PA R T N A M E S
MICROWAVE OVEN PARTS
5
4
3 2
1 Door open button
Push to open door.
2 Oven door with see-through window
3 Safety door latches
The oven will not operate unless the
door is securely closed.
4 Door hinges
5 Door seals and sealing surfaces
6 Turntable motor shaft
7 Removable turntable support
Carefully place the turntable support in
the center of the oven floor.
DISPLAY
ON
9
6
DEF. LBS. QTY. CHECK
10
13
12
1
11
8 Removable turntable
Place the turntable securely on the
turntable support. The turntable will
rotate clockwise or counterclockwise.
Only remove for cleaning.
9 Ventilation openings (Rear)
10 Oven light
It will light when oven is operating.
11 Waveguide cover: DO NOT REMOVE.
12 Auto-Touch control panel
13 Time display: 99 minutes, 99 seconds
7
8
7
Time display
Indicators
