
4. Carefully flip the spring back into the housing, placing it around the
wire harness.
5. Reinstall the plenum covering on the headlight assembly.
6. Adjust headlight aim. See page 29.
Replacing Taillight Bulbs
1. Remove the screws securing the taillight lens.
2. Push the bulb in and twist counterclockwise and replace the bulb.
3. Replace the taillight lens.
130
Spring
Harness
Bulb
