Baumatic BO920TS User Manual

90cm multifunction oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

BO920TS
90cm Multifunction oven
Multi-language user manual

Advertisement

Table of Contents
loading

Related Manuals for Baumatic BO920TS

Summary of Contents for Baumatic BO920TS

  • Page 1 BO920TS 90cm Multifunction oven Multi-language user manual...

  • Page 2: Table Of Contents

    INDEX OVEN PRESENTATION Installation and Connection Demo mode Regulating the clock Switching on the oven Main Functions View of front console Cooking functions Simple gestures for cooking Regulating the cooking temperature Residual heat The food probe Special functions: turbo heat and turbo clean Oven light control Programming the oven Programming the timer: cooking time...

  • Page 4: Oven Presentation

    OVEN PRESENTATION Dear Customer, your new oven is managed by an electronic card which constantly monitors its operation in order to improve its all-round performance. The state-of-the-art, reliable and precise touch control system. The elegant, orderly and discreet interface, more user-friendly than ever before! Just a few buttons, lots of functions and no difficult combination or sequence of buttons.

  • Page 6: Demo Mode

    Demo mode This is the name of the mode usually implemented by the oven every time the electricity supply fails and also when the oven is first connected. The aim is to display all the control potentials with a recorded sequence of commands.

  • Page 7: Regulating The Clock

    Regulating the clock The oven signals the connection to the electricity main with a double beep. To regulate the system time, press the TIMER FUNCTIONS button for 5 sec. Every control used is confirmed by a beep. Regulate the clock using the + and – buttons: the dividing dots flash while the time is being set and stop flashing when the time has been acquired.

  • Page 8: Switching On The Oven

    Switching on the oven The oven is switched on using the ON/OFF symbol shown in the figure. The control activates all the symbols, illuminating the background. The control will wait eight seconds after switch-on for a cooking function to be chosen.

  • Page 9: Main Functions

    MAIN FUNCTIONS View of front console Cooking functions Special functions Programming the oven Oven On/Off Oven lock On/Off Temperature Oven lock Clock Cooking functions The control makes a total of twelve specific cooking functions available! Every function has a set temperature chosen on the basis of cooking tests using frequently used recipes and can easily be adjusted to suit personal preference.

  • Page 10: Simple Gestures For Cooking

    Simple gestures for cooking Two simple movements are all it takes to set a cooking programme, thanks to the state-of-the-art control logic: switch on the oven and select the best function for the dish you are preparing. Simply select it and touch it! The control proposes a temperature for every function.

  • Page 11: Regulating The Cooking Temperature

    Temperature Regulation The control makes use of a temperature probe with a level of precision of ±5°C offering maximum reliability of the cooking times required. To change the temperature simply use the plus and minus symbols. The range of regulation varies from +50°C to +250°C. It isn’t necessary to confirm the change, as the control is automatically activated after just a few seconds.

  • Page 12: The Food Probe

    Food probe (or probe thermometer) (available on certain models) The food probe is a thermometer which, when inserted into the food, makes it possible to check the internal temperature and use it to establish the end of cooking. For example, meat may look like it is cooked on the outside, but still be pink on the inside! The temperature reached by food during cooking is closely linked to problems relating to health and hygiene.

  • Page 13: Using The Food Probe

    Using the food probe The food probe socket is situated in the top front corner of the oven cavity, protected by a metal cover. Push the plug in as far as it will go. If it is correctly inserted, the control will give off a double beep.
  • Page 14 Remember that the probe will not work if it is connected when the oven is already switched on! Switch on the oven! Select the best cooking function for your recipe. After 5 sec. the temperature display switches to indicate the temperature of the food probe, i.e., the temperature which must be reached inside the food.
  • Page 15 FOOD MINIMUM INTERNAL TEMPERATURE Mince Hamburger 71°C Beef, veal, lamb, pork 74°C Chicken, turkey 74°C Beef, veal, lamb Roasts and steaks: The cooking temperature for rare meat is not indicated Rare by the NFSD as it is unsafe for health reasons Medium-rare 63°C Medium...

  • Page 16: Special Functions: Turbo Heat And Turbo Clean

    The end of cooking, established by reaching the internal temperature set for the food probe. All the oven programming functions (timer functions) are stopped, apart from the beeper (minute counter). When the food probe senses the temperature for which it has been set, the oven is automatically deactivated and you will hear a beep! When the cooking time is up, remember to disconnect the food probe and remove it from the oven.

  • Page 17: Oven Light Control

    5 sec.!! The cleaning process takes place at a temperature of 250°C and lasts one hour. Do not use it for cooking food!! The oven light is activated and can be switched off and on again at any time. All the self-cleaning panels will perform effectively for thirty cleaning processes, after this limit the panels must be replaced.

  • Page 18: Programming The Oven

    PROGRAMMING THE OVEN The programming of the oven offers three modes for controlling the cooking time. They are available with the standard cooking functions. When the food probe is used, they are deactivated (see specific chapter). The functions can be selected in sequence, from left to right, by touching the clock symbol: every time it is touched, a symbol lights up in sequence.

  • Page 19: Programming The Timer: Cooking End Time

    The count begins now. When the time is up, the oven will make a beeping sound, the heating elements will be switched off and cooking will stop. The special symbol will flash, as will the duration which was set on the clock display. Press any button to stop the beeping sound.

  • Page 20: Programming The Timer: Delayed Cooking

    The count begins now. When the set time is reached, the oven will give off a beep, the heating elements will be switched off and cooking will stop. The special symbol will flash, as will the cooking end time which was set on the clock display: press any button to stop the beeping sound.

  • Page 21: Programming The Timer: Minute Counter

    Change the cooking end time to make it coincide with the time you require. In our example this is 1.00 p.m. The oven now enters into stand-by and the oven light switches off. When it is time to start cooking, the light will not be automatically switched on because it is logical to assume that the delayed start coincides with your absence, so it is pointless to leave the light on for no reason.

  • Page 22: Programming The Timer: Cancelling The Programme

    Set the minutes using the + and - symbols. The count begins now. When the time indicated is up, the oven will make a beeping sound and the special symbol will flash. Press any button to interrupt the beeping sound. Programming the timer: cancelling the programme To cancel a programme, it is necessary to take the value assigned previously to zero or switch off the oven.
  • Page 23 Lock deactivated: white padlock open symbol on the display...
  • Page 24 cod. 2.002.05.0 - 3°ed...
  • Page 25 IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Customer Care Department. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.
  • Page 26 United Kingdom Czech Republic Baumatic Ltd., Baumatic CR spol s.r.o. Baumatic Buildings, Lípovà 665 6 Bennet Road, 460 01 Liberec 4 Reading, Berkshire Czech Republic RG2 0QX United Kingdom +420 483 577 200 www.baumatic.cz Sales Telephone (0118) 933 6900 Slovakia Sales Fax Baumatic Slovakia, s.r.o.
