Transmitter Setup

Transmitter group and channel must be manually set to match the receiver.
Group (letter)
1. Press and release the group button on the transmitter to activate the display. Press the group button again and the
display flashes.
2. While the display is flashing, press the group button again to advance to the desired group setting.
Channel (number)
If channel needs to be changed, follow the same procedure using the channel button instead of the group button.
Note: When the group and channel correctly match the receiver, the ready LED on receiver illuminates.

Multiple System Setup

Up to 12 systems can operate simultaneously (band and RF environment dependent).
Important: Set up each system one-at-a-time. Once a receiver and transmitter is tuned to the same group and channel,
leave the transmitter powered on. Otherwise, scans from the other receivers will not detect that channel as occupied. For
the BLX88, be sure to setup both transmitters before progressing to the next receiver.
Turn on any other equipment that could cause interference during the performance so it will be detected during the group
and channel scans in the following steps.
Before you begin system set up, turn all receivers ON and all transmitters OFF.
For the first receiver:
1. Perform a group scan.
This finds the group with the most clear channels.
Note: For the BLX88, the group scan sets up both receivers at the same time.
2. Turn on the first transmitter and change the group and channel to match receiver.
3. Leave the transmitter on and continue with the additional systems.
For each additional receiver:
1. Use manual setup to change the receiver to match the group setting of the first receiver. Recall that each time the
group setting is changed, a channel scan is automatically done.
2. Turn on the transmitter and change the group and channel to match the receiver.
3. Leave the transmitter on and continue to the next system.
4. Once all receivers are set up, perform an audio check on all microphones.

Locking and Unlocking Controls

Lock system controls to prevent accidental setting changes or power off.
Transmitter
Turn the transmitter on. Hold the group button, then
press the channel button for approximately 2 seconds.
The LED indicator rapidly flashes amber when locked and
green when unlocked.
4
Receiver
Turn the receiver on. Simultaneously press the group
and channel button to lock or unlock. The display flashes
rapidly.
When locked, the LED display flashes rapidly if any key
is pressed.
The BLX88 can be locked from either side for both sides.
