Allows you to connect a USB cable or an AV cable to the camera. Microphone Allows you to record sound with the recorded movie clips. Shutter release button Flash Power button Mode dial Microphone Viewfinder Self-timer LED PC/AV terminal DC input terminal Lens EN-1...
LCD monitor Provides menu information to operate the camera, and previews the picture before taking it and review it afterwards. Four-way controller Allows you to scroll through menus and pictures, and then select choices. ( )- Selects the flash mode in Capture mode. ( )- Selects the self-timer mode in Capture mode.
GETTING STARTED Attaching the Camera Strap Attach the camera strap as shown in the illustration. Inserting the Battery 1. Open the battery/card cover. 2. Insert the battery in the correct orientation as shown on the right. 3. Close the battery/card cover.
Inserting the SD Memory Card (Optional Accessory) 1. Open the battery/card cover. 2. Insert the SD memory card in the correct orientation as shown on the right. Hold the SD memory card with its metal contact end surface facing the rear side of the camera, and then insert the card as far as it can 3.
Page 6
Choosing the OSD (On-Screen Display) Language 1. Set the mode dial to 2. Use the four-way controller ( ) to select [Language] and press the button. 3. Use the four-way controller ( select the language. 4. Press the language selection. EN-6 ) to button to confirm the...
Setting the Date and Time 1. Set the mode dial to 2. Select [Date Adjust] with the four-way controller ( ). 3. Use the four-way controller ( select the date type. 4. Press the button. The Date Adjust screen appears. 5.
Taking Still Pictures Shutter release button Power button Viewfinder LCD monitor 1. Press the 2. Set the mode dial to 3. Compose your image in the LCD monitor or through the viewfinder. 4. Press the shutter release button halfway down to automatically focus the image.
Recording Movie Clips This mode allows you to record movie clips with sound via built-in microphone. 1. Rotate the mode dial to your camera on by pressing the button. 2. Press the shutter button to start recording. 3. To stop recording, press the shutter button again.
Erasing Images 1. Press the The last image will be displayed on the screen. 2. Select the image you want to erase with the four-way controller ( 3. Press the 4. Use the four-way controller ( select [This Image]. 5. Press the 6.
Setting Up Your Digital Camera After installing the necessary software on your computer, you must now set up your digital camera to transfer images from the camera to your computer. The USB driver included in the CD-ROM (S-SW38) is exclusively for Windows 98/98SE.
Connecting the Camera to Your Computer 1. Connect the camera to the PC with the USB cable. If there is no SD Memory Card in the camera, the images stored in the internal memory will be transmitted to the computer. 2.
Page 13
Downloading Images/Movie Clips When the camera is turned on and connected to your computer, it is considered to be a disk drive, just like a floppy disk or CD. You can download (transfer) images by copying them from the “removable disk” (“untitled”...
USING THE DIGITAL CAMERA AS A PC CAMERA Your digital camera can act as a PC camera, which allows you to videoconference , or have a real-time conversation with friends or family. 1. Install the PC camera driver. The PC-camera driver included in the CD-ROM (S-SW38) is exclusively for Windows.
Page 15
To use Windows NetMeeting for videoconferencing 1. Go to Start=>Programs=>Accessories=>Communications => NetMeeting to launch the NetMeeting program. 2. Click the Start Video button to view live video. 3. Click the Place Call button. 4. Type the e-mail address or the network address of the computer that you are calling.
