Page 1 VIPA System 300S SM-DIO | | Manual HB140 | SM-DIO | | en | Rev. 16-43 Digital signal modules - SM 32x(S) www.vipa.com/en/service-support/manual...
Page 2 VIPA GmbH Ohmstr. 4 91074 Herzogenaurach Telephone: 09132-744-0 Fax: 09132-744-1864 Email: info@vipa.com Internet: www.vipa.com 300S_SM-DIO,4,GB - © 2016...
Page 3: Table Of Contents
VIPA System 300S Table of contents Table of contents Basics........................5 1.1 Copyright © VIPA GmbH ................. 5 1.2 About this manual..................... 6 1.3 Safety information..................... 7 Assembly and installation guidelines..............8 2.1 Safety information for users................8 2.2 Overview......................9 2.3 Installation dimensions..................
Page 4 VIPA System 300S Table of contents 5.2.1 Technical data....................77 5.3 323-1BL00 - DI 16xDC 24V, DO 16xDC 24V 1A..........80 5.3.1 Technical data....................82 Digital Modules FAST - SPEED-Bus..............85 6.1 Addressing at SPEED-Bus................85 6.2 Project engineering..................85 6.2.1 Fast introduction..................
Page 5: Basics
VIPA System 300S Basics Copyright © VIPA GmbH Basics 1.1 Copyright © VIPA GmbH All Rights Reserved This document contains proprietary information of VIPA and is not to be disclosed or used except in accordance with applicable agreements. This material is protected by the copyright laws. It may not be reproduced, distributed, or...
Page 6: About This Manual
VIPA System 300S Basics About this manual VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany Telefax: +49 9132 744-1204 EMail: documentation@vipa.de Technical support Contact your local VIPA Customer Service Organization representative if you encounter problems with the product or have questions regarding the product. If you are unable to locate a customer service centre, contact VIPA as follows: VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany...
Page 7: Safety Information
VIPA System 300S Basics Safety information 1.3 Safety information Applications conforming The system is constructed and produced for: with specifications communication and process control general control and automation tasks industrial applications operation within the environmental conditions specified in the technical data...
Page 8: Assembly And Installation Guidelines
VIPA System 300S Assembly and installation guidelines Safety information for users Assembly and installation guidelines 2.1 Safety information for users Handling of electrostatic VIPA modules make use of highly integrated components in MOS-Technology. These sensitive modules components are extremely sensitive to over-voltages that can occur during electrostatic discharges.
Page 9: Overview
VIPA System 300S Assembly and installation guidelines Installation dimensions 2.2 Overview General While the standard peripheral modules are plugged-in at the right side of the CPU, the SPEED-Bus peripheral modules are connected via a SPEED-Bus bus connector at the left side of the CPU. VIPA delivers profile rails with integrated SPEED-Bus for 2, 6 or 10 SPEED-Bus peripheral modules with different lengths.
Page 10 VIPA System 300S Assembly and installation guidelines Installation dimensions Dimensions Installation dimensions HB140 | SM-DIO | | en | Rev. 16-43...
Page 11: Assembly Speed-Bus
VIPA System 300S Assembly and installation guidelines Assembly SPEED-Bus 2.4 Assembly SPEED-Bus Pre-manufactured SPEED- For the deployment of SPEED-Bus modules, a pre-manufactured SPEED-Bus rail is Bus profile rail required. This is available mounted on a profile rail with 2, 6 or 10 extension slots.
Page 12 VIPA System 300S Assembly and installation guidelines Assembly SPEED-Bus Installation of the profile Bolt the profile rail with the background (screw size: M6), so that you still have min- rail imum 65mm space above and 40mm below the profile rail. Please look for a low- impedance connection between profile rail and background.
Page 13 VIPA System 300S Assembly and installation guidelines Assembly SPEED-Bus To connect the SPEED-Bus modules, plug it between the triangular positioning helps to a slot marked with "SLOT ..." and pull it down. Only the "SLOT1 DCDC" allows you to plug-in either a SPEED-Bus module or an additional power supply.
Page 14: Assembly Standard Bus
VIPA System 300S Assembly and installation guidelines Assembly standard bus CAUTION! – The power supplies must be released before installation and repair tasks, i.e. before handling with the power supply or with the cabling you must disconnect current/voltage (pull plug, at fixed connection switch off the concerning fuse)! –...
Page 15 VIPA System 300S Assembly and installation guidelines Assembly standard bus Bus connector For the communication between the modules the System 300S uses a backplane bus connector. Backplane bus connectors are included in the delivering of the peripheral modules and are clipped at the module from the backside before installing it to the profile rail.
Page 16: Cabling
VIPA System 300S Assembly and installation guidelines Cabling Click the CPU downwards and bolt it like shown. Repeat this procedure with the peripheral modules, by clicking a backplane bus connector, stick the module right from the modules you've already fixed, click it downwards and connect it with the backplane bus connector of the last module and bolt it.
Page 17 VIPA System 300S Assembly and installation guidelines Cabling CageClamp technology For the cabling of power supply of a CPU, a green plug with CageClamp technology is (green) deployed. The connection clamp is realized as plug that may be clipped off carefully if it is still cabled.
Page 18 VIPA System 300S Assembly and installation guidelines Cabling 20pole screw connection 392-1AJ00 Open the front flap of your I/O module. Bring the front connector in cabling position. For this you plug the front connector on the module until it locks. In this position the front connector juts out of the module and has no contact yet.
Page 19: Installation Guidelines
VIPA System 300S Assembly and installation guidelines Installation guidelines 40pole screw connection 392-1AM00 Open the front flap of your I/O module. Bring the front connector in cabling position. For this you plug the front connector on the module until it locks. In this position the front connector juts out of the module and has no contact yet.
Page 20 VIPA System 300S Assembly and installation guidelines Installation guidelines What does EMC mean? Electromagnetic compatibility (EMC) means the ability of an electrical device, to function error free in an electromagnetic environment without being interfered respectively without interfering the environment. The components of VIPA are developed for the deployment in industrial environments and meets high demands on the EMC.
Page 21: General Data I/O Modules
VIPA System 300S Assembly and installation guidelines General data I/O modules In special use cases you should appoint special EMC actions. – Consider to wire all inductivities with erase links. – Please consider luminescent lamps can influence signal lines. Create a homogeneous reference potential and ground all electrical operating sup- plies when possible.
Page 22: General Data
VIPA System 300S Assembly and installation guidelines General data I/O modules > General data Reliability Wiring by means of spring pressure connections (CageClamps) at the front connector Core cross-section 0.08 ... 2.5mm or 1.5 mm Total isolation of the wiring at module change Potential separation of all modules to the backplane bus 2.8.1 General data...
Page 23 VIPA System 300S Assembly and installation guidelines General data I/O modules > General data Environmental conditions to EN 61131-2 Oscillation EN 60068-2-6 1g, 9Hz ... 150Hz Shock EN 60068-2-27 15g, 11ms Mounting conditions Mounting place In the control cabinet Mounting position...
Page 24: Digital Input Modules
VIPA System 300S Digital Input Modules 321-1BH01 - DI 16xDC 24V Digital Input Modules 3.1 321-1BH01 - DI 16xDC 24V Properties The digital input module collects the binary control signals from the process level and transmits them isolated to the superordinate bus system. It has 16 channels and their status is monitored via LEDs.
Page 25: Technical Data
VIPA System 300S Digital Input Modules 321-1BH01 - DI 16xDC 24V > Technical data Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram not used LEDs (green) I+0.0 to I+1.7 Input I+0.0 from ca. 15V on, the signal is recognized as Input I+0.7...
Page 26 VIPA System 300S Digital Input Modules 321-1BH01 - DI 16xDC 24V > Technical data Order no. 321-1BH01 Number of inputs Cable length, shielded 1000 m Cable length, unshielded 600 m Rated load voltage Current consumption from load voltage L+ (without load) Rated value DC 20.4...28.8 V...
Page 27: 321-1Bl00 - Di 32Xdc 24V
VIPA System 300S Digital Input Modules 321-1BL00 - DI 32xDC 24V Order no. 321-1BH01 Datasizes Input bytes Output bytes Parameter bytes Diagnostic bytes Housing Material Mounting Rail System 300 Mechanical data Dimensions (WxHxD) 40 mm x 125 mm x 120 mm...
Page 28 VIPA System 300S Digital Input Modules 321-1BL00 - DI 32xDC 24V Structure LEDs flap with labeling strip contact bar flap opened with inner label Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram not used LEDs (green) I+0.0 to I+3.7 2...9...
Page 29: Technical Data
VIPA System 300S Digital Input Modules 321-1BL00 - DI 32xDC 24V > Technical data Schematic diagram Numeric representation 3.2.1 Technical data Order no. 321-1BL00 Type SM 321 SPEED-Bus Current consumption/power loss Current consumption from backplane bus 35 mA Power loss 6.5 W...
Page 30 VIPA System 300S Digital Input Modules 321-1BL00 - DI 32xDC 24V > Technical data Order no. 321-1BL00 Input resistance Input current for signal "1" 7 mA Connection of Two-Wire-BEROs possible ü Max. permissible BERO quiescent current 1.5 mA Input delay of "0" to "1"...
Page 31: 321-1Fh00 - Di 16Xac120/230V
VIPA System 300S Digital Input Modules 321-1FH00 - DI 16xAC120/230V Order no. 321-1BL00 Weight 240 g Environmental conditions Operating temperature 0 °C to 60 °C Storage temperature -25 °C to 70 °C Certifications UL certification KC certification 3.3 321-1FH00 - DI 16xAC120/230V...
Page 32 VIPA System 300S Digital Input Modules 321-1FH00 - DI 16xAC120/230V Pin assignment Circuit diagram Status monitor Assignment Circuit diagram Description Neutral LEDs (green) conductor I+0.0 to I+0.7 I+1.0 to I+1.7 Input I+0.0 from ca. AC 79V on, Input I+0.1 the signal is recog- Input I+0.2...
Page 33: Technical Data
VIPA System 300S Digital Input Modules 321-1FH00 - DI 16xAC120/230V > Technical data 3.3.1 Technical data Order no. 321-1FH00 Type SM 321 SPEED-Bus Current consumption/power loss Current consumption from backplane bus 35 mA Power loss Technical data digital inputs Number of inputs...
Page 34 VIPA System 300S Digital Input Modules 321-1FH00 - DI 16xAC120/230V > Technical data Order no. 321-1FH00 Group error display none Channel error display none Isolation Between channels ü Between channels of groups to Between channels and backplane bus ü Insulation tested with...
Page 35: Digital Output Modules
VIPA System 300S Digital Output Modules Safe shutdown of non-safe outputs > Safe shutdown Digital Output Modules 4.1 Safe shutdown of non-safe outputs 4.1.1 Introduction General In this section, a security concept is shown, which shows how the safe shutdown of non- safe outputs in the System 300S can be realized.
Page 36: Requirements And Fault Exclusions
VIPA System 300S Digital Output Modules Safe shutdown of non-safe outputs > Requirements and fault exclusions System 300S output module (group) Safety switch DC 24V power section supply 4.1.3 Requirements and fault exclusions Precondition On this way the product reaches a MTTdF value (Mean Time To dangerous Failure:...
Page 37 VIPA System 300S Digital Output Modules Safe shutdown of non-safe outputs > Requirements and fault exclusions Actuators which are connected to the outputs of the DO modules are: – not allowed switching-on a maximum leak current of 2mA – not allowed switching-on at an output voltage of up to 5V.
Page 38: 322-1Bf01 - Do 8Xdc 24V 2A
VIPA System 300S Digital Output Modules 322-1BF01 - DO 8xDC 24V 2A 4.2 322-1BF01 - DO 8xDC 24V 2A Properties The digital output module collects the binary control signals from the superordinate bus system and transmits them isolated to the process level. The module has to be provided with 24V via the front slot.
Page 39: Technical Data
VIPA System 300S Digital Output Modules 322-1BF01 - DO 8xDC 24V 2A > Technical data Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram Supply voltage 1L+, LED (green) DC 24V (1L+) supply voltage is on Output Q+0.0 LEDs (green) Q+0.0 to Q+0.7...
Page 40 VIPA System 300S Digital Output Modules 322-1BF01 - DO 8xDC 24V 2A > Technical data Order no. 322-1BF01 Technical data digital outputs Number of outputs Cable length, shielded 1000 m Cable length, unshielded 600 m Rated load voltage DC 24 V...
Page 41: 322-1Bh01 - Do 16Xdc 24V 1A
VIPA System 300S Digital Output Modules 322-1BH01 - DO 16xDC 24V 1A Order no. 322-1BF01 Isolation Between channels ü Between channels of groups to Between channels and backplane bus ü Insulation tested with DC 500 V Datasizes Input bytes Output bytes...
Page 42 VIPA System 300S Digital Output Modules 322-1BH01 - DO 16xDC 24V 1A Structure LEDs flap with labeling strip contact bar flap opened with inner label HB140 | SM-DIO | | en | Rev. 16-43...
Page 43: Technical Data
VIPA System 300S Digital Output Modules 322-1BH01 - DO 16xDC 24V 1A > Technical data Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram Supply voltage 1L+, LED (green) DC 24V (1L+) supply voltage is on LEDs (green) Q+0.0 to Q+1.7...
Page 44 VIPA System 300S Digital Output Modules 322-1BH01 - DO 16xDC 24V 1A > Technical data Order no. 322-1BH01 Technical data digital outputs Number of outputs Cable length, shielded 1000 m Cable length, unshielded 600 m Rated load voltage DC 24 V...
Page 45: 322-1Bh41 - Do 16Xdc 24V 2A
VIPA System 300S Digital Output Modules 322-1BH41 - DO 16xDC 24V 2A Order no. 322-1BH01 Isolation Between channels ü Between channels of groups to Between channels and backplane bus ü Insulation tested with DC 500 V Datasizes Input bytes Output bytes...
Page 46 VIPA System 300S Digital Output Modules 322-1BH41 - DO 16xDC 24V 2A Structure LEDs flap with labeling strip contact bar flap opened with inner label HB140 | SM-DIO | | en | Rev. 16-43...
Page 47 VIPA System 300S Digital Output Modules 322-1BH41 - DO 16xDC 24V 2A Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram Supply voltage 1L+, LED (green) DC 24V (1L+) supply voltage is on LEDs (green) Q+0.0 to Q+1.7 As soon as an output...
Page 48: Technical Data
VIPA System 300S Digital Output Modules 322-1BH41 - DO 16xDC 24V 2A > Technical data 4.4.1 Technical data Order no. 322-1BH41 Type SM 322 SPEED-Bus Current consumption/power loss Current consumption from backplane bus 110 mA Power loss Technical data digital outputs...
Page 49 VIPA System 300S Digital Output Modules 322-1BH41 - DO 16xDC 24V 2A > Technical data Order no. 322-1BH41 Diagnostic interrupt Diagnostic functions Diagnostics information read-out none Supply voltage display green LED per group Group error display red SF LED Channel error display...
Page 50: 322-1Bh60 - Do 16Xdc 24V 0.5A For Manual Operation
VIPA System 300S Digital Output Modules 322-1BH60 - DO 16xDC 24V 0.5A for manual operation 4.5 322-1BH60 - DO 16xDC 24V 0.5A for manual operation Properties The module is configured as in-/output module. It has 16 channels and their status is monitored via LEDs.
Page 51 VIPA System 300S Digital Output Modules 322-1BH60 - DO 16xDC 24V 0.5A for manual operation Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram Supply voltage DC LED (green) supply voltage is on Output Q+0.0 LEDs (green) Q+0.0 to Q+1.7...
Page 52: Deployment
VIPA System 300S Digital Output Modules 322-1BH60 - DO 16xDC 24V 0.5A for manual operation > Technical data 4.5.1 Deployment Please regard that the module is installed as 323-1BL00. You are allowed to request the switch position of the according channel via the input word. For this is valid:...
Page 53 VIPA System 300S Digital Output Modules 322-1BH60 - DO 16xDC 24V 0.5A for manual operation > Technical data Order no. 322-1BH60 Total current per group, vertical configuration Output current at signal "1", rated value 0.5 A Output delay of "0" to "1"...
Page 54: 322-1Bl00 - Do 32Xdc 24V 1A
VIPA System 300S Digital Output Modules 322-1BL00 - DO 32xDC 24V 1A Order no. 322-1BH60 Parameter bytes Diagnostic bytes Housing Material Mounting Rail System 300 Mechanical data Dimensions (WxHxD) 40 mm x 125 mm x 120 mm Weight 230 g...
Page 55 VIPA System 300S Digital Output Modules 322-1BL00 - DO 32xDC 24V 1A Structure LEDs flap with labeling strip contact bar flap opened with inner label HB140 | SM-DIO | | en | Rev. 16-43...
Page 56 VIPA System 300S Digital Output Modules 322-1BL00 - DO 32xDC 24V 1A Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram Supply voltage 1L+ 1/3L+, LED (green) 2/4L+ supply voltage is on Output Q+0.0 LEDs (green) Q+0.0 to Q+3.7...
Page 57: Deployment
VIPA System 300S Digital Output Modules 322-1BL00 - DO 32xDC 24V 1A > Technical data 4.6.1 Deployment Numeric representation From the application level to the hardware level the data is stored in Motorola-Format, i.e. "ready for reading". The following picture shows the output of the number 287454020dez res.
Page 58 VIPA System 300S Digital Output Modules 322-1BL00 - DO 32xDC 24V 1A > Technical data Order no. 322-1BL00 Parallel switching of outputs for redundant control of a load possible (only outputs group) Parallel switching of outputs for increased power not possible Actuation of digital input ü...
Page 59: 322-5Ff00 - Do 8Xac 120/230V 2A
VIPA System 300S Digital Output Modules 322-5FF00 - DO 8xAC 120/230V 2A Order no. 322-1BL00 Dimensions (WxHxD) 40 mm x 125 mm x 120 mm Net weight 260 g Weight including accessories Gross weight Environmental conditions Operating temperature 0 °C to 60 °C Storage temperature -25 °C to 70 °C...
Page 60 VIPA System 300S Digital Output Modules 322-5FF00 - DO 8xAC 120/230V 2A Structure LEDs flap with labeling strip contact bar flap opened with inner label HB140 | SM-DIO | | en | Rev. 16-43...
Page 61 VIPA System 300S Digital Output Modules 322-5FF00 - DO 8xAC 120/230V 2A Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram Rated load voltage LED (red) Group error LED, error if module is not Q+0.0 supplied with param- eters by the CPU...
Page 62: Parameterization
VIPA System 300S Digital Output Modules 322-5FF00 - DO 8xAC 120/230V 2A > Parameterization CAUTION! The outputs must be protected by a fast-acting 3.15A, AC 250V fuse. When mounted in a hazardous area, the fuse may only be removed by a tool.
Page 63: Technical Data
VIPA System 300S Digital Output Modules 322-5FF00 - DO 8xAC 120/230V 2A > Technical data Byte Bit 7 ... Bit 0 Default value Reaction to CPU Stop Bit 0: Keep last valid value Bit 1: Substitute a value Bit 6: reserved...
Page 64 VIPA System 300S Digital Output Modules 322-5FF00 - DO 8xAC 120/230V 2A > Technical data Order no. 322-5FF00 Rated load voltage AC 120/230 V Current consumption from load voltage L+ (without load) 2 mA Total current per group, horizontal configuration, 40°C Total current per group, horizontal configuration, 60°C...
Page 65: 322-1Hh00 - Do 16Xrelay
VIPA System 300S Digital Output Modules 322-1HH00 - DO 16xRelay Order no. 322-5FF00 Insulation tested with AC 1500 V Datasizes Input bytes Output bytes Parameter bytes Diagnostic bytes Housing Material Mounting Rail System 300 Mechanical data Dimensions (WxHxD) 40 mm x 125 mm x 120 mm...
Page 66 VIPA System 300S Digital Output Modules 322-1HH00 - DO 16xRelay Structure LEDs flap with labeling strip contact bar flap opened with inner label HB140 | SM-DIO | | en | Rev. 16-43...
Page 67 VIPA System 300S Digital Output Modules 322-1HH00 - DO 16xRelay Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram LED (green) Q+0.0 to Q+1.7 Relay-Output Q+0.0 As soon as an output is active, the Relay-Output Q+0.7 according LED is...
Page 68: Technical Data
VIPA System 300S Digital Output Modules 322-1HH00 - DO 16xRelay > Technical data Maximum toggle capacity Life Time 4.8.1 Technical data Order no. 322-1HH00 Type SM 322 SPEED-Bus Current consumption/power loss Current consumption from backplane bus 80 mA Power loss...
Page 69 VIPA System 300S Digital Output Modules 322-1HH00 - DO 16xRelay > Technical data Order no. 322-1HH00 Switching frequency on lamp load max. 0.33 Hz Internal limitation of inductive shut-off voltage Short-circuit protection of output Trigger level Number of operating cycle of relay outputs...
Page 70 VIPA System 300S Digital Output Modules 322-1HH00 - DO 16xRelay > Technical data Order no. 322-1HH00 Certifications UL certification KC certification HB140 | SM-DIO | | en | Rev. 16-43...
Page 71: Digital Input/Output Modules
VIPA System 300S Digital Input/Output Modules 323-1BH00 - DIO 16xDC 24V 1A Digital Input/Output Modules 5.1 323-1BH00 - DIO 16xDC 24V 1A Properties The module is a combined module. It has 16 channels that can be used either as inputs or outputs.
Page 72 VIPA System 300S Digital Input/Output Modules 323-1BH00 - DIO 16xDC 24V 1A Pin assignment Circuit diagram Status monitor Assignment Circuit diagram Description Supply voltage 1L+, LED (green) +DC 24V (1L+) supply voltage is on In-/Output I/Q+0.0 In-/Output I/Q+0.7 Ground 1...
Page 73: Technical Data
VIPA System 300S Digital Input/Output Modules 323-1BH00 - DIO 16xDC 24V 1A > Technical data 5.1.1 Technical data Order no. 323-1BH00 Type SM 323 SPEED-Bus Current consumption/power loss Current consumption from backplane bus 130 mA Power loss Technical data digital inputs...
Page 74 VIPA System 300S Digital Input/Output Modules 323-1BH00 - DIO 16xDC 24V 1A > Technical data Order no. 323-1BH00 Output delay of "0" to "1" 150 µs Output delay of "1" to "0" 100 µs Minimum load current Lamp load Parallel switching of outputs for redundant control of a load possible (only outputs group)
Page 75: 323-1Bh01 - Di 8Xdc 24V, Do 8Xdc 24V 1A
VIPA System 300S Digital Input/Output Modules 323-1BH01 - DI 8xDC 24V, DO 8xDC 24V 1A Order no. 323-1BH00 Housing Material Mounting Rail System 300 Mechanical data Dimensions (WxHxD) 40 mm x 125 mm x 120 mm Weight 230 g Environmental conditions Operating temperature 0 °C to 60 °C...
Page 76 VIPA System 300S Digital Input/Output Modules 323-1BH01 - DI 8xDC 24V, DO 8xDC 24V 1A Structure LEDs flap with labeling strip contact bar flap opened with inner label CAUTION! Please regard that the voltage applied to an output channel must be £ the voltage supply applied to L+.
Page 77: Technical Data
VIPA System 300S Digital Input/Output Modules 323-1BH01 - DI 8xDC 24V, DO 8xDC 24V 1A > Technical data Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram Not used LED (green) supply voltage is on Input I+0.0 LED (green) I+0.0 ...
Page 78 VIPA System 300S Digital Input/Output Modules 323-1BH01 - DI 8xDC 24V, DO 8xDC 24V 1A > Technical data Order no. 323-1BH01 Number of inputs Cable length, shielded 1000 m Cable length, unshielded 600 m Rated load voltage DC 24 V...
Page 79 VIPA System 300S Digital Input/Output Modules 323-1BH01 - DI 8xDC 24V, DO 8xDC 24V 1A > Technical data Order no. 323-1BH01 Switching frequency with resistive load max. 1000 Hz Switching frequency with inductive load max. 0.5 Hz Switching frequency on lamp load max.
Page 80: 323-1Bl00 - Di 16Xdc 24V, Do 16Xdc 24V 1A
VIPA System 300S Digital Input/Output Modules 323-1BL00 - DI 16xDC 24V, DO 16xDC 24V 1A Order no. 323-1BH01 Operating temperature 0 °C to 60 °C Storage temperature -25 °C to 70 °C Certifications UL certification KC certification 5.3 323-1BL00 - DI 16xDC 24V, DO 16xDC 24V 1A...
Page 81 VIPA System 300S Digital Input/Output Modules 323-1BL00 - DI 16xDC 24V, DO 16xDC 24V 1A CAUTION! Please regard that the voltage applied to an output channel must be £ the voltage supply applied to L+. Due to the parallel connection of in- and output channel per group, a set output channel may be supplied via an applied input signal.
Page 82: Technical Data
VIPA System 300S Digital Input/Output Modules 323-1BL00 - DI 16xDC 24V, DO 16xDC 24V 1A > Technical data Schematic diagram 5.3.1 Technical data Order no. 323-1BL00 Type SM 323 SPEED-Bus Current consumption/power loss Current consumption from backplane bus 130 mA Power loss 5.8 W...
Page 83 VIPA System 300S Digital Input/Output Modules 323-1BL00 - DI 16xDC 24V, DO 16xDC 24V 1A > Technical data Order no. 323-1BL00 Technical data digital outputs Number of outputs Cable length, shielded 1000 m Cable length, unshielded 600 m Rated load voltage...
Page 84 VIPA System 300S Digital Input/Output Modules 323-1BL00 - DI 16xDC 24V, DO 16xDC 24V 1A > Technical data Order no. 323-1BL00 Between channels of groups to Between channels and backplane bus ü Insulation tested with DC 500 V Datasizes Input bytes...
Page 85: Digital Modules Fast - Speed-Bus
VIPA System 300S Digital Modules FAST - SPEED-Bus Project engineering Digital Modules FAST - SPEED-Bus 6.1 Addressing at SPEED-Bus Overview To provide specific addressing of the installed peripheral modules, certain addresses must be allocated in the CPU. With no hardware configuration present, the CPU assigns automatically peripheral I/O addresses during boot procedure depending on the plug-in location amongst others also for plugged modules at the SPEED-Bus.
Page 86: Fast Introduction
VIPA System 300S Digital Modules FAST - SPEED-Bus Project engineering > Preconditions 6.2.1 Fast introduction For the employment of the I/O modules at the SPEED-Bus the inclusion via the GSD-file from VIPA in the hardware catalog is required. To be compatible with the Siemens SIMATIC manager, you have to execute the following steps: Start the hardware configurator from Siemens and include the speedbus.gsd for...
Page 87: Steps Of Project Engineering
VIPA System 300S Digital Modules FAST - SPEED-Bus Project engineering > Steps of project engineering Installation of the The GSD (Geräte-Stamm-Datei) is online available in the following language versions. SPEEDBUS.GSD Further language versions are available on inquires: Name Language SPEEDBUS.GSD German (default) SPEEDBUS.GSG...
Page 88 VIPA System 300S Digital Modules FAST - SPEED-Bus Project engineering > Steps of project engineering Project engineering of the The modules at the right side of the CPU at the standard bus are configured with the fol- modules at the standard...
Page 89: 321-1Bh70 - Di 16Xdc 24V
VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V 6.3 321-1BH70 - DI 16xDC 24V Properties The fast digital input module collects the binary control signals from the process level and transmits them galvanically separated to the superordinate bus system. It has 16 chan- nels and their status is monitored via LEDs.
Page 90 VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V Construction LEDs flap with labeling strip contact bar flap opened with inner label HB140 | SM-DIO | | en | Rev. 16-43...
Page 91 VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram DC 24V LEDs (green) I+0.0 to I+1.7 Input I+0.0 from ca. 15V on, the signal is recognized as "1"...
Page 92: Parameterization
VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Parameterization 6.3.1 Parameterization Depending on the project engineering, 2byte res. 48byte in the input range of the CPU where occupied by the module. For project engineering there are the following possibili-...
Page 93 VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Parameterization The record set has the following structure: Byte Bit 1 ... 0: Edge selection I+0.0 – 00b = de-activated – 01b = Process interrupt at ascending edge –...
Page 94 VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Parameterization Byte Bit 7 ... Bit 0 Bit 1, 0: Time stamp channel 0 (I+0.0) – 00 = no time stamp – 01 = Time stamp at ascending edge –...
Page 95 VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Parameterization Byte Bit 7 ... Bit 0 1. edge evaluation (1 = edge detected, 0 = no edge detected) Here the last presence of an edge since the last read access to the reg- ister is stored.
Page 96: Process Interrupt
VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Process interrupt Byte 44 ... 47 Byte Bit 7 ... Bit 0 2. edge evaluation (1 = edge detected, 0 = no edge detected). Here the last presence of an edge since the last read access to the FA1 register is stored.
Page 97: Diagnostic Interrupt
VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Diagnostic interrupt Local double word 8 of the The local double word 8 of the OB 40 has the following structure: OB 40 Local byte Bit 7 ... Bit 0 Bit 0: Edge at I+0.0...
Page 98 VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Diagnostic interrupt Example: Diagnostic interrupt pro- Every OB 82 call causes an entry in the diagnostic buffer of the CPU containing error cessing cause and module address. By using the SFC 59 you may read the diagnostic bytes. At de-activated diagnostic interrupt you have access to the last recent diagnostic event.
Page 99 VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Diagnostic interrupt Byte Bit 7...0 Bit 0: set at module failure Bit 1: 0 (fix) Bit 2: set at external error Bit 3: set at channel error Bit 4: set when external auxiliary supply is missing Bit 7 ...
Page 100: Technical Data
VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Technical data Byte Bit 7...0 Diagnostic interrupt due to "process interrupt lost" at... Bit 0: ... input I+0.4 Bit 1: 0 (fix) Bit 2: ... input I+0.5 Bit 3: 0 (fix) Bit 4: ...
Page 101 VIPA System 300S Digital Modules FAST - SPEED-Bus 321-1BH70 - DI 16xDC 24V > Technical data Order no. 321-1BH70 Rated value DC 24 V Input voltage for signal "0" DC 0...5 V Input voltage for signal "1" DC 15...28.8 V...
Page 102: 322-1Bh70 - Do 16Xdc 24V 0.5A
VIPA System 300S Digital Modules FAST - SPEED-Bus 322-1BH70 - DO 16xDC 24V 0.5A Order no. 321-1BH70 Housing Material Mounting DIN rail SPEED-Bus Mechanical data Dimensions (WxHxD) 40 mm x 125 mm x 120 mm Weight 190 g Environmental conditions Operating temperature 0 °C to 60 °C...
Page 103 VIPA System 300S Digital Modules FAST - SPEED-Bus 322-1BH70 - DO 16xDC 24V 0.5A Structure LEDs flap with labeling strip contact bar flap opened with inner label HB140 | SM-DIO | | en | Rev. 16-43...
Page 104 VIPA System 300S Digital Modules FAST - SPEED-Bus 322-1BH70 - DO 16xDC 24V 0.5A Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram Supply voltage 1L+, 2L+ LED (green) DC 24V (1L+) supply voltage is on Output Q+0.0 LEDs (green) Q+0.0 to Q+1.7...
Page 105: Technical Data
VIPA System 300S Digital Modules FAST - SPEED-Bus 322-1BH70 - DO 16xDC 24V 0.5A > Technical data 6.4.1 Technical data Order no. 322-1BH70 Type SM 322S - SPEED-Bus SPEED-Bus ü Current consumption/power loss Current consumption from backplane bus 390 mA...
Page 106: 323-1Bh70 - Dio 16Xdc 24V 0.5A
VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A Order no. 322-1BH70 Diagnostic interrupt Diagnostic functions Diagnostics information read-out none Supply voltage display green LED per group Group error display red SF LED Channel error display...
Page 107 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A Useable for switches, approximate switches, magnetic valve Activity monitoring of the channels via LED Structure LEDs flap with labeling strip contact bar flap opened with inner label CAUTION! Please regard that the voltage applied to an output channel must be £...
Page 108 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A Pin assignment Circuit diagram Status monitor Assignment Circuit Description diagram Supply voltage 1L+, 2L LED (green) +DC 24V (1L+) supply voltage is on I/Q +0.0 I/Q +0.7...
Page 109: Parameterization
VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Parameterization 6.5.1 Parameterization Dependent on project engineering 2byte each in the in and output range respectively 48byte in the input and 2byte in the output range of the CPU where occupied by the module.
Page 110 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Parameterization Record set 80h Edge Via this record set you may activate a process interrupt for I+0.0 ... I+1.7 and define for selection (Byte 0 ... 15) which edge of the input signal a process interrupt is thrown.
Page 111 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Parameterization Byte Bit 7 ... Bit 0 Bit 1, 0: Time stamp channel 0 (I+0.0) – 00 = no time stamp – 01 = Time stamp at ascending edge –...
Page 112 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Parameterization Byte Bit 7 ... Bit 0 1. edge evaluation (1 = edge detected, 0 = no edge detected) Here the last presence of an edge since the last read access to the reg- ister is stored.
Page 113 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Parameterization Byte 44 ... 47 Byte Bit 7 ... Bit 0 2. edge evaluation (1 = edge detected, 0 = no edge detected). Here the last presence of an edge since the last read access to the FA1 register is stored.
Page 114: Process Interrupt
VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Diagnostic interrupt Depending to the system, the SFC 14 (DPRD_DAT) "Read consistent data" cannot be used with this module. 6.5.2 Process interrupt Via the edge selection you may activate a process interrupt in your parameterization and define on which edge of the input signal a process interrupt should be initialized.
Page 115 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Diagnostic interrupt Example Diagnostic interrupt pro- Every OB 82 call causes an entry in the diagnostic buffer of the CPU containing error cessing cause and module address. By using the SFC 59 you may read the diagnostic bytes. At de-activated diagnostic interrupt you have access to the last recent diagnostic event.
Page 116 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Diagnostic interrupt Byte Bit 7 ... Bit 0 Bit 0: set at module failure Bit 1: 0 (fix) Bit 2: set at external error Bit 3: set at channel error Bit 4: set when external auxiliary supply is missing Bit 7 ...
Page 117: Technical Data
VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Technical data Byte Bit 7 ... Bit 0 Diagnostic interrupt due to "process interrupt lost" at... Bit 0: ... input I+0.4 Bit 1: 0 (fix) Bit 2: ...
Page 118 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Technical data Order no. 323-1BH70 Rated value DC 20.4...28.8 V Input voltage for signal "0" DC 0...5 V Input voltage for signal "1" DC 15...28.8 V...
Page 119 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Technical data Order no. 323-1BH70 Trigger level Number of operating cycle of relay outputs Switching capacity of contacts Output data size 2 Byte Status information, alarms, diagnostics...
Page 120 VIPA System 300S Digital Modules FAST - SPEED-Bus 323-1BH70 - DIO 16xDC 24V 0.5A > Technical data Order no. 323-1BH70 UL certification KC certification HB140 | SM-DIO | | en | Rev. 16-43...
