DIFFERENCE FEATURE LIST
Clarion No.
Destination
QC-6820E-A
Europe
QC-6820K-C
Australia
The difference of the specification between QC-6820E-A
and QC-6820K-C is only a region code.
SPECIFICATIONS
FM tuner section
Frequency range:
87.5MHz to 108.0MHz
Usable sensitivity:
9dBf
50dB quieting sensitivity:
15dBf
Alternate channel selectivity:
70dB
Stereo separation:
35dB(1kHz)
Frequency response:
30Hz to 15kHz(+3/-3dB)
AM tuner section
Frequency range:
MW
LW
Usable sensitivity:
28dBu
DVD player section
System:
Digital versatile disc system with
CDDA capable
Usable discs:
DVD video disc,Compact disc
Frequency response:
20Hz to 20kHz(CD)(+1/-1dB)
Signal to noise ratio:
100dB(1kHz)IHF-A
Dynamic range:
100dB(1kHz)
Distortion:
0.01%
Audio amplifier section
Rated power output:
18W x 4(20Hz to 20kHz, 1%, 4 ohm)
Max. power output:
204W(51W x 4)
Speaker impedance:
4 ohm(4 to 8 ohm)
Clarion Co., Ltd.
50 Kamitoda, Toda-shi, Saitama 335-8511 Japan
Service Dept.: 5-66 Azuma , Kitamoto-shi, Saitama 364-0007 Japan
Tel: +81-48-541-2335 / 2432 FAX: +81-48-541-2703
Video system
Region code
PAL
Region 2
PAL
Region 4
531kHz to 1602kHz
153kHz to 279kHz
- 1 -
Service Manual
RDS-EON RADIO/DVD MULTIMEDIA
CENTER WITH CeNET CONTROL
QC-6820E-A
Model
QC-6820K-C
Model
Input section
Video input:
Audio input:
Video output section
Video output:
LCD monitor section
Screen size:
Display method:
Drive method:
Pixels:
General
Power source voltage: 14.4V DC
Ground:
Current consumption: 4.0A(1W)
Auto antenna rated current:
Dimensions(mm):
Weight:
*
Specifications comply with JEITA Standards.
Published by Service Dept.
298-6202-00 Nov.2004
Printed in Japan
1.0V +0.2/-0.2 Vp-p
(input impedance 75 ohm)
130mV +60/-60m Vrms(High)
600mV +80/-80m Vrms(Mid)
840mV +100/-100m Vrms(Low)
(input impedance 10k ohm or
greater)
1.0V +0.2/-0.2 Vp-p
(output impedance 75 ohm)
7-inch wide type
(152mm Width x 85mm Height)
Transmission type TN Liquid
Crystal Display
TFT(thin-film transistor) active
matrix driving
336,960(1440x234)
(10.8 to 15.6V allowable)
Negative
500mA less
Main unit
178(W)x50(H)x165(D)
Remote control unit
54(W)x28.8(H)x155(D)
Main unit 2.4kg
Remote control unit 100g
(including battery)
VRX848RVD
VRX746VD
