Page 2
2. CAUTION: Invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam. 3. CAUTION: Do not open the top cover. There are no user serviceable parts inside the Unit; leave all servicing to qualified service personnel. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Specifications..............68 To locate a desired selection using the numeric buttons...31 Table of languages and their abbreviations.. Appendix A To locate a desired selection using 4 or ¢ ....32 Country code list for Parental Lock....Appendix B Downloaded From DvDPlayer-Manual.com JVC Manuals...
A format for DVD AUDIO with the compression ratio of about 2:1 while allowing the PCM signal to be completely recreated by the MLP decoder (required in all DVD AUDIO players). It supports up to 192kHz/24- bit. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Other convenient NOTES procedures, etc. • When appears on the TV screen in step 1: The current scene is not recorded from multiple angles. • During the operation above, audio is muted. Downloaded From DvDPlayer-Manual.com JVC Manuals...
It lights in green during playback of a film-source DVD VIDEO disc when “PROGRESSIVE MODE” in “PREFERENCE 1” is set to “SMART” , “FILM” or “AUTO.” In other conditions when the Progressive scan mode is active, it lights in red. Downloaded From DvDPlayer-Manual.com JVC Manuals...
See “How to make the Progressive scan mode active” 8 AV COMPU LINK jacks (64) on page 17 for details. Connects with other JVC equipment supporting the AV Compulink function to facilitate integrated operations. 4 Region code label (14) Indicates the region code of the unit.
TV screen (for DVD VIDEO/Video CD/ chapter number for the Chapter search. SVCD). When the TV - DVD switch is set to TV, these buttons are used to select a TV channel as well as mute the TV audio. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Page 11
Cancels the last selection of the program when the § ON SCREEN button TV - DVD switch is set to DVD. Brings up an appropriate on-screen display for controlling advanced functions for the current disc on the TV screen. Downloaded From DvDPlayer-Manual.com JVC Manuals...
One of the displays shown on the right appears when a disc is set and stopped. For a disc that does not contain any picture (such as an Audio CD), the opening display does not disappear after starting playback. (for Video CD/SVCD) (for Audio CD) Downloaded From DvDPlayer-Manual.com JVC Manuals...
Page 13
One of the displays above appears according to the or while stopped) disc contents and the unit's status. GROUP EACH 2:34:58 REMAIN TRACK TIME TIME SELECT REPEAT ALL REPEAT A-B REPEAT PRESS ENTER EXECUTE TIME SEARCH PROGRAM RANDOM AUDIO 2 / 3 Downloaded From DvDPlayer-Manual.com JVC Manuals...
• You can select one of several screen saver modes available (see page 59). • The screen saver function is not activated during Audio CD/MP3 disc playback or after stopping Audio CD/MP3 disc playback. Downloaded From DvDPlayer-Manual.com JVC Manuals...
* There is another method for selecting a track or group of an MP3 disc. See the appropriate section. To select a TV channel Press the corresponding numeric buttons. See page 23 and 24 for details. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Note that, with some formats and/or depending on the unit's “DIGITAL AUDIO OUTPUT” setting, digital audio signals are not always output from the unit's DIGITAL output jacks as are recorded on the disc. See “DIGITAL AUDIO OUTPUT” on page 57 for details. Downloaded From DvDPlayer-Manual.com JVC Manuals...
• Connect VIDEO OUT of the unit directly to the video input of your TV. Connecting VIDEO OUT of the unit to a TV via a VCR may cause a monitor problem when playing back a copy-protected disc. Downloaded From DvDPlayer-Manual.com JVC Manuals...
• You should note that not all Progressive TV and High-Definition TV sets are fully compatible with the unit and may cause artifacts to be displayed in the picture. In case of progressive scan picture problems, it is recommended that you switch the setting to the “Interlace Scan” output. Downloaded From DvDPlayer-Manual.com JVC Manuals...
• When using the unit with a stereo amplifier or receiver, make the “DOWN MIX” setting in “PREFERENCE 2” to “Lo/Ro” and the Speaker setting in “SPK. SETTING” to “2 CH.” (see pages 58 and 59). Downloaded From DvDPlayer-Manual.com JVC Manuals...
• When using the 5.1-channel outputs of the unit, set the “DOWN MIX” in the “PREFERENCE 2” on-screen display to “OFF” and select “5.1 CH.” or “EXPERT” in the “SPK.SETTING” on-screen display. If the “EXPERT” is selected, you can control the audio output balance of the speakers (see pages 58 and 59). Downloaded From DvDPlayer-Manual.com JVC Manuals...
• When you connect the unit's DIGITAL output to a Dolby Digital or DTS decoder (or amplifier with a built-in decoder) to enjoy surround sound, the unit's “COMPRESSION” setting in the “PREFERENCE 2” on-screen display and all settings in the “SPK. SETTING” display are invalid. Make appropriate surround audio settings by the decoder. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Place the cover over the compartment, and press down lightly. • The batteries will last about six months with normal use. If the functions of the remote control become erratic, replace the batteries. See next page for more information. Downloaded From DvDPlayer-Manual.com JVC Manuals...
ENTER ∞ REMOTE CONTROL NOTE • If the remote sensor on the unit is exposed to the sunshine or strong light, you may not be able to control the unit from the remote control unit. Downloaded From DvDPlayer-Manual.com JVC Manuals...
PHILCO/DAEWOO NOKIA PANASONIC LG (GOLDSTAR) FUNAI GRUNDIG SAMSUNG SHARP NEC/GRADIENTE SAMSUNG/PEONY/CHANGHONG SONY PHILCO SAMSUNG TOSHIBA BEIJING/NOBLEX AIWA ZENITH JVC (ONWA) DAEWOO PHILCO/HITACHI JVC (ONWA) JINXING/PEONY PANASONIC JVC (ONWA) PEONY SAMSUNG THOMSON KONKA SANYO/SEARS FERGUSON TOSHIBA Downloaded From DvDPlayer-Manual.com JVC Manuals...
Page 26
Adjusts the TV volume. NOTES • The remote control unit is initially set operating a JVC TV. • If there is more than one code listed for the manufacturer of your TV, try them one by one until you succeed.
• If you insert a DVD VIDEO disc whose region code does not match the unit, “REGION CODE ERROR!” is shown in the DVD opening display. For detail about the region code, see page 14. Downloaded From DvDPlayer-Manual.com JVC Manuals...
The unit stops playback. • If you press 0 (OPEN/CLOSE) during playback, the unit stops playback and opens the tray. To stop playback temporarily Press 8. The unit pauses playback. To resume playback, press 3. Downloaded From DvDPlayer-Manual.com JVC Manuals...
When you play a Video CD/SVCD disc with the PBC function or a DVD VIDEO disc, the unit may locate a different place, but it will generally locate the beginning of the title, chapter or track. Downloaded From DvDPlayer-Manual.com JVC Manuals...
• The resume function does not work with Audio CD and MP3 discs. • In the case of a Video CD/SVCD disc with PBC function, the unit may resume playback from a point slightly earlier or later than the resume point you stored. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Make sure that the TV - DVD switch is set to “DVD” when using the CURSOR 5 5 5 5 /∞ ∞ ∞ ∞ /2 2 2 2 /3 3 3 3 , numeric and TV/VIDEO - CANCEL buttons for controlling the unit. Downloaded From DvDPlayer-Manual.com JVC Manuals...
ENTER. The unit starts playback of the selected item. Use the numeric buttons to select the desired item. • See page 13 for details about how to use the numeric buttons. Downloaded From DvDPlayer-Manual.com JVC Manuals...
(except when a menu is shown), a chapter is specified. * While a DVD VIDEO/DVD AUDIO is stopped, a title is specified. * For an Audio CD, Video CD or SVCD, a track is specified. Downloaded From DvDPlayer-Manual.com JVC Manuals...
To select chapter number 8: Press “8” → ENTER. To select chapter number 37: Press “3” → “7” → ENTER. The specified number appears in the message area. Press ENTER. The unit starts playback from the selected chapter. Downloaded From DvDPlayer-Manual.com JVC Manuals...
(for the last two digits in the example above). Of course, it is possible to enter them. ¶ For DVD VIDEO: During playback For DVD AUDIO/Audio CD: During playback or while stopped For Video CD/SVCD: During playback without PBC function or while stopped Downloaded From DvDPlayer-Manual.com JVC Manuals...
• With some discs, depending on the contents, it may REMOTE CONTROL take some time until all the scenes appear on the screen. ¶ For DVD VIDEO: While stopped or during playback For Video CD/SVCD: While stopped or during playback without PBC function Downloaded From DvDPlayer-Manual.com JVC Manuals...
Press and hold 8 for more than 1 second. • The sound is muted during slow-motion playback. • Reverse slow-motion playback is not possible for a Nine continuous still Video CD/SVCD. pictures appear on the TV screen. Downloaded From DvDPlayer-Manual.com JVC Manuals...
(down to x 1/8). ZOOM x 4 At the top-left of the screen, the information for the current magnification appears, as well as the zoomed-in position of the scene that can be moved by operating the next step. Downloaded From DvDPlayer-Manual.com JVC Manuals...
3 : 54 TRACK 1 TIME 3 : 54 EACH REMAIN REMAIN TIME SELECT TIME SELECT REPEAT REPEAT A-B REPEAT A-B REPEAT PRESS NUMERIC KEY PRESS NUMERIC KEY TIME SEARCH TIME SEARCH PROGRAM PROGRAM RANDOM RANDOM Downloaded From DvDPlayer-Manual.com JVC Manuals...
3 : 54 EACH TRACK 1 TIME 3 : 54 REMAIN REMAIN TIME SELECT TIME SELECT REPEAT REPEAT A-B REPEAT A-B REPEAT PRESS ENTER EXECUTE PRESS ENTER EXECUTE TIME SEARCH TIME SEARCH PROGRAM PROGRAM RANDOM RANDOM Downloaded From DvDPlayer-Manual.com JVC Manuals...
A-B REPEAT (current track repeat) TIME SEARCH LPCM VCDVD GROUP TITLE TRACK CHAP PROGRAM MPEG No indication DOLBY RANDOM PROGRAM OGRAM DIGITAL AUDIO RANDOM RANDOM 2 / 3 (off) Repeat mode Selected repeat mode indicators Downloaded From DvDPlayer-Manual.com JVC Manuals...
Use CURSOR 5/∞ to move to [A-B until [REPEAT] returns to its original color. REPEAT], then press ENTER at the beginning of the part you want to repeat (point A). The color of A-B REPEAT changes. Downloaded From DvDPlayer-Manual.com JVC Manuals...
TV screen. Use ANGLE or CURSOR 2/3 to select the desired angle. Each time you press ANGLE or CURSOR 2/3, the angle changes. 1 / 3 Example: 2 / 3 3 / 3 Downloaded From DvDPlayer-Manual.com JVC Manuals...
1 / 3 Example: 2 / 3 3 / 3 NOTES • To turn off the on-screen display Press ON SCREEN. • When appears on the TV screen The current scene is not recorded from multiple angles. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Pressing CURSOR 2/3 cycles among the subtitles recorded on the disc. To turn the subtitle on and off, press Example: SUBTITLE. 1/3 ENGLISH To select the desired subtitle language, use 2/3 FRENCH CURSOR 2/3. 3/3 SPANISH -/3 (off) Downloaded From DvDPlayer-Manual.com JVC Manuals...
Use CURSOR 2/3 or AUDIO - S.FREQ for audio selection. REMOTE CONTROL Each time you press CURSOR 2/3 or AUDIO - S.FREQ, the audio changes. See the examples for audio selection on the next page. Downloaded From DvDPlayer-Manual.com JVC Manuals...
See the DVD AUDIO disc): step below. You cannot select the audio. To define a user setting, select a parameter to be edited using CURSOR 5/∞ from the followings. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Suitable for action movies and sports programs in which sounds dynamically move. • DRAMA Natural and warm sound. You can enjoy movies in a relaxed mood. • THEATER You can enjoy sound effects like in a major theater in Hollywood. Downloaded From DvDPlayer-Manual.com JVC Manuals...
• When you select “EACH REMAIN” while stopped, you can change the track by pressing 4 or ¢. ¶ For DVD AUDIO: During playback of audio only or while stopped For Audio CD: During playback or while stopped For Video CD/SVCD: While stopped Downloaded From DvDPlayer-Manual.com JVC Manuals...
The page selection display appears on the TV Each time you press CURSOR 2/3, the page screen. changes. PAGE Use CURSOR 2/3 to select the desired page. NOTE • You can also advance to the next page by pressing the PAGE button. Downloaded From DvDPlayer-Manual.com JVC Manuals...
If you enter the key number correctly, the unit starts playback of the bonus group. If you enter a wrong key number, the unit does not start playback and the display window and TV screen again prompt you to reenter the key number. Downloaded From DvDPlayer-Manual.com JVC Manuals...
• This function is also applied to an MP3 disc. • You cannot check the quantization bit length via the display window. • With some disc, the sampling frequency may not be shown in the display window. Downloaded From DvDPlayer-Manual.com JVC Manuals...
• The screen saver function is not active with an MP3 disc, as with an Audio CD. • The unit only can play back Tracks with any of the following file extensions; “ .MP3” , “ .Mp3” , “ .mp3” and “ .mP3” . Downloaded From DvDPlayer-Manual.com JVC Manuals...
0 6 - C h e r t y o h B a b y . m p 3 0 7 - I G o t Y o u B a b e . m p 3 Selected Group Selected Track Downloaded From DvDPlayer-Manual.com JVC Manuals...
• To stop repeat playback Press 7 . • To quit repeat playback Press REPEAT as many times until no repeat icon is shown on the display window. NOTE • You cannot repeat all contents on the disc. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Pressing CURSOR 2 changes the language setting in the C. SP Small R. SP Small reverse order of the above. BASS S.woofer PRESS TEST TONE * If the selected language is not recorded, the disc’s default display language will be displayed. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Pressing CURSOR 2 changes the language setting in the reverse order of the above. • OFF The on-screen guide will not be displayed. * If the selected language is not recorded, the disc’s default subtitle language will be displayed. Downloaded From DvDPlayer-Manual.com JVC Manuals...
TV that supports both the PAL and NTSC systems. If you select one of these options, the unit outputs a PAL or NTSC video signal according to the disc, regardless of the NTSC - PAL selector setting. Downloaded From DvDPlayer-Manual.com JVC Manuals...
20 or 24 bit digital signal may be output. NOTE • When playing a DVD VIDEO or Audio CD disc with DTS, use a DTS decoder to get correct signals from your speakers. Downloaded From DvDPlayer-Manual.com JVC Manuals...
AV COMPULINK MODE DVD1 PRESS The auto standby function is off. • ON Audio is played back with the dynamic range compressed. • OFF Audio is played back as it was recorded. Downloaded From DvDPlayer-Manual.com JVC Manuals...
F. SP Large C. SP Small R. SP Small S.woofer BASS PRESS TEST TONE Select the speaker to be set using CURSOR 5/∞. • F.SP: Front speakers • C.SP: Center speaker • R.SP: Rear speakers Downloaded From DvDPlayer-Manual.com JVC Manuals...
Page 62
The color of “LEVEL” changes. NOTE • To exit the speaker level (or delay) setting mode Move to [LEVEL] (or [DELAY]) in the on-screen display and press ENTER until [LEVEL] (or [DELAY]) returns to its original color. Downloaded From DvDPlayer-Manual.com JVC Manuals...
ENTER until [TEST TONE] returns to its original See “Appendix B: Country code list for Parental color. Lock” . PARENTAL LOCK Country Code NONE Set Level – – – – PASSWORD EXIT PRESS ENTER Press ENTER. moves to [Set Level]. Downloaded From DvDPlayer-Manual.com JVC Manuals...
• If you enter an undesired password in step 6 above, reenter the password before pressing ENTER. select the parental level. To change the set level, use CURSOR 2/3 to select the desired level while points [Set Level], and then press ENTER. moves to [PASSWORD]. Downloaded From DvDPlayer-Manual.com JVC Manuals...
ENTER. moves to the [PASSWORD] field. When selecting [NO], PARENTAL LOCK This DISC can’t play now! press 0 (OPEN/CLOSE) Temporary Level Change ? – – – – to remove the disc. PASSWORD PRESS ENTER EXECUTE Downloaded From DvDPlayer-Manual.com JVC Manuals...
Additional information AV COMPU LINK remote control system The JVC AV COMPU LINK system allows you to enjoy video or audio with the simplest operation. If your video/audio player (such as a DVD player, CD player and VCR) and television or/and...
• Setting the source of the television to the external input (VIDEO-1 or VIDEO-2). • Turning on the power for the receiver. • Setting the source of the receiver to the component which has started playback. Downloaded From DvDPlayer-Manual.com JVC Manuals...
Sometimes during play noise or images may be garbled. This is sometimes due to the disc. (It may not be up to industry standards.) These symptoms are caused by the discs, not by the malfunction of the unit. Downloaded From DvDPlayer-Manual.com JVC Manuals...
The display window does not light The brightness of the display window is Change the brightness of the display window. when the STANDBY/ON indicator set to “off” . (See page 49.) on the front panel is lit in green. Downloaded From DvDPlayer-Manual.com JVC Manuals...
20 bit: More than 110 dB 24 bit: More than 110 dB Wow and flutter: Unmeasurable (less than ± 0.002%) Total harmonic distortion: less than 0.002% * Specifications and appearance subject to change without prior notice. Downloaded From DvDPlayer-Manual.com JVC Manuals...
