SECTION 1
' ' GENERAL
• Number of channel
• Type of emission
• Freqency stability
• Freqency resolution
• Power supply requirement (negative ground)
• Current drain
• Operating temperature range
• Number of CTCSS frequency
• Dimensions (projections not included)
• Weight (included 3 cells)
' ' TRANSMITTER
• Output power
• Modulation system
• Max. frequency deviation
• Spurious emissions
• Adjacent channel power
• External microphone connector
' ' RECEIVER
• Receiving system
• Intermediate frequency
• Sensitivity (12 dB SINAD)
• Adjacent channal selectivity
• Spurious response
• Intermodulation
• Audio output power
• External SP connector
All stated specifications are subject to change without notice or obligation.
SPECIFICATIONS
: 69 channels (simplex; 433.075–434.775 MHz)
: 16K0F3E (FM)
: ±2500 Hz (±5.7 ppm)
: 25 kHz
: 3 × AA (R6) dry, alkaline; or BP-202 (optionl battery pack)
: Less than 140 mA
: –10˚C to +55˚C
: 38(67.0–250.3 Hz)
: 52.5 (W) × 102.5 (H) × 26.5 (D) mm
: 200 g
: 10 mW
: Variable reactance frequency modulation
: ±5.0 kHz
: 0.25 µW
: More than 47 dB
: 3-conductor 2.5(d) mm/2.2 kΩ
: Double conversion superheterodyne system
: 1st; 21.7 MHz
: 0.2 µV; –14 dBµ
: More than 40 dB
: More than 40 dB
: More than 40 dB
: 100mW at 10% distortion with an 8 Ω load
: 2-conductor 3.5(d) mm(
2nd; 450 kHz
⁄
1
8"
1 - 1
)/8 kΩ
