Operation Manual
CD RDS RECEIVER
DEH-80PRS
English

Advertisement

Table of Contents
loading

Related Manuals for Pioneer DEH-80PRS

Summary of Contents for Pioneer DEH-80PRS

  • Page 1 Operation Manual CD RDS RECEIVER DEH-80PRS English...

  • Page 2: Table Of Contents

    Contents Thank you for purchasing this PIONEER product. To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe WARNINGs and CAUTIONs in this manual. Please keep the manual in a safe and accessible place for future refer- ence.

  • Page 3: Before You Start Specifications

    Electrical shock could result. purchased the items. Also, damage to this unit, smoke, and over- heating could result from contact with liquids. ! The Pioneer CarStereo-Pass is for use only in Germany. ! Always keep the volume low enough to hear outside sounds.

  • Page 4: In Case Of Trouble

    Do not use the unit in standard mode when a contact your dealer or nearest authorized speaker system for 3-way network mode is con- nected to this unit. This may cause damage to PIONEER Service Station. the speakers. Use a thin, flathead screwdriver to Resetting the microprocessor...

  • Page 5: Switching Between Rca Input Modes

    Section Before you start Switching between RCA settings. Select Demonstration (demo display setting) and turn off the demo display. For de- input modes tails, refer to Initial settings on page 34. If you connect the unit to an audio device with RCA output, or to one with no RCA output, you can set it up so that the audio from the About this manual...

  • Page 6: Operating This Unit

    EQ/DISP OFF While in the operating menu, press to control functions. CAUTION Use a Pioneer USB cable when connecting the USB audio player/USB memory device as devices connected to the unit directly will protrude out, which is dangerous. Do not use unauthorized products.

  • Page 7: Set Up Menu

    Section Operating this unit Set up menu 1 Turn M.C. to adjust the contrast level. 0 to 15 is displayed as the level is increased or de- When you turn the ignition switch to ON after creased. installation, set up menu appears on the dis- 2 Press M.C.

  • Page 8: Use And Care Of The Remote Control

    1 Press the open button to open the front panel. iPod2 (iPod connected using USB input2) at 2 Grip the left side of the front panel and pull it the same time, use a Pioneer USB cable (CD- gently outward. U50E) in addition to the regular Pioneer USB Take care not to grip it too tightly or to drop the cable.

  • Page 9: Menu Operations Identical For Function Settings/Audio Adjustments/Initial Settings/Lists

    Section Operating this unit ! When disposing of used batteries, comply Tuner with governmental regulations or environmen- Basic operations tal public institutions’ rules that apply in your country/area. Important ! Do not store the remote control in high tem- peratures or direct sunlight. ! The remote control may not function properly in direct sunlight.

  • Page 10: Switching The Rds Display

    Section Operating this unit Switching the RDS display Selecting a band 1 Press BAND/ until the desired band (FM-1, FM- RDS (radio data system) contains digital infor- 2,FM-3 for FM or MW/LW) is displayed. mation that helps search for the radio sta- tions.

  • Page 11: Using Radio Text

    Section Operating this unit — iPhone 4 Using radio text — iPhone 3GS — iPhone 3G Displaying radio text — iPhone You can display the currently received radio text and the three most recent radio texts. However, tag information can be stored in this 1 Press and hold down (list) to display radio text.

  • Page 12: Cd/Cd-R/Cd-Rw And External Storage Devices (Usb, Sd)

    Section Operating this unit When Alternative FREQ is used, the regional func- Tuning Mode (LEVER tuning setting) tion limits the selection of stations to those broad- You can assign a function to the LEVER on the unit. casting regional programs. Select Manual (manual tuning) to tune up or down 1 Press M.C.

  • Page 13: Displaying Text Information

    ! You can switch between up to 32 different mem- 1 Press h (eject). ory devices. Playing songs on a USB storage device 1 Use a Pioneer USB cable to connect the USB sto- Notes rage device to the unit. ! When playing compressed audio, there is no ! Plug in the USB storage device using the USB sound during fast forward or reverse.

  • Page 14: Browsing For A Song

    Section Operating this unit Use M.C. to select the desired file name Notes ! This unit must create an index in order to facil- (or folder name). itate Artists, Albums, Songs, and Genres Changing the file or folder name searches. Typically, it will take approximately 1 Turn M.C.

  • Page 15: Ipod

    Section Operating this unit Playing songs on an iPod 1 Press M.C. to display the setting mode. 1 Connect an iPod to the USB cable using an iPod 2 Turn M.C. to change the mode; press to select. Dock Connector. ! Artist –...

  • Page 16: Playing Songs Related To The Currently Playing Song

    Section Operating this unit Operating this unit’s iPod Playing a song in the selected category 1 When a category is selected, press and hold M.C. function from your iPod You can listen to the sound from your iPod ap- Searching the list by alphabet 1 When a list for the selected category is displayed, plications using your car’s speakers, when press...

  • Page 17: Audio Adjustments

    Section Operating this unit — Track up/down 1 Press M.C. to select your favorite setting. ! When the control mode is set to iPod/APP, ! Shuffle Songs – Play back songs in the se- only Pause, Tags transfer or lected list in random order. Sound Retriever is available.

  • Page 18: Way Network Mode

    Section Operating this unit 2 Auto TA and EQ (auto-time alignment and auto- Operation mode marks equalizing) This manual uses the following marks to make 3 Using fader/balance adjustment (F/B) the description clear. 4 Recalling equalizer curves : This mark indicates a function only in 3-way network mode or an operation in 3-way network mode.

  • Page 19: Introduction Of Audio Adjustments

    Section Operating this unit Introduction of audio adjustments Press M.C. to display the setting mode. # You can also switch between the audio func- tions in reverse order by turning M.C. counter- clockwise. # When selecting FM as the source, you cannot switch to SLA.

  • Page 20: Using The Position Selector

    Section Operating this unit Press M.C. and hold to switch between Using fader/balance adjustment left/right common mode and left/right in- You can change the fader/balance setting to dependent mode. provide an ideal listening environment for all L/R (left/right common mode)—Left (left)— of the occupied seats.

  • Page 21: About The Network Function

    Section Operating this unit # You cannot select Auto TA if auto TA and EQ Turn LEVER to adjust the distance be- has not been carried out. In this case, tween the selected speaker and the listen- Please set Auto TA appears. ing position.
  • Page 22 Section Operating this unit Adjustable parameters Phase You can switch phase (normal, reverse) for The network function enables adjustment of each speaker unit’s input signal. When the the following parameters. Make adjustments continuity of sound between speakers is im- in line with the reproduced frequency band precise, try switching phase.
  • Page 23 Section Operating this unit Phase adjustment Turn LEVER to select the speaker unit When the cross-over point value for filters on (filter) to be adjusted. both sides is set to –12 dB/oct., the phase is Low LPF (low-range speaker LPF)—Mid HPF (middle-range speaker HPF)—Mid LPF (mid- reversed 180 degrees at the filter cut-off fre- quency.

  • Page 24: Using Subwoofer Output

    Section Operating this unit 10 Press M.C. to switch the phase of the Adjusting subwoofer settings selected speaker unit (filter). The cut-off frequency and output level can be NOR (normal)—REV (reverse) adjusted when the subwoofer output is on. # You can adjust the parameters for other Use M.C.

  • Page 25: Using The High Pass Filter

    Section Operating this unit Using the high pass filter Turn M.C. to select cut-off frequency. 50—63—80—100—125—160—200 (Hz) When you do not want low sounds from the Only frequencies higher than those in the se- subwoofer output frequency range to play lected range are output from the front speak- from the front or rear speakers, turn on the ers.

  • Page 26: Adjusting Equalizer Curves

    Section Operating this unit Use M.C. to select A.EQ in the audio Adjusting equalizer curves function menu. The factory supplied equalizer curves, with the Refer to Introduction of audio adjustments on exception of Flat, can be adjusted to a fine de- page 19.

  • Page 27: Using Automatic Sound Levelizer

    Section Operating this unit Turn M.C. to select the equalizer band Turn LEVER to adjust the source vo- to adjust. lume. +4 to –4 is displayed as the source volume is 20—31.5—50—80—125—200—315—500— 800—1.25k—2k—3.15k—5k—8k—12.5k— increased or decreased. 20k (Hz) Notes Turn LEVER to adjust the level of the ! The MW/LW volume level can also be adjusted equalizer band.
  • Page 28 Section Operating this unit ! When this unit is connected to a power WARNING amp with input level control, auto TA and As a loud tone (noise) may be emitted from the EQ may not be possible if the power amp’s speakers when measuring the car’s interior input level is set below the standard level.
  • Page 29 Section Operating this unit Performing auto TA and EQ Plug the microphone into the micro- phone input jack on this unit. Stop the car in a place that is quiet, close all the doors, windows and sun roof, and then turn the engine off. # If the engine is left running, the noise from the engine may cause incorrect auto TA and EQ.

  • Page 30: Using Bluetooth Wireless Technology

    Section Operating this unit Using Bluetooth wireless Canceling call waiting 1 Press technology Adjusting the other party’s listening volume Using Bluetooth telephone 1 Turn LEVER while talking on the phone. ! When private mode is on, this function is not Important available.
  • Page 31 Delete device (deleting a device from the device list) ! To complete the connection, check the device ! When no device is selected in the device list, this name (Pioneer BT Unit) and enter the PIN code on your device. function is not available.

  • Page 32: Bluetooth Audio

    Section Operating this unit Setting up for Bluetooth audio Device INFO (Bluetooth device address display) Before you can use the Bluetooth audio func- 1 Press M.C. to display the setting mode. tion you must set up the unit for use with your 2 Turn M.C.

  • Page 33: Phone Menu Operation

    Section Operating this unit Play (play) ! The phone book in your cellular phone will be transferred automatically when the phone is con- 1 Press M.C. to start playback. nected to this unit. ! Depending on the cellular phone, the phone book Stop (stop) may not be transferred automatically.

  • Page 34: Initial Settings

    Section Operating this unit Initial settings Normally, the FM tuning step setting employed for seek tuning is 50 kHz. The tuning step changes to 100 kHz automatically when the alternative frequen- cies search or traffic announcement standby function is in use. It may be preferable to set the tuning step to 50 kHz when the alternative frequencies search func- tion is on.

  • Page 35: Other Functions

    Section Operating this unit When listening to a CD or other source on which the Bluetooth device data can be deleted. To protect per- recording level is high, setting the equalizer curve sonal information, we recommend deleting this data level to high may result in distortion. You can switch before transferring the unit to other persons.

  • Page 36: Using Different Entertainment Displays

    Section Operating this unit ! You need to activate the AUX setting in the Turn M.C. to change the menu option initial setting menu. Refer to AUX1 (front and press to select ENTERTAINMENT. AUX input setting)/AUX2 (rear RCA input Turn M.C. to select the function. setting) on page 34.
  • Page 37 Section Operating this unit ! Three sets of colors (WARM, AMBIENT, Turn M.C. to change the menu option and press to select ILLUMI. CALM) ! CUSTOM (customized illumination color) Turn M.C. to display Key and press to select. Note For details about colors on the list, refer to Select- Turn M.C.
  • Page 38 Section Operating this unit Turn M.C. to display Key or Display. Press to select. Press M.C. and hold until the customiz- ing illumination color setting appears in the display. Press M.C. to select the primary color. R (red)—G (green)—B (blue) Turn M.C.

  • Page 39: Additional Information

    Appendix Additional information Troubleshooting Symptom Cause Action ! Press and hold The display in- Demo mode is Symptom Cause Action dication does /DISP to cancel not turn off demo mode. The display You did not per- Perform operation ! Turn off the when EQ/DISP automatically form any opera-...

  • Page 40: Error Messages

    Error messages storage device and connect. When you contact your dealer or your nearest The connected Follow the USB Pioneer Service Center, be sure to note the USB storage de- storage device in- error message. vice has security structions to dis- enabled.
  • Page 41 ON. above action, –Disconnect or please contact eject the external your dealer or an storage device. authorized Pioneer –Change to a dif- Service Station. ferent source. Then, return to the Auto TA and EQ USB or SD source. ! Disconnect the...

  • Page 42: Handling Guidelines

    Appendix Additional information Unfinalized CD-R/RW discs cannot be played back. Message Cause Action ! Confirm that the ERR:Front The microphone Do not touch the recorded surface of the discs. Speaker, ERR: cannot pick up speakers are con- Store discs in their cases when not in use. Front-Lch, the measuring nected correctly.

  • Page 43: Compressed Audio Compatibility (Disc, Usb, Sd)

    Appendix Additional information Firmly secure the USB storage device when driving. About iPod settings ! When an iPod is connected, this unit changes the Do not let the USB storage device fall onto the floor, where it may become jammed under the brake or ac- EQ (equalizer) setting of the iPod to off in order to celerator pedal.

  • Page 44: Sd Memory Card

    There may be a slight delay at the start of playback of audio files embedded with image data or audio files ! Pioneer accepts no responsibility for data lost stored on a USB storage device that has numerous on USB memory/USB portable audio players/ folder hierarchies.

  • Page 45: Ipod Compatibility

    However, depending on the system environ- Cable is required. ment, you may not be able to specify the play- A Pioneer CD-IU51 interface cable is also available. back sequence. For details, consult your dealer. For USB portable audio players, the sequence About the file/format compatibility, refer to the iPod is different and depends on the player.

  • Page 46: Copyright And Trademark

    Bluetooth SIG, Inc. the developer to meet Apple performance and any use of such marks by PIONEER COR- standards. Apple is not responsible for the op- PORATION is under license. Other trademarks...

  • Page 47: Specifications

    Appendix Additional information Specifications HPF (rear) Frequency ....50 Hz/63 Hz/80 Hz/100 Hz/ General 125 Hz/160 Hz/200 Hz Slope ......0 (Pass)/–6 dB/oct./–12 dB/ Power source ......14.4 V DC (10.8 V to 15.1 V oct. allowable) Gain ......+6 dB to –24 dB/Mute (1 Grounding system ....
  • Page 48 Appendix Additional information CD player MW tuner System .......... Compact disc audio system Frequency range ...... 531 kHz to 1 602 kHz Usable discs ......Compact disc Usable sensitivity ..... 25 µV (S/N: 20 dB) Signal-to-noise ratio ....105 dB (1 kHz) (IEC-A net- Signal-to-noise ratio ....
  • Page 52 PIONEER ELECTRONICS OF CANADA, INC. 340 Ferrier Street, Unit 2, Markham, Ontario L3R 2Z5, Canada TEL: 1-877-283-5901 TEL: 905-479-4411 PIONEER ELECTRONICS DE MEXICO, S.A. de C.V. Blvd.Manuel Avila Camacho 138 10 piso Col.Lomas de Chapultepec, Mexico, D.F. 11000 TEL: 55-9178-4270 先鋒股份有限公司...
