JVC KD-R460J Service Manual

Hide thumbs

SERVICE MANUAL

2015

7 S ERVICE MANUAL

MA596<Rev.005>

KD-R460J, KD-R461DA9, KD-R461E, KD-R461EN, KD-R461EY,

KD-R461MA9, KD-R461U, KD-R461UT, KD-R462E, KD-R462EN,

KD-R462EY, KD-R463EU, KD-R464E, KD-R464EN, KD-R466U, KD-R467EE,

KD-R469E, KD-R469EY, KD-R469UR, KD-R660J, KD-R661E, KD-R661EN,

KD-R661EY, KD-R661MA9, KD-R661U, KD-R661UT, KD-SR41J, KD-SR61J

DC cord

(QAM1329-001)

(QAM1345-003)

(QAM1378-001)

Hook

Trim plate

(GE40685-001A) x2

(GE20363-00xA)

Carrying case

Remote control unit

(GE40521-001A)

(RM-RK52M)

CD RECEIVER

DC cord assy

(E3A-0181-00)

Escutcheon

(B0H-0021-00)

Screw (M5x8)

(QYSDSP5008ZA) x4

Lead free solder used in the board (material: Sn-Ag-Cu, melting point: 219 Centigrade)

Lead free solder used in the board (material: Sn-Cu, melting point: 230 Centigrade)

DETACHABLE PANEL

KD-R460J

KD-R461DA9

KD-R461E

DC cord assy

KD-R461EN

(E3A-0218-00)

KD-R461EY

KD-R461MA9

KD-R461U

KD-R461UT

KD-R462E

KD-R462EN

KD-R462EY

KD-R463EU

Mounting sleeve

KD-R464E

(GE20362-002A)

KD-R464EN

KD-R466U

KD-R467EE

KD-R469E

KD-R469EY

KD-R469UR

KD-R660J

KD-R661E

Screw (M5x10)

KD-R661EN

(QYSDSP5010ZA) x4

KD-R661EY

KD-R661MA9

KD-R661U

KD-R661UT

KD-SR41J

KD-SR61J

Model

Parts number

CP-R460JD

CP-R461ED

CP-R461UD

CP-R462ED

CP-R463EU

CP-R464ED

CP-R466UD

CP-R467EED

CP-R469ED

CP-R660JD

CP-R661ED

CP-R661UD

CP-SR41JD

CP-SR61JD

No.MA596<Rev.005>

2015/7

Table of Contents

Summary of Contents for JVC KD-R460J

Page 1 SERVICE MANUAL CD RECEIVER MA596<Rev.005> 2015 7 S ERVICE MANUAL KD-R460J, KD-R461DA9, KD-R461E, KD-R461EN, KD-R461EY, KD-R461MA9, KD-R461U, KD-R461UT, KD-R462E, KD-R462EN, KD-R462EY, KD-R463EU, KD-R464E, KD-R464EN, KD-R466U, KD-R467EE, KD-R469E, KD-R469EY, KD-R469UR, KD-R660J, KD-R661E, KD-R661EN, KD-R661EY, KD-R661MA9, KD-R661U, KD-R661UT, KD-SR41J, KD-SR61J DETACHABLE PANEL...
Page 2: Specification
SPECIFICATION For US TUNER Frequency Range 87.9 MHz to 107.9 MHz (200 kHz step) 87.5 MHz to 108.0 MHz (50 kHz step) Channel Space Selection 50 kHz/200 kHz 8.2 dBf (0.71 µV/75 Ω) Usable Sensitivity (S/N = 26 dB) 17.2 dBf (2.0 µV/75 Ω) Quieting Sensitivity(DIN S/N = 46 dB) Frequency Response (±3 dB) 30 Hz to 15 kHz...
Page 3 SPECIFICATION For Europe TUNER Frequency Range [Except KD-R467] 87.5 MHz to 108.0 MHz (50 kHz step) Frequency Range [KD-R467] FM: 87.5 MHz to 108.0 MHz (50 kHz step) FM-Lo: 65.0 MHz to 74.0 MHz (30 kHz step) 0.71 µV/75 Ω Usable Sensitivity (S/N = 26 dB) 2.0 µV/75 Ω...
Page 4 For ASIA TUNER Frequency Range 87.5 MHz to 108.0 MHz (50 kHz step) 8.2 dBf (0.71 µV/75 Ω) Usable Sensitivity (S/N = 26 dB) 17.2 dBf (2.0 µV/75 Ω) Quieting Sensitivity(DIN S/N = 46 dB) Frequency Response (±3 dB) 30 Hz to 15 kHz Signal-to-Noise Ratio (MONO) 64 dB Stereo Separation (1 kHz)
Page 5: Section 1 Precaution
SECTION 1 PRECAUTION Safety Precautions (1) This design of this product contains special hardware and Critical parts for safety many circuits and components specially for safety purpos- In regard with component parts appearing on the silk-screen es. For continued protection, no changes should be made printed side (parts side) of the PWB diagrams, the parts that are to the original design unless authorized in writing by the printed over with black such as the resistor (...
Page 6: Class 1 Laser Product
Handling the traverse unit (optical pickup) Attention when traverse unit is decomposed (1) Do not subject the traverse unit (optical pickup) to strong *Please refer to "Disassembly method" in the text for the shocks, as it is a sensitive, complex unit. pickup unit.
Page 7: Section 2 Specific Service Instructions
SECTION 2 SPECIFIC SERVICE INSTRUCTIONS How to repair a fuse pattern 2.1.1 Purpose of fuse pattern In order to prevent serious damage on the circuit, fuse pattern is prepared on the GND line of RCA Terminal. This damage may take due to improper part replacement with a external equipment via RCA line. 2.1.2 Repair Procedure (1) Check the shorted circuit at the meltdown point.
Page 8 MICROCOMPUTER’S TERMINAL DESCRIPTION IC701 (R5S726A0D216FP) on MAIN PWB ASSY Processing/Operation/ Pin No. Pin Name Application Description LCD_INH Display On/Off Control L: Display OFF/ H: Display ON DAB_COM_ON Enable DAB micon (For DAB model) H: ON/L: OFF No Use (for non DAB model) PVcc Power supply for I/O circuits NRST...
Page 9 STAGE1 Model Selecting Input 1 STEERING_REMO OE Remote In 1 (for DOP models) TEL_MUTE Tel Mute Detection Input (for JVC Model) LINE_MUTE Line Mute Detection Input (For KWD Model) No Use (for non support Tel mute model) DC_ERR1 Detect DC Offset Error from EVOL IC...
Page 10 Processing/Operation/ Pin No. Pin Name Application Description Debugging Interface. Serial Output for Instructions and Data Debugging Interface. Serial Input for Instructions and Data Debugging Interface. Test Mode Select Signal Input. Debugging Interface. Test Clock Input. No Use No Use PVcc Power supply for I/O circuits SPBCLK FLASH SPI Multi I/O Bus Clock output...
Page 11 Description CD_DSP_SW CD DSP Switch L: Other sources/ H: CD USB SD source DIM_IN Dimmer Control Input (for JVC Model) L: Dimmer Detect ON/ H: Dimmer Detect OFF No Use (For KWD Model) keep L output setting REG_FLG Power Detection...
Page 12: Section 3 Disassembly
SECTION 3 DISASSEMBLY Main body (5) Disconnect the FFC wire from connector CN1. (See Fig.4) 3.1.1 Removing the MAIN PWB (See Fig.1 to 5) (1) Disengage the 8 hooks a, and remove the FRONT CHAS- SIS ASSY. (See Fig.1) FRONT CHASSIS ASSY Fig.1 (2) Remove the 1 screw A and 2 screws B.
Page 13 3.1.2 Removing the CD MECHANISM (See Fig.6) CD mechanism (1) Remove the 3 screws D, and remove the CD • NOTICE FOR HANDRIG OF MECHANISM ASSY MECHANISM. (See Fig.6) Handle CHASSIS part. Do not stay MECHANISM ASSY in upside-down condition for 1 hour and more.
Page 14 • NOTICE FOR HANDRIG OF FEED MOTR ASSY 3.2.1 Removing the CD MECHA PWB (See Fig.1 to 3) (1) Solder the short land on the PICKUP. (See Fig.1) CAUTION: For mounting FEEDMOTOR ASSY, DON'T bump this part. Because handling may cause this part easily deformed. SOLDER FEED MOTOR WORM 1...
Page 15 3.2.2 Removing the TRAVERSE MECHANISM (See Fig.4, 5) 3.2.3 Removing the PICKUP ASSY (See Fig.6) (1) Remove the 4 springs from the TRAVERSE MECHANISM. (1) Remove the 1 screw C. (See Fig.4) (2) Remove the MAIN SHAFT in the direction of the arrow. (3) Remove the SPRING.
Page 16 3.2.5 Removing the CLAMP ARM ASSY (See Fig.8) (1) Remove the SPRING. (2) Remove the CLAMP ARM ASSY in the direction of the arrow. CLAMP ARM ASSY SPRING Fig.8 3.2.6 Removing the FEED MOTOR (See Fig.9, 10) (1) Remove the 5 screws D, and remove the FEED MOTOR ASSY.
Page 17: Section 4 Adjustment
SECTION 4 ADJUSTMENT Outline 4.1.1 Panel ACCENT SEARCH RETURN A symbol " " in the key column indicates that the key should be pressed and held for 1 second or longer. 4.1.2 Test Modes These test modes are available in normal production ROM. Transition to Test Mode shall be available during DC Error detection.
Page 18 Production Test Mode Press and hold [1] key and [3] key and reset. 4.2.1 Test Mode Defaults During Production Test Mode, the following settings defer from the Normal Mode. The settings will change immediately after mode activation. Difference in action Setting value Period to prohibit TEL/LINE MUTE function (Normal Mode: 10 secs) 1 second...
Page 19 4.2.6 Version Display Mode Item Operation Display content Details All Lights ON/ All lights ON TEST Syscom version ## = File Number display – @@@ = Syscon Version Number Stage Setting ##: Stage Setting for current hardware Serial No. Display (8 digits) Display to support ASCII characters Serial No.
Page 20 4.2.8 USB Test Mode Specification Applicable for iPod model only. Status Display content Details ## = Blank: Verifying NG: IC not mounted **: Non iPod support model Upon source change to USB source or USB device plug in: Verifying: Show "iPod: ##" NG: Always show "iPod: NG"...
Page 21 4.3.4 CD Error Information Display Mode (Not applicable for mechaless models) Item Operation Display content Details CD error Transit to CD error information display mode. ACCENT information (*2) display mode CD Mecha error Mecha error history 1,2,3 (latest) log display #:History No.
Page 22 Service Information Clear Mode Press and hold [2] key and [5] key and reset. 4.4.1 Default status immediately after the mode activation It shall be same as normal activation. 4.4.2 Mode content After entering this mode, Syscon shall clear the information stored for service and output the result to the display. CD will be ejected upon process end.
Page 23 DC Error Information Mode Press and hold [3] key and [6] key and reset. 4.5.1 Default status immediately after the mode activation It shall be same as normal activation. 4.5.2 Mode content Syscon shall display the following information after entering this mode. Display content Details When DC error is detected...
Page 24 User White Iveco DISP User Alfa Romeo Blue White Volkswagen User Chevrolet Green Peugeot Orange Nissan Isuzu Yellowish Green Skoda User (R=22, G=31, B=0) Yellow Amber Daihatsu DISP (Same as Suzuki) Return to default JVC normal setting. Default RETURN (No.MA596<Rev.005>)24/28...
Page 25 HC Mecha Running Mode Press and hold [SRC] key and [EJECT] key and reset. The software specification for evaluating HC Mecha is described. This mode is set for the general operation test and the endurance running test. 4.7.1 Mode Display Specification for Evaluation Display content Operation Display content...
Page 26 4.7.2 ERROR CODE for MODEL with FLM-HCI MECHA (Ver1.1) DISPLAY SIGN ERROR Item Condition Details In LOAD operating. Anomaly detection of SW state at LOADING. LI-E LOADING TIME OVER Or 5 sec TIME OVER from LOAD start. In EJECT operating. Anomaly detection of SW state at EJECT.
Page 27: Section 5 Troubleshooting
DC Offset error description 4.9.5 Manipulate after detect DC Offset • If detected error 10 consecutive times, and 10th error occurred 4.9.1 DC Offset detection circuit design in "Mis-connect detection period", judge as "Mis-connect". • Purpose: • If detected error 10 consecutive times, and 10th error occurred To prevent breakdown, when occur DC offset between speak- in "Capacitor leak detection period", judge as "Capacitor leak ".
Page 28 JVC KENWOOD Corporation Automotive Consumer Business Unit 2967-3, Ishikawa-machi, Hachioji-shi, Tokyo, 192-8525, Japan (No.MA596<Rev.005>) Printed in Japan...
Page 29: Schematic Diagrams
SCHEMATIC DIAGRAMS CD RECEIVER KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J (No.MA596<Rev.005>)1/30...
Page 30 ■ PRECAUTIONS ON SCHEMATIC DIAGRAMS Due to the improvement in performance, some part numbers shown in the circuit diagrams may not agree with those indicated in the Parts List. The parts numbers, values and rated voltage etc. in the Schematic Diagrams are for reference only.
Page 31: Switch Pwb
BLOCK DIAGRAM-1 (SIGNAL BLOCK) J471 CN901 J601 J321 DC P.CORD MAIN PWB IC301 POWER AMP SXM_RxD SXI_L Jack PWIC_MUTE FL OUT SXM_TxD SXI_R PWIC_STBY FL OUT/SWL SXM_PWR IC470 IC471 SXI_G FR OUT BEEP FR OUT/SWR Level Shiftor SW (Mono) REMOTE TU_L IC161 IC601...
Page 32 BLOCK DIAGRAM-2 (SUPPLY BLOCK) CN901 J471 J321 J601 MEM14.4V DC P.CORD IC301 POWER AMP VCC1 VCC2 (21) Jack IC161 E-VOLUME Q470 Q471 DIMMER TEL MUTE Mute Circuit (24) IC601 3.3V TU_3.3V (13) 0.45mA TUNER VDDD AU_9/12V 0.25mA VDDA_IFADC VDDA_RF VCC1 SW_3.3V CD_8V 1.3A...
Page 33 (RXM) IC831 BU4228F-W Model list KD-R460J, KD-R461U Series, KD-R466U Series, KD-R461E Series, KD-R462E Series, KD-R469E Series, KD-R463EU, KD-R467EE, KD-AR565J, KD-R561U Series, KD-R561E Series, KD-R561EU, KD-R567EE, KD-R660J, KD-R661U Series, Parts are safety assurance parts. KD-R661E Series, KD-R760J, KD-AR765SJ, KD-R761E Series, KD-R464E Series,...
Page 34 MAIN PWB ASSY-2 (XJ1-033x-xx) Except KD-R469UR MAIN PWB:J7J-0020-00 R542 C544 0.01u R541 1. VOLTAGES ARE DC-MEASURED WITH A DIGITAL VOLT METER WITHOUT INPUT SIGNAL 5.6k UNLESS OTHERWISE SPECIFIED. R544 ALL RESISTORS ARE 1/10W 5% METAL GLAZE RESISTOR. C545 ALL CAPACITORS ARE 50V OR 25V CERAMIC CAPACITOR. 0.01u ALL RESISTANCE VALUES ARE IN OHM.
Page 35 MAIN PWB ASSY-3 (XJ1-033x-xx) Except KD-R469UR DIFFERENT TABLE 0-10 0-11 0-12 0-13 0-14 2-71 2-72 2-73 2-74 2-75 0-21 0-22 0-23 3-81 3-82 reference PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber PartNumber IC411 MFI337S3959-X MFI337S3959-X MFI337S3959-X...
Page 36 MAIN PWB ASSY-1 (XJ1-0463-20) KD-R469UR ?J470 TL56 (SXI.L) J321 J600 TL472 TL476 TL57 QNN0874-001 QNB0356-001 (SXI.R) IC301 TL475 JCV8034 TL480 TL50 TL51 ?RA470 (TU.R) (TU.L) ?C472 ?R1011 TU.R ?C1004 TU.L ?R253 ?D601 ?D602 ?C1003 1. VOLTAGES ARE DC-MEASURED WITH A DIGITAL VOLT METER TL625 TL260 GND3...
Page 37 MAIN PWB ASSY-2 (XJ1-0463-20) KD-R469UR MAIN PWB:J7J-0020-00 R542 C544 0.01u R541 5.6k R544 C545 0.01u R543 5.6k R546 C546 6800p R548 C547 6800p ?C543 CN502 QGF1040F1-24 ?C542 C550 0.15u CD3.3 C541 C548 0.1u 4.7u C540 C549 0.1u ?C582 M_SRDATA_CD 0.1u To CD MECHA PWB ASSY 20 19 18 17 16 15 14 13 12 11 10 (LVA20106-01A):...
Page 38 4.3k EASY EQ 4/RNDM 5/RPT BACK/SEARCH S11A FOLDER DOWN 3/ FOLDER UP TL10 MODEL LIST: KD-X120U SERIES IPOD/USB/PHONE KD-R660J KD-X120EU KD-R460J KD-R661U SERIES KD-R461U SERIES KD-X120EE DISP/SETUP FORWARD BACKWARD KD-R661E SERIES TL11 KD-R466U SERIES KD-X125EE KD-SR61J KD-X220J KD-R461E SERIES KD-R462E SERIES...
Page 39 SWITCH PWB ASSY-2 (XJ6-024x-xx) Except KD-R469UR DIFFERENCE TABLE FOR PWB #J7J-0113-00 XJ6-0240-10 XJ6-0242-71 XJ6-0242-72 XJ6-0242-73 XJ6-0242-74 XJ6-0240-21 XJ6-0240-30 USB Yamb REMO reference USB RED REMO USB RED WO REMO USB BLUE WO REMO USB GREEN REMO USB G/R WO REMO USB White REMO IC90 SIR8630B6T...
Page 40 SWITCH PWB ASSY (XJ6-0363-20) KD-R469UR SWITCH PWB: J7J-0113-** J7J-0033-** IC90 QNS0279-001 SIR8630B6T R1006 T9K-0007-00 1000p 1000p ?D11 ?D10 ?Q91 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 QGZ2006K1-20X ?C90 *ED1...
Page 41 CD MECHA PWB ASSY (LVA20106-01A): FC2-2A00NXN To MAIN PWB ASSY-2 To MAIN PWB ASSY-2 (XJ1-033x-xx) Except KD-R469UR (XJ1-0463-20) KD-R469UR CN502 CN502 The differences between X92-6820-01 and FC2-2A00NXN, 1/4W 1/4W please refer to SECTION 2 "How to identify the CD mechanism ASSY". OPEN QGF1044F2-24X 0.1u...
Page 42 CD MECHA PWB ASSY (X32-6680-00): X92-6820-01 To MAIN PWB ASSY-2 To MAIN PWB ASSY-2 (XJ1-033x-xx) Except KD-R469UR (XJ1-0463-20) KD-R469UR CN502 CN502 The differences between X92-6820-01 and FC2-2A00NXN, please refer to SECTION 2 "How to identify the CD mechanism ASSY". QGF1044F2-24X OPEN 1/4W 1/4W...
Page 43 MAIN PWB ASSY XJ1-033x-xx (J7J-0020-00) Except KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) Q272 R270 D271 Q250 R1042 Q340...
Page 44 MAIN PWB ASSY XJ1-033x-xx (J7J-0020-00) Except KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) How to repair a fuse pattern. Refer to "2.1 How to repair a fuse pattern".
Page 45 MAIN PWB ASSY XJ1-0463-20 (J7J-0020-00) KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) Q272 R270 D271 Q250 R1042 Q340 Q330...
Page 46 MAIN PWB ASSY XJ1-0463-20 (J7J-0020-00) KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) How to repair a fuse pattern. Refer to "2.1 How to repair a fuse pattern".
Page 47 SWITCH PWB ASSY-1 XJ6-024x-xx (J7J-0113-00) Except KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) IC90 S11A R1010 No.MA596 created date:2015-04-22 (No.MA596<Rev.005>)19/30...
Page 48 SWITCH PWB ASSY-1 XJ6-024x-xx (J7J-0113-00) Except KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) J7J-0113-00 MARK XJ6-024 IC90 XJ6-036 R1009...
Page 49 SWITCH PWB ASSY-2 XJ6-024x-xx (J7J-0113-00) Except KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) No.MA596 created date:2015-04-22 (No.MA596<Rev.005>)21/30...
Page 50 SWITCH PWB ASSY-2 XJ6-024x-xx (J7J-0113-00) Except KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) J7J-0113-00 MARK XJ6-036 XJ6-024 No.MA596 created date:2015-04-22...
Page 51 SWITCH PWB ASSY-1 XJ6-0363-20 (J7J-0113-00) KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) IC90 S11A R1010 No.MA596 created date:2015-04-22 (No.MA596<Rev.005>)23/30...
Page 52 SWITCH PWB ASSY-1 XJ6-0363-20 (J7J-0113-00) KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) J7J-0113-00 MARK XJ6-024 IC90 XJ6-036 R1009 FL80...
Page 53 SWITCH PWB ASSY-2 XJ6-0363-20 (J7J-0113-00) KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) No.MA596 created date:2015-04-22 (No.MA596<Rev.005>)25/30...
Page 54 SWITCH PWB ASSY-2 XJ6-0363-20 (J7J-0113-00) KD-R469UR (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) J7J-0113-00 MARK XJ6-036 XJ6-024 No.MA596 created date:2015-04-22 (No.MA596<Rev.005>)26/30...
Page 55 CD MECHA PWB ASSY LVA20106-01A (LVB20106-001B) FC2-2A00NXN (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) The differences between X92-6820-01 and FC2-2A00NXN, please refer to SECTION 2 "How to identify the CD mechanism ASSY".
Page 56 CD MECHA PWB ASSY LVA20106-01A (LVB20106-001B) FC2-2A00NXN (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) The differences between X92-6820-01 and FC2-2A00NXN, please refer to SECTION 2 "How to identify the CD mechanism ASSY".
Page 57 CD MECHA PWB ASSY X32-6680-00 (J76-0898-12) X92-6820-01 (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) The differences between X92-6820-01 and FC2-2A00NXN, please refer to SECTION 2 "How to identify the CD mechanism ASSY".
Page 58 CD MECHA PWB ASSY X32-6680-00 (J76-0898-12) X92-6820-01 (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) The differences between X92-6820-01 and FC2-2A00NXN, please refer to SECTION 2 "How to identify the CD mechanism ASSY".
Page 59: Parts List
PARTS LIST CD RECEIVER KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J (No.MA596<Rev.005>)1/35...
Page 60 ■ PRECAUTIONS ON SCHEMATIC DIAGRAMS Due to the improvement in performance, some part numbers shown in the circuit diagrams may not agree with those indicated in the Parts List. The parts numbers, values and rated voltage etc. in the Schematic Diagrams are for reference only.
Page 61: Exploded View (Unit)
EXPLODED VIEW (UNIT) Block No.M1MM F901 (MAIN) DME1 (SWITCH) LCD1 Parts with the exploded numbers larger than 700 are not supplied. No.MA596 created date:2015-07-21 (No.MA596<Rev.005>)3/35...
Page 62 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 63 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 64 EXPLODED VIEW (CD MECHANISM: FC2-2A00NXN) Block No.MBMM The differences between X92-6820-01 and FC2-2A00NXN, please refer to SECTION 2 "How to identify the CD mechanism ASSY". Grease JVS-1003 W01-2067-08 FPC1 DPU1 Back view Back view Parts with the exploded numbers larger than 800 are not supplied. No.MA596 created date:2015-04-22 (No.MA596<Rev.005>)6/35...
Page 65 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 66 EXPLODED VIEW (CD MECHANISM: X92-6820-01) Block No.MCMM The differences between X92-6820-01 and FC2-2A00NXN, please refer to SECTION 2 "How to identify the CD mechanism ASSY". Grease JVS-1003 W01-2067-08 FPC1 DPU1 Back view Back view Parts with the exploded numbers larger than 800 are not supplied. No.MA596 created date:2015-04-22 (No.MA596<Rev.005>)8/35...
Page 67 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 68 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 69 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 70 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 71 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 72 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 73 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 74 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 75 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 76 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 77 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 78 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 79 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 80 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 81 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 82 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 83 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 84 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 85 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 86 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 87 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 88 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 89 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 90 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 91 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 92 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
Page 93 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-R460J KD-R461DA9 KD-R461E KD-R461EN KD-R461EY KD-R461MA9 KD-R461U KD-R461UT KD-R462E KD-R462EN KD-R462EY KD-R463EU KD-R464E KD-R464EN KD-R466U KD-R467EE KD-R469E KD-R469EY KD-R469UR KD-R660J KD-R661E KD-R661EN KD-R661EY KD-R661MA9 KD-R661U KD-R661UT KD-SR41J KD-SR61J Safe Symbol No. Parts No.
