Disassembly and reassembly
(d) Remove the TOP PCB ASSY.

3-3 Disassembly of barrel

1. Disassembly of PCB FPC-CCD ASSY.
(a) Remove the three SCREWs from the PCB FPC-CCD ASSY.
3-10
TOP PCB ASSY
Fig 3-18
SCREW-TAPTYPE
Fig 3-19
