Harbinger M350 Owner's Manual

2.1 portable pa system
Hide thumbs Also See for M350:
Table of Contents

Advertisement

Quick Links

M350
2.1 P
Pa S
ortable
yStem
MuV ¨
PORTABLE
PA
S E R I E S

Advertisement

Table of Contents
loading

Related Manuals for Harbinger M350

Summary of Contents for Harbinger M350

  • Page 1 M350 2.1 P Pa S ortable yStem MuV ¨ PORTABLE S E R I E S...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . FEATURES .

  • Page 3: Safety Instructions

    Please keep this instruction manual for future reference and for the duration wide blade or the third prong is provided for your safety. If the provide of owning the M350 Portable PA System. Please carefully read and plug does not fit into your outlet, consult an electrician for replacement of understand the instructions inside this owner’s manual before attempting to...
  • Page 4 THIS SYMBOL IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE ACCOMPANYING THE UNIT. APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS. M350 Owner's Manual...

  • Page 5: System Maintenance

    • Turn the power switch off when the M350 is not in use. • The AC cable should be unplugged from the AC outlet if the M350 will not be used for an extended period • Avoid plugging the AC adapter into an AC outlet that is also powering high-consumption appliances such as electric heaters or televisions •...
  • Page 6 • A slightly damp cloth may be used to remove stubborn grime and dirt. Never use cleaners such as alcohol or thinner • The M350 contains electronic circuitry that may cause interference if placed too close to radio or television receivers. If this occurs, move...

  • Page 7: What's In The Boxes

    M350 2.1 PORTABLE PA SYSTEM WHAT’S IN THE BOXES BOX #1 AC Cable The Main Sub Speaker/Amp/Mixer Speaker Mounts And Satellite Speakers Speaker Cables BOX #2 Speaker Stands Carrying Case (For The Stands And Mounts) M350 Owner's Manual...

  • Page 8: System Configurations

    S E R I E S SYSTEM CONFIGURATIONS The M350 Portable PA System can be set up for optimal sound in any studio, stage or practice room. 2.1 STEREO SETUP Place the subwoofer/amp module in the center of your setup. Place the two satellite speakers on their respective tripods and position them equidistant from the subwoofer for realistic spatial realism.
  • Page 9 (taken from one of the speaker tripods) and insert it into the mounting hole. Place one satellite speaker onto the pole, and slide the other satellite speaker on top. This method only uses a single cable. M350 Owner's Manual...

  • Page 10: Setting Up The System

    7. Turn on the power of the sub speaker/mixer. Slowly increase the level on the channel you’ve connected. 8. Turn the sub knob up to the desired level to set the low frequency response for the entire system. M350 Owner's Manual...

  • Page 11: Panel Controls

    M350 2.1 PORTABLE PA SYSTEM PANEL CONTROLS M350 Owner's Manual...

  • Page 12: Subwoofer Volume

    This will turn off and on the built-in effects processor. Power LED The Power LED is green to indicate that the M350’s power cable is connected to an electrical outlet, and the Power Switch is turned on. EQ Controls The Low EQ will provide +/- 15dB of boost or cut below 100Hz. Turn the Low EQ up to add bass or warmth to the speaker. The High EQ will provide +/- 15dB of boost or cut above 10kHz.

  • Page 13: Troubleshooting

    Use to switch to different voltages. Normally set at the factory at 100-120 volts. Fuse Holder Disconnect the M350 from mains before replacing fuse. Only use fuse of the same rating and power. The correct fuse is specified on the rear panel.

  • Page 14: Specifications

    Twin Mode: 120 Watt @ 4 Ohm Amplifier Class-D Amplifier and Switching Power Design Frequency Response Subwoofer: 50Hz – 160kHz Satellites (Single mode): 155Hz – 20kHz Power 100-240V ~50/60Hz Switchable Dimensions 18” x 13” x 16” Weight 44 lbs. M350 Owner's Manual...

  • Page 15: Block Diagram

    M350 2.1 PORTABLE PA SYSTEM BLOCK DIAGRAM M350 Owner's Manual...

  • Page 16: Warranty

    There are no express warranties Harbinger provides, to the original purchaser, a two (2) year limited warranty beyond those stated here. In the event that applicable law does not allow...
