Summary of Contents for Clevo P375SM

  • Page 1 P375SM/P375SMF...
  • Page 3 Preface Notebook Computer P375SM/P375SMF Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the P375SM/ P375SMF series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: System Startup

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    External Locator - Front & Right side Views .........1-5 Bottom ................... A-4 External Locator - Left Side & Rear View ........1-6 LCD (P375SM) ................A-5 External Locator - Bottom View .............1-7 LCD (P375SMF) ................A-6 Mainboard Overview - Top (Key Parts) .........1-8 Mainboard ..................
  • Page 12 Preface PCH 2/9 - PCIE, SMBUS, CLK ..........B-20 Front LED Board ................B-52 PCH 3/9 - DMI, FDI, PWRGRD ..........B-21 Top LED Board ................B-53 PCH 4/9 - LVDS, DDI, CRT ............B-22 Fingerprint Board ................B-54 PCH 5/9 - PCI, USB, RSVD ............B-23 TPM ....................B-55 PCH 6/9 - GPIO, CPU ..............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the P375SM/P375SMF series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about drivers (e.g. VGA & audio) is also found in User’s Manual. That manual is shipped with the computer.

  • Page 14: System Specifications

    Introduction System Specifications Storage Interface Processor Options Up to Two (Factory Option) Changeable 2.5" Four USB 3.0 Ports (Including one AC/DC Pow- Intel® Core™ i7 Processor (6cm) 9.5mm (h) SATA (Serial) Hard Disk ered USB port) i7-4930MX (3.00GHz) Drives/Solid State Drives (SSD) supporting RAID One eSATA Port (USB 2.0 Port Combined) 8MB L3 Cache, 22nm, DDR3L-1600MHz, TDP level 0/1...
  • Page 15 Introduction Communication Built-In Giga Base-TX Ethernet LAN Dual Camera Module (5.0M Pixels / 1.0M HD) WLAN/ Bluetooth Half Mini-Card Modules: (Factory Option) Intel® Centrino® Ultimate-N 6300 Wireless LAN (802.11a/g/n) (Factory Option) Intel® Centrino® Advanced-N 6235 Wireless LAN (802.11a/g/n) + Bluetooth (Factory Option) Intel®...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-In 1.0M HD PC Camera 2. PC Camera LED 3. Built-In Array Microphone 4. LCD 5. Volume Bar LED 6. Speakers 7. Power Button LED 8.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. LED Power Indicators Figure 3 Right Side Views 1. Optical Device Drive Bay 2. Emergency Eject Hole 3. Combined eSATA/ USB 2.0 Port 4. Powered USB 3.0 Port 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. RJ-45 LAN Jack 3. Multi-In-1 Card Reader 4. Line-In Jack 5. S/PDIF-Out Jack 6. Microphone-In Jack 7. Headphone-Out Jack 8. Rear LED Figure 5 Rear View 1.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Fan Outlet/Intake 2. Component Bay Cover 3. Sub Woofer 4. Battery 5. HDD Bay  Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. CMOS Battery 2. LynxPoint Controller 3. ITE8587 4. Memory Slots DDR3 So-DIMM 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. VGA Sockets 2. CPU Socket 3. Memory Slots DDR3 So-DIMM 4. Mini-Card Connector (SSD Module) 5. Mini-Card Connector (WLAN/3G Module) Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. Fingerprint Cable Connector 2. Power Cable Connector 3. LCD Cable Connector 4. Keyboard Indicator LED Connector 5. 3D Emitter Cable Connector 6. Keyboard Cable Connector 7. CMOS Battery Connector 8.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. 3* USB 3.0 Port 2. Powered USB 3.0 Port 3. eSATA/USB 2.0 Port 4. HDMI-Out Port 5. Thunderbolt Port 6. DC-In Jack 7. CPU Fan Connector 8. Battery Connector 9.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the P375SM/P375SMF series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Wireless LAN Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal If you are confident in undertaking upgrade procedures yourself, for safety reasons it is best to remove the battery. Slide the latch and 1. Turn the computer off, remove the AC/DC adapter and turn it over. hold it in place.

  • Page 30: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 2 Optical Device 1. Turn off the computer, and turn it over and remove the battery (page 2 - Removal 2. Locate the hard disk bay cover and remove screws , and remove the bay cover 3.

  • Page 31: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 3 The hard disk drive is mounted in a removable case and can be taken out to accommodate other 2.5" SATA hard disk HDD Assembly drives with a height of 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary driv- Removal ers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 32 Disassembly 5. Remove screws from the hard disk assembly. Figure 4 6. Grip the tab and slide the hard disk assembly in the direction of the arrow (Figure 4e). HDD Assembly 7. Carefully lift the hard disk assembly out of the computer (Figure 4f).
  • Page 33 Disassembly Removing the Hard Disk(s) in the Secondary HDD Bay Figure 5 1. Turn off the computer, and turn it over and remove the battery and any HDD in the upper slot. Secondary HDD 2. The secondary hard disk bay is located under the first hard disk. Assembly Removal 3.
  • Page 34 Disassembly Hard Disk Size Note (Foam Rubber Insert) Note that the hard disks pictured on the following pages are all 9.5mm(H) hard disk drives. In some cases 7mm(H) hard disk drives will be installed. For more information contact your distributor/supplier, and bear in mind your warranty terms.

  • Page 35: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 7 Keyboard 1. Turn off the computer, and turn it over and remove the battery (page 2 - Removal 2. Turn the computer over, open the Lid/LCD, and carefully unsnap up the center cover module from point (between F11 &...
  • Page 36 Disassembly 9. Remove the keyboard , and screws from the keyboard shielding plate. Figure 8 Keyboard Removal  (cont’d.) Re-Inserting the Keyboard e. Disconnect cable from the locking collar. When re-inserting the keyboard f. Remove the keyboard. firstly align the five keyboard g.

  • Page 37: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 9 The computer has three memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) DDR III RAM-1 Module (DDR3) supporting 1600 MHz. The main memory can be expanded up to 32GB. The total memory size is automatically Removal detected by the POST routine once you turn on your computer.
  • Page 38 Disassembly 5. Gently pull the two release latches & on the sides of the memory socket in the direction indicated by Figure 10 the arrows (Figure 10d). RAM-1 Module 6. The RAM module will pop-up, and you can then remove it. Removal (cont’d.) 7.
  • Page 39 Disassembly Secondary System Memory Upgrade Process Figure 11 1. Turn off the computer, and turn it over to remove the battery (page 2 - 5), and keyboard (page 2 - 11). RAM-2 Module 2. The RAM module will be visible at point on the mainboard (Figure 11a).

  • Page 40: Removing And Installing The Processor

    Disassembly Removing and Installing the Processor Figure 12 Processor Removal Processor Removal Procedure 1. Turn off the computer, and turn it over to remove the battery (page 2 - 5), and component bay cover (page 2 - 13). a. Locate the heat sink. 2.
  • Page 41 Disassembly 7. Turn the release latch (towards the unlock symbol , to release the CPU (Figure 13e). 8. Carefully (it may be hot) lift the CPU up out of the socket (Figure 13e). Figure 13 9. See page 2 - 18 for information on inserting a new CPU.
  • Page 42 Disassembly Processor Installation Procedure Figure 14 Processor 1. Insert the CPU , pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE IT!). Installation 2. Turn the release latch towards the lock symbol as indicated. 3.

  • Page 43: Removing The Vga-1 Card

    Disassembly Removing the VGA-1 Card Figure 15 VGA-1 Card 1. Turn off the computer, and turn it over to remove the battery (page 2 - 5) and component bay cover (page 2 - Removal 2. The VGA-1 card will be visible at point on the mainboard (Figure 15a).
  • Page 44 Disassembly 6. Remove screws & from the VGA-1 assembly. Figure 16 7. If your system includes two video cards you will need to disconnect the cable between the master and slave VGA-1 Card cards (do not forget to reconnect the cable if you are replacing two cards). Removal (cont’d) 8.

  • Page 45: Removing The Vga-2 Card

    Disassembly Removing the VGA-2 Card Figure 17 VGA-2 Card 1. Turn off the computer, and turn it over to remove the battery (page 2 - 5), component bay cover (page 2 - 13) and Removal (page 2 - 16). 2. The VGA-2 card will be visible at point on the mainboard (Figure 17a).
  • Page 46 Disassembly 5. Remove screws & from the VGA-1 assembly. Figure 18 6. Disconnect the VGA cable between the master and slave cards (do not forget to reconnect the cable if you are VGA-2 Card replacing two cards). Removal (cont’d) 7. Carefully lift the VGA-2 card off the mainboard.

  • Page 47: Installing The Vga-1 Card

    Disassembly Installing the VGA-1 Card Figure 19 1. Do not forget to replace the master and slave cable if you are replacing two video cards. VGA-1 Card 2. Prepare to fit the VGA card into the slot by holding it at about a 30° angle. Installation 3.
  • Page 48 Disassembly 8. Remove the sticker from the heat sink (Figure 20c). Figure 20 9. Hold the VGA heatsink-2 by the tab and insert it back on the card (page 2 - 21). VGA-1 Card 10. Remove the sticker from the heat sink (Figure 20d).

  • Page 49: Installing The Vga-2 Card

    Disassembly Installing the VGA-2 Card Figure 21 1. Connect the master and slave cable to the two VGA cards before preparing to fit the VGA-2 card into the slot VGA-2 Card by holding it at about a 30° angle. Installation 2.
  • Page 50 Disassembly 7. Remove the sticker from the heat sink (Figure 22c). Figure 22 8. Hold the VGA heatsink by the tab and insert it back on the card and VGA-2 Card 9. secure screws in the order indicated in (Figure 22d).

  • Page 51: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 23 Wireless LAN 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5), keyboard and keyboard shielding plate Module Removal (page 2 - 11). 2. Remove the screw and carefully disconnect cables a.

  • Page 52: Removing The Speaker Module

    Disassembly Removing the Speaker Module Figure 24 Speaker Module 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5), optical device (page 2 - 6), hardisk (page Removal 7), keyboard (page 2 - 11), RAM (page 2 - 13), CPU (page 2 -...

  • Page 53: Removing The Volume Board Module

    Disassembly Removing the Volume Board Module Figure 25 Volume Board 1. Turn off the computer, and turn it over, remove the battery (page 2 - 5), optical device (page 2 - 6), hardisk (page Module Removal 7), keyboard (page 2 - 11), RAM (page 2 - 13), CPU...
  • Page 54 Disassembly 2 - 30 Removing the Volume Board Module...

  • Page 55: Part Lists

    Part Lists Appendix A: Part Lists This appendix breaks down the P375SM/P375SMF series notebook’s construction into a series of illustrations. The com- ponent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 56: Part List Illustration Location

    The following table indicates where to find the appropriate part list illustration. Table A- 1 Part List Illustration Location Parts page A - 3 Bottom page A - 4 LCD (P375SM) page A - 5 LCD (P375SMF) page A - 6 Mainboard page A - 7 page A - 8 COMBO...

  • Page 57: Top

    Part Lists Figure A - 1 Top A - 3...

  • Page 58: Bottom

    Part Lists Bottom Figure A - 2 Bottom ONLY FOR 單卡用 A - 4 Bottom...

  • Page 59: Lcd (P375Sm

    Part Lists LCD (P375SM) Figure A - 3 LCD (P375SM) LCD (P375SM) A - 5...

  • Page 60: Lcd (P375Smf

    Part Lists LCD (P375SMF) Figure A - 4 LCD (P375SMF) A - 6 LCD (P375SMF)

  • Page 61: Mainboard

    Part Lists Mainboard Figure A - 5 Mainboard ONLY FOR 雙卡用 Mainboard A - 7...

  • Page 62: Dvd

    Part Lists Figure A - 6 A - 8 DVD...

  • Page 63: Combo

    Part Lists COMBO Figure A - 7 COMBO COMBO A - 9...
  • Page 64 Part Lists A - 10...

  • Page 65: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the P375SM/P375SMF notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...
  • Page 66 Schematic Diagrams System Block Diagram P370EM Chief River System Block Diagram VDD3,VDD5 AUDIO BOARD 6-71-P37E8-D03 PHONE JACK x4, RJ45 5V,3.3V,5VS,3VS,1.5VS PWR Switch BOARD 6-71-P37ES-D03 1.05VS 1067/1333/1600 MHz MXM-III VGA FRONT LED BOARD DDR3 / 1.5V Master Ivy Bridge 6-71-P37E4-D02 1.5V,VTT_MEM PCIEx16 TOP LED BOARD PCIEx8...
  • Page 67 Schematic Diagrams Processor 1/7 - DMI, FDI, PEG Ivy Bridge Processor 1/7 ( DMI,PEG,FDI ) 1.05VS_VTT U26A 20 mil PEG_IRCOMP_R R130 24.9_1%_04 PEG_ICOMPI PEG_ICOMPO DMI_TXN0 DMI_RX#[0] PEG_RCOMPO PEG_RXN[0..7] 13 DMI_TXN1 DMI_RX#[1] DMI_TXN2 DMI_RX#[2] C360 0.22u_10V_X5R_04 PEG_RXN0 DMI_TXN3 DMI_RX#[3] PEG_RX#[0] PEG_RXN1 C370 0.22u_10V_X5R_04 PEG_RX#[1]...
  • Page 68 Schematic Diagrams Processor 2/7 - CLK, MISC Ivy Bridge Processor 2/7 ( CLK,MISC,JTAG ) PU/PD for JTAG signals 1.05VS_VTT XDP_TMS R395 51_04 XDP_TDI_R R396 51_04 U26B XDP_PREQ# R397 *51_04 XDP_TDO_R R394 51_04 XDP_TCLK R400 51_04 XDP_TRST# R389 51_04 CLK_EXP_P 19 BCLK PROC_SELET H_SNB_IVB#...
  • Page 69 Schematic Diagrams Processor 3/7 - DDR3 Ivy Bridge Processor 3/7 ( DDR3 ) U26C U26D 9,10 M_A_DQ[63:0] M_A_CLK_DDR0 9 11,12 M_B_DQ[63:0] M_B_CLK_DDR0 12 SA_CK[0] SB_CK[0] M_A_CLK_DDR#0 9 M_B_CLK_DDR#0 12 SA_CLK#[0] SB_CLK#[0] M_A_DQ0 M_B_DQ0 SA_DQ[0] SA_CKE[0] M_A_CKE0 9 SB_DQ[0] SB_CKE[0] M_B_CKE0 12 M_A_DQ1 M_B_DQ1 SA_DQ[1]...

  • Page 70: Processor 4/7 - Power

    Schematic Diagrams Processor 4/7 - POWER Ivy Bridge Processor 4/7 ( POWER ) POWER U26F PROCESSOR CORE POWER PROCESSOR UNCORE POWER VCORE 8.5A 1.05VS_VTT 1.05VS_VTT AG35 VCC1 AG34 AH13 ICCMAX Maximum Processor VCC2 VCCIO1 AG33 AH10 VCC3 VCCIO2 AG32 AG10 C406 C408 C141...

  • Page 71: Processor 5/7 - Gfx Pwr

    Schematic Diagrams Processor 5/7 - GFX PWR Ivy Bridge Processor 5/7 ( GRAPHICS POWER ) 1.5VS_CPU ¨Ï¥Î1% ¹qªý,1/11 R413 100_1%_04 POWER AO3402L U26G 11/29 V_SM_VREF V_SM_VREF_CNT AT24 AK35 C421 R412 VAXG1 VAXG_SENSE AT23 AK34 VAXG2 VSSAXG_SENSE R401 AT21 0.1u_10V_X5R_04 100_1%_04 VAXG3 AT20 AT18...

  • Page 72: Processor 6/7 - Gnd

    Schematic Diagrams Processor 6/7 - GND Ivy Bridge Processor 6/7 ( GND ) U26H U26I AT35 AJ22 VSS1 VSS81 AT32 AJ19 VSS2 VSS82 AT29 AJ16 VSS3 VSS83 VSS161 VSS234 AT27 AJ13 AT25 VSS4 VSS84 AJ10 VSS162 VSS235 AT22 VSS5 VSS85 VSS163 VSS236 VSS6...

  • Page 73: Processor 7/7 - Rsvd

    Schematic Diagrams Processor 7/7 - RSVD Ivy Bridge Processor 7/7 ( RESERVED ) U26E CFG Straps for Processor AH27 VCC_DIE_SENSE AK28 AH26 CFG0 CFG[0] VSS_DIE_SENSE AK29 PEG Static Lane Reversal - CFG2 is for the 16x CFG[1] AL26 CFG2 CFG[2] AL27 CFG[3] AK26...

  • Page 74: Ddr3 Cha So-Dimm 0

    Schematic Diagrams DDR3 CHA SO-DIMM 0 Channel A SO-DIMM 0 CHANGE TO STANDARD JDIMM4A 4,10 M_A_A[15:0] M_A_DQ[63:0] 4,10 M_A_A0 M_A_DQ0 JDIMM4B D Q0 M_A_A1 M_A_DQ1 D Q1 M_A_A2 M_A_DQ2 D Q2 M_A_A3 M_A_DQ3 1.5V D Q3 M_A_A4 M_A_DQ4 D Q4 M_A_A5 M_A_DQ5 D Q5...

  • Page 75: Ddr3 Cha So-Dimm 1

    Schematic Diagrams DDR3 CHA SO-DIMM 1 Channel A SO-DIMM 1 CHANGE TO STANDARD JD IMM2A M_A_A[15:0] M_A_DQ[63:0] 4,9 M_A_A0 M_A_DQ0 JDIMM2B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 M_A_A3 M_A_DQ3 1.5V M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 VD D1 VSS16 M_A_A6 M_A_DQ6 VD D2 VSS17 M_A_A7 M_A_DQ7 VD D3...

  • Page 76: Ddr3 Chb So-Dimm 0

    Schematic Diagrams DDR3 CHB SO-DIMM 0 Channel B SO-DIMM 0 CHANGE TO STANDARD JDIMM1A 4,12 M_B_B[15:0] M_B_DQ[63:0] 4,12 M_B_B0 M_B_DQ0 JDIMM1B M_B_B1 M_B_DQ1 M_B_B2 M_B_DQ2 M_B_B3 M_B_DQ3 1.5V M_B_B4 M_B_DQ4 M_B_B5 M_B_DQ5 VDD1 VSS16 M_B_B6 M_B_DQ6 VDD2 VSS17 M_B_B7 M_B_DQ7 VDD3 VSS18 M_B_B8...

  • Page 77: Ddr3 Chb So-Dimm 1

    Schematic Diagrams DDR3 CHB SO-DIMM 1 Channel B SO-DIMM 1 CHANGE TO STANDARD JDIMM3A 4,11 M_B_B[15:0] M_B_DQ[63:0] 4,11 M_B_B0 M_B_D Q0 JDIMM3B M_B_B1 M_B_D Q1 M_B_B2 M_B_D Q2 M_B_B3 M_B_D Q3 1.5V M_B_B4 M_B_D Q4 M_B_B5 M_B_D Q5 VDD1 VSS16 M_B_B6 M_B_D Q6 VDD2...

  • Page 78: B - 14 Mxm 3.0 Master

    Schematic Diagrams MXM 3.0 MASTER PWR_SRC PWR_SRC 5VRUN OPEN-3mm MXM 3.0 J_MXM1A J_MXM1B E1-1 E2-1 CLK_PCIE_MXM# MXM1_CLKREQ# 19 E1-2 PWR_SRC PWR_SRC E2-2 PEX_REFCLK# CLK_REQ# 3.3VS 3VRUN MXM1_RST# CLK_PCIE_MXM PWR_SRC PWR_SRC PEX_REFCLK PEX_RST# E1-3 E2-3 OPEN-2mm PWR_SRC PWR_SRC VGA_DDC_DAT E1-4 E2-4 12/1 PWR_SRC(10A)--7-20V E1-5...

  • Page 79: Mxm 3.0 Slave

    Schematic Diagrams MXM 3.0 SLAVE PWR_SRC2 PWR_SRC2 PJ24 5VRUN2 OPEN-3mm MXM 3.0 J_MXM2A J_MXM2B E1-1 E2-1 CLK_PCIE_MXM2# MXM2_CLKREQ# 19 E1-2 PWR_SRC PWR_SRC E2-2 PEX_REFCLK# CLK_REQ# 3.3VS PJ17 3VRUN2 MXM2_RST# PWR_SRC PWR_SRC CLK_PCIE_MXM2 PEX_REFCLK PEX_RST# E1-3 E2-3 OPEN-2mm PWR_SRC PWR_SRC VGA_DDC_DAT E1-4 E2-4 PWR_SRC(10A)--7-20V...

  • Page 80: Panel, Inverter, Edp

    Schematic Diagrams Panel, Inverter, eDP 3.3VS VGA_BKLPWM PANEL BRIGHTN ESS ADD R25 R 46 J_LCD1 2/29 Stanley 2.2K_04 2.2K_04 LVDS_UC LKN LVDS_UC LKP LVD S_U CLKN LVDS_UCLKP 13 LVDS_U1N LVDS_U2N PLVD D 3.3VS LVDS_U1N LVDS_U2N 13 LVDS_U1P LVDS_U2P D 19 R 378 0_04 LVD S_D DC _DAT...

  • Page 81: Display Port

    Schematic Diagrams Display Port DISPLAY PORT PLEASE CLOSE TO CONNECTOR Follow nVidia Recommend 12/22 0_04 Close to Display PORT LPS for «D¨¾¤õ§÷ 0_04 3/8 Stanley DP_A#3 C 13 0.1u_10V_X7R _04 D_D P_A#3 C 12 0.1u_10V_X7R _04 D_D P_A3 DP_A3 *D VI2012F2SF -900T05_08 For Safety LPS.

  • Page 82: Hdmi

    Schematic Diagrams HDMI HDMI CONNECTOR(W/LevelShift,CO-LAY) 5VS_HDMI For ESD 5VS_HDMI RB551V-30S2 J_HDMI1 R348 1_04 1.5K_04 1.5K_04 C332 C331 *BAV99 *BAV99 *BAV99 HDMI_HPD-C HDMI_SCL-C HOT PLUG DETECT HDMI_SDA-C DDC/CEC GND HDMI_SDA-C HDMI_SCL-C HDMI_HPD-C RESERVED R340 *499_1%_04 TMDS_CLOCK# TMDS CLOCK- CLK SHIELD TMDS_CLOCK R344 *499_1%_04 TMDS CLOCK+...

  • Page 83: Pch 1/9 - Rtc, Hda, Sata

    Schematic Diagrams PCH 1/9 - RTC, HDA, SATA INTVRMEN- Integrated SUS PantherPoint - M (HDA,JTAG,SPI,SATA) 1.05V VRM Enable RTCVCC High - Enable Internal VRs Low - Enable External VRs 20mils C215 D03 modify NO REBOOT STRAP R176 change to 1.5M, C261,C244 change to 10p VDD3 20mils 10p_50V_NPO_04...

  • Page 84: Pch 2/9 - Pcie, Smbus, Clk

    Schematic Diagrams PCH 2/9 - PCIE, SMBUS, CLK R N3 3.3V 2.2K_8P4R_04 SML0_DATA PantherPoint - H (PCI-E,SMBUS,CLK) SML0_CLK SMB_DATA SMB_CLK R N7 U15B 10K_8P4R_04 U SB_OC#1112 USB_OC #1112 BG34 1394_PCIECLKRQ5# PERN 1 BJ34 PCH _BT_EN# U SB_OC #78 PCH_BT_EN# 22,29 USB_OC#78 AV32 PERP1...

  • Page 85: Pch 3/9 - Dmi, Fdi, Pwrgrd

    Schematic Diagrams PCH 3/9 - DMI, FDI, PWRGRD PantherPoint - H (DMI,FDI,GPIO) 3.3VS U15C BC24 BJ14 PM_CLKRUN# R266 8.2K_04 DMI_RXN0 DMI0RXN FDI_RXN0 BE20 AY 14 DMI_RXN1 BG18 DMI1RXN FDI_RXN1 BE14 DMI_RXN2 BG20 DMI2RXN FDI_RXN2 BH13 Follow Checklist DMI_RXN3 DMI3RXN FDI_RXN3 BC12 3.3V FDI_RXN4...

  • Page 86: Pch 4/9 - Lvds, Ddi, Crt

    Schematic Diagrams PCH 4/9 - LVDS, DDI, CRT PantherPoint - H (LVDS,DDI) U15D AP43 L_BKLTEN SDVO_TVCLKINN AP45 L_VDD _EN SDVO_TVCLKINP AM42 L_BKLTCTL SDVO_STALLN AM40 SDVO_STALLP L_DDC_CLK AP39 L_DDC_DATA SD VO_INTN AP40 SDVO_IN TP L_CTRL_CLK L_CTRL_DATA AF37 LVD_IBG SDVO_CTRLC LK AF36 LVD_VBG SDVO_CTRLDATA AE48...

  • Page 87: Pch 5/9 - Pci, Usb, Rsvd

    Schematic Diagrams PCH 5/9 - PCI, USB, RSVD PantherPoint - H (PCI,USB,NVRAM) Boot BIOS Strap BBS_BIT1 BBS_BIT0 Boot BIOS Location U15E AY 7 RSVD1 RSVD2 Reserved (NAND) BG26 RSVD3 BJ26 BH25 RSVD4 BJ16 AT10 RSVD5 BG16 RSVD6 AH38 AH37 RSVD7 BBS_BIT1 AK43 R462...

  • Page 88: Pch 6/9 - Gpio, Cpu

    Schematic Diagrams PCH 6/9 - GPIO, CPU PantherPoint - H (GPIO,VSS_NCTF,RSVD) EDID_SELECT# R247 10K_04 3.3V U15F EDP_CARD_DET# SATA_ODD_PWRGT BMBUSY # / GPIO0 TACH4 / GPIO68 SMI# GPIO69 1.5K_1%_04 R169 D03 modify SMI# TACH1 / GPIO1 TACH5 / GPIO69 add C597 R563 10K_1%_04 EDP_CARD_DET#...

  • Page 89: Pch 7/9 - Power

    Schematic Diagrams PCH 7/9 - Power PantherPoint - H (POWER) D03 modify 3.3VS R151 *15mil_short_06 POWER U15G 1.05VS +V1.05S_PCH_VCC VCCA_DAC_3.3VS HCB1608KF-121T25 AA23 VCCCORE[1] VCCADAC AC23 VCCCORE[2] AD21 C477 C498 C522 C463 C186 C185 C178 C177 C174 R153 C169 VCCCORE[3] AD23 AF21 VCCCORE[4] VSSADAC...

  • Page 90: Pch 8/9 - Power

    Schematic Diagrams PCH 8/9 - Power PantherPoint - H (POWER) *HCB1005KF-121T20 +VCCACLK 1.05VS 3.3V 1.05VS POWER U15J C513 AD49 VCCACLK VCCIO[29] 0.1u_10V_X5R_04 C480 VCCIO[30] 1u_6.3V_X5R_04 VCCDSW3_3 VCCIO[31] 3.3V C534 *0.1u_10V_X5R_04 PCH_VCCDSW 142.6mA DCPSUSBYP VCCIO[32] 3.3VS R459 *10mil_short VCCIO[33] C502 C526 VCC3_3[5] C446 C450...

  • Page 91: Pch 9/9 - Gnd

    Schematic Diagrams PCH 9/9 - GND PantherPoint - H (GND) U15I U15H AY 4 VSS[159] VSS[259] VSS[0] AY 42 VSS[160] VSS[260] AY 46 AA17 AK38 VSS[161] VSS[261] VSS[1] VSS[80] AY 8 VSS[162] VSS[262] VSS[2] VSS[81] AK42 VSS[163] VSS[263] VSS[3] VSS[82] AA33 AK46 VSS[164]...

  • Page 92: Usb+Esata, Usb Charging

    Schematic Diagrams USB+eSATA, USB Charging TPS2540 USB Charging PORT U31 change to MSOP-8 Stanley 5/21 USBVCC2.0 100 mil R506 *0_04 USB_OC#910 FLG# VOUT1 C541 C540 C556 VIN1 VOUT2 VDD5_USBCHG (DD_ON) (VDD5) (VDD5) VIN2 VOUT3 R497 0_04 0.1u_16V_Y5V_04 *0.1u_16V_Y 5V_04 *10u_10V_Y 5V_08 60 mil 60 mil 36,38,40...

  • Page 93: Gen-Iii Sata Hdd Re-Driver

    Schematic Diagrams GEN-III SATA HDD Re-driver Layout Cancel co-lay 0 ohm 3/5 Stanley 3.3VS SN75LVCP412RTJ SN75LVCP601RTJ Redriver. De-Emphasis dB(at 6GPbps) R678 0_04 R648 Note: -4 (default) 4.7K_04 Closed TO U2 SN75LVC P601RTJ SATATXP0 SATA_TXP0 C667 0.01u_16V_X7R _04 SATATXP0 RX_0P TX_0P SATATXN0 SATA_TXN0 C666...

  • Page 94: Bt, Ccd+Mic, Mini Pcie

    Schematic Diagrams BT, CCD+MIC, MINI PCIE (USB Port 5) Bluetooth Port 11 3.3V Change BT CON(8pin),12/16 50mil J_BT1 3.3V C529 10u_6.3V_X5R_08 R527 USB_PN11 10K_04 USB_PP11 BT_DET# CHANGE 6P CONN (pitch=0.8) 5/22 Stanley BT_EN# 5V_CCD From EC default HI 48 mil 85205-08001 VOUT 33,34...

  • Page 95: Fan Control

    Schematic Diagrams Fan Control CPU FAN CONTROL CPU_FAN VGA FAN CONTROL-Selector FON1# VOUT DEL R417,R418,R419 C190 C189 VSET ADD TEST ,12/20 0.1u_16V_Y5V_04 AX995SA 4.7u_6.3V_X5R_06 3.3VS CPU_FAN 33 6-03-53158-0J0 5VS_CPU_FAN J_FAN1 C451 0.1u_16V_Y5V_04 C175 10u_10V_Y5V_08 85205-03701 VGA_FAN2SEN R488 0_04 Z1812 VGA_FAN2SEN VGA_FAN1SEN R477 0_04...

  • Page 96: Codec Realtek Alc892

    Schematic Diagrams Codec Realtek ALC892 3.3V Layout Note: U43 pin 1 ~ pin 11 and pin 47 and pin 48 C330 0.1u_16V_Y5V_04 are Digital signals. R285 DEL R637(AGND to GND) C323 0.1u_16V_Y5V_04 *100K_04 HCB1005KF-121T20 Stanley 5/23 The others are Analog signals. C685 0.1u_16V_Y5V_04 3.3VS...

  • Page 97: Apa2607 / Tpa2008D2

    Schematic Diagrams APA2607 / TPA2008D2 AMP_5VS STEREO AMP HCB1608KF -121T25 C 657 C672 C280 TPA2008D2 0.1u_16V_Y 5V_04 0.1u_16V_Y 5V_04 22u_6.3V_X5R_08 3.3VS AUDG AUDG AUDG Front Speaker R / L AMP_EN ROUTP FCM1005KF -121T03 ROUT+ SHUTDOWN ROUTP J_STERO1 R606 C652 C 656 2.2u_6.3V_X5R_06 40 Mil AUDG...

  • Page 98: Kbc-Iteit8518E

    Schematic Diagrams KBC-ITEIT8518E KBC_AVDD HCB1005KF-121T20 VDD3 VDD3 VDD3 C209 C191 C213 C197 ¤W±µÄ² ¤U±µÄ² C537 C536 C543 0.1u_16V_Y5V_04 10u_10V_Y5V_08 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 R165 J_KB1 J_KB2,3 C193 100K_04 P370EM HCB1005KF-121T20 0.1u_16V_Y5V_04 KBC_AGND J_KB1=>J_P151KB1 EC_VCC KBC_WRESET# 3.3VS J_KB2=>J_P15KB1 Backlight K/B only,12/1 0_04 for M760T/TU J_KB3=>J_P17KB1 Backlight KB...

  • Page 99: Msata, Fan, Tp, Fp, Multi Con

    Schematic Diagrams mSATA, Fan, TP, FP, MULTI CON SCREW HOLD update screw,3/18 FOR CLICK PAD 3.3VS Stanley Reserve 10uf for improve click pad VDD rising Stanley 5/28 H8_0D2_8 H8_0D2_8 H8_0D2_8 H8_0D2_8 H8_0D2_8 H8_0D2_8 H8_0D2_8 *10u_6.3V_X5R_08 H6_0D3_6 H6_0D3_6 H6_0D3_6 H6_0D3_6 H6_0D3_6 12/21 R261 R262...

  • Page 100: Backlight Keyboard

    Schematic Diagrams Backlight Keyboard P/N 6-06-05822-061 Stanley 3/14 2.2uH,3A 4.35*4.8*2.0 DEFAULT PJ15 SHORT P/N:6-19-41001-011 U4 change to G5110RE1U KB_LEDPWR_IN KB_LEDPWR_SW KB_LED_PWR BCIHP0420TB-2R2M PJ15 OPEN_2A DEL R420 FM5822 Stanley 5/8 KB_LEDPWR_IN KB_LEDPWR_FREQ FREQ KB_LED_PWR_FB R434 *10mil_short R419 KB_LEDPWR_EN 200K_1%_06 SHDN R417 10_04 C436 R418...

  • Page 101: Usb3.0

    Schematic Diagrams USB3.0 USB3.0 PORT2 C152 22u_6.3V_X5R_08 U7,U9,U24 change to MSOP-8 Stanley 5/21 DEL BRAD C151 22u_6.3V_X5R_08 USBVCC3.0_2 3/5 Stanley USBVCC3.0_2 C426 *220u_6.3V_6.3*6.3*4.2 100 MIL R147 *0_04 J_USB3_2 19,22 USB_OC#12 FLG# VOUT1 C156 C157 CLOSE TO CONNECTOR VIN1 VOUT2 VIN2 VOUT3 C149 0.1u_10V_X7R_04...

  • Page 102: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR 74 *0_04 PR73 0_04 PC76 1u_10V_Y 5V_06 PR71 PR77 EN_3V EN_5V PC78 100K_04 100K_04 PC80 1000p_50V_X7R_04 1000p_50V_X7R_04 PU 4 VREG3 PC138 PC141 VDD3 PC 79 PR 78 *10K_04 5.14V 4.7u_25V_X5R _08 4.7u_25V_X5R _08 SY S5V VDD5 LDO3 1u_6.3V_X5R _06...

  • Page 103: 5Vs, 3.3Vs, 1.5Vs

    Schematic Diagrams 5VS, 3.3VS, 1.5VS VIN1 R243 *100K_04 DD_ON 3.3VS R242 100K_04 VIN1 DD_ON_LATCH 33 R246 *100K_04 DD_ON_LATCH USB_CHARGE_EN 27,33,37 R241 1K_1%_04 R517 10K_04 D03 modify C221 VDD3 M_BTN# M_BTN# PWR_SW# R461 100K_NC -> 10K R240 *100K_04 R516 1K_1%_04 bug 61.2 PWR_SW# 33 INSTANT-ON USB_CHARGE_EN...

  • Page 104: Power 1.05Vs

    Schematic Diagrams Power 1.05VS PR 163 1.05V_ON 100K_1%_04 PC152 SUSB *0.1u_16V_Y 5V_04 3,38,40,41 SUSB PQ55 MTN7002ZHS3 PR 165 820K_1%_06 PC150 PC149 PC151 PC146 Sheet 39 of 54 PQ53 PR161 PC147 ME4894-G 0_06 0.1u_10V_X7R_04 1.05V_ON Power 1.05VS EN_PSV 21.5A PJ19 1.05VS BC IH1030HC-R56M PR 166 VOU T...

  • Page 105: Power 1.5V / Vtt_Mem

    Schematic Diagrams Power 1.5V / VTT_MEM D03 modify value bug 28 PC119 PC118 PC41 PC40 VDDQ PQ38 uP6163 NTMFS4926N RB0540S2 PC44 VTT_MEM 10u_10V_Y 5V_08 1.5V PC46 0.1u_10V_X5R_04 VLDOIN VBST VDDQ PJ10 PR135 VTT_MEM DRVH 3.3_06 *OPEN_2A 1.0UH_10*10* 4.5 PJ14 PC121 PC120 PC45 VTTGND...

  • Page 106: Power 1V, 1.8Vs

    Schematic Diagrams Power 1V, 1.8VS 1.8VS -n²¾¾aªñPIN6¸} V1.8 1.8VS 3.3V PJ13 PC67 1u_10V_Y5V_06 *OPEN_2A PR62 10K_04 3.3V VCNTL 1.8VS_PWRGD R146 *10mil_short 3,20 1.8VS_PWRGD VOUT PR59 10K_04 VOUT EN1.8VS PC64 PC65 PC69 PC62 PR61 1.27K_1%_04 PQ10 *1u_6.3V_Y5V_04 PR54 1M_04 2N7002_D PC66 82p_50V_NPO_04 AX6610 / GS7113 3,38,39,40...

  • Page 107: Power V-Core1

    Schematic Diagrams Power V-Core1 VCORE_1 Vcore GND/GND,12/21 PR122 *10mil_04 VGND disable AUX 1.05VS_VTT CORRECT netname CSP1A 2/29 Stanley CSP2A PR123 2_06 PC111 PWMA PR10 1.05VS_VTT VDDBP BSTA 75_04 54.9_1%_04 2.2u_6.3V_X5R_04 VRDYA 130_1%_04 VR_ON PR11 PC11 NCP6132A 0_04 H_CPU_SVIDDAT 2_06 0.22u_10V_X5R_04 SDIO H_CPU_SVIDDAT H_CPU_SVIDALRT#...

  • Page 108: Power V-Core2

    Schematic Diagrams Power V-Core2 VCORE_2 §ïDIP 12/29 PC15 PC12 PC31 PC13 PC10 PQ30 PQ37 PQ27 PQ34 NTMFS4926N NTMFS4926N NTMFS4926N NTMFS4926N Sheet 43 of 54 PL3,PL4,PL5 §ó§ïfootprint EM I BCIHP1040-m 3/19 Power V-Core2 EM I co-lay ¤W¥óPL18,12/6 EM I co-lay ¤W¥óPL19,12/6 PR129 0_06 HG1_R...

  • Page 109: Power 0.85Vs

    Schematic Diagrams Power 0.85VS PC87 PR162 0.022u_16V_X7R_04 10K_04 0.9V (Set0) 0.8V (Set2) 0.725V (Set1) 0.675V (Set3) 0.85VS_PWRGD 20 VCCSA_VID0 VCCSA_VID1 PR90 0_04 PR86 9.31K_1%_04 PR88 9.31K_1%_04 PD14 RB0540S2 Sheet 44 of 54 PR85 12K_1%_04 PR87 10K_1%_04 PR89 VCCSA_SENSE 6 100_04 Power 0.85VS PR91 10K_1%_04...

  • Page 110: Audio Board

    Schematic Diagrams Audio Board ¤½®y AJ_AUDIO1 ALINE_SENSE AMIC1-R AJD_SENSEA AJ_LINE1 AMIC1-L ALINE-R AHP_MUTE ALINE-L AL10 close to Codec AJD_SENSEB ALINE-R FCM1005KF-121T03 AHEADPHONE-R ASIDE_R 10K_1%_04 ALINE_SENSE AHEADPHONE-L ASIDE_L AJD_SENSEA AMIC_SENSE ALINE-L 20K_1%_04 FCM1005KF-121T03 ASPDIFO 39.2K_1%_04 AHP_SENSE AGND A_3.3VS AJD_SENSEB 5.1K_1%_04 ASIDE_SENSE 2SJ-T351-018 HP_PLUG A_VGA_FAN2...

  • Page 111: Lan (Rtl8411

    Schematic Diagrams LAN (RTL8411) Switching Regulator close to PIN48 LAN (RTL8411) 0_06 (>20mil) AVDD10 AVDD3 PULL HIGH: SWR Mode Crystal 5032 Co-lay RSET AR31 2.49K_1%_04 REGOUT AVDD10 ENSWREG *0_04 AGND (>20mil) meet realtek Freq tolerance 50ppm «ÝEMI½T»{§¹,§ïSHORT *SWF2520CF-4R7M-M XTAL2 From PCH LAN_25MHz AR15 0_04 meet realtek Freq tolerance 50ppm...

  • Page 112: Power Charger, Dc In

    Schematic Diagrams Power Charger, DC IN Z4606 Charge Current : 2.8A Charge Voltage 16.8V V_BAT Total Power : 200W PQ60 P2003EVG PR100 0_04 PQ31 ME4425 PQ61 P2003EVG PR29 PR99 HCB4532K-800_18 0.01_1%_32 470K_04 6-20-B3H20-103 Z4602 EMI request ¾aªñJBATTA1 D01B 02/21 PQ62A Stanley 5/28 PR19 PD1503Y VS...

  • Page 113: Odd Board

    Schematic Diagrams ODD Board O_5VS ¤½®y OJ_SATA_ODD1 OSATA_TXP2 OSATA_TXN2 OSATA_RXN2 OSATA_RXP2 OSATA_ODD_PRSNT# OSATA_ODD_DA# OJ_ODD1 OSATA_TXP2 0.01u_16V_X7R_04 C1952 OSATA_TXN2 0.01u_16V_X7R_04 OSATA_RXN2 0.01u_16V_X7R_04 OGND OGND OSATA_RXP2 0.01u_16V_X7R_04 Sheet 48 of 54 ODD Board OGND OSATA_ODD_PRSNT# O_5VS O_5VS OSATA_ODD_DA# Change conn 12/21 GND1 GND2 FP->AT13035BAA089 0.1u_16V_Y5V_04...

  • Page 114: Hdd Board

    Schematic Diagrams HDD Board HJ_HDD1 H_5VS ¤½®y HJ_SATA_HDD1 0.01u_16V_X7R_04 HSATA_TXP0 HSATA_TXN0 HSATA_TXP0 0.01u_16V_X7R_04 HSATA_TXN0 0.01u_16V_X7R_04 HSATA_RXN0 0.01u_16V_X7R_04 HSATA_RXP0 HSATA_RXN0 HSATA_RXP0 HSATA_TXP1_R H_3.3VS HSATA_TXN1_R H_3.3VS HSATA_RXN1_R HSATA_RXP1_R HC14 HC11 *10u_10V_08 C1952 *0.01u_16V_04 H_5VS HGND HGND HGND HGND HC21 HC23 HC24 HC22 HC25 HC15 HC16...

  • Page 115: Power Board

    Schematic Diagrams Power Board POWER SWITCH B'D POWER BUTTON L1_SW1 L1_M_BTN# §ï¥Î´À¥N®ÆP/N:6-53-3050B-242 SFNQRMP2125T 5/25 POWER L1_3.3VS SWITCH L1_GND LJ_PWR1 L1_3.3VS 20mil Sheet 50 of 54 L1R2 L1_LID_SW# Power Board 130_1%_04 L1_M_BTN# LID SWITCH IC 20mil L1_VDD3 20mil L1C3 85201-06051 L1_VDD3 *0.1u_16V_04 12/26 Follow common Design MH248 L1R1...

  • Page 116: Front Led Board

    Schematic Diagrams Front LED Board LLED_BAT_CHG LLED_BAT_FULL Change conn(85205) 12/20 LLED_ACIN LLED_PWR L2R2 L2R1 L2R4 L2R3 180_04 180_04 180_04 180_04 L2_3.3VS LJ_LED2 L2D4 L2D3 LBT_EN RY -SP155HY Y G4-1 LWLAN_LED# RY -SP155HY Y G4-1 LLED_BAT_FULL LLED_BAT_CHG LLED_PWR Sheet 51 of 54 LLED_ACIN Front LED Board L2_GND...

  • Page 117: Top Led Board

    Schematic Diagrams Top LED Board Change to 6P 3/7 Stanley L3_3.3VS LJ_LED3 L3H1 L3H2 H7_0D2_3 H7_0D2_3 L3_SATA_LED# L3_LED_NUM# L3_LED_CAP# L3_LED_SCROLL# 85201-06051 Sheet 52 of 54 L3_GND L3_GND Top LED Board L3_3.3VS L3_GND L3_3.3VS L3_3.3VS L3_3.3VS HDD/CD-ROM L3R1 L3R5 L3R4 L3R3 L3R2 220_04 220_04...

  • Page 118: Fingerprint Board

    Schematic Diagrams Fingerprint Board FGND FPU1 FJ_FP1 FREG_OUT F3.3V F3.3V DVDD1 REG_OUT FUSB_PN FUSB_PP FAVDD DVDD2 AVDD 85201-04051 FPD_REG FBDRIVE1 PD_REG BDRIVE1 FGND FBDRIVE2 FC11 BDRIVE2 33p_50V_NPO_04 ADD FP CONN,12/19 FUSB_PN FBEZEL1 USB_DN BEZEL1B FUSB_PP FBEZEL2 USB_DP BEZEL2B FTESD_GND Sheet 53 of 54 20mil FMCS BEZEL1A...

  • Page 119: Tpm

    Schematic Diagrams 3.3VS TPM 1.2 C172 C171 C204 C206 18,33 LPC_AD0 LAD0 VDD1 0.1u_16V_Y 5V_04 0.1u_16V_Y 5V_04 0.1u_16V_Y 5V_04 1u_6.3V_X5R_04 18,33 LPC_AD1 LAD1 VDD2 18,33 LPC_AD2 LAD2 VDD3 18,33 LPC_AD3 LAD3 VDD3 1uf¦@¥ÎX5R_04 PCLK_TPM LCLK Stanley 5/25 18,33 LPC_FRAME# LFRAME# 3,13,14,22 PLT_RST# LRESET#...

  • Page 120: Power On Sequence

    Schematic Diagrams Power On Sequence P370EM_D01 POWER on SEQUENCE DD_ON DD_ON_LATCH 370uS VDD5 102mS RSMRST# PWR_BTN# 101mS 57mS SUSC# 103mS 36uS SUSB# 1.2mS 140uS 1.5V 127uS DDR1.5V_PWRGD Sheet 55 of 54 968uS VTT_MEM 205mS Power On SUSB 230uS 614uS Sequence 504uS 1.03mS 3.3VS...

  • Page 121: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...
  • Page 122 BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.

This manual is also suitable for:

P375smf

Table of Contents
