Panasonic KX-TG5521RUB Service Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Answering Machine
  5. KX-TG5521RUB
  6. Service manual
Panasonic KX-TG5521RUB Service Manual

Panasonic KX-TG5521RUB Service Manual

Digital cordless answering system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AOH and Caller ID Compatible
KX-TGA551RUB
(Handset)
(Charger Unit)
Configuration for each model
Model No
Base Unit
Handset
KX-TG5521 1 (TG5521) 1 (TGA551)
KX-TGA551*
1 (TGA551)
* KX-TGA551 is also an optional accessory, which contains
a handset and a charger.
KX-TG5521RUB
(Base Unit)
Charger Unit Expandable
Up to 6
1
Telephone Equipment
KX-TG5521RUB
Model No.
KX-TGA551RUB
Digital Cordless Answering System
B: Piano Black Version
(for Russia)
© Panasonic System Networks Co., Ltd. 2010
Unauthorized copying and distribution is a
violation of law.
ORDER NO. KM41007179CE
