- Page 1 SOHOConnect Series FSD-401ST / FSD-401SC 5-port 10/100Mbps Ethernet Switch SOHOConnect Series...
-
Page 3: Fcc Warning
Trademarks Copyright © PLANET Technology Corp. 2001. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Contents subject to revision without prior notice. FCC Warning This device has been tested and found to comply with limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 5: Table Of Contents
Table of Contents CHAPTER 1 ................2 ...........2 ENERAL NTRODUCTION Checklist ................2 Introduction ..............2 Features.................2 CHAPTER 2 ................2 ...........2 ARDWARE ESCRIPTION Front Panel..............2 Rear Panel ..............2 Hardware Installation ............2 Configuration..............2 Switch Operation............2 CHAPTER 3 ................2 ............2 ROUBLESHOOTING APPENDIX A...............2 :..............2 PECIFICATIONS SOHOConnect Series... - Page 6 This page is intentionally left blank FSD-401 User's Manual...
-
Page 7: General Introduction
Introduction The FSD-401ST/FSD-401SC, 5-port 10/100Mbsp Ethernet Switch is designed to allow simultaneous transmission of multiple packets via an internal high-speed data channel including 100Base-FX fiber-optic. - Page 8 In the following sections, the term “Switch” will represent Planet’s FSD-401, the both model, and “switch” for third part Ethernet switches. This Switch is a highly reliable network switch and is the ideal device for bridging Ethernet to Fast Ethernet workgroups or networks. Simple and cost-effective, the Switch complies to IEEE802.3u, IEEE802.3,...
-
Page 9: Features
that need it most. The fifth port of the FSD-401 is a 100Base-FX fiber- optic ports that can help to implement the switched network up to 2 kilometers away to your central office. Features ♦ 4-port 10/100base-TX Auto-Negotiation, 1-port 100Base-FX Ethernet Switching Hub ♦... -
Page 11: Chapter 2
The unit front panel provides a simple interface monitoring the Switch. It includes a power indicator for each port. The only difference of the model is the fifth port of FSD-401. FSD-401ST is with two round ST type connection and FSD-401SC is with SC type connector. - Page 12 LED indicators Color Description Function Power Green This indicator lights green when the hub is (PWR) receiving power, otherwise, it is off. Link/ Act Green This indicator green when the port is connected to a either 10Mbps Ethernet or 100Mbs Fast Ethernet station , If the station to which the hub is connected is powered off, or if there is a problem with the link, the LED will remain off.
-
Page 13: Rear Panel
Rear Panel Power Inlet The rear panel of the Switch indicates a 100~240VAC Power inlet for the Switch Figure 2. Rear Panel of FSD-401 Power Notice: 1. The device is a power-required device, it means, it will not work till it is powered. - Page 14 the Switch and all the devices connect to the Switch. Notice: 1. Cable distance for the Switch The UTP cable distance between the Switch and hub/PC should not exceed 100 meters. The fiber-optic cable should not exceed 412 meters in Half-duplex mode and 2 kilometers for Full- duplex mode.
-
Page 15: Configuration
Configuration 100Mbps Server to 10/100Mbps Hub Plug one end of the Category 5 UTP Cable into any one port of the Switch, and the other end of this cable into the RJ-45 of Fast Ethernet Adapter in the server. The cable length between these 2 connecting points should not exceed 100 meters. -
Page 16: Switch Operation
device like repeater hub, switch or workstations. Be noted for the duplex mode. For Hub, only Half-Duplex mode can be selected, at the mean time, the cable distance cannot exceed 412 meters. For Switch or end-node, the maximum distance cannot exceed 2 kilometers. The pair of the connectors must be crossed, i.e. - Page 17 The Ethernet Switch will lookup the address table for the destination address. If not found, this packet will be forwarded to all the other ports except the port which this packet comes in. And these ports will transmit this packet to the network it connected. If found, and the destination address is located at different port from this packet comes in, the Ethernet Switch will forward this packet to the port where this destination address is located according to the information from...
- Page 18 cofigured in any Ethernet network environment to significantly boost bandwidth using conventional cabling and adapters. Due to the learning function of the Ethernet switch, the source address and corresponding port number of each incoming and outgoing packet are stored in a routing table. This information is subsequently used to filter packets whose destination address is on the same segment as the source address.
- Page 19 100Mbps, no auto-negotiation 100Mbps • • 100Mbps, with auto-negotiation 100/200Mbps (100Base-TX/Full-Duplex) SOHOConnect Series...
- Page 20 This page is intentionally left blank FSD-401 User's Manual...
-
Page 21: Chapter 3
Chapter 3 Troubleshooting This chapter contains information to help you solve problems. If the Switch is not functioning properly, make sure the Switch was set up according to instructions in this manual. The Link LED is not Lit Solution: Make sure the switch configuration is consistent with the connecting device Check the cable connections. - Page 22 information. FSD-401 User's Manual...
-
Page 23: Specifications
Appendix A Specifications: General (Ethernet) Standards: IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100 Base-TX/FX Fast Ethernet IEEE 802.3 MAC layer frame size: 64 - 1518 Bytes Protocol: CSMA/CD Data Transfer Rate: Ethernet: Fast Ethernet: 10Mbps (half duplex) 100Mbps (half duplex) 20Mbps (full duplex) 200Mbps (full duplex) Topology:... - Page 24 General (Ethernet) FCC Class A, CE Mark Class A Performance Transmission Store-and-forward Method Filtering Address 1 K entries / device Table Packet 148,800pps per port (for 100Mbps) Filtering/Forwarding 14,880pps per port (for 10Mbps) Rate MAC Address Automatic update / Max age: fixed Learning FSD-401 User's Manual...
- Page 25 RJ-45 Pin Specification When connecting your FSD-401 10/100Mbps Ethernet Switch to another switch, a bridge or a hub, a modified crossover cable is necessary. Please review these products for matching cable pin assignment. The following diagram and tables show the standard RJ-45 receptacle/connector and their pin assignments for the switch-to-network adapter card connection, and the straight / crossover...
- Page 26 Crossover cable for Switch (MDI-X port) to switch/hub or other network devices (MDI-X port) connection FSD-401 User's Manual...
