- Page 1 GW-60 Quick Start Guide ↵ START/▲ ADJUST/ GPS Function RESET/▼ MODE/BACK GPS Antenna Blinking: searching for GPS Alarm status Steady on: GPS is ready Battery level Charging status Full charge www.locosystech.com...
-
Page 2: Section 1. Brief Introduction
Section 1. Brief Introduction Before operating your GW-60, clip the device and full-charge it with DC +5V/500mA charger for at least 3~4 hours. Press MODE/BACK to select Time modes (1) CLOCK; (2) ALARM; (3) STOPWATCH; (4) TIMER ↵ Press ADJUST/ to setting page. - Page 3 (Press any key to extend backlight time) Lock screen: START+MODE, press again to unlock. Sleep mode: Hold for 1 sec to sleep mode. At clock mode, GW-60 will turn to sleep mode in 15sec. Tip: Press MODE/BACK to wake up the watch.
-
Page 4: Section 2. Time Mode
Tip: Quick clock time setup for first time usage. (1) GMT Setting: Refer to 3.6 (2) GPS Time Synchronization: Under open sky environment, switch to mode and wait until the GPS fixed. GW-60 will automatically synchronize to precise GPS UTC time. Alarm Mode ↵ Press ADJUST/ to adjust alarm time. -
Page 5: Section 3. Setting
Section 3. Setting Setting page: ↵ ADJUST/ : Enter edit mode/ Confirm. ▲: Up. ▼: Down. MODE/BACK: Exit edit mode/ Cancel. BUZZER: set buzzer/ sound. O : On/ Enable. X : Off/ Disable. LOGGING: Log rate setting. OFF : No logging. 1HZ : When speed over [MIN SPEED], log rate in 1Hz. - Page 6 UNIT: Speed measurement unit. KM : Kilometer. MI : Mile. NM : Nautical mile. GMT: Set GMT/Time zone, e.g. +8:00 for Taipei. Available number: GMT-12:00 to GMT+13:00. SPEED AVG: Time interval for speed averaging. Available number: 1 sec to 60 sec. SPD GENIE: Auto-speed report, setting the minimum speed threshold to initiate [SPD GENIE].
- Page 7 SPD FONT: Speed display font for Speed report. 3.10 SMALL : Small font. BIG : Big font. SPEED HISTORY: Display speed history record in 3.11 speed report. O : On/ Enable. X : Off/ Disable. SCROLL SECOND: Set scroll second in speed report 3.12 Available number: 1 sec to 2.5 sec.
- Page 8 TO USB MSC: Connection by Mass Storage Class (MSC) 3.14 mode mainly for non-Windows platform user. Tip: How to get GPS data in USB MSC mode (1) Set“USB CLASS”option to“UMS”first. (Note: Before setting, the USB charging cable MUST be disconnected.) ↵...
-
Page 9: Section 4. Gps Mode
Section 4. GPS Mode Action Speed: Display current instant speed or N-sec. average speed. Vertical Bar: Log memory usage. Horizontal Bar: Speed accuracy indicator. (Long bar means good signal) GPS searching Symbol :Not logging data Symbol : logging data ▲... - Page 10 Auto Speed Report: If [SPD GENIE] is enabled, the auto speed report screen shows at the end of each session. e.g. MAX SPEED: 61.65 KH Small Font N-SEC SPEED: 50.57 KH (Medal icon: New record achieved.) When in Big Font mode, 3 screens are displayed one after another MAX SPEED N-SEC SPEED...
- Page 11 Top 10 Max Speeds: Display Top 10 max speed record. ▲ ▼ Press to next page/ previous page. Press MODE/BACK to scroll page. ↵ Press ADJUST/ to delete records. Top 10 AVG Speeds: Display Top 10 average speed records.
-
Page 12: Section 5. Gw-60 Pc Utility
Section 5. GW-60 PC Utility (Windows platform only) Device connection procedure : (Make sure USB driver is installed) (1) Select COM port properly. (2) Click “Connect” to connect device. Once the device is connected, the firmware version will be displayed. - Page 13 Click “Log Data” to select log function page. In this page, users can see “Log Info”, and be able to download log data (in SBP format). www.locosystech.com...
- Page 14 Click “Convert Log” to convert the SBP file into PLT, CSV, KML and GPX files. (Check [] Google Earth View to see the travel trajectory) www.locosystech.com...
- Page 15 Click “Google Earth View” to link with Google Earth Viewer. www.locosystech.com...
- Page 16 Click “Download” to download the TOP 10 Speeds in SBP file. www.locosystech.com...
- Page 17 Click “Browse” to view logged data. Click item number to link up Google Map. www.locosystech.com...
- Page 18 Click the SBP record in the browse page to view the point on Google Map. Or, to view the converted GPX and KML files on Google Earth. www.locosystech.com...
-
Page 19: Section 6. Maintenance & Support Service
Section 6. Maintenance & Support service All GW-60 go through inspections before users have it. In this section, we will explain how to prevent the malfunctions, and how to care for the watch. Do not operate buttons under water. Do not operate the device in extreme temperatures. -
Page 20: Section 7. Warranty & Return Information
Section 7. Warranty & Return Information Warranty Coverage GW-60 is warranted for 12 months and warranty coverage is effective from the date of purchases. (Note: Some areas may extend to 24 months) LOCOSYS warrants our products and its parts against defects in material and workmanship under normal use within the warranty period. - Page 21 Where to get help Local dealers support Contact the LOCOSYS-authorized dealers to reach a support service, or repair service to return the damaged device to LOCOSYS. Website support Visit LOCOSYS website www.locosystech.com for firmware update, and trouble-shooting information. You can e-mail LOCOSYS to get tips, usage information, and FAQs, download utilities.
