Installer:
Leave this manual with the
appliance.
Consumer: Retain this manual for future
reference.
This appliance may be installed in an after-
market permanently located, manufactured
(mobile) home, where not prohibited by
local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
fireplace is not convertible for use with
other gases.
WARNING: If the information in these
instructions are not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do
not use any phone in your building.
•
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
— Installation
and
performed by a qualified installer, service
agency or the gas supplier.
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
service
must
be
CONTEMPORARY LINEAR
VENT-FREE GAS FIREPLACE
GAS-FIRED
MODELS
VFLL38FP(3,9)0L25(N,P)-1
VFLL38FP(3,9)0L(N,P)-2
VFLL48FP(3,9)0L(N,P)-1
MH46389
Vent-Free Linear Logset Shown
WATER VAPOR: A BY-PRODUCT OF
UNVENTED ROOM HEATERS
Water vapor is a by-product of gas
combustion. An unvented room heater
produces approximately one ounce (30ml)
of water for every 1,000 BTU's (.3KW's) of
gas input per hour. Refer to page 13.
This is an unvented gas-fired heater. It
uses air (oxygen) from the room in which
it is installed. Provisions for adequate
combustion and ventilation air must be
provided. Refer to pages 13 - 14.
WARNING: If not installed, operated and
maintained in accordance with the
manufacturer's instructions, this product
could expose you to substances in fuel or
from fuel combustion which can cause
death or serious illness.
Page 1
