- Page 1 Model PA-S450 400 Watt 4-Channel Amplifier Owner's Owner's Owner's Owner's Owner's Manual Manual Manual Manual Manual...
-
Page 2: Table Of Contents
INDEX Specifications ...1 Precautions ... 2 Installation Instructions ...3 Wiring Instructions ... 4 - 5 4-Channel and Mixed-Mono Input Wiring Diagram ... 6 4-Channel and Mixed-Mono Output Wiring Diagram ... 7 3-Channel Input Wiring Diagram ... 8 3-Channel Output Wiring Diagram ... 9 2- Channel Mono (Bridged) Input Wiring Diagram ... -
Page 3: Specifications
10 - 50,000 Hz. ± 1 dB Channel Separation: 50 dB Signal / Noise Ratio: 90 dB (A-Weighted) * Due to continuing improvement, Audiovox reserves the right to change features and design without notice. HELP! 1-800-645-4994 Monday-Friday Saturday Input Impedance:... -
Page 4: Precautions
6. Make certain that the speaker(s) to be used with this amplifier are capable of handling the output power (wattage) of the unit. Use of speaker(s) not rated for the output of this amplifier may cause damage to or failure of the speaker(s) for which Audiovox will not be liable. -
Page 5: Installation Instructions
INSTALLATION INSTRUCTIONS 1. Select a mounting area where the amplifier will have sufficient air circulation for proper cooling. Inadequate air circulation will cause the temper- ature of the amplifier to rise and will trigger the thermal protection mode. 2. Place the amplifier on the mounting surface and mark the locations of the four mounting holes as shown in the illustration. -
Page 6: Wiring Instructions
WIRING INSTRUCTIONS The wiring of your amplifier will depend on the system and speakers you are using but will either be a 4-channel, 3-channel, 2-channel, or mixed-mono application. The following pages illustrate the input and output wiring for these types. Please refer to the appropriate diagrams for the system configuration you are using. -
Page 7: Wiring Instructions
WIRING INSTRUCTIONS 4. Speaker Connections Depending on the type and number of speakers used with the amplifier, wire them to the speaker terminals as per the appropriate wiring diagram. For most applications, #18 gauge wire should be used for the speaker leads but in no case thinner than #20 gauge. -
Page 8: 4-Channel And Mixed-Mono Input Wiring Diagram
4-CHANNEL AND MIXED-MONO INPUT WIRING DIAGRAM LOW-LEVEL RCAOUTPUTS LEFT REAR RIGHT REAR LEFT FRONT RIGHT FRONT IMPORTANT USEEITHERHIGH-LEVELOR LOW-LEVEL INPUTS, NOT BOTH. RCATYPE SHIELDEDCABLES (NOTINCLUDED) HIGH-LEVEL (SPEAKER) OUTPUTS CAR STEREO RIGHT FRONT - RIGHT FRONT + LEFT FRONT - LEFT FRONT + TO CH1 TO CH2 TO CH3... -
Page 9: 4-Channel And Mixed-Mono Output Wiring Diagram
USE THIS OUTPUT WIRING WITH INPUT WIRING ON PAGE 6 LEFT FRONT SPEAKER SPEAKERIMPEDANCE 4-CHANNEL MODE : 2-8 OHMS MIXED-MONO MODE : 4-8 OHMS LEFTREAR SPEAKER CH3 / CH4 MIXED-MONO SPEAKER OR SUB-WOOFER WITH CROSSOVER 4-8 OHMS 4-CHANNEL AND MIXED-MONO OUTPUT WIRING DIAGRAM RIGHT FRONT SPEAKER RIGHT REAR... -
Page 10: 3-Channel Input Wiring Diagram
3-CHANNEL INPUT WIRING DIAGRAM LOW-LEVEL RCAOUTPUTS LEFT RIGHT MONO OR SUBWOOFER IMPORTANT USEEITHERHIGH-LEVELOR LOW-LEVEL INPUTS, NOT BOTH. RCATYPE SHIELDEDCABLES (NOTINCLUDED) "Y"CABLE HIGH-LEVEL (SPEAKER) OUTPUTS CAR STEREO RIGHT - RIGHT + LEFT - LEFT + MONO OR SUBWOOFER - MONO OR SUBWOOFER + TO CH1 TO CH2... -
Page 11: 3-Channel Output Wiring Diagram
USE THIS OUTPUT WIRING WITH INPUT WIRING ON PAGE 8 LEFT SPEAKER 2-8 OHMS (4-8 OHMS IN MIXED-MONOMODE) CH3 / CH4 MIXED-MONO SPEAKER OR SUB-WOOFER WITH CROSSOVER 4-8 OHMS 3-CHANNEL OUTPUT WIRING DIAGRAM RIGHT SPEAKER 2-8 OHMS (4-8 OHMS IN MIXED-MONOMODE) MONOSPEAKER USE#10GAUGE... -
Page 12: 2- Channel Mono (Bridged) Input Wiring Diagram
2-CHANNEL MONO (BRIDGED) INPUT WIRING DIAGRAM LOW-LEVEL RCAOUTPUTS LEFT RIGHT IMPORTANT USEEITHERHIGHORLOW-LEVEL INPUTS, NOT BOTH. "Y" RCA TYPE SHIELDED CABLES (NOT SUPPLIED) HIGH-LEVEL (SPEAKER)OUTPUTS CAR STEREO LEFT - LEFT + RIGHT - RIGHT + TO CH1 TO CH2 TO CH3 TO CH4 -10- USE THIS INPUT WIRING WITH... -
Page 13: 2-Channel Mono (Bridged) Output Wiring Diagram
USE THIS OUTPUT WIRING WITH INPUT WIRING ON PAGE 10 LEFTSPEAKER SUB-WOOFER 4 - 8 OHMS 2-CHANNEL MONO (BRIDGED) OUTPUT WIRING DIAGRAM RIGHTSPEAKER SUB-WOOFER 4 - 8 OHMS USE#10GAUGE WIRE (SEE TEXT) AUTO-ANTENNALEAD -11- CONNECTTHIS WIRE LAST 12 VOLT VEHICLE CHASSIS BATTERY GROUND... -
Page 14: Operation
OPERATION After initial set-up, the amplifier should not require any further adjustment unless there is a change in the car stereo or speaker system with which it is used. Power Indicator The Power LED functions as a power and warning indicator. The indicator is white when the power to the amplifier is off. - Page 15 Filter Selectors These switches allow selection of the frequency filters that permit the respective channels of the amplifier to be used to reproduce the entire audio range, just the bass, or all frequencies above the bass range. In the "OFF" position of the switch, the response is flat and unaffected so the entire audio frequency range is reproduced by the amplifier.
-
Page 16: Warranty
CD changers, power amplifiers, equalizers and accessories. AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with new or reconditioned product (at the Company's option) without charge for parts and repair labor.
