Page 39
ENGLISH Contents Before Use ..........40 Image Eff ects ..........53 Filter ...............53 Part Names ..........41 Adjusting the Brightness .......54 Display on the LCD Monitor ....42 Vignette ..............54 Using the selector buttons ......42 More on Photography ......55 Using the command dial ........42 Using AF/AE Lock ..........55 Attaching the Strap ......43 Using the Self Timer .........55...
Before Use Before using the camera, check the following. Supplied Accessories • NP-50 rechargeable battery (1) Make sure supplied accessories are included in the package. • USB cable for charging (1) Ÿ Read "IMPORTANT SAFETY NOTICE" (Page 68) and "Handling the Battery"...
Attaching the Strap Ÿ Place the shoulder strap clip on each Attaching the Hand Strap strap eyelet. Attach the strap as illustrated below. Hook the strap eyelet in the clip opening. Remove the • When you carry or use the camera, put the strap around tool using the other hand to keep the clip in place.
Inserting/Charging the Battery Inserting the Battery • Use an AC adapter to meet the rated output below: DC 5.0 V/1000 mA • You can take a picture or print an image while charging is in progress. • Charging time is approximately three to four hours. Charging status indication Slide the battery cover to open.
Turning the Camera on/off To turn the camera on, turn the lens ring (power switch) clockwise. To turn it off, turn the switch counterclockwise. The camera turns on and shooting screen Checking Remaining Battery Life appears. Pressing the (Back) button on the shooting/playback screen displays remaining battery life on the LCD monitor.
Performing Initial Settings The language, date, and time are not specified when the camera is turned on for the first time. Follow the procedure below to specify them. You can specify these settings at any time. See page 62 if you perform these settings later or change them.
Performing Initial Settings Function Setting for the Shutter Button Assign a function to each of the shutter buttons from the combinations on the table below. Shutter button (Right) Shutter button (Left) Shutter button Shutter button Shutter button Shooting mode switching button Function Shutter button Shooting mode switching button...
The film cover (black) is Notes on the film pack ejected automatically when • Each FUJIFILM Instant Film “instax SQUARE” pack contains the back cover is closed. 1 black film protective cover and 10 film sheets. Remove the film cover from •...
Print Mode Two print modes are available. • Auto print mode • Manual print mode (initial setting) When the auto print mode is selected, printing starts immediately after the image is saved in the memory. When the manual print mode is selected, the image is saved in the memory. You can select and print images later. ■...
Basic Photography and Playback Taking a Picture This section describes basic operation for photography. Turn the lens ring (power switch) clockwise to turn Lightly press the shutter button the rest of the way the camera on. down to take the picture. The picture is taken and it is saved in the camera’s memory.
Basic Photography and Playback Viewing Images Changing the Playback Display Images can be viewed on the monitor. Take a test shot and You can zoom in on the image on the monitor or change check the results before printing a picture. the number of images displayed at a time.
(Page 51) • For details on taking out the film, refer to the instructions and warnings on the FUJIFILM Instant Film “instax SQUARE” pack. • The development time is approximately 90 seconds. (The time varies depending on the ambient temperature.)
Image Eff ects You can select an effect menu directly by pressing a button on the rear to adjust the image effect while the shooting/ playback screen is displayed. ■ Filter eff ects you can use Filter Type Details Follow the steps below to select a filter. Cornelius Intensifies shadows and brightens Press the...
Image Eff ects Adjusting the Brightness Vignette Follow the steps below to adjust the brightness. Adjust the brightness of four corners on the image. Follow the steps below to adjust the brightness. Press the (Brightness) button while shooting/ Press the (Vignette) button while shooting/ playback screen is displayed.
More on Photography Using AF/AE Lock Using the Self Timer Use "AF/AE lock" to lock focus/exposure by pressing the Use the self timer to include a photographer in a group shutter button halfway. AF/AE lock is useful when you take photo or to reduce blur when the shutter button is pressed.
More on Photography Using the Flash Use the flash when shooting at night or indoors under low light. ■ Flash settings Press the MENU/OK button on the shooting Select one of the settings below. screen. • AUTO FLASH The flash fires automatically when the camera recognizes it is dark.
Changing the Shooting Mode Select a shooting mode according to the subject or purpose. Selecting a Shooting Mode Shooting Mode Follow the steps below to select a shooting mode. STANDARD Press the MENU/OK button on the shooting screen. Select for normal photography. The flash fires automatically when the camera recognizes it is dark.
Printing from Print History (Reprint) Print an image with the same settings (e.g. image effect) as those specified when you printed the image in the past. Follow the steps below for operation. Press the (Playback) button. Press the (Print) button. ¤...
Using a Memory Card This camera can save approximately 50 images in the memory. However, using a memory card enables you to save more images. Inserting the Memory Card Caution on the memory card • Micro SD/micro SDHC cards have been approved Slide the card slot cover to open.
Menus Shooting Menu ■ Items on the shooting menu Follow the steps below to specify/change the shooting menu. SHOOTING MODE Press the MENU/OK button on the shooting screen. Select a shooting mode according to the purpose or situation. (Page 57) •...
Menus Playback Menu Follow the steps below to specify/change the playback ERASE menu. Delete an image one by one or delete all at one time. Press the MENU/OK button on the playback screen. Option: FRAME/ALL FRAMES IMAGE ROTATE Rotate an image by 90 degrees. Use the command dial for operation.
Menus Setup Menu Follow the steps below to specify/change the setup OPERATION VOL. menu. Adjust the volume of the operation, shutter, or startup Press the MENU/OK button on the shooting/ sound. playback screen. Option: OFF/1/2/3 Select OFF to disable sounds. SHUTTER BUTTON SETTINGS Assign the function for the left/right shutter button.
SPECIFICATIONS Camera Image sensor 1/4-in., CMOS with primary color fi lter Eff ective pixels 1920 x 1920 Storage media Built-in memory, microSD/microSDHC memory card Recording capacity Built-in memory: Approx. 50 fi les microSD/microSDHC memory card: Approx. 1000 fi les per 1 gigabyte File system Compliant with Design Rule for Camera File System (DCF), Exif Ver.2.3, Com- pliant with JPEG and PIM...
Page 64
SPECIFICATIONS Printer Film FUJIFILM Instant Film “instax SQUARE” (Purchased separately) Photo capacity 10 prints/pack Film size 86 mm x 72 mm Image size 62 mm x 62 mm Supported image size 800 x 800 dots Printing solution 12.5 dots/mm (318 dpi, 80 μm dot pitch)
TROUBLE SHOOTING Review below if you think the camera has some trouble. If you cannot find the solution, contact a FUJIFILM authorized distributor. Or visit our website below. FUJIFILM website : http://fujifilm.com/ During operation Problem Possible Causes Solution The camera cannot be ①...
Page 66
The camera is ① Malfunction occurs temporarily. ① Remove the battery and reinsert it. ② The battery is running out. If this does not solve the problem, contact a unresponsive. FUJIFILM authorized distributor. ② Replace with a fully-charged battery.
Page 67
Solution The film pack cannot ① The fi lm pack is not for your camera. ① Use FUJIFILM Instant Film “instax SQUARE” only. ② The fi lm pack is not being loaded (No other fi lms can be used.) be loaded, or cannot be ②...
IMPORTANT SAFETY NOTICE This product has been designed with safety in mind, and to provide safe service when handled correctly and in accordance with the User’s Guide and instructions. It is important that both the product and the INSTAX fi lm are handled properly and used only to print pictures as instructed in this User’s Guide and in the INSTAX mini fi lm instructions.
If anything is wrong with the camera, never attempt to repair it by yourself. You may be injured. If this product is dropped or damaged so that the inside is showing, do not touch it. Contact your FUJIFILM dealer. Do not touch any parts or projecting parts inside the back cover. You may be injured.
• Connect the equipment into an outlet on a circuit different from that to which the receiver id connected • Consult the dealer or an experienced radio/TV technician for help Changes or modifications not expressly approved by FUJIFILM responsible for compliance could void the user’s authority to operate the equipment.
Page 71
INSTAX SQUARE FILM AND PRINT CARE See FUJIFILM Instant Film “instax SQUARE” for film use instructions. Follow all instructions for safe and proper use. 1 Keep the film in a cool and dry place. Do not leave the film in a place where the temperature is extremely high (e.g., in a closed car) for many hours.
Required shock. Contact your FUJIFILM dealer. The Battery The following describes the proper use of batteries and how to prolong their life. Incorrect use can shorten battery life or cause leakage, overheating, fire, or explosion.
■ Notes on the Battery The battery gradually loses its charge when not in use. Charge the battery one or two days before use. Battery life can be extended by turning the camera off when not in use. Battery capacity decreases at low temperatures; a depleted battery may not function when cold. Keep a fully charged spare battery in a warm place and exchange as necessary, or keep the battery in warm place and insert it in the camera only when shooting.
Page 74
Information for FUJIFILM in Canada Address, City: Dusseldorf Heesenstrasse 31, FUJIFILM Canada Inc. 40549 600 Suffolk Court, Mississauga, Ontario L5R Country: Germany If you have any inquiries about this product, please contact a FUJIFILM authorized distributor, or access the website below.
