Contec BX710 Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IPC Series
BOX-PC
for BX710 Series
User's Manual
CONTEC CO.,LTD.

Advertisement

Table of Contents
loading

Related Manuals for Contec BX710 Series

Summary of Contents for Contec BX710 Series

  • Page 1 IPC Series BOX-PC for BX710 Series User’s Manual CONTEC CO.,LTD.
  • Page 2 1 *3 1 *3 *1 Please confirm latest information on the CONTEC homepage though the user's manual is stored in Recovery Media. The installation method is described in this document as well as the UsersManual. [File storing place: ¥Manual] *2 It is not packed to the Windows XP Professional pre-install model.

  • Page 3: Copyright

    No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 4: Table Of Contents

    Limited One-Year Warranty ........................3 How to Obtain Service..........................3 Liability ..............................3 Safety Precautions........................... 4 Safety Information ........................... 4 Caution on the BX710 Series ......................4 SYSTEM REFERENCE Specification............................7 Power Management Features........................9 Physical Dimensions ..........................10 HARDWARE SETUP Before Using the BOX-PC for the First Time ..................
  • Page 5 Defaults Menu ............................82 Supervisor/User Password Setting ......................83 Exit Selecting............................84 POST Messages .............................84 POST Beep.............................84 Error Messages ............................85 Locations and Settings of CMOS/ROM Clear SW ................90 EACH COMPONENT FUNCTION Component Name ..........................91 Front View ............................91 System Configuration..........................93 BX710 series User’s Manual...
  • Page 6 Memory Map ............................111 I/O Port Addresses ..........................112 Interrupt Level List ..........................113 POST Codes ............................114 COM I/O Address and Register Function ..................119 Battery ..............................125 Difference from IPC-BX700 series ....................127 LIST OF OPTIONS BX710 series User’s Manual...
  • Page 7 BX710 series User’s Manual...

  • Page 8: Introduction

    PC. Embedded-type CPU and chip set have been adopted. The use of readily available parts ensures the ease of the use of the product. In addition, the use of CONTEC-customized BIOS allows support to be provided at the BIOS level.

  • Page 9: Supported Os

    In addition, the use of a CONTEC-customized BIOS (mfd. by Award) allows support to be provided at the BIOS level. Structure free from mechanical moving parts (Windows Embedded Standard-installed model) The use of a CF card or a SSD for the storage device has eliminated any moving parts, improving the levels of the environment resistance (ambient temperature, impact, vibration), reliability and quietness.

  • Page 10: Customer Support

    You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited One-Year Warranty CONTEC products are warranted by CONTEC CO., LTD.

  • Page 11: Safety Precautions

    CAUTION indicates a potentially hazardous situation which, if not avoided, may CAUTION result in minor or moderate injury or in property damage. Caution on the BX710 Series Handling Precautions WARNING Always check that the power supply is turned off before connecting or disconnecting power cables.
  • Page 12 To prevent corruption of files, always shutdown the OS before turning off this product. CONTEC reserves the right to refuse to service a product modified by the user. In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord immediately and contact your retailer.
  • Page 13 Operation of this equipment in a residential area is likely to cause harmful interference at his own expense. WARNING TO USER Change or modifications not expressly approved the manufacturer can void the user's authority to operate this equipment. BX710 series User’s Manual...

  • Page 14: System Reference

    ICH7M-DH built in. The real-time clock is accurate within ±3 minutes (at 25°C) per month. Lithium backup battery life: 10 years or more Power Management Power management setup via BIOS. Modem Ring On/Wake One LAN. Supports PC98/PC99 ACPI Power management. BX710 series User’s Manual...
  • Page 15 *1 The total of the external device power supply load for +5V should be 3A or lower. * The PCI bus slot is for 32 bit specification. No operational tests are done for the 32/64 bit boards. BX710 series User’s Manual...

  • Page 16: Power Management Features

    APM v1.2 compliant PCI bus clock run, Power Management Enable (PME) control, all with hardware automatic wake-up Multiple suspends power plane controls and suspends status indicators Normal, doze, suspend and conserve modes Global and local device power control BX710 series User’s Manual...

  • Page 17: Physical Dimensions

    2. System Reference Physical Dimensions BX-710-AC5 Figure 2.1. BX-710-AC5 BX710 series User’s Manual...
  • Page 18 2. System Reference BX-710P2-AC5 Figure 2.2. BX-710P2-AC5 BX710 series User’s Manual...
  • Page 19 2. System Reference BX-710P4-AC5 Figure 2.3. BX-710P4-AC5 BX710 series User’s Manual...

  • Page 20: Hardware Setup

    * Before using the BOX-PC, be sure to execute " LOAD SETUP DEFAULTS" to initialize the BIOS settings to their default values. (See Chapter 4, "Main Menu.") CAUTION Be sure to connect the keyboard and mouse to it before turning the power on for the first time. BX710 series User’s Manual...

  • Page 21: Hardware Setup

    When tightening the screws to fasten the HDD to the bracket or the HDD mounted bracket to the system unit, do not use any tool such as an electric screwdriver, which vibrates the HDD. Not doing so will damage the HDD. BX710 series User’s Manual...

  • Page 22: Attaching The Cf Attachment Fittings

    Do not tighten screws with excess force. The tightening torque should be 4kg/cm or less. Figure 3.5. Attaching the Attachment Fittings CAUTION Screw holes may be damaged if screws are tightened with a torque greater than the specified torque. BX710 series User’s Manual...

  • Page 23: Expansion Board Installation Procedure

    Figure 3.6. Removing the Top Cover (3) Remove the brace that holds the printed circuit board (PCB) down. Remove the screws on the brace. The brace will separate toward you. Figure 3.7. Removing the PCB Brace 2 BX710 series User’s Manual...
  • Page 24 Make sure carefully that the board has been secured in the slot. (5) Install the PCB brace. It can hold down a board if its height is at least 50mm. Figure 3.9. Attaching the PCB Brace BX710 series User’s Manual...
  • Page 25 3. Hardware Setup (6) Replace the expansion slot cover. Figure 3.10. Replacing the Top Cover BX710 series User’s Manual...
  • Page 26 Figure 3.11. Removing the Top Cover (3) Remove the brace that holds the printed circuit board (PCB) down. Remove the screws on the brace. The brace will separate toward you. Figure 3.12. Removing the PCB Brace 2 BX710 series User’s Manual...
  • Page 27 Make sure carefully that the board has been secured in the slot. (5) Install the PCB brace. It can hold down a board if its height is at least 50mm. Figure 3.14. Attaching the PCB Brace BX710 series User’s Manual...
  • Page 28 3. Hardware Setup (6) Replace the expansion slot cover. Figure 3.15. Replacing the Top Cover BX710 series User’s Manual...

  • Page 29: Fastening The Cable

    Please notice that once you attach the cable, it is impossible to remove it. (1) Attach the tip of the cable tie to the hole above the AC inlet. Figure 3.17. Attaching the AC cable clamp BX710 series User’s Manual...
  • Page 30 (3) Apply the clamp to the AC power cable. Figure 3.19. Installing the Clamp (4) Move the clamp as close to the AC inlet as possible, then tighten the clamp to fasten the AC power cable. Figure 3.20. Fixing the Clamp BX710 series User’s Manual...
  • Page 31 3. Hardware Setup Using example of cable clamp The photo below shows an example of using a cable clamp. Fix the cable with a clamp without applying stress to the connector. Figure 3.21. Using example of cable clamp BX710 series User’s Manual...

  • Page 32: Installation Requirements

    CAUTION Note that even though the ambient temperature is within the specified range, an operational malfunction may occur if there is other device generating high heat; the radiation will influence the product to increase its temperature. BX710 series User’s Manual...
  • Page 33 Do not install this product into the fully-sealed space except the case in which the internal temperature is adjustable by equipment such as air conditioner. Troubles such as operational malfunctions could be occurred by the temperature increase caused by long-term usage. BX710 series User’s Manual...
  • Page 34 In this product, the ambient temperature is decided from the multiple measurement points as shown below. When making use of the product, the air current should be adjusted to prevent that all the temperatures measured at the measurement points exceed the specified temperature. Figure 3.25. Ambient temperature BX710 series User’s Manual...
  • Page 35 3. Hardware Setup BX710 series User’s Manual...

  • Page 36: Bios Setup

    <Ctrl>, <Alt>, and <Delete> keys. If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked Press F1 to continue, DEL to enter SETUP BX710 series User’s Manual...

  • Page 37: Using Setup

    Even a seemingly small change to the chipset setup has the potential for causing you to use the override. A Final Note About Setup The information in this chapter is subject to change without notice. BX710 series User’s Manual...

  • Page 38: Main Menu

    Use this menu to change the values in the chipset registers and optimize your system's performance. Integrated Peripherals Use this menu to specify your settings for integrated peripherals. Power Management Setup Use this menu to specify your settings for power management. BX710 series User’s Manual...
  • Page 39 Supervisor / User Password Use this menu to set User and Supervisor Passwords. Save & Exit Setup Save CMOS value changes to CMOS and exit setup. Exit Without Save Abandon all CMOS value changes and exit setup. BX710 series User’s Manual...

  • Page 40: Standard Cmos Setup

    The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. BX710 series User’s Manual...

  • Page 41: Main Menu Selections

    All, but Keyboard Displays the amount of conventional memory Base Memory detected during boot up Displays the amount of extended memory Extended Memory detected during boot up Displays the total memory available in the Total Memory system BX710 series User’s Manual...

  • Page 42: Ide Adapters

    **** Warning: Precomp Max = 65535 Setting a value of 65535 means no HDD, CF card Min = 0 Landing zone **** Max = 65535 Min = 0 Sector Number of sectors per track Max = 255 BX710 series User’s Manual...

  • Page 43: Advanced Bios Features Setup

    Advanced BIOS Features Setup This section allows you to configure your system for basic operation. You have the opportunity to select the system’s default speed, boot-up sequence, keyboard operation, shadowing and security. Figure 4.3. Advanced BIOS Features Setup BX710 series User’s Manual...

  • Page 44: Cpu Feature

    Press <Enter> to configure the settings relevant to CPU Feature. Table 4.4. CPU Features Selections Description Choice Delay Prior to Thermal Select the interval to setup the delay timer for CPU Thermal-Throttling C1E Function CPU C1E Function Select. BX710 series User’s Manual...

  • Page 45: Hard Disk Boot Priority

    When disabled, forces the XD feature flag to always return Hard Disk Boot Priority Figure 4.5. Hard Disk Boot Priority With the field, there is the option to choose, aside from the hard disks connected, “Bootable add-in Cards” which refers to other external device. BX710 series User’s Manual...

  • Page 46: Virus Warning

    These allow you to enable (speed up memory access) or disable the cache function. Quiet Post Skip certain self-diagnosis processes such as checking memory or other several devices for shorter bootup time. Default setting (Disabled) does not simplify the self-diagnosis process. BX710 series User’s Manual...
  • Page 47 BIOS and delays the start of the access to the USB devices. Therefore, the boot will be delayed by the specified waiting time. First Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. BX710 series User’s Manual...
  • Page 48 Boot Up NumLock Status Toggle between On or Off to control the state of the NumLock key when the system boots. When toggled On, the numeric keypad generates numbers instead of controlling cursor operations. BX710 series User’s Manual...
  • Page 49 6, 8, 10, 12, 15, 20, 24 or 30 characters per second. Typematic Delay (Msec) When the speed setting for the key input is enabled, you can specify the interval of waiting time for the continuous key input. BX710 series User’s Manual...
  • Page 50 PCI bus configurations and improve future expandability. OS Select For DRAM > 64M Select the operating system that is running with greater than 64MB of RAM on the system. BX710 series User’s Manual...
  • Page 51 When the backup process is finished, the message “BACKUP finish, Press any key reboot.” is displayed. Enter any one of the alphabet keys from A to Z. The system reboots upon the key input. Backup completes when the above steps are done. BX710 series User’s Manual...

  • Page 52: Advanced Chipset Features Setup

    The only time you might consider making any changes would be if you discovered that data was being lost while using your system. BX710 series User’s Manual...
  • Page 53 The precharge time is the number of cycles it takes for the RAS to accumulate its charge before DRAM refresh. If insufficient time is allowed, refresh may be incomplete and the DRAM may fail to retain data. BX710 series User’s Manual...
  • Page 54 1 to 2 Sec. System BIOS Cacheable Selecting Enabled allows caching of the system BIOS ROM at F0000h-FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result. BX710 series User’s Manual...
  • Page 55 However, if any program writes to this memory area, a system error may result. Memory Hole At 15M-16M In order to improve performance, certain space in memory can be reserved for ISA card. This memory must be mapped into the memory space below 16MB. BX710 series User’s Manual...

  • Page 56: Pci Express Root Port Function

    PCI Express Root Port Function Selections Description Choice PCI Express Port 1/2/3/4/5/6 This item allows you to enable or disable or Auto configure the PCI Express Port 1/2/3/4/5/6. PCI-E Compliancy Mode This item allows you to set PCI Express compliancy mode. BX710 series User’s Manual...

  • Page 57: Vga Setting

    BFFFh and a CPU-to-PCI write buffer are implemented. DVMT Mode Allows you to set the Dynamic Video Memory Technology (DVMT) mode. DVMT/FIXED Memory Size Allows you to set the Dynamic Video Memory Technology (DVMT) memory size. BX710 series User’s Manual...
  • Page 58 Boot Display This item allows you to select the boot display device. Panel Number These fields allow you to select the LCD Panel type. 640 x 480, 800 x 600 and 1024 x 768 can be selected. BX710 series User’s Manual...

  • Page 59: Watch Dog Timer Setting

    WDT Time-up State This item is enabled with "WDT Output to PO2" set to "Enabled". Set the state of output from the watchdog timer when the watchdog timer causes a time-out BX710 series User’s Manual...

  • Page 60: Integrated Peripherals

    This section sets configurations for your hard disk and other integrated peripherals. The first screen shows three main items for user to select. Once an item selected, a submenu appears. Details follow. Figure 4.8. Integrated Peripherals BX710 series User’s Manual...

  • Page 61: Onchip Ide Device

    4. BIOS Setup OnChip IDE Device Figure 4.9. On Chip IDE Device BX710 series User’s Manual...
  • Page 62 This item allow you to enable or disable the IDE DMA transfer access. On-Chip Primary PCI IDE The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately. BX710 series User’s Manual...
  • Page 63 ATA commands and the ATA bus to allow DMA commands to transfer data at a maximum burst rate of 33 MB/s. When you select Auto in the two IDE UDMA fields, the system automatically determines the optimal data transfer rate for each IDE device. BX710 series User’s Manual...
  • Page 64 4. BIOS Setup Description Choice On-Chip Secondary PCI IDE This should be set to Enabled. IDE Secondary Master / Slave PIO This should be set to Auto. IDE Secondary Master/Slave UDMA Auto設定にてご使用ください。 BX710 series User’s Manual...

  • Page 65: On Chip Serial Ata Setting

    SATA Only : SATA is operated in legacy mode. SATA PORT Speed Settings Disables speed setting for SATA port, or forces to set in “GEN I” or “GEN II”. PATA IDE Mode RATA IDE mode is fixed in “Secondary”. BX710 series User’s Manual...
  • Page 66 4. BIOS Setup Description Choice SATA Port Sets serial ATA channel in “Primary”. Notes : Only this item is displayed. BX710 series User’s Manual...

  • Page 67: Onboard Device

    4. BIOS Setup Onboard Device Figure 4.10. Onboard Device Table 4.11. On board device Selections Description Choice USB Controller Selects enable/disable for the USB (Universal Serial Bus) controller. In normal cases, use it while “Enable”. BX710 series User’s Manual...
  • Page 68 In normal cases, use it while “Enable”. USB Keyboard Support Select “Enabled” when using the USB keyboard. AC97 Audio Select “Enabled” when using the audio function. Onboard LAN A Select “Enabled” when using the Onboard LAN A controller. BX710 series User’s Manual...
  • Page 69 Sets Enabled / Disabled for the terminating resistance for RS422/485. If set in “Disabled”, there is no terminating resistance. If set in “Enabled”, it is terminated with 120Ω resistance. Onboard Lan Boot ROM Select “Enabled” when PXE network boot up is to be performed. BX710 series User’s Manual...

  • Page 70: Super Io Device

    Table 4.12. Super I/O device Selections Description Choice Onboard Serial Port A Select an address and corresponding interrupt for the A serial port. Onboard Serial Port B Select an address and corresponding interrupt for the B serial port. BX710 series User’s Manual...
  • Page 71 This serial port should be set to Disable since it is for the device of future expansion. The I/O address is fixed in 2A8H. Serial Port D IRQ Select the IRQ to use in the D serial port. BX710 series User’s Manual...
  • Page 72 This serial port is for the RS422/485 on the RAS connector. The I/O address is fixed in 2A0H. The I/O address is fixed in 2B0H. Serial Port E IRQ Select the IRQ to use in the E serial port. BX710 series User’s Manual...

  • Page 73: Power Management Setup

    Power Management Setup The Power Management Setup allows you to configure you system to most effectively save energy while operating in a manner consistent with your own style of computer use. Figure 4.12. Power Management Setup BX710 series User’s Manual...
  • Page 74 V/H SYNC+Blank : This option disconnects the power for the vertical and horizontal synchronizing ports of the system, and writes blanks to the video buffer. DPMS : Signals for the initial power management of the display. BX710 series User’s Manual...
  • Page 75 CPU clock stops and the video signal is suspended. When a power management event is detected, the full powered functions are recovered. * If the item of USB Keyboard Support is set [Enabled], this function is not available. BX710 series User’s Manual...
  • Page 76 PCI Express WAKE By default, this field is “Disabled”. Selecting “Enable” enables On board Lan “WOL” function. Note that the “Wake-Up by PCI Card” setting below should be Enable alike. BX710 series User’s Manual...
  • Page 77 When Enabled, your can set the date and time at which the RTC (real-time clock) alarm awakens the system. Reload Global Timer Events : When Enabled, an event occurring on each listed device restarts the global timer for Standby mode. BX710 series User’s Manual...
  • Page 78 4. BIOS Setup Description Choice BX710 series User’s Manual...

  • Page 79: Pnp/Pci Configuration Setup

    Figure 4.13. PnP/PCI Configuration Setup Table 4.14. PCI PnP/PCI Configuration Setup Selections Description Choices Init Display First Initialize the onboard video display before initializing any other display device on the system. Thus the onboard display becomes the primary display. BX710 series User’s Manual...
  • Page 80 The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play – compatible devices. If you select Auto, all the interrupt request (IRQ) and DMA assignment fields disappear, as the BIOS automatically assigns them BX710 series User’s Manual...

  • Page 81: Irq N Resources

    Legacy ISA Devices compliant with the original PC AT bus specification, requiring a specific interrupt (Such as IRQ4 for serial port 1) PCI/ISA PnP Devices compliant with the Plug and Play standard, whether designed for PCI or ISA bus architecture. The Choice : Legacy ISA and PCI/ISA PnP BX710 series User’s Manual...
  • Page 82 - Bus 0 Dev 2 Func 0 USB 1.0/1.1 UHCI Controller - Bus 0 Dev 29 Func 3 INT Pin 2 Assignment Devices(s) using this INT : Multimedia Device - Bus 0 Dev 30 Func 2 BX710 series User’s Manual...
  • Page 83 SMBus Controller - Bus 0 Dev 31 Func 3 INT Pin 5 Assignment Devices(s) using this INT: Network Controller - Bus 1 Dev 8 Func 0 Simple Communication Controller - Bus 0 Dev 30 Func 3 BX710 series User’s Manual...
  • Page 84 Devices(s) using this INT : - Reserved INT Pin 8 Assignment Devices(s) using this INT : USB 1.0/1.1 UHCI Controller - Bus 0 Dev 29 Func 0 USB 2.0 EHCI Controller - Bus 0 Dev 29 Func 7 BX710 series User’s Manual...

  • Page 85: Pci Express Relative Items

    4. BIOS Setup PCI Express relative items Table 4.16. PCI Express Relative Items Selections Description Choices Maximum Payload Size Set maximum TLP payload size for the PCI Express Devices. The unit is byte. BX710 series User’s Manual...

  • Page 86: Pc Health Status

    4. BIOS Setup PC Health Status Figure 4.15. PC Health Status The BIOS shows the PC health status in this window. BX710 series User’s Manual...
  • Page 87 Current CPU Temp. This field displays the current CPU temperature. Current System Temp. This field displays the current system temperature. Vcore / +1.5V / +1.8V / +1.05V / +5V / 5VSB This field displays the current voltage. BX710 series User’s Manual...

  • Page 88: Frequency/Voltage Control

    EMI. Enabling pulse spectrum spread modulation changes the extreme values from spikes to flat curves, thus reducing EMI. This benefit may in some cases be outweighed by problems with timing-critical devices, such as a clock-sensitive SCSI device. BX710 series User’s Manual...

  • Page 89: Defaults Menu

    When you press <Enter> on this item you get a confirmation dialog box with a message similar to: Load Optimized Defaults (Y/N) ? N Pressing ‘Y’ loads the default values that are factory settings for optimal performance system operations. BX710 series User’s Manual...

  • Page 90: Supervisor/User Password Setting

    (see Section 3). If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup. BX710 series User’s Manual...

  • Page 91: Exit Selecting

    BIOS cannot initialize the video screen to display any additional information. This beep code consists of a single long beep followed by two short beeps. The other code indicates that your DRAM error has occurred. This beep code consists of a single long beep repeatedly. BX710 series User’s Manual...

  • Page 92: Error Messages

    Setup and change the VIDEO selection. Display type has changed since last BOOT Since last powering off the system, the display adapter has been changed. You must configure the system for the new display type. BX710 series User’s Manual...
  • Page 93 The non-volatile memory containing EISA configuration information was programmed incorrectly or has become corrupt. Re-run EISA configuration utility to correctly program the memory. CAUTION When either of these errors appear, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility. BX710 series User’s Manual...
  • Page 94 Press F1 to disable NMI, F1 to REBOOT When BIOS detects a Non-mask able Interrupt condition during boot, this will allow you to disable the NMI and continue to boot, or you can reboot the system with the NMI enabled. BX710 series User’s Manual...
  • Page 95 [PLEASE RUN EISA CONFIGURATION UTILITY] The board ID does not match the ID stored in the EISA non-volatile memory. CAUTION When this error appears, the system will boot in ISA mode, which allows you to run the EISA Configuration Utility. BX710 series User’s Manual...
  • Page 96 M/B burn in test. BIOS ROM checksum error – System halted The checksum of ROM address F0000H-FFFFFH is bad. Memory test fail BIOS reports the memory tests fail if the onboard memory is tested error. BX710 series User’s Manual...

  • Page 97: Locations And Settings Of Cmos/Rom Clear Sw

    (3) Turn on the system unit to start the system. During system startup, invoke BIOS Setup to set up the BIOS again. (4) After completing the setting, turn the ROM clear switch (SW1-2) off again and save settings, then reboot. BX710 series User’s Manual...

  • Page 98: Each Component Function

    5. Each Component Function 5. Each Component Function Component Name Front View BX-710-AC5 Figure 5.1. Front View < BX-710-AC5 > BX-710P2-AC5 Figure 5.2. Front View < BX-710P2-AC5 > BX-710P4-AC5 Figure 5.3. Front View < BX-710P4-AC5 > BX710 series User’s Manual...
  • Page 99 Serial port B connector (9pin D-SUB/male) RAS function and RS-485 connector (15pin D-SUB/female ) A-RGB Display (15pin D-SUB/female) LVDS LVDS (26pin half pitch connector) Expansion Slot PCI x 2 < P2 model >, PCI x 4 < P4 model > BX710 series User’s Manual...

  • Page 100: System Configuration

    5. Each Component Function System Configuration BX-710-AC5、BX-710P2-AC5、BX-710P4-AC5 Figure 5.4. System Configuration BX710 series User’s Manual...

  • Page 101: Component Function

    The audio driver is required to use the microphone input and line output interfaces. Install the appropriate audio driver for your OS from the CONTEC's web site [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.)

  • Page 102: Serial-Ata : S-Ata

    Signal name Direction DD11 DD12 DD13 DD14 DD15 CS0- Output CD3- Output DIOR- Output DIOW- Output INTRQ Input CSEL- Output RESET- Output IOCHRDY Input Output DDRQ Input Output DDACK- Output Output DACT- Output PDIAG- Output DD10 BX710 series User’s Manual...

  • Page 103: Fast-Ethernet : Lana, Lanb

    10M : Off, 100M : Green, 1000M : Orange LAN drivers Install the appropriate audio driver for your OS from the CONTEC's web site [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) USB Ports : USB The BOX-PC is equipped with six channels for USB 2.0 interface.

  • Page 104: Serial Port Interface : Serial A, Serial B

    Pin No. Meaning Direction name Carrier detect Input Received data Input Transmitted data Output Data terminal ready Output Signal ground ----- Data set ready Input Request to send Output Clear to send Input Ring indicator Input BX710 series User’s Manual...
  • Page 105 RS-422/485 (Serial port D). For more information see section, "General-purpose I/O and Remote Reset" in Chapter 5. Modem control register (Set I/O address +4H) bit 1 0 … RTS is High. (Disable transmission) 1 … RTS is Low. (Enable transmission) BX710 series User’s Manual...

  • Page 106: Display Interface : Vga

    For the LCDs that can be connected, please refer to Chapter 7, “List of Options”. Display driver Install the appropriate audio driver for your OS from the CONTEC's web site [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.)

  • Page 107: Lvds Interface : Lvds

    * Please do not connect anything with the RESERVED pin. Display driver Install the appropriate audio driver for your OS from the CONTEC's web site [IPC-SLIB-01]. (For information on the latest version of IPC-SLIB-01, check the CONTEC's web site.) BX710 series User’s Manual...

  • Page 108: Ras Functions

    General-purpose input or interrupt input P12/IRQ General-purpose input plus common PCOM General-purpose input CAUTION Pin 4 NCOM (minus common dedicated to PO2) and pin 6 NCOM (minus common shared by PO0 and PO1) are electrically separated from each other. BX710 series User’s Manual...

  • Page 109: Watchdog Timer

    Resets or generates an interrupt at time-up (Port setting). External alarm output: Photocoupler insulated open-collector output (the output status is set by software). For more information, see the general-purpose I/O specifications. I/O addresses: 4000h - 4007h (RAS port) BX710 series User’s Manual...
  • Page 110 : Stop the WDT timer and cancel the alarm. Out 4003h 0Fh : Set the WDT expiration time to 15sec. Out 4002h A5h : Start and clear the WDT. In 4002h : Stop the WDT and cancel the alarm. BX710 series User’s Manual...
  • Page 111 W : Writes watchdog timer count data. Write watchdog timer counter expiration time data. → 1sec → 8sec → 15sec → 30sec * 4004h : Event output control RESET R/W (Default: XXXX0000b) Figure 5.9. Event Output Control Port (4004h) BX710 series User’s Manual...
  • Page 112 WDT : WDT status This is the WDT status bit. This bit is cleared when the WDT stops (read port 4002h). 0 : The WDT is either stopped or counting. 1 : The time set on the WDT expired. BX710 series User’s Manual...

  • Page 113: General-Purpose I/O And Remote Reset

    How to Use General-purpose I/O and Remote Reset Event output Output data to port 4001h to set PI0, PI2 or PO2 mode. control Implement input and output with port 4000h. Figure 5.11. How to Use General-purpose I/O and Remote Reset BX710 series User’s Manual...
  • Page 114 Inhibit the remote reset input function of the RAS connector's PI2/IRQ (14) signal. Use as the remote reset input function of the RAS connector's PI2/IRQ (14) signal. CAUTION A bit indicated with "rsv" is used by the system. Do not modify the bit. BX710 series User’s Manual...
  • Page 115 1 :Transmission permitted RX-(11) 0 :Transmission TE_GATE permitted RX+(3) 1 :Transmission TX-(10) prohibited 0 :Receiving TX+(2) permitted RE_GATE 1 :Receiving prohibited 120kΩ RS485 Terminator Enabled : On Control Disabled : Off Figure 5.15. Half-Duplex Connection Method BX710 series User’s Manual...
  • Page 116 5. Each Component Function Figure 5.16. Full-Duplex Connection Method External I/O Circuit Figure 5.17. Input Circuit Figure 5.18. Output Circuit BX710 series User’s Manual...

  • Page 117: Expansion Slots (Bx-710P2-Ac5, Bx-710P4-Ac5)

    A board that uses the back of the board edge connector (the shaded area in the figure) may not be mounted. The PCI bus slot is for 32 bit. Operational tests are not performed for the dual purpose boards for 64bit / 32bit such as ADAPTEC 39160SCSI board or Intel Pro1000/MT network board. BX710 series User’s Manual...

  • Page 118: Appendix

    Main DRAM Address Range Top of Main Memory Extended SMRAM Address Range Top of Main Memory To 4GB PCI Memory Address Range FEC0000h - FECFFFFFh, APIC configuration space FEE00000h - FEEFFFFFh FFE0000h - FFFFFFFFh High BIOS Area BX710 series User’s Manual...

  • Page 119: I/O Port Addresses

    Reserved 0800 - 088F 143 bytes Reserved 0A79 - 0A79 1 byte Reserved 0CF8 - 0CFF 4 bytes PCI configuration register 0CF9 1 byte Turbo and reset control register 4000 - 400F 16 byte Reserved (RAS) BX710 series User’s Manual...

  • Page 120: Interrupt Level List

    IRQ5 is used as default when the serial port 3 is set to Enable. IRQ6 is used as default when the serial port 4 is set to Enable. IRQ7 is used as default when the serial port 5 is set to Enable. BX710 series User’s Manual...

  • Page 121: Post Codes

    Detect CPU information including brand, SMI type (Cyrix or Intel®) and CPU level (586 or 686). Reserved Reserved Initial interrupts vector table. If no special specified, all H/W interrupts are directed to SPURIOUS_INT_HDLR & S/W interrupts to SPURIOUS_soft_HDLR. Reserved BX710 series User’s Manual...
  • Page 122 Put information on screen display, including Award title, CPU type, CPU speed …. Reserved Reserved Reserved Reserved Reserved Reset keyboard except Winbond 977 series Super I/O chips. Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Test 8254 Reserved Test 8259 interrupt mask bits for channel 1. BX710 series User’s Manual...
  • Page 123 Show message for entering AWDFLASH.EXE from FDD (optional) Reserved Initialize Init_Onboard_Super_IO switch. Initialize Init_Onbaord_AUDIO switch. Reserved Reserved Okay to enter Setup utility; i.e. not until this POST stage can users enter the CMOS setup utility. Reserved Reserved Reserved Reserved Initialize PS/2 Mouse BX710 series User’s Manual...
  • Page 124 USB final Initialization NET PC: Build SYSID structure Switch screen back to text mode Set up ACPI table at top of memory. Invoke ISA adapter ROMs Assign IRQs to PCI devices Initialize APM Clear noise of IRQs. BX710 series User’s Manual...
  • Page 125 Program daylight saving Update keyboard LED & typematic rate Build MP table Build & update ESCD Set CMOS century to 20h or 19h Load CMOS time into DOS timer tick Build MSIRQ routing table. Boot attempt (INT 19h) BX710 series User’s Manual...

  • Page 126: Com I/O Address And Register Function

    Interrupt ID register 03FBH Line control register 03FCH Modem control register 03FDH Line status register 03FEH Modem status register 03FFH Scratch register DLAB (Divisor Latch Access Bit) : The value in bit 7 of the line control register. BX710 series User’s Manual...
  • Page 127 IER: Interrupt Enable Register [DLAB=0] EMS ELSI ETHREI ERDAI Received data Interrupt enable Received data register empty Interrupt enable Receiver line status Interrupt enable Modem status interrupt enable [Always used at 0.] 1: Enable interrupt 0: Disable interrupt BX710 series User’s Manual...
  • Page 128 0 : Break signal off 1 : Send break signal DLAB (Divisor Latch Access Bit) In order to access the divisor latch register, you need to set the bit to 1. To access another register, set the bit to 0. BX710 series User’s Manual...
  • Page 129 Framing error (1 for occurrence of an error) Break interrupt (1 for detection of break state) Transmitter holding register empty (1 for transmission buffer being empty) Transmitter empty (Set to 1 when both transmitter holding register and transmitter shift register are empty.) BX710 series User’s Manual...
  • Page 130 DDCD TERI DDSR DCTS Delta CTS Delta DSR Trailing edge RI Delta data carrier detect 03FFH SCR : Scratchpad Register This is an 8-bit, readable/writable register which is available to the user to allow data to be saved temporarily. BX710 series User’s Manual...
  • Page 131 3600 4800 7200 9600 14400 19200 28800 38400 57600 76800 115200 153600 230400 Example : To set 9,600 bps, write "00" to the (MSB) divisor latch register and "12 (decimal)" to the (LSB) divisor latch register. BX710 series User’s Manual...

  • Page 132: Battery

    (1) Ensure that the power is turned off. (2) Remove the top cover. Figure 6.1 Removing the battery 1 (3) Remove the screws fixing the battery and remove the battery. Figure 6.2 Removing the battery 2 BX710 series User’s Manual...
  • Page 133 Figure 6.4 Removing the battery 2 (4) Remove the screws fixing the battery and remove the battery. Figure 6.4 Removing the battery 3 Disposing the battery Dispose the removed battery properly as instructed by local government. BX710 series User’s Manual...

  • Page 134: Difference From Ipc-Bx700 Series

    100BASE-TX/10BASE-T x 1 1000BASE-T x 1, 1000BASE-T × 2 100BASE-TX/10BASE-T x 1 Storage 2.5 inch IDE HDD or silicon disk 2.5 inch IDE HDD or silicon disk 2.5 inch SATA HDD drive drive PS/2 I/F None BX710 series User’s Manual...
  • Page 135 6. Appendix BX710 series User’s Manual...

  • Page 136: List Of Options

    Touch-panel cable for an analog RGB display IPC-CBL3-2 AT host Touch panel, COM cable (2m) IPC-CBL3-5 AT host Touch panel, COM cable (5m) Terminal block for connecting the RAS connector IPC-PSD-20 Terminal block for connecting the RAS connector BX710 series User’s Manual...
  • Page 137 7. List of Options CAUTION Precautions when using products other than our options If a product other than our option is used, the normal operation may be impaired or the functions may be limited. BX710 series User’s Manual...
  • Page 138 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [07072010] [05192010] Management No. NA00566 [07072010_rev2] Parts No. LYLE952...

Table of Contents
