Page 2
使用工具 開梱する Preparing Tools Take out the whole bike from carton box 包装材を外す 前輪を取る Remove packing Take off front wheel...
Page 3
前輪ディスク保護用のカバーを外す 取り外し前フォーク保護装置 Remove the front disc-brake protector Remove the front disc-brake protector Fetch the front fork protector Take off front fork protector ブレーキディスクとブレーキを正しく装着して クイツクレバー、きつく前輪をロックしてください Install the front wheel correctly Lock firmly the front wheel with quick release...
Page 4
ねじ(ヘッドの上方)をしっかり缔めてください 前輪に取り付けて完成する Front wheel installation completes Unscrew off the top screw of stem ねじ(ヘッドの側面)をしっかり缔めてください ヘッド玉当たり調整を行います Unscrew off side screws of stem Turn around stem in 180 degree...
Page 5
ヘッドのふたを外す。この調整をする時、クランプボルトは緩めておいてください Remove the handlebar /stem cap ハンドルを取り付け完了 ハンドルポストの高さ調整 Put the handlebar into stem and lock cap tightly Handlebar installation completes...
Page 6
ランプを取り付けて Install the front bike light バッテリーパックを取り付けて Install the battery pack...
Page 7
電源コードをつながる Plug in the power line to the battery ペダルの固定 Install the pedals correctly ( "R" is for right side crank arm ; "L" is for left side crank arm)
Page 8
保護用のカバーを外す サドルの調整のしかた to remove the rear protector Install the seat Install the seat post Do Remember カバーに覆いをする Install the protective jacket(on right side)
Page 10
電源を入れ直してください Plug in the charger to battery, and then plug in the charger to socket リチウムイオンバッテリー: 約6時間(初充電) 充電が完了する 3-5 時間(通常の場合) Full charged (green light on) Charging(red light on,3 – 5 hours)
