Danfoss FP975 Installation Manual page 7

IMPORTANT NOTE
If the timeswitch to be replaced is listed below it may be worth
considering a FP715 Si as an alternative to the FP975. The FP715 Si
off ers wallplate compatibility for those models listed below, although
some re-wiring may be required.
MAKE
ACL
Drayton
Landis & Gyr RWB 2, RWB 2-9, RWB 200, RWB 252, RWB 20, RWB 40
Glowworm
Potterton
If the new unit is replacing an existing time control having an
incompatible wiring confi guration, then the wiring conversions
(tables A and B, pages 12-15) will be of assistance.
4. For wiring connections please refer to diagrams on pages 9-10.
Please note, the FP975 does not require an earth connection,
although a terminal is provided for earth continuity purposes.
5. Ensure that the two retaining screws on the top of the timeswitch
are fully unscrewed. Locate the retaining lugs on the bottom
inside surface of the plug-in module under the wallplate base and
hinge the unit upwards until the module is pressed fully against
the top of the wallplate. Tighten the two screws on the top of the
module to secure the module to the wallplate.
6. A small blanking plug is supplied to blank the unused recessed
bottom fi xing screw.
7. Before setting the programmes the unit should be RESET by
pressing the recessed button marked R/S. Ensure the mains
power to the control circuit is switched on, and check the circuits
as follows.
8. Use the
switch the hot water output ON. Adjust the cylinder thermostat
and check the service operates correctly. Use the SELECT button
to get to OFF mode and check that the service does not operate.
9. Use the
switch the heating output ON. Adjust any remote thermostat(s)
and check that the service operates correctly. Use the SELECT
button to get to OFF mode and check that the service does not
operate.
Danfoss Heating
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - info@mytub.co.uk
MODELS
LS2411, LS522, LS722, LP241, LP522, LP722
Tempus 3, Tempus 4, Tempus 7
Mastermind
Mini-Minder
(Hot Water) SELECT button to get to the ON mode to
(Heating) SELECT button to get to the ON mode to
GB
7
