  • Page 1 PLANAR LCD MONITOR PV150 MANUAL www.planar.com...

  • Page 3: Preface

    About this manual This manual is designed to assist you in setting up and using your New Planar LCD Monitor. Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the con- tents.
  • Page 4 6. Safe storage of your New Planar LCD Monitor is in a range of minus 20 to plus 65 degrees Celsius (68°F- 149°F). Storing your New Planar LCD Monitor outside this range could result in permanent damage.

  • Page 5: Table Of Contents

    CHAPTER 1 ... 1 Your New Planar LCD Monitor! ...1 Unpacking ...1 Identifying Components ...1 Your New Planar LCD Monitor — Front View ... 2 Your New Planar LCD Monitor — Rear View... 2 Adjusting the Monitor’s Position ...3 Connecting AC Power...3 Connecting Video ...4...

  • Page 7: Chapter 1

    New Planar LCD Monitor and your computer do not become too hot. Set up your New Planar LCD Monitor so that the panel does not face a window where sunlight often comes in.

  • Page 8: Your New Planar Lcd Monitor - Front View

    Planar User’s Manual Your New Planar LCD Monitor — Front View Your New Planar LCD Monitor — Rear View Stereo Speakers (optional) The LCD monitor’s built-in stereo speakers are located in the bottom the monitor and face the direc- tion of the desktop.

  • Page 9: Adjusting The Monitor's Position

    6. Audio Line-in (optional) Connect your PC’s line-out to this jack to listen the PC’s audio on the LCD monitor’s stereo speakers. (You can also connect your CD-ROM’s line-out to this jack.) Adjusting the Monitor’s Position Your LCD monitor’s tilting angle can be adjusted in both the landscape and optional portrait mode. Adjusting the Tilting Angle The LCD monitor’s angle settings range from -5°...

  • Page 10: Connecting Video

    Planar User’s Manual Connecting Video Turn off your PC and the LCD monitor before connecting your LCD monitor to the computer. Loop the 1.5M VGA cable through the hole in the LCD monitor’s stand and plug it into the LCD moni- tor’...

  • Page 11: Connecting Usb Devices

    Connecting USB Devices The following section covers connecting USB devices. The LCD monitor supports an upstream and two downstream USB connections. Upstream You can connect the LCD monitor’s upstream USB port to your PC’s USB port and use the LCD monitor as a USB hub. The following explains how to connect the upstream USB port to your PC: 1.

  • Page 12: Chapter 2

    LCD Monitor Control Panel 1. OSD Menu Button Press this button to activate the OSD (On-Screen Display) menu. This button is also used as the ◄ Selection button. 2. Adjust Button This button allows you to apply settings and enter submenus in the OSD. This button also is used to increase the value of the selected menu item.
  • Page 13 The 7-topline menus are: The Auto Adjust option lets the monitor determine and select the settings that are most appropriate for your system requirements. This function will tune the display to your computers video card. The Monitor-Control option allows you to adjust the LCD monitor’s display characteristics such as the display’s horizontal or vertical position, display phase, display clock, and factory reset.
  • Page 14 Planar User’s Manual Pressing the Adjust key while the Monitor Control icon is selected activates the Monitor Control submenu. Use the ◄ ► FUNCTION select buttons to scroll between the submenu items. You should only use this menu item if the results of the Auto Adjust function are not satisfactory.
  • Page 15 Pressing the Adjust key while the Graphic Control icon is selected activates the Graphic Control submenu. Use the ◄ ► FUNCTION select buttons to scroll between the submenu items. Contrast: Press the Adjust play. The contrast level can range from 0 to 63. Brightness: Press the Adjust Sharpness: Press the...

  • Page 16: Planar Tft Lcd Monitor Specifications

    Planar TFT LCD Monitor Specifications Model LCD Panel Control Functions Power Main Menu On-Screen Display (OSD) Auto Adjust Monitor Control OSD Control Misc. Control Graphic Control Graph/Text OSD Exit Display Colors Response Time(ms) (Rise/Fall) Contrast Ratio Brightness Pixel Pitch (mm)

  • Page 17: Timing For Model Wt1503Z (Xga Resolution)

    Timing for Model WT1503Z (XGA Resolution) Item Standards Resolution NEC PC98 640x400 NEC PC98 640x400 MAC 13" mode 640x480 MAC 16" mode 832x624 MAC 17" mode 1024x768 640x350 640x400 640x480 VESA 640x480 VESA 640x480 VESA 800x600 SVGA 800x600 VESA 800x600 VESA 800x600 720x400...

  • Page 18: Troubleshooting Procedures

    If there is no display on the LCD, please perform the following steps: 1. Make sure that the power indicator on your New Planar LCD Monitor is lit, all connections are secure, and the system is running on the correct timing. Refer to the Appendix B for information on timing.
