P A R T N A M E S
MICROWAVE OVEN PARTS
1 One touch door open button
Push to open door.
2 Oven door with see-through window
3 Safety door latches
The oven will not operate unless the
door is securely closed.
4 Door hinges
5 Door seals and sealing surfaces
6 Turntable motor shaft
7 Removable turntable support
Carefully place the turntable support in
the center of the oven floor.
DISPLAY
OM1
5 9
6
4
3 2 11 3
Words in the lower portion of the display will light to include
what function is in process.
9
10
13
12
1
8 Removable turntable
Place the turntable on the turntable
support securely. The turntable will
rotate clockwise or counterclockwise.
Only remove for cleaning.
9 Ventilation openings (Rear)
1 0 Oven light
It will light when oven is operating or
door is open.
1 1 Waveguide cover: DO NOT REMOVE.
1 2 Auto-Touch control panel
1 3 Time display: 99 minutes, 99 seconds
