Panasonic CF-73 Series Reference Manual

Panasonic CF-73 Series Reference Manual

Personal computer
Hide thumbs Also See for CF-73 Series:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Reference Manual
When the cursor is moved to an item under [Contents] or to ⇒ page number (green display), the shape of the
cursor will change to
page in the Reference Manual will be displayed.
We recommend that this Reference Manual be printed.
Contents
Read Me First................................................................2
Key Combinations........................................................3
LED Indicators..............................................................6
Touch Pad.....................................................................7
Touchscreen* ...............................................................9
Standby/Hibernation Functions................................12
Security Measures .....................................................16
Computing on the Road ............................................20
Battery Power .............................................................22
Multimedia Pocket......................................................27
CD Drive ......................................................................29
PC Cards .....................................................................34
RAM Module ...............................................................36
Port Replicator ...........................................................37
Printer .........................................................................38
External Display ........................................................39
USB Devices ..............................................................42
Modem ........................................................................44
LAN..............................................................................46
Wireless LAN ..............................................................48
Hard Disk Drive ..........................................................51
Setup Utility ................................................................52
Technical Information................................................59
DMI Viewer ..................................................................60
List of Error Codes.....................................................61
Dealing with Problems (Advanced) .........................63
* Only for models with touchscreen
. Under this condition, if characters are tapped (or a click is made), the corresponding
Personal Computer
Reference Manual
CF-73
Model No.
®
Series

Advertisement

Table of Contents
loading

Related Manuals for Panasonic CF-73 Series

Summary of Contents for Panasonic CF-73 Series

  • Page 1: Table Of Contents

    ® Personal Computer Reference Manual CF-73 Series Model No. Contents Read Me First..............2 Key Combinations............3 LED Indicators..............6 Touch Pad..............7 Touchscreen* ...............9 Standby/Hibernation Functions........12 Security Measures .............16 Computing on the Road ..........20 Battery Power .............22 Multimedia Pocket............27 CD Drive ..............29 PC Cards ..............34 RAM Module ...............36 Port Replicator ............37 Printer .................38...

  • Page 2: Read Me First

    Read Me First ● If the user has logged on without the administrator authority, some functions may not be executable, and some screens may not be displayed as shown in this manual. If this happens, log on with the administrator authority to enable these functions. ●...

  • Page 3: Key Combinations

    Key Combinations CAUTION ● Do not press the following key combinations while using the touch pad (external mouse), touchscreen (only for mod- els with touchscreen) or other keys. NOTE ● Do not press the following key combinations until you log on to Windows and the hard disk drive indicator turns off. Note, however, that the key combinations Fn + F1 , Fn + F2 and Fn + F3 are operable in the Setup Utility.
  • Page 4 Key Combinations Popup Window Functions Function Descriptions (Displayed after logging on to Windows) Volume control (down) Pressing this key combination adjusts the vol- Fn + F5 Volume control (up) ume of the internal speakers and headphone Fn + F6 jack. NOTE ●...
  • Page 5 Windows 2000 Select [Start] - [Programs] - [Panasonic] - [Hotkey Settings]. Windows XP Select [Start] - [All Programs] - [Panasonic] - [Hotkey Settings]. Set the parameters. A.Use Fn key lock Add the check mark if you want to enable the Fn key lock function.

  • Page 6: Led Indicators

    Quickly save your data and power off your computer. Remove the battery pack and disconnect the AC adaptor, then connect them again. If the problem persists, contact Panasonic Technical Support. Blinking orange* : Battery cannot be recharged temporarily because...

  • Page 7: Touch Pad

    Touch Pad Use the touch pad to move the cursor on the display and perform normal computer operations. A.Work Surface (Touch Pad) B.Left Button C.Right Button Function Operation Moving the Cursor Move the tip of your finger lightly over the work surface.
  • Page 8 Touch Pad Handling the Touch Pad ● The touch pad is designed to be used with a fingertip only. Therefore, avoid the following actions, which may cause damage to the work surface. • Placing any object on the work surface •...

  • Page 9: Touchscreen

    Touchscreen <Only for models with touchscreen> Your computer is equipped with a touchscreen display allowing you to perform the same operations as the touch pad or mouse by touching the surface of the display with the stylus (included). The following explanation gives one example (for the default settings). ⇒...

  • Page 10: Configuring The Touchscreen

    Touchscreen <Only for models with touchscreen> Configuring the Touchscreen When needed, the touchscreen can be configured using the following steps. Windows 2000 Select [Start] - [Settings] - [Control Panel] - [Touch Panel]. Windows XP Select [Start] - [Control Panel] - [Other Control Panel Options] - [Touch Panel].
  • Page 11 Touchscreen <Only for models with touchscreen> Handling the Touchscreen ● Use the stylus included with the computer. Do not use an implement other than the sty- lus that comes with the computer. ● Do not place any object on the surface or press down forcefully with sharp-pointed objects (e.g., nails), hard objects that can leave marks (e.g., pencils and ball point pen).

  • Page 12: Standby/Hibernation Functions

    Standby/Hibernation Functions Starting Up Your Computer Quickly If you use the standby or hibernation function, you can shut down the computer without closing programs and documents. Upon restarting your computer from either the standby or hibernation mode, you can immediately continue working in all programs, or documents that were open at the time the computer was placed into standby or hibernation mode.
  • Page 13 Standby/Hibernation Functions Setting for Using the Hibernation Mode Windows 2000 Select [Start] - [Settings] - [Control Panel] - [Power Options]. In [Hibernate], add the check mark for [Enable hibernate support] and select [OK]. Windows XP Select [Start] - [Control Panel] - [Performance and Maintenance] - [Power Options].

  • Page 14: Using The Power Switch

    Standby/Hibernation Functions ■ In standby or hibernation mode ● Do not insert or remove peripherals; abnormal operation may result. ● Do not insert or remove the multimedia pocket device (except when using a second battery pack). ● In standby mode, power is consumed. If PC Cards are inserted, more of that power is consumed.

  • Page 15: Resuming Operation

    Standby/Hibernation Functions Resuming Operation Press the power switch (A). When [Standby]* or [Hibernate] is selected as the setting for [When I close the lid of my portable computer] in [Control Panel]* - [Power Options] - [Advanced], the com- puter will enter either the standby or hibernation mode when the display is closed. Operation will resume when the display is opened.

  • Page 16: Security Measures

    Security Measures To prevent unauthorized access of your computer, the various security measures are pro- vided below. Situation Function to use Reference ⇒ below You do not want your com- Supervisor Password puter to be used without per- User Password mission.
  • Page 17 ● Do not forget your password. If your Supervisor Password is forgotten you will be unable to use your computer. Contact Panasonic Technical Support. ● When running the Setup Utility, do not leave your computer even for a short time, as...
  • Page 18 ● Do not forget your password. If a password is forgotten, you will be unable to use your computer. Contact Panasonic Technical Support. ● When running the Setup Utility, do not leave your computer even for a short time, as...
  • Page 19 Press F10 and select [Yes], then press Enter. CAUTION ● To change your hard disk drive • To change your hard disk drive, contact Panasonic Technical Support. • Before changing the hard disk, be sure to set the [Hard Disk Lock] to [Disable].

  • Page 20: Computing On The Road

    Windows 2000 Select [Important Battery Tips] or [Important Tips] in [Start] - [Programs] - [Panasonic] - [On-Line Manuals]. Windows XP Select [Important Battery Tips] or [Important Tips] in [Start] - [All Programs] - [Panasonic] - [On-Line Manuals]. ● Four Important Points POINT Be sure to charge your battery before use.
  • Page 21 Computing on the Road Setting the Intel(R) SpeedStep (TM) technology Windows 2000 By using the Intel(R) SpeedStep(TM) technology applet, you can set the computer's performance to optimize power consumption. Starting up the Intel(R) SpeedStep (TM) technology Select on the taskbar. NOTE ●...

  • Page 22: Battery Power

    Quickly save your data and power off your computer. Remove the battery pack and disconnect the AC adaptor, then connect them again. If the problem persists, contact Panasonic Technical Support. Blinking orange* Battery cannot be recharged temporarily because the internal temperature of the battery pack is outside of the acceptable temperature range for recharging.
  • Page 23 Battery Power Checking the Remaining Battery Power Press to Check the Remaining Battery Power on the Screen (After logging on to Windows) When the battery pack is inserted in the computer (example) When the battery pack is not inserted in the computer NOTE ●...
  • Page 24 Battery Power When the Remaining Battery Charge Becomes Low The following is factory default setting. When remaining battery capacity falls to 10% When remaining battery capacity falls to 5% [Low battery alarm] [Critical battery alarm] ● ● Displays a message indicating the low Displays a message indicating the low battery level.
  • Page 25 Battery Power Accurately Displaying Battery Capacity The battery pack has a function for measuring, storing and learning about battery capacity. Using this function properly to accurately display remaining battery capacity requires that the battery pack be fully charged (charged to 100%), then fully discharged, and then fully charged again.

  • Page 26: Replacing The Battery Pack

    Battery Power Replacing the Battery Pack When the charge provided by your battery pack is supplied for only a short period of time, even after fully charging according to the instructions, it may be time to replace your bat- tery pack. The battery pack is a consumable item and therefore will require replacement (CF-VZSU26).

  • Page 27: Multimedia Pocket

    Multimedia Pocket You may use any of the following devices. ● DVD-ROM drive ● DVD-ROM & CD-R/RW drive ● Second battery pack Confirm the latest information on optional products in catalogs, etc. NOTE ● Be sure to read the Operating Instructions of the devices. ●...
  • Page 28 Multimedia Pocket Inserting/Removing CAUTION ● Do not insert/remove the multimedia pocket device in the standby or hibernation mode, or when the hard disk drive indicator ( ) is on. ● Do not select [Standby] or [Hibernate] as the setting for [When I close the lid of my portable computer] in [Control Panel] - [Power Options] - [Advanced].

  • Page 29: Cd Drive

    CD Drive Usage Precautions CD Drive ● Do not leave the tray in the open position or touch the lens area. Should the lens become soiled by dust or dirt, the unit may not read discs properly. Under some condi- tions, dust may build up on the optical lens or disc, possibly resulting in malfunction.
  • Page 30 CD Drive Setting a Disc Power on your computer Open the disc tray Press the eject button (A) and slowly pull out the tray. Place a disc Place the disc with the label facing upward in the drive and push down until the cen- ter holder (B) clicks.
  • Page 31 CD Drive Information for the DVD-ROM Drive (Model with a DVD-ROM Drive) ● To play DVD-Video or MPEG2 files, install the DVD playback software (included). For information on how to install the software, refer to the instructions of the software ⇒...
  • Page 32 CD Drive Information for the DVD-ROM & CD-R/RW Drive (Model with a DVD-ROM & CD-R/RW Drive) ● Before using the drive for the first time, remove the protective sheet from the lens area. The protective sheet inside the drive delays the opening of the drive by about ten sec- onds.
  • Page 33 CD Drive ■ When writing to CD-R/RW discs ● Using the CD-ROM of the CD-R/RW writer software (included), install the applica- tion software on your computer. For information on how to install the software, refer to the instructions of the CD-R/RW writer software. ●...

  • Page 34: Pc Cards

    PC Cards Your computer has two PC Card slots. These slots conform to the PC Card Standard; therefore, communications or SCSI devices, etc., may be utilized. The slots allow you to use two Type I or Type II cards (or one Type I and one Type II), or one Type III card. ■...

  • Page 35: Removing A Pc Card

    PC Cards CAUTION ● When using a PC Card to connect a peripheral device (SCSI, etc.): Connect the peripheral device to the card. Turn the device ON. Slide the card in until it snaps into place. ● When inserting a card, do not force the card in if difficulty is encountered. Depend- ing on the shape of the card, a segment may remain protruding from the slot after insertion.

  • Page 36: Ram Module

    RAM Module Inserting additional RAM modules and increasing memory will enable you to run Windows and application software more easily, and to increase overall operating efficiency. Use a RAM module meeting the RAM module specifications below. If a module is used that does not meet the specifications, there are cases in which data may become unusable or the computer may not operate properly..

  • Page 37: Port Replicator

    Port Replicator A port replicator is available as an option (CF-VEB731). This device eliminates the has- sles of having you connect/disconnect the various cables when carrying your computer around and allows a variety of peripherals to be connected including a headphone or microphone, etc.

  • Page 38: Printer

    Printer The following methods can be used to connect a printer. ● USB printer: Can be connected to a USB port on this computer. ● Parallel printer: • Optional I/O Box (CF-VEBU03) or Port Replicator (CF-VEB731) is required. For more information about these connections, refer to the I/O Box or Port Replicator Operating Instructions.

  • Page 39: External Display

    External Display ( ⇒ Power off your computer. “Starting Up/Shutting Down”) Do not shut down using the standby or hibernation function. Connect the external display to the external display port (A) on your computer. Turn on the external display, then turn on your computer. After Windows starts up, the screen is displayed on both the internal LCD and the external display.

  • Page 40: Extended Desktop

    External Display Extended Desktop Windows XP With Extended Desktop, you can use both the internal LCD and the external display as an extended display domain. You can also drag a window from the internal LCD to the exter- nal display. Select [Settings] in [Control Panel] - [Appearance and Themes] - [Display].
  • Page 41 External Display Precautions ● When the application running is not shown on the display, refer to the following items. Under the condition the application is in the external display, or after the application is closed in the external display, there are cases the application will not be shown in the display when performed the next time if the position of the extended display is changed or the Extended Desktop is closed.

  • Page 42: Usb Devices

    USB Devices Connecting/Removing USB devices Connecting USB Devices Connect the USB device to the USB port (A) of your computer. For information on how to connect to the USB device or install the driver, refer to the oper- ation manual of the USB device. NOTE ●...

  • Page 43: Usb Floppy Disk Drive

    USB Devices USB Floppy Disk Drive Note the following when using an optional USB floppy disk drive (CF-VFDU03). ● Do not power off your computer or press the floppy disk drive eject button while the floppy disk drive being accessed. Doing so may damage the data on the floppy disk and render the floppy disk useless.

  • Page 44: Modem

    Modem Connecting the Internal Modem with a Telephone Jack CAUTION ● Do not use the PBX internal phone lines inserted in company offices. Doing so may lead to a fire or electric shock. ● It is not possible to connect the modem to any of the following lines. •...
  • Page 45 Modem Ring Resume Function With this function, if the telephone that is connected to the modem rings in the standby mode, the power of the computer automatically switches ON. This function is convenient when using automatic information receiving applications such as a FAX application.

  • Page 46: Lan

    When using the computer as a network computer, some additional settings may have to be made depending on the usage conditions. We recommend asking your system admin- istrator or the person in charge of the network. Connecting LAN ( ⇒ Power off your computer.
  • Page 47 Wake up from LAN This is a function of the internal LAN to automatically power the computer on from a net- work server when the computer is in the standby or hibernation mode. To use this function, it is necessary to have a network environment that accommodates Wake up from LAN. Enabling the Wake up from LAN Function Windows 2000 Select [Device Manager] in [Start] - [Settings] - [Control Panel] - [System] - [Hard-...

  • Page 48: Wireless Lan

    Wireless LAN If you use a wireless LAN, you can use a network without cable connections. CAUTION ● Communication is performed through the wireless LAN antenna. Do not block the antenna area (A) with your hand or otherwise interfere with the passage of the radio signals.
  • Page 49 Wireless LAN Setting At the time of purchase, the profile for the wireless LAN has not been set. Set the profile using the following procedure. The settings will vary for different network environments depending on the network system being used. For more details, ask your system administrator or the person in charge of the network.
  • Page 50 Wireless LAN Check the Communication Status Windows 2000 Select [Start] - [Programs] - [Intel Network Adapters] - [Intel(R) PROSet] to open the Intel PROSet. Windows XP Select [Start] - [All Programs] - [Intel Network Adapters] - [Intel(R) PROSet] to open the Intel PROSet.

  • Page 51: Hard Disk Drive

    Hard Disk Drive To Change your Hard Disk Drive, Contact Panasonic Technical Support. Inserting/Removing the Hard Disk Drive CAUTION ● To change your hard disk drive, contact Panasonic Technical Support. ● Be sure to back up all important data before the change.

  • Page 52: Setup Utility

    Setup Utility Running the Setup Utility Press the power switch to turn on the computer, and immedi- ately hold down F2. Release the key when the Setup Utility starts up. If [Enter Password] is displayed, enter your password. ⇒ page When a User Password is entered, some contents cannot be changed ( 16).

  • Page 53: Information Menu

    Setup Utility Information Menu Language: [English] Model No.: CF-xxxxxx Serial No.: xxxxxxxxxxx CPU Type: xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx CPU Speed: xxx GHz BIOS : Vx.xxLxx Embedded Controller: Vx.xxLxx System Memory: xxx MB Video RAM: xx MB Primary Master: xx GB Secondary Master: CD Drive ■...

  • Page 54: Main Menu

    Setup Utility Main Menu System Date: [xx/xx/xxxx] System Time: [xx:xx:xx] Touch Pad: [Enable] [Enable] Touchscreen* [Simultaneous] Display: [Enable] Display Expansion: [High] CD Drive Speed: [Normal Temperature] Environment: [Disable] Audio Power Management: ■ Parameters : Default) Touch Pad Disable Enable Disable Touchscreen* Enable External Monitor...

  • Page 55: Advanced Menu

    Setup Utility Advanced Menu Serial Port A: [Auto] Serial Port B: [Auto] Parallel Port: [Auto] Mode: [ECP] Modem: [Enable] LAN: [Enable] Boot up from LAN: [Enable] Wireless LAN: [Enable] Legacy USB Support: ■ Parameters : Default) Serial Port A Disable Enable Auto 3F8/IRQ4 I/O IRQ*...

  • Page 56: Security Menu

    Setup Utility Security Menu Password on boot: [Enable] Set Supervisor Password: [Enter] Boot First Menu: [Enable] Hard Disk Lock: [Disable] User Password Protection: [No Protection] [Enter] Set User Password: NOTE ● When the Setup Utility is started up with the User Password: •...

  • Page 57: Boot Menu

    ● The device for starting up the operating system can also be selected during com- puter start-up. After the computer is turned on and ESC is pressed at [Panasonic] screen, [Boot Menu] (the device selection display) will appear. When the setting of [Boot] menu is changed, the selection screen display will also change.

  • Page 58: Exit Menu

    Setup Utility Exit Menu Save Values & Exit Exit Without Saving Changes Get Default Values Load Previous Values Save Current Values Refresh Battery ■ Parameters Save Values & Exit Exit the Setup Utility and save your changes to CMOS. Exit Without Saving Changes Exit the Setup Utility without saving your changes to CMOS.

  • Page 59: Technical Information

    Technical Information Network Connections and Communications Software If the power saving function (standby or hibernation mode) activates while communications software is being used, the network connection may be interrupted, or performance may be adversely affected. If this happens, restart the computer. Be sure to close the communications software before using the power saving function.

  • Page 60: Dmi Viewer

    Select [DMI Viewer] from [Start] - [Programs] - [Panasonic]. Windows XP Select [DMI Viewer] from [Start] - [All Programs] - [Panasonic]. The screen shown below is displayed. When you select an item, detailed information on that item will be displayed.

  • Page 61: List Of Error Codes

    If your system displays any of the below error messages other that the ones marked with an asterisk (*), write down the message and contact Panasonic Technical Support. If your system fails after you make changes in the Setup menus, reset the computer, enter Setup and install Setup defaults or correct the error.
  • Page 62 List of Error Codes 02F5: DMA Test Failed ServerBIOS2 test error: Cannot write to extended DMA (Direct Memory Access) registers. 02F6: Software NMI Failed ServerBIOS2 test error: Cannot generate software NMI (Non-Maskable Interrupt). 02F7: Fail - Safe Timer NMI Failed ServerBIOS2 test error: Fail-Safe Timer takes too long.

  • Page 63: Dealing With Problems (Advanced)

    Dealing with Problems (Advanced) When a problem occurs, refer to this page. If a problem appears to be related to a software application, read the software related manual. If you still cannot troubleshoot the problem, contact Panasonic Technical Support. ● Starting Up ●...
  • Page 64 Select [Start] after selecting required items in [Check disk options]. ● At startup, hold down F8 when [Panasonic] screen disappears, and release your finger when the Windows Advanced Option Menu is displayed. Start the computer in Safe Mode, and confirm the details of the error.
  • Page 65 Setup Utility ● [Enter Password] is displayed Enter the User Password or Supervisor Password. If you have forgotten it, contact Panasonic Technical Support. ● [Advanced] and [Boot] menu Restart the Setup Utility with the Supervisor Password. can not be registered ●...
  • Page 66 Quickly save your data and power off your computer. Remove the battery pack and disconnect the AC adaptor, then connect them again. If the problem persists, contact Panasonic Technical Support. The battery pack or recharging function may be defective. ●...
  • Page 67 Check to see if the hard disk is full. If it is full, delete unnecessary files. ● Your hard disk content may be corrupted. Contact Panasonic Technical Support. ● Trouble has occurred with the You may need to clean the lens or disc.
  • Page 68 Dealing with Problems (Advanced) ● Connecting Peripherals ● An error occurs while installing When you install the driver for a PC Card or peripheral device, be sure to use a the driver driver that is compatible with the operating system. If you use an incompatible driver, malfunction may occur.
  • Page 69 Dealing with Problems (Advanced) ● Connecting Peripherals (Continued) ● A USB device does not work Make sure a driver is installed. ● Contact the manufacturer of the product. ● When is displayed in the Device Manager, try removing and inserting the device once more.
  • Page 70 Dealing with Problems (Advanced) ● Others ● Press Ctrl + Shift + ESC to open Task Manager and close the software applica- Computer hangs tion which is not responding. ● After shutting down by pressing the power switch for more than four seconds, press the power switch to power on and open the application again.
