Generac Power Systems 45kW Owner's Manual page 36

EXPLODED VIEW: EV CPL C2&C4 R200C CB CONN
DRAWING #: 0H1730
ITEM PART#
1 0F3137
2 0F3188
3 0F3189
4 023484N
5 0F6366B
0F6366A
6 043180
7 022264
8 0C3990
(1) 9 046357
10 022155
11 0C2428
12 0G7992
13 0A9457
14 057073
(2) 15 0D5466
(2) 16 0A7822
17 022237
18 022241
19 049226
20 0C2266
21 0C2454
23 022473
24 022097
(1) 26 0D4698
27 0H0026
28 025433
29 024469
30 067210A
31 0D6029
32 081008
33 077043J
34 051713
35 0F6156
36 029289
37 047411
(3) 39 0G0770
(4) 40 0H0348
(4) 41 036943
(4) 42 023897
(4) 43 022152
(4) 44 022158
45 0C2454
46 055934D
47 0F6145
48 048766
49 0G7991
1)
A 0F3328
C 0D5552
0D5553
0D5554
0D5556
0D9693
D 0F0492
E 048927
F 023897
G 022152
H 022158
J 0C2454
K 029289
REVISION: J-9104-D
DATE: 6/23/14
QTY. DESCRIPTION
PAGE 1
1 PAN CB CONN BOX
1 STAND RH CONTROL
1 STAND LH CONTROL
1 BUSHING SNAP SB-2.5-31
1 XFMR DUAL 120V/16V (FOR 120/240V & 277/480V UNITS)
1 XFMR DUAL 104V/16V (FOR 120/208V UNITS)
2 WASHER FLAT M4
2 WASHER LOCK #8-M4
2 SCREW PHTT M4-0.7 X 10 ZYC
REF BLOCK TERM 20A 6 X 6 X 1100V
6 WASHER LOCK #6
6 SCREW PHTT #6-32 X 1/2 ZYC
1 DECAL RTS CUSTOMER CONNECTION
1 DECAL NEUTRAL
2 JUNCTION BLOCK 3/8-16
REF BUS BAR NEUTRAL BLOCK 390
REF LUG SLDLSS 600/250-1/0 X 1/4-28
2 WASHER LOCK 3/8
2 NUT HEX 3/8-16 STEEL
6 WASHER LOCK M5
6 SCREW PHTT M5-0.8 X 16 ZYC
8 SCREW THF M6-1 X 16 N WA Z/JS
8 WASHER FLAT 1/4-M6 ZINC
4 WASHER LOCK M6-1/4
REF BLOCK TERM 20A 6 X 3 X 1100V
1 DECAL CHARGER POWER 120VAC C2
1 LUG SLDLSS #6-14 X 13/64 CU
1 SCREW HHTT #10-32 X 3/8 CZ
1 DECAL GROUND LUG
4 SCREW HHTT M6-1.0 X 16 ZYC
1 GROMMET 1.25 X .25 X .75
1 CONDUIT FLEX 2.0" ID (36" LG)
2 WASHER FLAT M5
1 PLATE WIRE SNGL GALV
1 TAPE ELEC 1/2 FOAM (AS REQ'D)
4 SCREW HHC M6-1.0 X 16 G8.8
1 HARNESS, TRANSFORMER ADAPTER
1 PCB ENCLOSURE ASSY 4.2L IGN MD
2 SCREW PPHM #10/32 X 2
4 WASHER FLAT #10 ZINC
2 WASHER LOCK #10
2 NUT HEX #10-32 STEEL
1 SCREW THF M6-1 X 16 N WA Z/JS
1 CLAMP VINYL 1.06 X .406 Z
A/R SEAL WEATHER .45"DIA
REF BLOCK TERM 20A 2 X 6 X 1100V
1 DECAL GTS CUSTOMER CONNECTION
UL CIRCUIT BREAKER (ED)
1 COVER ED CB SHORT STND
REF CB 0050A 3P 480V S ED4 LL
REF CB 0060A 3P 480V S ED4 LL
REF CB 0070A 3P 480V S ED4 LL
REF CB 0090A 3P 480V S ED4 LL
REF CB 0125A 3P 480V S ED4 LL
1 INSULATOR CB S (ED-3P)
4 SCREW RHM #10-32 X 4-1/2
4 WASHER FLAT #10 ZINC
4 WASHER LOCK #10
4 NUT HEX #10-32 STEEL
9 SCREW THF M6-1 X 16 N WA Z/JS
1 TAPE ELEC 1/2 FOAM (AS REQ'D)
GROUP A
Page 4 of 8
