otee!
1
Please note that this image is a general representation
of the product and may differ slightly from your product.
otee!
1
Please note that during storage and transportation,
especially at high ambient temperature, some of the oil
and grease used for assembling may leak and stain the
packaging. This is in no way detrimental to the product,
wipe off the excessive oil/grease with a cloth.
Shock absorber for BMW 1M (E82) - front
BMZ MN01
Mounting Instructions
Kit Contents
Description
Shock absorber
Dust boot
Spring
Lock nut M14
Plastic spacer
Spacer
Lower spring seat
Lock nut
Used for front and rear
C-spanner
Sticker Öhlins
Owner's manual
otee!
1
Before installing this product, check the contents of the
kit. If anything is missing, please contact an Öhlins dealer.
⚠
Warninge!
Before installing this product, read the Öhlins Owner's
Manual. The shock absorber is an important part of the
vehicle and the vehicle stability.
Pcs
2
2
2
2
2
2
2
2
2
1
1
Advertisement
Related Manuals for Ohlins BMZ MN01
Summary of Contents for Ohlins BMZ MN01
- Page 1 This is in no way detrimental to the product, wipe off the excessive oil/grease with a cloth. Shock absorber for BMW 1M (E82) - front BMZ MN01 Mounting Instructions...
- Page 2 MOU TI G I STRUCTIO S ⚠ Warninge! We strongly recommend to have an Öhlins dealer install this product. ⚠ Warninge! If working on a raised vehicle, ensure that it is securely supported to prevent it from tipping over. otee! When working on this product, see the Vehicle Service Manual for vehicle specific procedures and important data.
- Page 3 MOU TI G I STRUCTIO S Install the stabilizer link. otee! Stabilizer Use an Allen key to hold the shock absorber in position link when tightening the top mount nut. Raise the wheel hub with a jack to ensure that Spacer Original nut the height adjuster is correctly seated on top...
-
Page 4: Setup Data
ADJUSTME TS ⚠ Warninge! Before riding, always make sure that the basic settings made by Öhlins are according to recommended Set- up Data. Read about adjustments and setting up in the Öhlins Owner’s Manual before you make any adjustments. Contact an Öhlins dealer if you have any questions about setting up. -
Page 5: Mounting Instructions
This is in no way detrimental to the product, wipe off the excessive oil/grease with a cloth. Shock absorber for BMW 1M (E82) - rear BMZ MN01 Mounting Instructions... - Page 6 MOU TI G I STRUCTIO S ⚠ Warninge! We strongly recommend to have an Öhlins dealer install this product. ⚠ Warninge! If working on a raised vehicle, ensure that it is securely supported to prevent it from tipping over. otee! When working on this product, see the Vehicle Service Manual for vehicle specific procedures and important data.
- Page 7 MOU TI G I STRUCTIO S Vehicle body Remove the OEM upper spring cup accord- ing to figure. Rubber seat Spring preload Install the Öhlins spring and the spring adjuster preload adjuster according to the figure. Flexibel Lock nut spacer Spring seat Install the Öhlins shock absorbers on the vehi- cle according to the vehicle service manual.
- Page 8 ADJUSTME TS ⚠ Warninge! Before riding, always make sure that the basic settings made by Öhlins are according to recommended Set- up Data. Read about adjustments and setting up in the Öhlins Owner’s Manual before you make any adjustments. Contact an Öhlins dealer if you have any questions about setting up.
