- Page 1 P-2612HNU-Fx 802.11n ADSL2+ VoIP IAD Firmware V3.00 Edition 1, 1/2010 DEFAULT LOGIN DETAILS IP Address: http://192.168.1.1 User Login: User Name: user Password: 1234 Administrator User Name: admin Login: Password: 1234 Copyright 2010 ZyXEL Communications Corporation www.zyxel.com...
- Page 2 Device Panels INTERNET POWER WLAN WLAN PHONE 1, 2 ETHERNET BUTTON LEDS DSL/WAN RESET ON/OFF ETHERNET PHONE PORTS PORT PORTS POWER PORT PORTS...
- Page 3 Overview The P-2612HNU-Fx is an ADSL Integrated Access Device (IAD) which combines high-speed ADSL Internet access, a built-in switch, a firewall and high-speed wireless networking capability. It also has a USB 2.0 port for sharing files via a USB compatible storage device and two phone ports for making calls over the Internet (Voice over IP or VoIP).
-
Page 4: Hardware Connections
• Internet Explorer 6.0 or later or Netscape Navigator 7.0 or later, with JavaScript enabled. See the User’s Guide on the CD for all configuration details including setting up a shared printer. Hardware Connections Remove the P-2612HNU-Fx’s plastic cover before using it. - Page 5 1. Do one of the following for your Internet connection: a. DSL: Use a telephone wire to connect this port to a telephone jack (or the DSL or MODEM jack on a splitter, if you have one). b. WAN: If you have a DSL router or modem already in your network or you want to use a cable modem, push the DSL/WAN switch to the WAN side and use an Ethernet cable to connect this port to an Ethernet jack with Internet access.
- Page 6 • The POWER light blinks during start-up and is green once the P- 2612HNU-Fx is ready. • An ETHERNET light turns on if the corresponding ETHERNET port is properly connected. An Ethernet port’s light blinks when the P- 2612HNU-Fx is sending or receiving data through it. •...
- Page 7 Log into the Web Configurator 1. Open your browser and enter http://192.168.1.1 (the P-2612HNU- Fx's default IP address) as the address. 2. For administrator login, enter username admin and password 1234 (default). Only administrators can configure the SIP account settings. For user login, enter user as the username and 1234 as the password.
-
Page 8: Set Up A Wireless Network
See your User’s Guide for how to use the Network > WAN screen to set up the WAN connection: • If the DSL/WAN switch is set to DSL and the DSL light is on but the INTERNET light is off. •... - Page 9 • Push Button Configuration - create a secure wireless network simply by pressing the P-2612HNU-Fx’s physical WPS button. See Push Button Configuration on page 9. • PIN Configuration - create a secure wireless network by entering your wireless device’s PIN (Personal Identification Number) into the configuration screen of the P-2612HNU-Fx.
- Page 10 5. Congratulations! Your computer is now ready to connect to the Internet wirelessly through your P-2612HNU-Fx. PIN Configuration 1. Place a WPS-enabled device that is installed in your computer and supports the WPS PIN configuration method within range of the P- 2612HNU-Fx.
- Page 11 4. Enter the PIN of the other WPS-enabled device into the Input Station’s PIN number text box and click Start. You can locate this PIN number in the other device’s utility or on the device itself. See the other device’s documentation if you cannot locate the PIN. 5.
- Page 12 Set Up a Wireless Network Manually Configure wireless devices to use the same wireless settings as the P- 2612HNU-Fx. If you didn’t configure the P-2612HNU-Fx’s wireless settings, use the wireless SSID (network name) and WPA-PSK encryption key on the P-2612HNU-Fx’s rear panel. The connection procedure is shown here using Windows XP as an example.
- Page 13 3. You are prompted to enter a password. Enter it and click Connect. 4. You may have to wait several minutes while your computer connects to the wireless network. 5. You should now be securely connected wirelessly to the P-2612HNU- Congratulations! Your computer is now ready to connect to the Internet wirelessly through your P-2612HNU-Fx.
- Page 14 • To dial a SIP number that only uses numbers (for example, “12345”), dial the number on your phone’s keypad. You can also set up a speed-dial entry, if you want. See the User’s Guide for instructions. • To dial a SIP number that uses letters, set up a speed-dial entry first.
- Page 15 Phone Functions Summary Keys Function Description *98# Call transfer Transfer a call to another phone. *92# Call return Place a call to the last person who called you. *95# Enable Do Use these to set your phone not to ring when someone calls Not Disturb you, or to turn this function off.
-
Page 16: Usb File Sharing
Keys Function Description #31# One Shot Activate call waiting on the next call only. Caller ID Display Deactivate call waiting on the next call only. *31* One Shot Caller ID Hidden To call into the phone that is attached to the P-2612HNU-Fx, use your VoIP service provider’s dialing plan. - Page 17 2. Check the box Enable File Sharing Services and click Apply. The P-2612HNU-Fx automatically recognizes the USB device which is connected to the USB port and makes it available for sharing (shown in the figure above). Browse to the USB File Share 1.
- Page 18 2. Enter the user name and password in the window prompt that appears and hit OK. 3. The files on the USB file sharing device connected to the P- 2612HNU-Fx are now part of your file structure and you can manage those files just like any other files on your computer.
