Summary of Contents for BMW Multi Tool

  • Page 1 BMW Multi Tool User Manual...

  • Page 2: Table Of Contents

    BMW Multi Tool User Manual Table of Contents Safety Precautions and Warnings ................3 General Information ...................... 4 Hardware Overview ...................... 5 3.1. Tool Description ....................5 3.2. Specifications..................... 6 3.3. System Requirements ..................7 Software Overview ....................... 8 4.1.

  • Page 3: Safety Precautions And Warnings

    BMW Multi Tool User Manual 1. Safety Precautions and Warnings To prevent personal injury or damage to vehicles and/or the tool, read this instruction manual first and observe the following safety precautions at a minimum whenever working on a vehicle: ...

  • Page 4: General Information

    BMW Multi Tool User Manual 2. General Information Thank you for choosing BMW Multi Tool. This manual includes the use of equipment notes, please read this manual carefully before use so that you can correctly use it. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission.

  • Page 5: Hardware Overview

    BMW Multi Tool User Manual 3. Hardware Overview 3.1. Tool Description ITEM Description OBD II CONNECTOR ❶ Connects the tool to the vehicle’s Data Link connector (DLC). Dongle ❷ USB dongle. USB CONNECTOR ❸ Connects the tool to the PC/Laptop through USB Cable.

  • Page 6: Specifications

    BMW Multi Tool User Manual 3.2. Specifications ITEM Description -20 to 70 °C ( -4 to 158 °F ) Operating Temperature Storage Temperature -40 to 85 °C ( -40 to 185 °F ) Diagnostic Interface 16 PIN USB Interface USB 2.0...

  • Page 7: System Requirements

    BMW Multi Tool User Manual 3.3. System Requirements PC/Laptop Minimum Specification Minimum Specification Recommended Specification Pentium 3/1GHz or above Pentium 4/1.6GHz or above Memory(RAM) 512M or above 1G or above 40G or above 60G or above 800 x 600 or above...

  • Page 8: Software Overview

    BMW Multi Tool User Manual 4. Software Overview 4.1. Overview BMW Multi Tool includes forth parts, hardware device, dongle, programmer, software. Before running software you must connect dongle and hardware device to computer. 1. OBD II: BMW Multi Tool connects to car directly.
  • Page 9 BMW Multi Tool User Manual 1. 7 Series CAS1/CAS2 pin method: 2. CAS2(While Box)/CAS3/CAS3+ pin method:...
  • Page 10 BMW Multi Tool User Manual 3. Device pin method:...

  • Page 11: Function

    BMW Multi Tool User Manual 4.2. Function Main window follows: Menu Tool: you can choose language here, support “English” and “Chinese Simplified” Restart software to apply your settings. File Make Key: you can prepare dealer key with EWS and CAS EEPROM dump.
  • Page 12 BMW Multi Tool User Manual Protocal type: Now BMT support there type of protocol: KWP-CAN BUS 100Kbps, KWP-CAN BUS 500Kbps, KWP-2000. “Auto Detect ” function can help you to choose the right protocol. After choose protocol okay, then press “Connect”. If connected success.
  • Page 13 BMW Multi Tool User Manual iii. EEPROM Function: Read EEPROM，Write EEPROM，Save File，Load File… 1． You should backup the CAS EEPROM before prepare dealer key. After succeed read EEPROM, please save it as back file. This step is very important. 2． Now can’t read the whole EEPROM for cas3 system. But the main section is contained.
  • Page 14 BMW Multi Tool User Manual 3． After success read it, you will get: 4． Write EEPROM function is only support CAS1, CAS2 system. Doesn’t support write to CAS3 system. (Write EEPROM to CAS1/CAS2 system need CAS PLUG).
  • Page 15 BMW Multi Tool User Manual Odometer: Support read and change KM stored in CAS system. Don’t support to change KM in instrument. If you want to change the KM display in instrument. You should change KM in CAS system first. Then modify the KM in instrument manually.
  • Page 16 BMW Multi Tool User Manual...
  • Page 17 BMW Multi Tool User Manual...
  • Page 18 BMW Multi Tool User Manual Synchronization Codes: 1、 CAS3 code-DME 、CAS3code-EGS: Read and write DME and EGS code stored in CAS3 system. 2、 Synchronize DME and CAS— this function will be useful while prepare dealer key or any other operation which cause can’t start the engine.
  • Page 19 BMW Multi Tool User Manual Key Learn Function introduction: 1. Get Key Info: With this function you can get the key cutting, remote frequency, and key data. 2. Save Key Info: Save the read key info. 3. Load Key Info: Load the saved key info. To see the key data and prepare for write key info.
  • Page 20 BMW Multi Tool User Manual vii. File Make Key 1． Choose CAS or EWS type. It will tips you:...
  • Page 21 BMW Multi Tool User Manual 2． Load the choose EEPROM file you will get the make dealer key window:...
  • Page 22 BMW Multi Tool User Manual 3． Choose key position and press “Make Dealer Key” button. Flow the given tips to prepare dealer key. After succeed you can save the new EEPROM dump file. For EWS1, EWS2, EWS3, EWS4, CAS1, CAS2, CAS3 type the prepared dealer key can start the engine directly.
  • Page 23 BMW Multi Tool User Manual viii. Device Update Open this window after connect to internet. You can see the latest software version, firmware version, dongle version. You can go to our website for further information. After succeeded update device firmware, must reconnect the hardware to computer.
  • Page 24 BMW Multi Tool User Manual 2． Device Update: This function can update the dongle and device.
  • Page 25 BMW Multi Tool User Manual Process to prepare dealer key: 1. On main window choose “Connect” to auto detect the current car protocol and get the CAS info. 2. On main window choose “Read EEPROM” to read the CAS EEPROM file and save it.
  • Page 26 BMW Multi Tool User Manual Picture 1:...
  • Page 27 BMW Multi Tool User Manual Picture 2:...
  • Page 28 BMW Multi Tool User Manual Picture 3:...
  • Page 29 BMW Multi Tool User Manual Picture 4: Warning: Make sure connect dongle to compute before run the software.

  • Page 30: Troubleshooting

    BMW Multi Tool User Manual 5. Troubleshooting 5.1. “Device not connected”Error Information: Hardware not connected to PC with USB port. Solution: Plug device to USB.

  • Page 31: Warranty And Service

    BMW Multi Tool User Manual 6. Warranty and Service 6.1. Limited One Year Warranty We warrants to its customers that this product will be free from all defects in materials and workmanship for a period of one(1) year from the date of the original purchase, subject to the following terms and conditions: ...
