ACC-40
DIGITAL AUDIO 6 DISC
COMPACT DISC CHANGER
MODEL ACC-40
6-DISC CD CHANGER
WITH WIRED COMMANDER
COMPACT
DIGITAL AUDIO
INSTALLATION MANUAL

Advertisement

Table of Contents
loading

Summary of Contents for Audiovox Rampage ACC40

  • Page 1 ACC-40 DIGITAL AUDIO 6 DISC COMPACT DISC CHANGER MODEL ACC-40 6-DISC CD CHANGER WITH WIRED COMMANDER COMPACT DIGITAL AUDIO INSTALLATION MANUAL...
  • Page 2: Packing List

    PACKING LIST MAIN UNIT CD Changer ACC-40 DIGITAL AUDIO 6 DISC COMPACT DISC CHANGER INSTALLATION PARTS Hex Head Bolt with Washer Base Mounting Bracket 2 pcs. Mounting Angle Adjustment Tool 1 pc. ACCESSORIES CD Magazine 1 pc. Commander (M5 x 12) 4 pcs.
  • Page 3: Before Installing The Unit

    BEFORE INSTALLING THE UNIT Transport Lock Screws The mechanism in the CD changer is "locked" into place during shipment by the 4 transport screws. Be sure to remove the screws prior to installation. Retain these screws for future use when transporting the unit for service/maintenance. After removing the transport lock screws, place the supplied seals over the screw holes.
  • Page 4: Installation

    INSTALLATION The unit can be installed horizontally, vertically or at a 45° angle. The position of the built-in anti-vibration springs (left and right side), must correspond to the mounting position chosen. If the springs are not set correctly for the type of installation chosen, the anti-vibration compensation will not be effective and vibration may cause the disc to skip.
  • Page 5 PROCEDURE FOR VERTICAL INSTALLATION Note If the anti-vibration spring position has been changed and verified for vertical mounting (as shown on page 3), start with step 2. Set the anti-vibration springs to position "V". position "V" Determine the mounting location, and drill four mounting holes.
  • Page 6 PROCEDURE FOR 45° ANGLE INSTALLATION Note If the anti-vibration spring position has been changed and verified for 45° angle mounting (as shown on page 3), start with step 2. Set the anti-vibration springs to position "45°". position "45°" 45° Determine the mounting location, and drill four mounting holes.
  • Page 7 You may also find some GM cars and others have an antenna plug that is too small to mate with the socket on the FM modulator. If this is found, call Audiovox’s Toll-Free Assistance for a special FM Modulator adaptor.
  • Page 8 You may also find some GM cars and others have an antenna plug that is too small to mate with the socket on the FM modulator. If this is found, call Audiovox’s Toll-Free Assistance for a special adaptor. This adaptor can also be purchased at most car stereo installation center.
