SERVICE MANUAL
XV-S56BK / XV-S57SL
Contents
Safety precautions ------------------------ 1-2
Preventing static electricity ------------- 1-3
Precautions for service ------------------ 1-4
Important for laser products ------------ 1-5
DVD VIDEO PLAYER
Each difference point
Model
XV-S56BK
XV-S57SL
Disassembly method -------------------- 1-6
Adjustment method ---------------------- 1-15
Troubleshooting -------------------------- 1-18
Description of major ICs ---------------- 1-22
This service manual is printed on 100% recycled paper.
COPYRIGHT
2001 VICTOR COMPANY OF JAPAN, LTD.
Body color
Black
Silver
XV-S56BK/XV-S57SL
Area Suffix (XV-S56BK)
E ----- Continental europe
EN ------ Northern europe
Area Suffix (XV-S57SL)
B --------------------------- U.K.
E ----- Continental europe
EN ------ Northern europe
No.A0019
Oct. 2001

Advertisement

loading

Related Manuals for JVC XV-S56BK

Summary of Contents for JVC XV-S56BK

  • Page 1 XV-S56BK/XV-S57SL SERVICE MANUAL DVD VIDEO PLAYER XV-S56BK / XV-S57SL Area Suffix (XV-S56BK) E ----- Continental europe EN ------ Northern europe Area Suffix (XV-S57SL) B --------------------------- U.K. E ----- Continental europe EN ------ Northern europe Each difference point Model Body color...
  • Page 2 XV-S56BK/XV-S57SL 1. This design of this product contains special hardware and many circuits and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services should be performed by qualified personnel only.
  • Page 3 XV-S56BK/XV-S57SL Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1. Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
  • Page 4 XV-S56BK/XV-S57SL Precautions for Service Handling of Traverse Unit and Laser Pickup 1. Do not touch any peripheral element of the pickup or the actuator. 2. The traverse unit and the pickup are precision devices and therefore must not be subjected to strong shock.
  • Page 5 XV-S56BK/XV-S57SL Important for Laser Products 5.CAUTION : If safety switches malfunction, the laser is able 1.CLASS 1 LASER PRODUCT to function. 2.DANGER : Invisible laser radiation when open and inter 6.CAUTION : Use of controls, adjustments or performance of lock failed or defeated. Avoid direct exposure to beam.

  • Page 6: Disassembly Method

    XV-S56BK/XV-S57SL Disassembly method <Main body> Removing the top cover (see Fig.1) 1.Remove the two screws A attaching the top cover on both sides of the body. 2.Remove the three screws B attaching the top cover on the back of the body.
  • Page 7 XV-S56BK/XV-S57SL Removing the servo control board (see Fig.4) * Prior to performing the following procedure, remove the top cover and mechanism assembly. 1.Disconnect the card wire from connector CN201 and CN202 on the servo control board respectively. 2.Disconnect the flexible wire from connector CN101...
  • Page 8 XV-S56BK/XV-S57SL <Loading assembly section> Removing the clamper assembly Joint a Joint a (See Fig.1) Remove the four screws A attaching the clamper assembly. Move the clamper in the direction of the arrow to release the two joints a on both sides.
  • Page 9 XV-S56BK/XV-S57SL Removing the traverse mechanism assembly (See Fig.4 and 5) Prior to performing the following procedure, remove the clamper assembly and the tray. Traverse mechanism Remove the four screws B attaching the traverse assembly mechanism assembly. ATTENTION: Before reattaching the traverse...
  • Page 10 XV-S56BK/XV-S57SL Removing the motor assembly (See Fig.8 and 9) Belt Prior to performing the following procedure, remove the clamper assembly, the tray, the traverse mechanism assembly and the elevator. Remove the belt from the pulley. Remove the screw C attaching the motor assembly.
  • Page 11 XV-S56BK/XV-S57SL Pulley gear Idle gear Pulley gear bracket Pulley gear Idle gear Pulley gear bracket Tads h Pulley gear Motor assembly Fig.10 Slide cam Removing the Idle gear / pulley gear / middle gear / slide cam (See Fig.10 to 12)
  • Page 12 XV-S56BK/XV-S57SL <Traverse mechanism assembly section> Feed motor assembly Removing the feed motor assembly (See Fig.13) Unsolder the two soldering j on the spindle motor board. Remove the two screws F attaching the feed motor assembly. Pickup Notch k Soldering j...
  • Page 13 XV-S56BK/XV-S57SL Removing the pickup (See Fig.16 and 17) Pickup Joint n Remove the screw I attaching the T spring (S) and Shaft holder the shaft holder. Remove also the plate. ATTENTION: When reattaching, make sure that the T spring (S) presses the shaft.
  • Page 14 XV-S56BK/XV-S57SL Spindle motor Removing the spindle motor assembly (See Fig.19 to 21) Remove the three screws L attaching the spindle motor on the bottom of the mechanism base. ATTENTION: When reattaching, pass the card wire extending from the spindle motor board through the notch of the spindle base.
  • Page 15 XV-S56BK/XV-S57SL Adjustment method (1) Initialization method If microprocessor (IC401,IC402,IC403) or pick-up is replaces, initialize the DVD player in the following matter 1)Take out the disc and close the tray. 2)Unplug the power plug. 3)Insert power plug into outlet while pressing both PLAY button and OPEN/CLOSE button.
  • Page 16 XV-S56BK/XV-S57SL For Jitter value The jitter value is displayed on the FL display referring to the previous page. The jitter value is displayed by the hexadecimal number and refer to the conversion table of following,please. If the indication value is 11% or less, it can be judged by this simple checking method that the signal read precision of the set is satisfactory.
  • Page 17 XV-S56BK/XV-S57SL (3) Flap adjustment of the pick-up guide shaft Assistance board <Tool list for adjustment> (Connect to main board) Stud (four pieces set) Parts No. : JIGXVS40 XV-S40 MAIN CONNECT Extension cord set (two cord and two board) Parts No. : EXTXVS40CB...

  • Page 18: Troubleshooting

    XV-S56BK/XV-S57SL Troubleshooting Servo volume Press OPEN /CLOSE key Is tray Confirmation of tray drive circuit operation and circuit in surrounding correct? Is the traverse moving See "(3) Traverse movement error" along the innermost in "Check points for individual errors" perimeter for SW detection? "NO DISC"...
  • Page 19 XV-S56BK/XV-S57SL Check points for each error (1) Spindle start error 1.Defective spindle motor *Are there several ohms resistance between each pin of CN201 "5-6","6-7","5-7"? (The power supply is turned off and measured.) *Is the sign wave of about 100mVp-p in the voltage had from each terminal? [ CN201"9"(H1-),"10"(H1+),"11"(H2-),"12"(H2+),"13"(H3-),"14"(H3+) ]...
  • Page 20 XV-S56BK/XV-S57SL (3) Traverse movement NG 1.Defective traverse driver *Has the voltage come between terminal of CN101 "1" and "2" ? 2.Defective BTL driver (IC271) *Has the motor drive voltage gone out to IC271"17" or "18"? 3.Has the control signal come from servo IC or the microcomputer? *Is it "H"...
  • Page 21 XV-S56BK/XV-S57SL (9) Neither picture nor sound is output 1.It is not possible to search *Has the tracking been turned on? *To "(5) Tracking ON NG" in "Check points for each error" when the tracking is not normal. *Is the feed operation normal? To "(3) traverse movement NG"...

  • Page 22: Description Of Major Ics

    XV-S56BK/XV-S57SL Description of major ICs AN8702FH(IC101):Frontend processor 1.Pin layout RFINN RFINP PC01 TESTSG PC02 AGCO TGBAL AGCG TBAL PEAK FBAL BOTTOM AN8702FH POFLT RFENV DTRD IDGT OFTR STANDBY DCRF VCC3 STDI RFOUT RSEL RFDIFO JLINE GND3 2.Pin function Symbol Description...
  • Page 23 XV-S56BK/XV-S57SL BA5983FM-X (IC271) : 4CH DRIVER 1.Block diagram STAND BY Level Shift Level Shift Level Shift Level Shift STAND BY CH1/2/3 2.Pin function Function Symbol Symbol Function Pin No. Pin No. Input for Bias-amplifier VO4(+) Non inverted output of CH4...
  • Page 24 XV-S56BK/XV-S57SL BA6664FM-X(IC251):Spindle motor driver 1.Pin layout 2.Pin function Symbol Description Pin No. Non connect Output 3 for spindle motor Non connect Output 2 for spindle motor Non connect Non connect Output 1 for spindle motor Connect to ground Positive input for hall input AMP 1...
  • Page 25 XV-S56BK/XV-S57SL MN101C35DGZ(IC701):System controller Pin function Pin No. Symbol Description DAC control data DDATA DAC control clock DCLK DAC control chip select DACOCS Chip select signal for rear L/R DAC (IC813) DAC1CS Chip select signal for sub woofer/center DAC (IC823) DAC2CS...
  • Page 26 XV-S56BK/XV-S57SL MN102L25GGX2(IC401):Unit CPU Pin function Symbol Function Symbol Function Pin No. Pin No. Micon wait signal input WAIT Read enable Spindle muting output to IC251 Serial enable signal for ADSC SPMUTE ADSCEN Write enable Power supply Non connect Serial enable signal for FEP...
  • Page 27 XV-S56BK/XV-S57SL MN103S13BDA(IC301):Optical disc controller 1.Pin layout HDD15 SBCK HDD0 HDD14 HDD1 PVDD HDD13 PVSS HDD2 OSCO1 HDD12 OSCI1 HDD3 LRCK HDD11 BLKCK HDD4 IPFLAG HDD10 DACCLK DACLRCK HDD5 DACDATA HDD9 NTRON MN103S13BDA HDD6 JMPINH HDD8 IDHOLD HDD7 SBCK/PLLOK VDDH CLKOUT2...
  • Page 28 XV-S56BK/XV-S57SL 3.Pin function (1/3) MN103S13BDA Symbol Description Pin No. ATAPI Data HDD15 ATAPI Data HDD0 ATAPI Data HDD14 Power supply 3V ATAPI Data HDD1 ATAPI Data HDD13 ATAPI Data HDD2 Connect to GND ATAPI Data HDD12 Power supply 2.7V ATAPI Data...
  • Page 29 XV-S56BK/XV-S57SL 3.Pin function (2/3) MN103S13BDA Symbol Description Pin No. CPUADR5 System control address CPUADR4 System control address CPUADR3 System control address CPUADR2 System control address CPUADR1 System control address Connect to GND CPUADR0 System control address System control chip select...
  • Page 30 XV-S56BK/XV-S57SL 3.Pin function (3/3) MN103S13BDA Symbol Description Pin No. OSCO1 Oscillation output terminal 16.9MHz Power supply 3V PVSS Connect to GND PVDD Power supply 3V Terminal master polarity switch input CIRC-RAM,OVER/UNDER Interruption Connect to GND SBCK Clock output for sub code,serial input...
  • Page 31 XV-S56BK/XV-S57SL MN67706ZY (IC201) : Auto digital servo controller 1.Pin layout CHCK40 TSTSG DAT3 DAT2 SYSCLK DAT1 OFTR DAT0 33VDD 33VSS 33VSS 33VDD FBAL TBAL XRESET TGBAL AVSS ROUT CPUIRQ LOUT MN67706ZY CPUCLK AVDD CPUDTIN JLINE CPUDTOUT DBALO MONA VCOF MONB...
  • Page 32 XV-S56BK/XV-S57SL 2.Pin function (2/3) MN67706ZY Pin No. Symbol Description VFOSHORT VFO short output AVDD Apply 3.3V(For analog circuit) HPFIN Pull-up to VHALF HPFOUT Connect to TP208 AVSS Ground(For analog circuit) LPFIN Pull-up to VHALF LPFOUT Not use CMPIN Connect to TP210...
  • Page 33 XV-S56BK/XV-S57SL 2.Pin function (3/3) MN67706ZY Pin No. Symbol Description 33VSS Ground(For I/O) 33VDD Apply 3.3V(For I/O) Digital audio interface XRESET Reset input (System control) Servo DSC serial I/F chip select (System control) CIRC serial I/F chip select (System control) CPUIRQ...
  • Page 34 XV-S56BK/XV-S57SL ZIVA-4.1-PA2(IC501):Back end - Digital decoder 1.Terminal layout 2.Pin function (1/5) Pin No. Symbol Description Read strobe input Read/write strobe input Power supply terminal 3.3V Transfer not complete / data acknowledge. WAIT Active LOW to indicate host initiated transfer is complete.
  • Page 35 XV-S56BK/XV-S57SL 2.Pin function (2/5) ZIVA-4.1-PA2 Pin No. Symbol Description Connect to ground Non connect Non connect Non connect Non connect Non connect Programmable I/O terminal PIO0 Connect to ground Power supply terminal 3.3V Programmable I/O terminal PIO1 Programmable I/O terminal...
  • Page 36 XV-S56BK/XV-S57SL 2.Pin function (3/5) ZIVA-4.1-PA2 Pin No. Symbol Description SDRAM address MADDR6 SDRAM address MADDR5 Power supply terminal 2.5V Connect to ground SDRAM address MADDR4 SDRAM write enable Active LOW SDRAM column address SD-CAS Power supply terminal 3.3V Connect to ground...
  • Page 37 XV-S56BK/XV-S57SL 2.Pin function (4/5) ZIVA-4.1-PA2 Pin No. Symbol Description Connect to ground Non connect VSS_DAC Connect to ground for analog video DAC VSS_VIDEO Connect to ground for analog video DAC video output format : CVBS. Macrovision encoded CVBS VDD_DAC Power supply terminal for analog video DAC...
  • Page 38 XV-S56BK/XV-S57SL 2.Pin function (5/5) ZIVA-4.1-PA2 Pin No. Symbol Description DVD parallel compressed data from DVD DSP. or CD-G clock indicating DVD-DATA7/CDG-SCLK sub code data clock input or output VDACK In synchronous mode, bitstream data acknowledge. Asserted when DVD data is valid.Polarity is programmable...
  • Page 39 XV-S56BK/XV-S57SL In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the parts that are printed over with black such as the resistor ( diode ( ) and ICP ( ) or identified by the " " mark nearby are critical for safety.

  • Page 40: Block Diagrams

    XV-S56BK/XV-S57SL Block diagrams DVD Servo control & AV decoder section(SHEET 5,6) CN503 CN502 WAITDEC DRVMUTE CN101 CN201 CN202...
  • Page 41 XV-S56BK/XV-S57SL System control & audio output section(SHEET 4) AIN0 J702 AIN2 AVCI, AVCO TO FW801 COMPULINK SHEET 1 Q709 COMPULINK RESET RESET IC702 POWERSW +12V TO SHEET 2 STANDBYIND REMO -12V TO FW802 SHEET 1 P.MUTE SYSTEM X701(8MHz) CONTROLLER MUTE...
  • Page 42 XV-S56BK/XV-S57SL DC Regulator section (SHEET 2) CN961...
  • Page 43 XV-S56BK/XV-S57SL Audio & Video signal output section(SHEET 3) S-VIDEO OUT COMPOSITE J603 VIDEO OUT C/Pr/R L601, L602 Q601 Y/Pb/B Q611 TO SHEET 2 L611, L612 Q621 CVBS/Y/G COMPOSITE L621, L622 Y/COMPOSITE Y/C SWITCH S691 CVBS Q631 L631, L632 TO SHEET 4...
  • Page 44 XV-S56BK/XV-S57SL XV-S56BK/XV-S57SL Standard schematic diagrams FL Display & operation switch section FW801 FW802 QUM123-11DGZ4 QUM125-09DGZ4 S801 IC801 QSW0651-001Z GP1U271X R801 S821 S831 D801 SLR-342VC-T C801 S832 C802 47/10 S833 S834 S835 TO SHEET 2 TO SHEET 4 C821 4.7/50...
  • Page 45 XV-S56BK/XV-S57SL Power supply section T901 C951 100p QQS0097-001 Q951 CP951 C906 KTD863/Y/-T ICP-N10-T R956 1000P/AC250V D901 S1WB/A/60-4101 R952 D951 F1T4-T2 C960 C961 C908 R901 82/10 D960 L901 0.0033/1K MTZJ4.7B-T2 QQR1105-001 F901 C952 100p C907 C909 Q953 R953 -VDISP R954 L951...
  • Page 46 XV-S56BK/XV-S57SL XV-S56BK/XV-S57SL Audio / Video signal output section L601 L602 R605 R601 R602 Q601 KTA1267/G/-T C/Pr/R C985 220/16 Y/Pb/B TO SHEET 2 L611 L612 R615 CVBS/Y/G R612 R611 Q611 KTA1267/G/-T CVBS L621 L622 R625 Q621 R621 R622 KTA1267/G/-T C629 R629 470/6.3...
  • Page 47 XV-S56BK/XV-S57SL System control & audio signal DAC section EP711 C704 100P R1713 DA_BCK J702 R708 L709 QNS0089-001 DA_LRCK L710 R707 DA_DATA1 SWOPEN C713 SWUPDN DA_DATA2 TOPEN DA_DATA3 IC703 IC705 PQ05RD11 TCLOSE MN35505-X /LMMUTE R797 Q791 KRA102S-X D791 1SS133-T2 S2UDT SCLKO...
  • Page 48 XV-S56BK/XV-S57SL XV-S56BK/XV-S57SL DVD Servo control section D2.7V TP158 TP156 TP154 C317 1/16 C145 0.01/16 D.GND CN101 C146 TP131 QGF0501F2-30X STD7 R301 TP306 TP132 STD6 R318 T2CD R317 F2CD R302 TP133 C324 C315 R316 0.1/16 0.1/16 STD5 T1CD C109 R303 X301 0.1/16...
  • Page 49 XV-S56BK/XV-S57SL AV Decoder section TP505 R531 MM3023DN-X KTC4377/C/-X 0.1/16 D2.7V 33/4 0.1/16 TP507 D.GND NQL044K-100X TP506 K502 NQR0007-002X C534 100/6.3 K501 NQR0007-002X D.GND D.GND S.GND M.GND D501 1SR154-400-X R553 R551 C/R/V NQR0007-002X R554 Y/B/U NQR0007-002X R556 R552 K506 CVBS/G/Y NQR0007-002X...
  • Page 50 XV-S56BK/XV-S57SL XV-S56BK/XV-S57SL Surround audio signal output section R894 R886 C868 R913 470/6.3 R876 3.3k C852 K812 C854 R888 C848 0.012 QQR0601-001Z R915 R892 2.7k 220P 220/16 C866 0.01 R896 IC812 R878 R914 C844 R909 R866 R864 NJM4580L 47/25 R882 NJM4580L 1.5k...
  • Page 51 XV-S56BK/XV-S57SL Printed circuit boards Main board J603 J691 J704 J701 Q697 R698 C736 R695 R685 C685 S691 R697 C1701 R1721 C691 K708 R629 C1706 C629 C904 R777 D702 R767 P901 R705 R694 C686 R778 C1704 R768 Q754 Q696 R681 C639...
  • Page 52 XV-S56BK/XV-S57SL XV-S56BK/XV-S57SL DVD Servo control board Forward side Reverse side R291 R292 C273 R301 TP38 R318 C313 R347 R280 R302 TP40 R317 R316 R348 R303 TP44 R349 C312 K302 C316 R304 R346 TP41 C311 R282 R305 TP48 C309 C307 C315...
  • Page 53 XV-S56BK/XV-S57SL Surround audio board BK811 C873 C842 C841 C874 R929 R867 R930 R868 R869 R931 R875 R932 R870 R938 R876 R937 C880 C848 C879 C847 C882 C850 R877 C881 C849 R940 R878 R873 R939 R936 R881 R874 R935 C877 C845...

  • Page 54: Parts List

    XV-S56BK/XV-S57SL PARTS LIST [XV-S56BK/XV-S57SL] * All printed circuit boards and its assemblies are not available as service parts. Area Suffix (XV-S56BK) E ----------- Continental Europe EN ------------ Northern Europe Area Suffix (XV-S57SL) B ------------------------------- U.K. E ----------- Continental Europe EN ------------ Northern Europe...
  • Page 55 XV-S56BK/XV-S57SL Exploded view of general assembly and parts list Block No. M 21 BACK SIDE Grease UD-24H2 24 BACK SIDE 44 43...
  • Page 56 AUDIO OUT QYSBSGY3008M SPECIAL SCREW VIDEO OUT QYSBSGY3008M SPECIAL SCREW 21P OUT COMPU LINK QYSBSGY3008M SPECIAL SCREW AC INLET QYSBSGY3008M SPECIAL SCREW Explanation of area column BKE =XV-S56BK ver.E BKEN =XV-S56BK ver.EN SLB =XV-S57SL ver.B SLE =XV-S57SL ver.E SLEN =XV-S57SL ver.EN...
  • Page 57 METAL COVER SLB,SLE,SLEN QYSBSGG3008E T.SCREW E406308-003 SPECIAL SCREW BKE,BKEN E406308-004 SPECIAL SCREW SLB,SLE,SLEN LE20536-004A FITTING BKE,BKEN LE20536-010A FITTING SLB,SLE,SLEN LE40757-001A MARK BKE,BKEN LE40757-002A MARK SLB,SLE,SLEN Explanation of area column =XV-S56BK ver.E BKEN =XV-S56BK ver.EN =XV-S57SL ver.B =XV-S57SL ver.E SLEN =XV-S57SL ver.EN...
  • Page 58 XV-S56BK/XV-S57SL DVD Traverse mechanism assembly and parts list Block No. M Grease EBS0006-013B 946P-1 CFD-4007ZY2 12.0mm 0.2mm 65.2mm...
  • Page 59 XV-S56BK/XV-S57SL Parts list (DVD Traverse mechanism assembly) Block No. M2MM Item Parts number Parts name Q'ty Description Area LE20520-002A MECHA BASE LE20516-001A SPINDLE BASE QYSDST2605M TAPPING SCREW LE30909-001A HOLDER QAR0165-001 FEED MOTOR LV41510-001A FEED GEAR QYSPSPU2040M SCREW LV41512-001A FEED GEAR...
  • Page 60 XV-S56BK/XV-S57SL DVD Loading mechanism assembly and parts list Block No. M Grease UD-24H2 EM-30L CFD-4007ZY2...
  • Page 61 XV-S56BK/XV-S57SL Parts list (DVD Loading mechanism assembly) Block No. M3MM Item Description Parts number Parts name Q'ty Area LV10454-007A LOADING BASE QAR0164-001 MOTOR LV42087-001A MOTOR PULLEY QYSPSPU1730Z SCREW VKZ4777-003 MINI SCREW LV42209-001A BELT LV42084-002A PULLEYGEAR LV42085-002A MIDDLE GEAR LV42086-001A IDLE GEAR...
  • Page 62 XV-S56BK/XV-S57SL Block No. 01 Electrical parts list (Main board) Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area BK801 LE20539-001A FL HOLDER C 906 QCZ9079-102 C CAPACITOR 1000PF C 601 NCS31HJ-471X C CAPACITOR C 907 QEZ0452-826 E.CAPACITOR...
  • Page 63 XV-S56BK/XV-S57SL Electrical parts list (Main board) Block No. 01 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area D 801 SLR-342VC-T STANDBY L 955 QQL26AK-220Z INDUCTOR D 901 S1WB/A/60-4101 BRIDGE DIODE L 957 QQL244K-100Z INDUCTOR...
  • Page 64 XV-S56BK/XV-S57SL Block No. 01 Electrical parts list (Main board) Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area R 703 NRSA63J-105X MG RESISTOR R 846 NRSA63J-681X MG RESISTOR R 704 NRSA63J-102X MG RESISTOR R 847...
  • Page 65 XV-S56BK/XV-S57SL Electrical parts list (Servo control board) Block No. 02 Item Parts number Parts name Remarks Area Item Remarks Parts number Parts name Area NCB31CK-104X C CAPACITOR C 220 NCB11CK-105X C CAPACITOR NEA70JM-226X E CAPACITOR C 221 NCB31HK-561X C CAPACITOR...
  • Page 66 XV-S56BK/XV-S57SL Electrical parts list (Servo control board) Block No. 02 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area C 319 NCB31CK-104X C CAPACITOR C 557 NCB31CK-104X C CAPACITOR C 320 NCB31CK-104X C CAPACITOR C 561...
  • Page 67 XV-S56BK/XV-S57SL Electrical parts list (Servo control board) Block No. 02 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area R 117 NRSA63J-123X MG RESISTOR R 258 NRSA63J-0R0X MG RESISTOR R 118 NRSA63J-303X MG RESISTOR R 259...
  • Page 68 XV-S56BK/XV-S57SL Electrical parts list (Servo control board) Block No. 02 Item Parts number Parts name Remarks Area R 432 NRSA63J-472X MG RESISTOR R 501 NRSA63J-102X MG RESISTOR R 502 NRSA63J-472X MG RESISTOR R 504 NRSA63J-330X MG RESISTOR R 506 NRSA63J-330X...
  • Page 69 XV-S56BK/XV-S57SL Electrical parts list (Surround audio board) Block No. 03 Item Parts number Parts name Remarks Area Item Parts number Parts name Remarks Area BK811 E409182-001SM GRAND TERMINAL IC822 NJM4580L C 838 QFLC1HJ-102Z M CAPACITOR 1000PF 5% 50V IC823 MN35505-X...
  • Page 70 XV-S56BK/XV-S57SL Electrical parts list (Surround audio board) Block No. 03 Item Parts number Parts name Remarks Area R 928 QRE141J-561Y C RESISTOR 560 5% 1/4W R 929 QRE141J-273Y C RESISTOR 27K 5% 1/4W R 930 QRE141J-273Y C RESISTOR 27K 5% 1/4W...
  • Page 71 XV-S56BK/XV-S57SL Packing materials and accessories parts list Block No. M4MM Block No. M5MM Accessories Except XV-S57SLB XV-S57SLB only 3-18...

  • Page 72: Packing List

    SIGNAL CORD(JES RM-SXVS56E REMOCON UNIT BKE,BKEN RM-SXVS57E REMOCON UNIT SLB,SLE,SLEN --------- BATTERY QPC02504015P POLY BAG A 10 QPC02503510P POLY BAG A 11 VNA3000-204 REGIST.CARD Explanation of area column =XV-S56BK ver.E BKEN =XV-S56BK ver.EN =XV-S57SL ver.B =XV-S57SL ver.E SLEN =XV-S57SL ver.EN 3-19...
