- Page 1 Operating Instructions Model No.: FPE1080 8” LCD TV/DVD Player For assistance, please call: 1-800-645-4994 Or Visit us at http://www.audiovox.com 128-7656 PDF created with FinePrint pdfFactory Pro trial version http://www.fineprint.com...
- Page 2 Thank you..for choosing this tablet DVD player. For your own safety and in order to learn all about the functions available, please read this manual and keep it for future reference. An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle information, system control, rear or side observation or navigation.
-
Page 3: Table Of Contents
Table of Contents A. Cautions and Warnings...04 B. About This Manual...06 C. Desktop Base Installation...08 D. Mount the unit on the wall...09 E. Prior to Operation...10 F. Remote Control...12 G. DVD Player...13 H. Power Supplies ..14 I. Connections...15 J. Receiving TV Programs...16 K. -
Page 4: Cautions And Warnings
A. Cautions and Warnings All operation and maintenance instructions must be followed and warnings adhered • Do not expose the unit to excessive moisture. • Do not place objects filled with liquids, such as vases, on the unit. • Do not use the unit where there are temperature extremes (below 41°F, 5°C or exceeding 95°F, 35°C). - Page 5 • When replacement parts are required, be sure the service technician has used replacement parts that are specified. Unauthorised substitutions may result in fire, electric shock or other hazards. • Upon completion of any service or repairs to the unit, ask the service techni- cian to perform operational checks to determine that the product is operating correctly.
-
Page 6: About This Manual
B. About This Manual The operations described mainly refers to the use of the remote control. Buttons with same or similar marking on the main unit have the same function as those on the remote control. If the symbol not supported by the media type inserted in the DVD player. The unit will play the following: Many Disc Formats are supported DVD-Video... - Page 7 • In this manual, the language in the on-screen display is English. If you change the language, please follow the selected language in the on-screen display. • The screen shown as an example in this manual may be different from the actual screen.
-
Page 8: Desktop Base Installation
C. Desktop Base Installation Screw Hole Unit Base 1. Place the tablet DVD player base on flat surface. 2. Align the thumb screw with the hole on the back of the DVD player. 3. Thread the thumb screw into the hole on the back of the DVD player and turn the thumb screw counter-clockwise to tighten the base to the DVD player. -
Page 9: Mount The Unit On The Wall
D. Mount the unit on the wall The unit can be easily be mounted on the wall. You will need an optional VESA75 Wall Mount Bracket. The VESA75 Wall Mount Bracket can be purchased at most local electronic retailers. The wall bracket plate which attaches to the wall has four screw holes. -
Page 10: Prior To Operation
E. Prior to Operation Place in Position For setting up the unit please choose a location with sufficient air circulation to prevent overheating. The product must be positioned horizontally only. Do not place heavy objects on its housing. To protect the laser unit avoid dusty surroundings. If necessary, please use a cleaning disc carefully following its operating instructions. - Page 11 Cleaning a Disc To clean a disc use a soft cloth without any cleaning agents. Only wipe from the center hole towards t h e o u t e r e d g e , Using the Remote Control Handset 1.
-
Page 12: Remote Control
F. The Remote Control 1. 0-9 2. PLAY/ PAUSE 4. STOP 5. CH+/ - 6. TV/CATV 7. SKIP SEARCH 8. AUTO 9. + / - 10. PICTURE 11. MENU 12. SETUP 13. REPEAT 16. SUBTITLE 17. AUDIO 18. DISPLAY 19. POWER 20. -
Page 13: Dvd Player
G. DVD Player PDF created with FinePrint pdfFactory Pro trial version P ROG 1 2 3 4 5 6 1. Power Button 12. Disk Slot 2. Program Button 13. Power Indicated LED 3. Channel +/- Button 14. IR Remote Sensor 4. -
Page 14: Power Supplies
H. Power Supplies a. Using AC adaptor Connect the supplied AC adaptor. INPUT: AC 100 ~ 240V, 50/60Hz, 0.4A OUTPUT: DC 12V, 1.7A • Use this unit only the supplied AC adaptor. Use with other AC adaptors may damage the unit. •... -
Page 15: Connections
After connecting the unit to power, picture will appear on the screen and the LED power indicator located on lower left front of the unit will be light. I. Connections Although this unit has its own screen, you can connect it to an external television set as well. -
Page 16: Receiving Tv Programs
1) Connect the supplied AV (RCA) cables into the Audio L+ R and video jack on the left side of the unit following the corresponding colors: (AudioLeft= White, Audio Right= Red, Video=yellow). 2) Connect the supplied AV cables on the other end to your TV. Match the cable by color code. -
Page 17: Playing Dvds
L. Playing DVDs DVD Playback 1. Press “DVD/TV/AUX” until the word “DVD” appears on the top right of the screen.; 2. Insert the disk in the right side of the unit with label facing to you. Then the disk will be pulled into the unit and play will begin automatically. - Page 18 Display a. During playback press the ‘DISPLAY’ button to display the current Title Number (1), the total Number of Titles (2), the current Chapter Number (3), the total Number of Chapters (4), and the Playing elapsed Time for the title (5). Press “DISPLAY”...
- Page 19 DVD Camera Angles During playback of a disc, press ‘ANGLE’ to display the available angles for discs containing multi-angles*. Press ‘ANGLE’ to select another angle, then press again to exit and return to the normal viewing angle. The angle display will disap- pear automatically if the ‘ANGLE’...
- Page 20 Repeat Modes a. During playback press ‘REPEAT’ constantly to see the repeat Repeat Modes Chapter: Repeat the current chapter Title: Repeat the current title All: Repeat all chapters and titles Off: Resume normal playback Change Soundtrack Language During DVD playback press the AUDIO button to select a different audio language (if the DVD disc contains several audio languages).
-
Page 21: Playing Cds
(if available). Press MENU again to resume playback in the same scene, where you first pressed MENU. Connecting Headphones You can connect one set of headphones with a 3.5 mm jack to the earphone socket on the left side of unit. Plug the jack into the socket which will then disconnect the built in speakers. - Page 22 1. Press the the screen. 2. Press ENTER to select the highlighted folder. The songs available under the folder will be listed. 3. Use begin playback of the highlighted song. 4. Use the button to move to the beginning of the previous song. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF.
-
Page 23: Setup
O. Setup System Setup Page 1) With no disc inside the player, press ‘SETUP’ to display the Main screen of the Setup Menu on the screen and “SYSTEM SETUP” appears. At the sam e time, “ 2) Press the 3) Press the 4) Press 5) Press the confirm your selection. - Page 24 TV DISPLAY 4:3 PS (Panscan): Select when a conventional TV set is connected. When the wide screen disc is played, it displays pictures cropped to fill your TV screen. The left and right edges are cut off. 4:3 LB (Letterbox): Select when a conventional TV set is connected.
- Page 25 5) Press the 6) Repeat steps 3-5 for other menus. Note: Press You can choose Japanese ,English, French ,Spanish, German as audio, subtitle and menu language. *EXIT SETUP: To exit the SETUP PAGE. * Press Video Setup 1) In Setup menu, Press the 2) Press the 3) Press the 4) Press...
- Page 26 5) Select the parental level you desire using function or multiple rating levels. These are listed from the lowest level (1 KID SAFE) to the highest level (8 ADULT). Press ENTER to confirm your selection. Note: The level of 8 Adult is the factory default. 6) Enter the “PASSWORD”...
-
Page 27: Specifications
P. Specifications: Model Number: FPE1080 Features UPC number: 0-44476-03140-3 Display Features Display type Screen Size Aspect Ratio Panel Resolution Brightness Contrast ratio Viewing Angle Backlight life TV Reception TV System Channel CATV - UHF/VHF Antenna Impedance Connector type Audio Maximum Audio Output... - Page 28 Playback Media Compatibility Audio CD CD-R CD-RW DVD-R DVD-RW DVD-Video Picture CD SVCD SD/MMC Playable Format (Codec) CD-DA VCD 1.1 VCD 2.0 Features Built-in DVD Player Removable Tilt/Swivel stand 12VDC input for Car use User friendly remote and On Screen Display (OSD) Built-in Secure Digital (SD) and Multi-Media Card (MMC) MP3 playback on Disc and SD/MMC Photo Show on Disc and SD/MMC...
- Page 29 Power Requirements Power Source Unit input power Power ON consumption Dimension (WxHxD) Unit W/stand Unit W/O stand Weight (N.W.) Unit W/stand Unit W/O Stand Warranty Parts & Labor Environment Operating Temperature Operating Humidity *Designs and specifications are subject to change without notice. PDF created with FinePrint pdfFactory Pro trial version 100-240 VAC 50/60Hz 12VDC 1.7A...
-
Page 30: Warranty
90 DAY LIMITED WARRANTY Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the origi- nal retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in...
