• Form No. 0529883D
0716
Owner's Manual
Read this manual for complete instructions
Français (page 17) / Español (página 33)
Questions?
Call Wagner Technical Service at:
1-800-328-8251
Register your product online at:
www.wagnerspraytech.com
Français
Español
English
Advertisement
Table of Contents
Related Manuals for WAGNER flexio 690
Summary of Contents for WAGNER flexio 690
-
Page 1: Table Of Contents
Français (page 17) / Español (página 33) Contents Important Safety Information Controls and Functions Questions? Material Preparation Assembly Call Wagner Technical Service at: Air and Material Controls 1-800-328-8251 Spray Pattern Adjustment Proper Spraying Technique Register your product online at: Cleanup www.wagnerspraytech.com... -
Page 2: Important Safety Information
Make sure that the product is connected to an outlet having the same configuration as the plug. No adapter should be used with this product. Grounded Outlet Grounding Pin Cover for grounded outlet box English © Wagner Spray Tech - All Rights Reserved... - Page 3 100ºF (38ºC). Thank you for your purchase! Thank you for purchasing the Wagner FLEXiO sprayer with best-in-class features that are designed for spraying residential paint, un-thinned, indoors or out. Only the FLEXiO sprayers have the power of the X-Boost® turbine and versatility of the iSpray nozzle that will help you finish projects fast and professionally.
-
Page 4: Controls And Functions
The material flow control The X-Boost™ power dial determines the amount of adjusts the level of air pressure spray material that is sprayed produced by the turbine. from the spray gun. English © Wagner Spray Tech - All Rights Reserved... -
Page 5: Material Preparation
Never exceed the thinning advice given by the coating manufacturer. Do not thin with materials that have a flashpoint below 100°F (38°C). The material flashpoint should be shown on the material container. English © Wagner Spray Tech. - All Rights Reserved... - Page 6 Make sure the suction tube is inserted as far as it will go to ensure a tight fit. 3. Carefully screw the cup back onto the spray gun assembly. Tighten firmly. English © Wagner Spray Tech. - All Rights Reserved...
- Page 7 6. Insert the air hose tightly into the connection on the spray handle. The connection can be positioned as desired. 7. Insert the air hose tightly into the connection into the turbine. The connections can be positioned as desired. English © Wagner Spray Tech - All Rights Reserved...
-
Page 8: Air And Material Controls
Low / Med Low / Med Polyurethane Low / Med Med/Heavy Low / Med Oil enamels Heavy Heavy Med-Hi Latex paints plus primers, Latex Heavy Med-Hi paints Oil or latex primers Heavy Med-Hi English © Wagner Spray Tech - All Rights Reserved... -
Page 9: Spray Pattern Adjustment
*note: The air cap can be set diagonally on the Detail Finish nozzle only. To achieve a round pattern with the iSpray nozzle, see the “Adjust Spray Width” section. English © Wagner Spray Tech - All Rights Reserved... -
Page 10: Proper Spraying Technique
Doing this will help avoid irregularities in the finish (i. e. runs and sags). Even coat throughout Correct 6 - 8 inches Keep stroke smooth and at an even speed English © Wagner Spray Tech - All Rights Reserved... - Page 11 • Spray gun movement - moving the gun too quickly will cause the spray pattern to be too thin and excess overspray. Moving the gun too slowly will cause the spray pattern to be too coarse or thick. English © Wagner Spray Tech - All Rights Reserved...
-
Page 12: Cleanup
IMPORTanT: If you cleaned the sprayer using mineral spirits, repeat steps 1-6 using warm, soapy water. Move on to “Cleanup - Cleaning the nozzle”, next page. PULL Empty waste container English © Wagner Spray Tech - All Rights Reserved... - Page 13 (the side with the groove) is occurs, make sure to pull it facing out towards the front of the out. nozzle. Improper installation will cause leakage and damage to the turbine. Groove English © Wagner Spray Tech - All Rights Reserved...
-
Page 14: Reassembly
Make sure the air valve tube is free of paint. If not, clean the air valve tube by following the instructions on the next page. If clean, make sure it is attached securely at both ends (see inset). English © Wagner Spray Tech - All Rights Reserved... -
Page 15: Maintenance
Turning the nozzle upside down will prevent the valve seal from falling out of the valve cover during reinstallation. 4. Place the air tube on the valve cover and on the nipple at the nozzle. English © Wagner Spray Tech. - All Rights Reserved... -
Page 16: Troubleshooting
Have you tried the recommendations above and are still having problems? In the United States, to speak to a customer service representative, call our Technical Service at 1-800-328-8251. See www.wagnerspraytech.com in the “Contact Us” section for Technical Service hours. English © Wagner Spray Tech. - All Rights Reserved... -
Page 17: Parts List
Turbina (incluye le item 2) articulo 2) 2307279 Filter Filtre Filtro 0414219 Air hose Tuyau d’air Manguera de aire 2303300 Turbine handle Poignée de pistolet Asa de pistola Français Español English English © Wagner Spray Tech. - All Rights Reserved... - Page 18 Tube / Joint de clapet Tube / Junta de la válvula 0417474 Seal Joint Sello 0417473 Suction tube Tube d’aspiration Tubo de succión 2303366 Material container Réservoir de liquide Recipiente Français English Español © Wagner Spray Tech - All Rights Reserved...
- Page 19 Container seal Joint d’étanchéité de Sello de recipiente réservoir 0417357 Suction tube Tube d’aspiration Tubo de succión 0414313 Material container (20 oz) Réservoir de liquide (600 ml) Recipiente (600 ml) Français Español English © Wagner Spray Tech - All Rights Reserved...
- Page 20 Français English Español © Wagner Spray Tech - All Rights Reserved...
