Furnace - Greenheck IGX Installation, Operation And Maintenance Manual

Start-Up Instructions:

Furnace

If the information in this manual is not followed exactly, a fire or explosion may result in
Open windows
1.
2. Don't touch electrical switches
3. Extinguish any open flames
4. Immediately call your gas supplier
5. The use and storage of gasoline or other flammable vapors and liquids in open
containers in the vicinity of this appliance is hazardous.
Furnace Performance Data
Furnace Input Output
Qty. Model (MBH) (MBH)
1 PVF 100 100
1 PVF 150 150
1 PVF 200 200
1 PVF 250 250
1 PVF 300 300
1 PVF 350 350
1 PVF 400 400
2 PVF 250 500
2 PVF 300 600
2 PVF 350 700
2 PVF 400 800
3 PVF 350 1,050
3 PVF 400 1,200
Ratings shown are for elevations up to 2000 ft. For higher elevations, the input should be reduced by 4% per
1000 ft. of elevation above sea level. In Canada, from 2000 to 4500 ft in elevation, the unit must be derated to
90% of the input listed above. The unit shall also be used in accordance with standard CGA 2.17.
property damage, personal injury or loss of life.
FOR YOUR SAFETY IF YOU SMELL GAS:
Air Temperature Rise Through Unit (°F)
25 30 35 40
80 2963 2469 2116 1852
120 4444 3704 3175 2778
160 5926 4938 4233 3704
200 7407 6173 5291 4630
240 8889 7407 6349 5556
280 10370 8642 7407 6481
320 11852 9877 8466 7407
400 14815 12346 10582 9259
480 NA 14815 12698 11111
560 NA NA 14815 12963 11523 10370
640 NA NA NA 14815 13169 11852 10774 9877
840 NA NA NA NA
960 NA NA NA NA
**WARNING**
45 50 55 60
CFM
1646 1481 1347 1235 1140
2469 2222 2020 1852 1709
3292 2963 2694 2469 2279
4115 3704 3367 3086 2849
4938 4444 4040 3704 3419
5761 5185 4714 4321 3989
6584 5926 5387 4938 4558
8230 7407 6734 6173 5698
9877 8889 8081 7407 6838
9428 8642 7977
9117
NA NA 14141 12963 11966 11111 10370 9722
NA NA NA 14815 13675 12698 11852 11111 10458 9877
22
65 70 75 80 85
1058 988 926 871
1587 1481 1389 1307
2116 1975 1852 1743
2646 2469 2315 2179
3175 2963 2778 2614
3704 3457 3241 3050
4233 3951 3704 3486
5291 4938 4630 4357
6349 5926 5556 5229
7407 6914 6481 6100
8466 7901 7407 6972
9150
90 95 100
823 780 741
1235 1170 1111
1646 1559 1481
2058 1949 1852
2469 2339 2222
2881 2729 2593
3292 3119 2963
4115 3899 3704
4938 4678 4444
5761 5458 5185
6584 6238 5926
8642 8187 7778
9357 8889
