Summary of Contents for Baumatic BO910SS
- Page 1 BO910SS 60 cm Built in multifunction self cleaning pyrolytic double oven.
- Page 2 User Manual for your Baumatic BO910SS 60 cm Built in multifunction self cleaning pyrolytic double oven NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 3: Table Of Contents
25 – 29 Electrical connection Connecting the mains supply cable 26 - 27 Replacing the mains supply cable Installing the oven into the kitchen cabinet Positioning the appliance Ventilation requirements My appliance isn’t working correctly 30 – 32 Baumatic consumables Contact details... -
Page 4: Environmental Note
Environmental note o The packaging materials that Baumatic uses are environmentally friendly and can be recycled. o Please discard all packaging material with due regard for the environment. -
Page 5: Important Safety Information
Baumatic’s Conditions Of Guarantee. The foregoing does not affect your statutory rights. o Repairs may only be carried out by Baumatic Service Engineers or their authorised service agent. Warning and safety instructions o This appliance complies with all current European safety legislation. - Page 6 Child Safety o Baumatic strongly recommend that babies and young children are prevented from being near to the appliance and not allowed to touch the appliance at any time. o If it is necessary for younger family members to be in the kitchen, please ensure that they are kept under close supervision at all times.
- Page 7 This appliance must be correctly installed by a suitably qualified person, strictly in accordance with the manufacturer’s instructions. o Baumatic Ltd. declines any responsibility for injury or damage, to person or property, as a result of improper use or installation of this appliance.
-
Page 8: Specifications
Specifications Product Dimensions Aperture dimensions Height: 885 mm 880-882 mm Width: 596 mm 562-565 mm Depth: 545 mm 560 mm (min) Cooling fans o Two tangential cooling fans are fitted inside of this appliance, to make the internal temperature of the oven stable and the external surface temperature lower. -
Page 9: Product Specifications
Product specifications: o Energy efficiency class: A/A o LED full programmer o 2 x Cooling fans o Thermostatically controlled grills o Electronically controlled thermostat (main oven only) o Triple-glazed removable doors o Moulded side racks (main oven only) o Pyro enamel o Main oven: multifunction self-cleaning pyrolytic oven o 9 functions o Gross capacity: 61 litres... -
Page 10: Control Panel
For future reference please record the following information which can be found on the rating plate and the date of purchase which can be found on your sales invoice. The rating plate for your oven can be located by opening the bottom oven door and looking on the front frame of the oven chassis. -
Page 11: Oven Programmer / Timer Display
Oven programmer / timer display 16) Auto function symbol 17) Minute minder symbol 18) Manual operation symbol Initial set-up of your oven Selecting manual operation mode After your appliance is connected to the mains supply for the first time, the numbers on the timer display will flash. Before you can select a cooking function or set a temperature, you must set the appliance into manual operation mode. -
Page 12: Timer Functions
o It is perfectly normal for a smell to be produced during this process. o You should make sure that any windows in the room are left open during this process. o It is advisable for you not to remain in the room whilst the burning off process is taking place. -
Page 13: The Duration Function (Main Oven Only)
o An alarm will sound when the countdown time has elapsed. The alarm can be silenced by pressing the minute minder button (10) or manual operation button (13). o Important: The oven will continue to heat once the alarm has been silenced. If you have finished cooking, then you should turn the oven function selector and thermostat control knob to the OFF position. -
Page 14: The End Cook Function (Main Oven Only)
o IMPORTANT: If you have not turned the main oven function selector knob and main oven thermostat control knob to their OFF positions, the appliance will continue to operate as soon as you press the manual operation button (13). The end cook function (main oven only) This function is similar to the duration function, however instead of selecting a period of time that you wish the oven to switch off after, you select the time of day that you wish the oven to switch off at. -
Page 15: The Start And End Time Function (Main Oven Only)
The start and end time function (main oven only) This function will allow you to set a time in the future that the oven switches on at and a time that the oven will switch off at. o Use the main oven function selection knob (3) to select the mode of cooking that you require. -
Page 16: Adjusting The Audible Signal
Adjusting the volume of the audible signal o To adjust the level of the audible signal, when it is sounding, press the minus button (14) and it will adjust through the 3 sound levels. Release the minus button and the sound level of the audible signal will be set. -
Page 17: Main Oven Thermostat Control Knob
roasting and baking on one shelf only. CONVECTION OVEN AND FAN: This method of cooking provides traditional cooking with heat from the top and the lower element, it also utilises the circulation fan. This ensures a fast and even distribution of the heat. Suitable for light and delicate baking, such as pastries. -
Page 18: Selecting A Lower Oven Function
Selecting a lower oven function o The lower oven function selection knob should be used to select the particular mode of cooking that you require. o The appliance will utilise different elements within the oven cavity, depending on the oven function that you select. o When a function is selected, the lower oven power indicator light will come on. -
Page 19: Oven Operating Lights (Main And Lower Oven)
Oven operating lights (main and lower oven) o These lights will come on to indicate that the oven’s heating elements are in operation. o The lights will switch off when the temperature set on the thermostat control knob has been reached. o They will cycle on and off throughout the cooking time. -
Page 20: Warnings
o The oven light will remain on during cooking. Warnings o Keep the oven door closed when using any of the cooking functions, including the grill functions. o Do not use aluminium foil to cover the enamelled baking tray or heat items wrapped in aluminium foil under the grill. -
Page 21: Cleaning And Maintenance
Cleaning and maintenance External cleaning operations must only be carried out when oven cool with appliance disconnected from your mains supply. o The oven should be thoroughly cleaned before it is operated for the first time. The pyrolytic cleaning process listed below should be followed AT LEAST once a month or more frequently if there have been food spillages inside of the cavity. -
Page 22: General Cleaning Instructions
o Use the plus (7) and minus (5) buttons to set the length of cleaning cycle that you require. o The oven door will automatically lock when the temperature inside the oven reaches 300°C. When this happens, the oven will give off an acoustic signal and the light underneath the key symbol on the control panel will light to indicate that the door is locked. -
Page 23: Replacing The Oven Bulb (Main Oven)
Any damage that is caused to the appliance by a cleaning product will not be fixed by Baumatic free of charge, even if the appliance is within the guarantee period. Replacing the oven bulb (main oven) -
Page 24: Removing The Oven Door For Cleaning
o Place the lamp cover back into position. There is a curve on one side of the cover; this should be on the right hand side as the cover goes back into place. Removing the oven door for cleaning To facilitate the cleaning of the inside of the oven and the outer frame of the oven, the door can be removed as follows:- o The hinges (A) have two movable bolts on them (B). -
Page 25: Installation
INSTALLATION The installation must be carried out by a suitably qualified person, in accordance with the current version of the following. o UK Regulations and Safety Standards or their European Norm Replacements. o Building Regulations (issued by the Department of the Environment). -
Page 26: Connecting The Mains Supply Cable
Connecting the mains supply cable o The mains terminal block is located on the rear of the oven and the terminals are accessible by removing the terminal block cover. You should remove the cover screw to access this. o The cable connections must be made in accordance with the diagram below:- o 1, 2 and 3 are the live connection, 4 and 5 are the neutral connection and the remaining one is the earth connection. -
Page 27: Replacing The Mains Supply Cable
o IMPORTANT: The appliance must NOT be connected to the mains supply by means of a 13A plug and socket. o The cable can be looped if necessary, but make sure that is not kinked or trapped when the oven is in position. Care must be taken to avoid the cable being in contact with hot parts of the appliance. -
Page 28: Installing The Oven Into The Kitchen Cabinet
Installing the oven into the kitchen cabinet Positioning the appliance o Ensure that the aperture that you will be fitting the oven into is of the size given in the above diagram. o The oven must be fitted into a housing unit with the ventilation cut-outs shown in the “Ventilation requirements”... -
Page 29: Ventilation Requirements
Ventilation requirements (Figure shows the ventilation and cut-out requirements for the installation of the appliance into a tall housing unit). o Ensure that the oven has been securely fixed into the housing unit. The fixing of the oven into the housing is made by using four screws. -
Page 30: My Appliance Isn't Working Correctly
My appliance isn’t working correctly o The ovens aren’t coming on. * Check that the oven is in manual operation mode. * Check that you have selected a cooking function and a cooking temperature. o There appears to be no power to the ovens. * Check that the appliance has been connected to the electrical mains supply correctly. - Page 31 o The oven light is not working * Refer to pages 23 - 24 and follow the “Replacing the oven bulb” section. o I am getting condensation in my oven * Steam and condensation is a natural by product of cooking any food with high water content, such as frozen food, chicken etc.
- Page 32 Or any installation other than the one specified by Baumatic Ltd. has been completed. Please refer to the conditions of guarantee that appear on the warranty card that you receive with the appliance.
-
Page 33: Baumatic Consumables
BC005 Stainless Steel Cleaner and Protector (250 ml) o BC007 E-Cloth – General Purpose Cloth o BC008 Microwave Cover To order a Baumatic consumable product please call 0123 5437 244 and quote the product code. You can also order online from eshop.baumatic.co.uk... -
Page 34: Contact Details
United Kingdom Czech Republic Baumatic Ltd., Baumatic CR spol s.r.o. Baumatic Buildings, Lípovà 665 6 Bennet Road, 460 01 Liberec 4 Reading, Berkshire Czech Republic RG2 0QX United Kingdom +420 483 577 200 Sales Telephone www.baumatic.cz (0118) 933 6900 Sales Fax...
