UNIT LAYOUT

1
2
10
11
1. Weatherhood
2. Filter Section
(with V-Bank filters)
3. Unit Electrical Connection
4. Unit Control Center
(removed for viewing only)
5. Motor and Blower Assembly
Greenheck warrants this equipment to be free from defects in material and workmanship for a period of one year from
the purchase date. Any units or parts which prove defective during the warranty period will be replaced at our option
when returned to our factory, transportation prepaid.
Motors are warranted by the motor manufacturer for a period of one year. Should motors furnished by Greenheck prove
defective during this period, they should be returned to the nearest authorized motor service station. Greenheck will not
be responsible for any removal or installation costs.
Due to continuing research, Greenheck reserves the right to change specifications without notice.
This manual is the property of the owner, and is required for future maintenance.
Please leave it with the owner when you complete the job.
